Roland JUPITER-80 Service Notes

Hide thumbs Also See for JUPITER-80:
Table of Contents

Advertisement

Quick Links

Download this manual
Jun. 2011

Table of Contents

Cautionary Notes ..............................................................2
Specifications .....................................................................2
Location of Controls (Top, Front) ...................................4
Location of Controls (Rear)..............................................8
Location of Controls (Rear) Parts List ............................8
Exploded View (All) .......................................................10
Exploded View (All) Parts List......................................11
Disassembly Procedure ..................................................11
Plane View (1)..................................................................12
Plane View (1) Parts List ................................................13
Plane View (2)..................................................................14
Plane View (2) Parts List ................................................15
Plane View (3)..................................................................16
Exploded View (Fig.A)...................................................17
Exploded View (Fig.B)....................................................18
Exploded View (Fig.C) ...................................................20
Exploded View (Fig.C) Parts List..................................21
Exploded View (Fig.D, E) ..............................................22
Exploded View (Fig.D, E) Parts List.............................23
Exploded View (Fig.F, G)...............................................24
Exploded View (Fig.F, G) Parts List .............................25
Keyboard Parts List (SK-1076-C) ..................................26
Keyboard Circuit Board (SK-1076-C) ...........................28
Wiring Diagram/Block Diagram..................................34
Parts List ...........................................................................36
Verifying the Version......................................................40
Data Backup and Restore Operations ..........................40
Performing a Factory Reset............................................41
Updating the System ......................................................41
Test Mode .........................................................................41
Copyright © 2011 Roland Corporation
All rights reserved. No part of this publication may be reproduced in any form without the written permission
of Roland Corporation.
Circuit Board (Main Board: 1/2)...................................50
Circuit Board (Main Board: 2/2)...................................52
Circuit Diagram (Main Board: 1/7) ..............................54
Circuit Diagram (Main Board: 2/7) ..............................56
Circuit Diagram (Main Board: 3/7) ..............................58
Circuit Diagram (Main Board: 4/7) ..............................60
Circuit Diagram (Main Board: 5/7) ..............................62
Circuit Diagram (Main Board: 6/7) ..............................64
Circuit Diagram (Main Board: 7/7) ..............................66
Board)................................................................................68
Circuit Diagram (Jack-A Board)....................................70
Circuit Diagram (Jack-D Board)....................................72
Circuit Diagram (LCD Board) .......................................74
Circuit Diagram (ENC Board) .......................................74
Circuit Diagram (INLET Board)....................................75
Circuit Diagram (Panel-L Board) ..................................78
Circuit Diagram (Panel-C Board)..................................80
Circuit Diagram (Panel-R Board)..................................82
Circuit Diagram (Bender Board) ...................................84
Board: 1/2) .......................................................................86
Board: 2/2) .......................................................................88
Circuit Diagram (Tone-L Board) ...................................90
Circuit Diagram (Tone-C Board)...................................92
Circuit Diagram (Tone-R Board)...................................94
Circuit Diagram (Front-L Board) ..................................96
Circuit Diagram (Front-R Board) ..................................98
Circuit Diagram (LED Board)......................................100
Circuit Diagram (USB Board) ......................................100
17058743E0
SERVICE NOTES
Issued by RJA
JUPITER-80
CC-KWS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JUPITER-80 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roland JUPITER-80

Summary of Contents for Roland JUPITER-80

  • Page 1: Table Of Contents

    Updating the System ............41 Circuit Diagram (LED Board)........100 Test Mode .................41 Circuit Diagram (USB Board) ........100 Copyright © 2011 Roland Corporation All rights reserved. No part of this publication may be reproduced in any form without the written permission of Roland Corporation. 17058743E0...

  • Page 2: Cautionary Notes

    • Because the part is made to order (at current market price). • Reverb: 1 unit, 5 types per each Upper/Lower (total: 2 units) • Because it is carried in electronic data on the Roland web site. for Solo part/Percussion part •...
  • Page 3 * Printed matters will not be supplied after the end of the production. Then, Pitch Bend/Modulation Lever download the electronic file from the Roland web site. Assignable buttons ([S1], [S2]) * In the interest of product improvement, the specifications and/or appearance of Assignable knobs ([E1]–[E4])

  • Page 4: Location Of Controls (Top, Front)

    Jun. 2011 JUPITER-80 Location of Controls (Top, Front) fig.panel.eps@L Top Panel Front Panel...
  • Page 5 Jun. 2011 JUPITER-80 fig.panel.eps@R...

