DS-KZCCA-AB Installation Procedure

Use this installation procedure if your system type is VAX4000™-100, -
100A, -105A, -106A, or MicroVAX3100™-85, -90, -95 or -96.

Removing System Cover

After the system has been shut down, and power has been removed from the
system, remove the system cover or access panel to gain access to the
processor module. Access to the enclosure differs based on your system
type, basic configuration examples are given here. Consult your system
documentation for more information regarding accessing the system
internals.

Figure 1: Removing the system cover

Note: To avoid damage from static discharge, as soon as you remove
the cover, and before touching anything inside the system unit,
touch the TOUCH ME FIRST label, or a metal part on the top of
the power supply. It is recommended that you wear an antistatic
wrist strap and use and antistatic mat when adding options inside
the system unit.
16
