Appendix A: Specifications

Mechanical Specifications (DS-KZCCA-
AB)

Physical Dimensions:

3.1 inches wide X 7.9 inches long

Connector and Jumper Configuration Drawing:

53C875
SCSI
Terminators
ULTRA-DIFF SCSI

Figure 16: Connecor and Jumper Positions (DS-KZCCA-AB)

Mechanical Specifications (DS-KZCCA-BB)

Physical Dimensions:
3.7 inches wide X 12.3 inches long
GA ROM
CDAL/
PCI GA
21140A
RJ45