  • Page 6: Location Of Controls (Top, Front) Parts List

    Jun. 2011 JUPITER-80 Location of Controls (Top, Front) Parts List Top Panel Part Code Part Name Description Q’ty 5100017578 TOP PANEL 5100001159 SUB-ASSY USB BOX GW-8 (LF) (990-07040-10-04) 5100020256 Y S-KEYTOP LD3H BLK 13169711 TACT SWITCH SKPDALD010 02125167 SLI-343DCT32W 5100020679...
  • Page 7 Jun. 2011 JUPITER-80 Part Code Part Name Description Q’ty 5100023708 RUBBER SW 3H-A YEG 5100019995 SDFG04002A1-A 5100020325 ESCUTCHEON 5100023711 RUBBER SW 3H-A GRN (left side) 5100023710 RUBBER SW 2H-A GRN (right side) 5100019378 TLWF1100C(T11) 5100020325 ESCUTCHEON 5100023712 RUBBER SW 3H-A BLU...

  • Page 8: Location Of Controls (Rear)

    Jun. 2011 JUPITER-80 Location of Controls (Rear) fig.panel-rear-1.eps fig.panel-rear-2.eps Location of Controls (Rear) Parts List Part Code Part Name Description Q’ty 01786012 SEESAW SWITCH JW-M11RKK 01786045 SW HOLDER AT-217K 5100021369 WIRING W2 (INLET) 5100019749 RCA CONNECTOR LPR6521-1301FC 5100009531 USB CONNECTOR B TYPE FEMALE...
  • Page 9 Jun. 2011 JUPITER-80...

  • Page 10: Exploded View (All)

    Jun. 2011 JUPITER-80 Exploded View (All) fig.bunkaizu-all.eps Refer to Fig.A Refer to Fig.B Refer to Fig.C Refer to Fig.G Refer to Fig.F Refer to Fig.E...

  • Page 11: Exploded View (All) Parts List

    Jun. 2011 JUPITER-80 Exploded View (All) Parts List Part Code Part Name Description Q’ty 5100020679 M R-KNOB KF-ELA BLK/LCG 5100020230 LED COVER 22485295 D S-KNOB S BLK/LCG 5100016996 M R-KNOB LF BLK MNP 04565478 KNOB ZE R-KNOB LF 01786012 SEESAW SWITCH...

  • Page 12: Plane View (1)

    Jun. 2011 JUPITER-80 Plane View (1) fig.bunkaizu-1.eps View 1 View 2 View 3...

  • Page 13: Plane View (1) Parts List

    Jun. 2011 JUPITER-80 Plane View (1) Parts List View 1 Part Code Part Name Description Q’ty 5100021415 STAND CAUTION LABEL 40237101 SCREW M3X8 PAN MACHINE W/SW+SMALL PW BZC 40233012 SCREW 2.6X8 BINDING TAPTITE P BZC 40011101 SCREW 3X8 BINDING TAPTITE B BZC...

  • Page 14: Plane View (2)

    Jun. 2011 JUPITER-80 Plane View (2) fig.bunkaizu-2.eps View 4 View 5...

  • Page 15: Plane View (2) Parts List

    Jun. 2011 JUPITER-80 Plane View (2) Parts List View 4 Part Code Part Name Description Q’ty 05012101 CLAMP RFC-21V0 5100021495 LOCKING CLAMP RLWC-3SV0 40567623 DOUBLE-FACED TAPE #575 W15MM 30M 40122434 DOUBLE-FACED TAPE #500 W7MM 20M 30P 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC...

  • Page 16: Plane View (3)

    Jun. 2011 JUPITER-80 Plane View (3) fig.bunkaizu-3.eps View 6 View 7 View 8 View 6 Part Code Part Name Description Q’ty 40122434 DOUBLE-FACED TAPE #500 W7MM 20M 30P 40010645 SCREW 4X8 TRUSS TAPPING A FE BZC View 7 Part Code...

