WIR TX900
SoundPlus
Infrared System
®
Simultaneous Interpretation • Audio Description • Conferences • Multi-Media Rooms • Boardrooms •
The WIR TX900 is a high performance, cost-effective infrared
system designed for simultaneous language interpretation of up
to four languages. Operating on 2.3-3.8 MHz, the WIR TX900
is less susceptible to traditional radio and lighting interference.
When using the optional RX22-4 four-channel receiver, the WIR
TX900 will operate up to 28,000 ft2 in single channel mode, ideal
for auditoriums, theaters or other large venues.
SPECIFICATION DATA
INFRARED
Courtrooms • Schools • Universities • Cinema • Churches
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Williams Sound SoundPlus Infrared System WIRTX900
Summary of Contents for Williams Sound SoundPlus Infrared System WIRTX900
- Page 1 WIR TX900 SoundPlus Infrared System ® Simultaneous Interpretation • Audio Description • Conferences • Multi-Media Rooms • Boardrooms • The WIR TX900 is a high performance, cost-effective infrared system designed for simultaneous language interpretation of up to four languages. Operating on 2.3-3.8 MHz, the WIR TX900 is less susceptible to traditional radio and lighting interference.
- Page 2 SoundPlus Infrared System ® MOD 232 Modulator Size, Weight: Color: Rack Mount: Power Supply: Modulation: Carrier Frequency: Signal-to-Noise Ratio: Frequency Response: Total Harmonic Distortion: Audio Processing: Auto Carrier Shut-Off: Power Switch: Power Indicator: Audio Level Controls: Audio Indicators: Carrier LEDs: Compress Control: Input Mix LED: Stereo LED: Phones Switch:...
- Page 3 CH A 1 2 3 4 5 6 7 8 CH B Configuration CH B Switches 100 Ohms MOD 232 Infrared System Modulator Williams Sound Baseband Input Output Output Power In 24 VAC, 15 VA, 50-60 Hz 50 Ohms Plug...
- Page 4 Power Supply Wiring: Use NEC, Class 2 Wiring, 18 ga. minimum, 200 ft. (70m) maximum length (18 ga.) Baseband Signal Wiring: Use RG58 Coax,1000 ft. (350m) max. length Williams Sound, Minneapolis, Minnesota, USA Made in U.S.A. Patent Pending 24 VAC Power In:...
- Page 5 SoundPlus Infrared System ® WIR RX22-4 Receiver Channel Earphone Selector Knob Jack "On" On/Off Indicator LED Volume Switch RX22-4 Top RX22-4 Front Fig. 9: WIR RX22-4 Receiver Receiver Style: Body-Pack, dual-lens detector, lanyard Size: 4.5” L x 2.85” W x 1.2” H (114.3 mm x 72.4 mm x 30.4 mm) Weight: 4.6 oz (130 g) with batteries Color and Material:...
- Page 6 Use NEC, Class 2 Wiring, 18 ga. minimum, 200 ft. (70m) maximum length (18 ga.) Baseband Signal Wiring: Use RG58 Coax,1000 ft. (350m) max. length Williams Sound Corp., Minneapolis, Minnesota, USA Made in U.S.A. Patent Pending 24 VAC Power In:...
- Page 7 CE, FCC, RoHS, and WEEE approval. The receiver shall be covered by a five-year parts and labor warranty, excluding earphones, headphones, batteries and chargers. The receiver shall be the Williams Sound model WIR RX22-4 or RX18. *DISCLAIMER: FCC RULES LIMIT USE OF THIS EQUIPMENT TO AUDITORY ASSISTANCE...
