Roland JUPITER-80 Owner's Manual page 85

Master EQ, Song EQ
Parameter Value
EQ Switch
OFF, ON
Low
Freq 200, 400 [Hz]
Gain -15–+15 [dB]
Mid1, 2
Freq 200–8000 [Hz]
Gain -15–+15 [dB]
Q
0.5–8.0
High
2000, 4000, 8000
Freq
[Hz]
Gain -15–+15 [dB]
Output
Level 0–127
MIDI
Parameter Value Explanation
MIDI
If you want to send and receive system exclusive
Device ID 17–32 messages, the device ID numbers of both devices
need to be matched.
Turn this "ON" if you're using an external MIDI
keyboard instead of the JUPITER-80's keyboard.
In this case, the MIDI transmit channel of your
Remote
external MIDI keyboard does not matter. Normally,
Keyboard
OFF, ON
this can be left at "OFF. "
Switch
* If you want to control the arpeggiator from an
external MIDI device, turn this "ON. "
USB MIDI
If this is "ON, " incoming MIDI messages will be
USB-MIDI Thru OFF, ON retransmitted from the MIDI OUT connector
without change.
MIDI Channel
Specifies the MIDI receive channel on which
Registration
Registrations can be switched by an external MIDI
Control 1–16, OFF
device. Turn this "OFF" if you don't want to switch
Channel
Registrations from a connected MIDI device.
Specifies the MIDI receive channel that will play
each of the JUPITER-80's Parts (PREC, LOWER,
Part Channel 1–16 UPPER, SOLO), and the MIDI transmit channel on
which each Part will transmit to an external MIDI
device.
Explanation
Equalizer (EQ) screen
Center frequency of the low range
Boost/cut for the low range
Center frequency of the mid range
Boost/cut for the mid range
Width of the mid range
Larger values will make the range
narrower
Center frequency of the high range
Boost/cut for the high range
Equalizer output volume
The JUPITER-80's System Settings
MIDI Tx/Rx
Parameter Value Explanation
MIDI Transmit
Transmit Program
OFF, ON Program change message transmission on/off
Change
Transmit Bank
OFF, ON Bank select message transmission on/off
Select
Transmit Active
OFF, ON Active sensing message transmission on/off
Sensing
Specifies whether parameter edits will be
Transmit Edit Data OFF, ON
transmitted as system exclusive messages.
MIDI Receive
Receive Program
OFF, ON Program change message reception on/off
Change
Receive Bank
OFF, ON Bank select message reception on/off
Select
Receive Exclusive OFF, ON System exclusive message reception on/off
Scale Tune
Parameter Value Explanation
Turn this ON if you want to play in a tuning
Scale Tune Switch OFF, ON
other than equal temperament.
Scale Tune for C–B -64–+63
Specifies the scale tuning.
These are templates that set all of the Scale Tune C–B settings
(the values for each key shown in the screen). After making
your selection, touch <SET>.
EQUAL Equal temperament
JUST-MAJ Just intonation (major)
JUST-MIN Just intonation (minor)
Scale Tune Type
PYTHAGORE Pythagorean tuning
KIRNBERGE Kirnberger (type 3)
MEANTONE Meantone temperament
WERCKMEIS Werckmeister (type 1, number 3)
ARABIC Arabic scale
Specifies the tonic note for the scale tune
Scale Tune Key C–B template. After making your selection, touch
<SET>.
85