  • Page 17: Exploded View (Fig.a)

    Jun. 2011 JUPITER-80 Exploded View (Fig.A) fig.bunkaizu-A.eps Part Code Part Name Description Q’ty 5100020228 LCD ESCT 5100020955 LCD TAPE 5100016526 LQ070Y3DG3B 5100020246 LCD CUSHION 5100020032 PANEL SHEET ASSY * This unit includes the following parts. ******** PANEL-C BOARD ******** PANEL-L BOARD Refer to Exploded View (All) (p.

  • Page 18: Exploded View (Fig.b)

    Jun. 2011 JUPITER-80 Exploded View (Fig.B) fig.bunkaizu-B.eps Part Code Part Name Description Q’ty 02011412 Y S-KEYTOP SD1H BLK (included in Panel-R Board) 02011456 Y S-KEYTOP SX1H BLK (included in Panel-R Board) ******** (included in the Rotary Encoder on ENC Board)
  • Page 19 Jun. 2011 JUPITER-80...

  • Page 20: Exploded View (Fig.c)

    Jun. 2011 JUPITER-80 Exploded View (Fig.C) fig.bunkaizu-C.eps Fig. C Refer to Fig.D View C1 View C2...

  • Page 21: Exploded View (Fig.c) Parts List

    Jun. 2011 JUPITER-80 Exploded View (Fig.C) Parts List Fig.C Part Code Part Name Description Q’ty 5100020224 SIDE PANEL L 5100020237 SIDE ANGLE 5100020235 PANEL ANGLE L 04892967 BENDER PANEL 22495278 D S-KEYTOP MD2H BLK (W/WINDOW) 5100020032 PANEL SHEET ASSY * This unit includes the following parts.

  • Page 22: Exploded View (Fig.d, E)

    Jun. 2011 JUPITER-80 Exploded View (Fig.D, E) fig.bunkaizu-DE.eps View D1 Fig. D Fig. E View E1 View E2...

  • Page 23: Exploded View (Fig.d, E) Parts List

    Jun. 2011 JUPITER-80 Exploded View (Fig.D, E) Parts List Fig.D Part Code Part Name Description Q’ty 5100001159 SUB-ASSY USB BOX GW-8 (LF) (990-07040-10-04) 5100020033 PANEL SW SHEET ASSY * This unit includes the following parts. ******** USB BOARD ******** TONE-L BOARD Refer to Exploded View (All) (p.

  • Page 24: Exploded View (Fig.f, G)

    Jun. 2011 JUPITER-80 Exploded View (Fig.F, G) fig.bunkaizu-FG.eps View F1 Fig. F Fig. G View G1 View G2...

  • Page 25: Exploded View (Fig.f, G) Parts List

    Jun. 2011 JUPITER-80 Exploded View (Fig.F, G) Parts List Fig.F Part Code Part Name Description Q’ty 5100020233 PWB HOLDER MAIN 5100019999 FERRITE-CORE ESD-FPL-35-8 5100020030 MAIN BOARD ASSY View F1 Part Code Part Name Description Q’ty 40011056 SCREW 3X6 BINDING TAPTITE B ZC Fig.G...

  • Page 26: Keyboard Parts List (Sk-1076-C)

    Jun. 2011 JUPITER-80 Keyboard Parts List (SK-1076-C) fig.key-SK1076C.eps Part Code Part Name Description Q’ty 5100001544 KEYBOARD ASSY SK-1076-C 73671489 NATURAL KEY SK-9 CF (W/WEIGHT) 73671490 NATURAL KEY SK-9 EB (W/WEIGHT) 73671501 NATURAL KEY SK-9 D (W/WEIGHT) 73671512 NATURAL KEY SK-9 G (W/WEIGHT)
  • Page 27 Jun. 2011 JUPITER-80...

  • Page 28: Keyboard Circuit Board (Sk-1076-C)

    Jun. 2011 JUPITER-80 Keyboard Circuit Board (SK-1076-C) fig.b-keybaord-L.eps@L fig.b-keybaord-M.eps@L fig.b-keybaord-H.eps...
  • Page 29 Jun. 2011 JUPITER-80 fig.b-keybaord-L.eps@R fig.b-keybaord-M.eps@R...

