Installation
Guide &
User
Manual
PERSONAL PA
Model R801
R801 Professional FM Auditory Assistance Receiver
Frequency Synthesized, Channel-Selectable
Frequency
Power
72.5 72.7
72.3
72.1
75.9
75.7
For use with Transmitter Models:
PPA T4, PPA T17, PPA T20, PPA T16,
PFM T30, PFM T31
MAN 098B
®
FM Monitor Receiver
Carrier
72.9
74.7
75.3
Squelch
75.5
Williams Sound
Phones
Williams Sound
Helping People Hear
®
Advertisement
Table of Contents
Related Manuals for Williams Sound R801
Summary of Contents for Williams Sound R801
-
Page 1: Installation Guide
Installation Guide & User Manual PERSONAL PA ® FM Monitor Receiver Model R801 R801 Professional FM Auditory Assistance Receiver Williams Sound Frequency Synthesized, Channel-Selectable Frequency Power 72.5 72.7 Carrier 72.3 72.9 72.1 74.7 Phones 75.9 75.3 Squelch 75.7 75.5 For use with Transmitter Models: PPA T4, PPA T17, PPA T20, PPA T16, ®... -
Page 2: Table Of Contents
R801 ODEL NSTALLATION AND ANUAL Contents Page System Overview System Components Quick Start Instructions R801 Receiver Features Optional Antennas Setting the Squelch Control Changing Frequencies Using Multiple Systems In Case Of Difficulty Optional Rack Mounting Kits Warranty Receiver Specifications ®... -
Page 3: System Overview
500 feet from the transmitter To avoid difficulties, please read through these instructions as you begin to use the system. Then save them for questions that arise as you continue to use your Williams Sound Monitor Receiver. If you have problems with the system, don’t hesitate to call us toll-free at 1-800-843-3544. -
Page 4: Quick Start Instructions
AC power, rack mounting,and antenna installation requirements. 3. Install the Antenna. The rubber duck antenna threads into the hole on top of the receiver. Remote antennas connect to the “F” type connector on the rear of the R801. See page 6 for remote antenna installation details. -
Page 5: R801 Receiver Features
WITCH Turns R801 power on or off. LED I OWER NDICATOR Glows when the R801 power is on. FM F REQUENCY WITCH The selected receiver channel must match the transmitter channel. The system is pre-set to 72.9 MHz. Change the receiver channel only if the transmitter channel has been changed. See your Transmitter instructions to change the transmitter channel. -
Page 6: Optional Antennas
DO NOT install the antenna within any metal enclosure. DO NOT install the antenna where it is separated from the listening area by any sub- stantial metal object, such as heating ducts, structural steel, foil backed insulation, steel studs or metal lath. ® Williams Sound Helping People Hear... -
Page 7: Setting The Squelch Control
When the squelch is properly adjusted, turn- ing off the Transmitter will cause the R801 to mute. The radio noise in each area is different, so you must adjust the squelch when the R801 is installed. -
Page 8: Using Multiple Systems
Carrier light comes on and the signal comes through. 5. Listen to the signal at the headphone jack on the R801. If there is no signal, there is either no Transmitter signal or there is a fault with the R801. If there is a good signal at the headphone jack, but not through your sound system, check the cable and audio connection between the R801 and the sound system. -
Page 9: Optional Rack Mounting Kits
Williams Sound offers two optional rack mounting kits for use with the R801 FM Monitor Receiver. Use the RPK 005 Kit to mount one R801 in a single rack space. Use The RPK 006 Kit to mount two R801’s in a single rack space. NOTE: If you are rack mounting the R801, you will likely need a remote antenna. -
Page 10: Receiver Specifications
Williams Sound Corp. 10399 West 70th St., Eden Prairie, MN 55344-3459 U.S.A. 800-328-6190 / 952-943-2252 / FAX: 952-943-2174 www.williamssound.com © 2000, Williams Sound Corp. MAN 098 B ® Williams Sound Helping People Hear...