  • Page 30: Keyboard Assembly Procedure (Sk-1076-C)

    Jun. 2011 JUPITER-80 Keyboard Assembly Procedure (SK-1076-C) How to Install the Contact Circuit Board The service-use contact circuit board (#5100006738) is supplied with the rubber switches mounted. To prevent problems with sound generation due to dust contamination, do not detach the rubber switches.
  • Page 31 Jun. 2011 JUPITER-80 Arrangement of the Sub-chassis The sub-chassis are of three types having a different number of keys. #04452190 SUB CHASSIS 12P #04452223 SUB CHASSIS 8P HI #04452234 SUB CHASSIS 8P LOW When replacing, refer to the figure below and install the specified sub-chassis at the specified location.
  • Page 32 Jun. 2011 JUPITER-80 How to Remove Keys Press down on the tip of the key with the finger. Insert needle-nose pliers into the U-shaped groove on the shaft side and press in the direction of the arrow. Lift up the shaft and detach the key from the chassis.
  • Page 33 Jun. 2011 JUPITER-80 Installing the Aftertouch and Cushions Affix from the “Affixing Start Position” shown in the figure below. Place the Aftertouch (white) against the guide bushing, and the SK-9 Cushions (green) against the chassis. Apply Syrex to the Aftertouch 2-(a)/(b) areas.

  • Page 34: Wiring Diagram/Block Diagram

    Jun. 2011 JUPITER-80 Wiring Diagram/Block Diagram fig.wiring-block.eps@L...
  • Page 35 Jun. 2011 JUPITER-80 fig.wiring-block.eps@R Part Code Part Name Description Q’ty 5100021351 WIRING 20624 FWR-P=1.00-K1-22-50 04455423 WIRING 20624 FWR-P=1.00-K1-10-50 5100021355 WIRING 20624 FWR-P=1.25-K1-10-270 5100021356 WIRING 20624 FWR-P=1.25-K1-28-250 5100021357 WIRING 20624 FWR-P=1.25-K1-24-500 04890245 WIRING FWR-P=1.00-K-28-80 5100014758 WIRING 20624 FWR-P=1.25-K1-14-120 5100021358 WIRING 20624 SFWR-P=0.50-K1-40-240...

  • Page 36: Parts List

    Jun. 2011 JUPITER-80 Parts List fig.-part1-e.eps Due to one or more of the following reasons, Safety Precautions: parts with parts code ******** cannot be supplied as service parts. The parts marked have safety-related characteristics. Use only listed parts for replacement.
  • Page 37 Jun. 2011 JUPITER-80 SWITCH 01340290 TACT SWITCH EVQ11A H=5.0 13169711 TACT SWITCH SKPDALD010 02781634 TACT SWITCH SKRGAED010 01786012 SEESAW SWITCH JW-M11RKK JACK, EXT TERMINAL 04452945 3.5MM JACK YKB21-5344N 13449275 6.5MM JACK YKB21-5074 13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 13429273 MIDI CONNECTOR...
  • Page 38 Jun. 2011 JUPITER-80 POTENTIOMETER 02781390 9M/M ROTARY POTENTIOMETER RK09K12A0D0S 20KAX2 13289189 POTENTIOMETER RK14K1240A2D L1=15 50KBX2 01905467 ROTARY ENCODER EVE GC1 F20 24B 04897256 SLIDE POTENTIOMETER RS45111-0A10-C0-P1-B103 FUSE, FUSE HOLDER 5100003343 FUSE 046801.5NR 5100019756 FUSE 0468002.NR WIRING, CABLE 5100021366 WIRING 1007#22 3X750-XHP-XHP-F...
  • Page 39 Jun. 2011 JUPITER-80 MISCELLANEOUS 40017378 COATING CLIP CS-7 40016512 INSULOK TIE 80M/M T-18S 40232134 ACETATE TAPE NITTO #5 BLACK W5MM 20M 40122556 DOUBLE FACED ADHESIVE TAPE #575X W30MM 30M 10P 30CM 40567623 DOUBLE-FACED TAPE #575 W15MM 30M 40122434 DOUBLE-FACED TAPE...

  • Page 40: Verifying The Version

    Jun. 2011 JUPITER-80 Verifying the Version Data Backup and Restore Operations Switch on the power to the unit. Press [MENU]. The MENU screen appears. Item Required fig.ver-01.eps • USB memory device (256 MB or larger; recommended: M-UF2G) Formatting the USB Memory Device Connect the USB memory device to the USB MEMORY connector at the left edge of the Top Panel.

  • Page 41: Performing A Factory Reset

    Jun. 2011 JUPITER-80 Performing a Factory Reset Test Mode * Executing a factory reset causes all user data in the unit to be lost. Before you Items Required start, refer to Data Backup and Restore Operations (p. 40) and back up the user data.
  • Page 42 Jun. 2011 JUPITER-80 Test Items 1. VERSION CHECK 1. VERSION CHECK (p. 42) This verifies the version of the main program. fig.test-01.eps 2. DEVICE (p. 42) 3. OUTPUT (XLR) (p. 42) 4. OUTPUT (TRS) (p. 43) 5. SUB OUT (p. 43) 6.
  • Page 43 Jun. 2011 JUPITER-80 4. OUTPUT (TRS) 6. PHONES This verifies the audio signals output from the MAIN OUTPUT L/MONO This verifies the audio signals (L and R) output from the PHONES and R connectors (1/4-inch phone jack). connector. fig.test-04.eps fig.test-06.eps Connect the oscilloscope to the MAIN OUTPUT L/MONO and R Connect the oscilloscope to the PHONES connector.
  • Page 44 Jun. 2011 JUPITER-80 8. MIDI THRU 10. AUDIO IN This verifies the operation of the MIDI THRU connector. This verifies audio signals (L and R) input to the AUDIO IN connector. fig.test-08.eps fig.test-10.eps Connect the MIDI keyboard to the MIDI IN connector.
  • Page 45 Jun. 2011 JUPITER-80 12. LCD 14. TOUCH-PANEL CHECK This verifies the display of the LCD screen. This verifies the operation of the touch screen. fig.test-12-1.eps fig.test-14.eps Press OCTAVE UP to change the display on the LCD screen. Using the touch pen, touch the center of the “+” symbol inside the box At each screen, verify that the display is free of dot drop-out, uneven color, grime, soiling, and scratches.
  • Page 46 Jun. 2011 JUPITER-80 17. SW/LED When verifying the buttons under the keyboard, verify that they are arranged in the sequence shown below. This verifies the operation of LED-equipped switches. From left: WRITE, PREV SET, A, B, C, D, 1, 2, 3, 4, 5, 6, 7, 8, and NEXT fig.test-17-1.eps...
  • Page 47 Jun. 2011 JUPITER-80 19. ENCODER 21. D BEAM CHECK This verifies the operation of the encoders. This verifies the operation of the D Beam controller. fig.test-19.eps fig.test-21.eps Rotate the control (encoder) indicated on the LCD screen Cover the D Beam controller with your hand, stopping at the position counterclockwise 2 turns, and verify that 0 is displayed.
  • Page 48 Jun. 2011 JUPITER-80 23. D/A NOISE 25. KEYBOARD This measures residual noise. This verifies the operation of the keyboard. fig.test-23.eps fig.test-25.eps Adjust the VOLUME control to MAX. Connect the headphones or speakers. Connect the noise meter to the MAIN OUT L/MONO and R connectors (1/ Play all keys, and verify that notes are produced with piano sound.
  • Page 49 Windows and the unit. Switch on the power to the unit. If No JUPITER-80 Driver Is Installed on the Computer Verify that the message “Found New Hardware. JUPITER-80” appears on the computer’s screen, and the Found New Hardware Wizard starts.

  • Page 50: Circuit Board (Main Board: 1/2)

    Jun. 2011 JUPITER-80 Circuit Board (Main Board: 1/2) fig.b-main-1.eps@L...
  • Page 51 Jun. 2011 JUPITER-80 fig.b-main-1.eps@R...

  • Page 52: Circuit Board (Main Board: 2/2)

    Jun. 2011 JUPITER-80 Circuit Board (Main Board: 2/2) fig.b-main-2.eps@L...
  • Page 53 Jun. 2011 JUPITER-80 fig.b-main-2.eps@R...

  • Page 54: Circuit Diagram (Main Board: 1/7)

    Jun. 2011 JUPITER-80 Circuit Diagram (Main Board: 1/7) fig.d-main-1.eps@L RA19 AUDCK LDA2 EXB28V220JX DGND DGND LDA1 RA11 LDA0 EXB28V103JX LCLK0 SHI2C_DA1 SHI2C_CK1 EN2B D+3.3V EN2A RA12 DB_PULSE EXB28V220JX SHI2C_DA0 SHI2C_CK0 RA13 EXB28V220JX TY2ON EXB28V330JX XCWR RA232 CCKE RA14 UnPop AUDATA1...
  • Page 55 Jun. 2011 JUPITER-80 fig.d-main-1.eps@R D+3.3V RA20 D+3.3V RA26 D+3.3V EXB28V103JX EXB28V103JX D+3.3V D+3.3V D+3.3V RA37 RA39 0.1uF 0.1uF DGND XCS3 EXB28V103JX XCRAS RA28 XCCAS XCWR R104 YA16 EXB28V103JX R102 CCKE EXB28V103JX UnPop D+3.3V DQMLL D+3.3V R105 RA38 RA40 RA21 RA27...

  • Page 56: Circuit Diagram (Main Board: 2/7)

    Jun. 2011 JUPITER-80 Circuit Diagram (Main Board: 2/7) fig.d-main-2.eps@L IC11 D+3.3V R156 AUDCKU UA20 R157 XTAP UA19 EXB28V220JX R158 BEAT_R UA18 RA52 R159 BEAT_G UA17 R160 R205 SW_SS2 UA16 R161 R206 UA15 SSC1I2C_DA R162 R207 UA14 SSC1I2C_CK R163 UA13 SHI2C_DA1...
  • Page 57 Jun. 2011 JUPITER-80 fig.d-main-2.eps@R D+3.3V UnPop EXB28V103JX EXB28V103JX R272 UXCWR UA16 UYA16 RA64 D+3.3V RA70 D+3.3V RA72 UXCCAS R273 UD15 UD11 EXB28V103JX UXCRAS UXCS3 R271 R274 UD14 UD10 UCCKE UA14 UYA14 UDQMLL UnPop UD13 RA73 UDQMLU EXB28V103JX UDQMUL R257 UD12...

  • Page 58: Circuit Diagram (Main Board: 3/7)

    Jun. 2011 JUPITER-80 Circuit Diagram (Main Board: 3/7) fig.d-main-3.eps@L D+3.3V 0.1uF DGND DGND BLM15BD471SN1D R311 SDT_SSC1 R312 SD_SSC2 R310 SD_SSC1 R317 BCKO DGND DGND IC62 D+1.5V TC74LCX574FT(EL.K) 28mA(Typ.) D+3.3V 112mA(Typ.) DGND 2 3.6V C221 C196 DGND 10uF DGND DGND 10uF...
  • Page 59 Jun. 2011 JUPITER-80 fig.d-main-3.eps@R D+3.3V 0.1uF C237 0.1uF C238 0.1uF C239 0.1uF C241 D+5V 0.1uF C240 0.1uF C242 D+3.3V 0.1uF C273 D+5V DGND DGND R333 R336 R322 IC26 1.8k KSMTXD D+5V R330 2SC4081 T106 QRS (PB FREE) R373 D+3.3V AK2923H-E2...

  • Page 60: Circuit Diagram (Main Board: 4/7)

    Jun. 2011 JUPITER-80 Circuit Diagram (Main Board: 4/7) fig.d-main-4.eps@L LED+5V C308 C309 0.1uF 10uF16V D+5V To Front-L BD R412 R414 DGND TP116 BEND TP113 D+5V TP115 L935 BLM15BD182SN1D R406 TP114 L943 BLM15BD601SN1D LDAF5V TP83 TP120 L944 BLM15BD601SN1D LCLKF5V TP79 R408...
  • Page 61 Jun. 2011 JUPITER-80 fig.d-main-4.eps@R D+5V LED+5V D+5V SSM3J02T(TE85L.F) R463 MPX_FSW R501 R464 DGND 1.8k BARON DTC114EKAT146(PB FREE) LED+5V D+3.3V DGND C337 47uF DGND 0.1uF C336 DGND C333 C335 LDAF5V LDAF to LED BD 10uF 0.1uF R465 IC30 IC30 TP196 DGND...

  • Page 62: Circuit Diagram (Main Board: 5/7)

    Jun. 2011 JUPITER-80 Circuit Diagram (Main Board: 5/7) fig.d-main-5.eps@L UnPop TP290 A+5V A+15V IC35 TP291 D+5V NJM78M05DL1A(TE1) R562 R563 TP211 AGND A+5V UnPop C370 A+5V 100pF D+3.3V 10uF 16V A+5V 4.7k C407 1SS362FV(TPL3) 1SS362FV(TPL3) R585 0.1uF 0.1uF A+15V C363 C367 R589 1.0VrmsMAX(2.2dBu)
  • Page 63 Jun. 2011 JUPITER-80 fig.d-main-5.eps@R A+5V 22FMN-BMTTN-A-TF (LF)(SN) CN20 IN_L TP301 TP303 IN_R TP302 TP220 TP305 R535 IN_INS TP307 TP306 XMUTE TP304 R318 TP240 TP242 TP241 TP243 TP245 TP244 TP246 TP248 TP247 TP249 TP251 TP250 TP252 TP254 AGND DGND D+3.3V C422 10uF 16V 0.1uF...

  • Page 64: Circuit Diagram (Main Board: 6/7)

    Jun. 2011 JUPITER-80 Circuit Diagram (Main Board: 6/7) fig.d-main-6.eps@L D+3.3V 1CA(22:1) RA120 0.1uF R624 RA118 EXB28V472JX D+3.3V C451 1CD(31:0) 4.7k EXB28V472JX R617 R669 1CA(16) R623 R643 3.3k R670 DGND 1CA(22) R644 4.7k 3.3k R671 1CA(21) 1CA(14) R645 DGND 1CA(20) RA124...
  • Page 65 Jun. 2011 JUPITER-80 fig.d-main-6.eps@R UnPop D+3.3V LED1 SML-512DWT86 UnPop UnPop 1MEMS1 100pF R794 1CD(31:0) UnPop 1WA(27:1) UnPop 1MEMS0 C557 1CD(28) DQ15 DGND 1CD(29) SYNC DQ14 R693 1CD(30) EXB28V470JX DQ13 R694 1CD(31) RA137 1XWCS0 DQ12 R698 1CD(24) 1XWCS1 DQ11 1CD(25) DQ10...

  • Page 66: Circuit Diagram (Main Board: 7/7)

    Jun. 2011 JUPITER-80 Circuit Diagram (Main Board: 7/7) fig.d-main-7.eps@L D+3.3V 2CA(22:1) RA175 0.1uF R717 RA173 EXB28V472JX D+3.3V C575 2CD(31:0) 4.7k EXB28V472JX R715 R752 2CA(16) R716 R733 3.3k R753 DGND 2CA(22) R734 4.7k 3.3k R754 2CA(21) 2CA(14) R735 DGND AUDCKS2 2CA(20)
  • Page 67 Jun. 2011 JUPITER-80 fig.d-main-7.eps@R UnPop D+3.3V LED2 SML-512DWT86 UnPop UnPop 2MEMS1 100pF R795 2CD(31:0) UnPop 2WA(27:1) UnPop 2MEMS0 2WD(15:0) C685 2CD(28) DQ15 DGND 2CD(29) SYNC DQ14 R770 2CD(30) EXB28V470JX DQ13 R771 2CD(31) RA192 2XWCS0 DQ12 R776 2CD(24) 2XWCS1 DQ11 2CD(25)

  • Page 68: Circuit Board (Jack-A/D, Lcd, Enc, Inlet Board)

    Jun. 2011 JUPITER-80 Circuit Board (Jack-A/D, LCD, ENC, INLET Board) fig.b-jack-1.eps@L fig.b-jack-2.eps@L...
  • Page 69 Jun. 2011 JUPITER-80 fig.b-jack-1.eps@R fig.b-jack-2.eps@R...

  • Page 70: Circuit Diagram (Jack-A Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Jack-A Board) fig.d-jackA.eps@L IN_INS XAMUTE IN_INS JK+5V R605 10pF R601 A+15V 2.7k 10pF UnPop R606 1SS362FV(TPL3) DGND AGND 100uF 2.7k AGND 100uF 100uF 4.7k 100uF C601 A-15V R104 L701 AUDIO IN NJM4580M(TE3) MMZ1608B601CT NJM4580M(TE3) AGND...
  • Page 71 Jun. 2011 JUPITER-80 fig.d-jackA.eps@R to Panel-L B6B-PH-K-S (LF)(SN) to MAIN 10pF C118 R145 A+15V D601 5.6k 22FMN-SMT-A-TF (LF)(SN) 1SS362FV(TPL3) R153 R175 R177 6.8k 100uF AGND BLM18BD601SN1D 1/2W 1/2W A-15V PHONES C126 R146 NJM4556AD 2SC4213-A(TE85L.F) YKB21-5074 A+15V 10pF AGND AGND DGND...

  • Page 72: Circuit Diagram (Jack-D Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Jack-D Board) fig.d-jackD.eps@L D+5V D+5V D203 1SS362FV(TPL3) BLM18BD601SN1D CTRL2 DGND L209 UnPop R204 R801 R218 IC201 CONTROL1 L207 AK2923H-E2 D+5V BLM18BD601SN1D JK203 YKB21-5074 R210 DGND DGND DGND 1/4W D+5V D+5V D204 1SS362FV(TPL3) DGND BLM18BD601SN1D CTRL1...
  • Page 73 Jun. 2011 JUPITER-80 fig.d-jackD.eps@R D+5V 100uF C218 C203 0.1uF DGND HOLD CTRL1 CTRL2 to MAIN MIDI_OUT MIDI_IN CN201 10FMN-SMT-A-TF (LF)(SN) DGND TER201 M1698 DGND...

  • Page 74: Circuit Diagram (Lcd Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (LCD Board) fig.d-LCD.eps@L TP+3.3V IC401 UnPop R422 R415 R702 Q701 AK2923H-E2 2SA1037AKT146(PB FREE) R701 TP_PEN BTP_PEN DGND DGND D+5V CDRH4D28NP-220NC-R TP+3.3V 2SC4117-GR(TE85L.F) TY2ON RB021VA-90 R424 2.7k Q405 R414 D401 4.7k L402 Q404 D407 TP+3.3V 22uH...

  • Page 75: Circuit Diagram (Inlet Board)

    UnPop TP_PEN CN404 04-6274-040-000-800+ DGND DGND D+5V L703 BLM21PG221SN1D D+3.3V to MAIN CN405 B3B-PH-SM4-TB (LF)(SN) DGND Circuit Diagram (INLET Board) fig.d-Inlet.eps JK301 JUPITER-80 WIRING W2 (INLET) UnPop UnPop UnPop DE2E3KH472MA3B DE2E3KH472MA3B SC-02-20G CN301 L301 B2P3-VH (LF)(SN) 7A/250V TER301 M1698 FGND...

  • Page 76: Circuit Board (Panel-L/C/R, Bender Board)

    Jun. 2011 JUPITER-80 Circuit Board (Panel-L/C/R, Bender Board) fig.b-panel.eps@L...
  • Page 77 Jun. 2011 JUPITER-80 fig.b-panel.eps@R...

  • Page 78: Circuit Diagram (Panel-L Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Panel-L Board) fig.d-panelL.eps@L PL+5V SSD5_PL D121 D122 D123 SW121 SW122 SW123 C137 C136 SKPDALD010 SKPDALD010 SKPDALD010 10uF 0.1uF PITCH VOLUME ASSIGNABLE 28FE-ST-VK-N SSD4_PL CN101 ToMain Board FFC(1.25mm) TAPSW0_PL D118 D119 D120 SW118 SW119 SW120 SSD5_PL...
  • Page 79 Jun. 2011 JUPITER-80 fig.d-panelL.eps@R PL+5V Q111 R148 LSD3_PL R149 LED104 LED108 LED112 LED116 Q110 SLI-343DCT32W SLI-343DCT32W SLI-343DCT32W SLI-343DCT32W R146 LSD2_PL ASSIGNABLE TEMPO TRANSPOSE_UP UPPER R147 LED121 LAYER1 A(RED) A(RED) LED103 LED111 LED115 LAYER3 SLR-343BCTT32 Q109 SLI-343DCT32W SLI-343DCT32W SLI-343DCT32W R144 A(GRN)

  • Page 80: Circuit Diagram (Panel-C Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Panel-C Board) fig.d-panelC.eps@L MEN U PC+3.3V LED202 PC+3.3V SLI-343DCT32W R202 C201 0.1uF SW0_PC ToMainBoard LED1_PC SW201 Q202 EVQ11A05R DTC114ESATP(PB FREE) FFC(1.25) 14FE-ST-VK-N D_GND_PC CN201 LED1_PC SW1_PC D_GND_PC EN1_A_PC EN1_B_PC EN2_A_PC EN2_B_PC EN3_A_PC EN3_B_PC PC+3.3V UnPop...
  • Page 81 Jun. 2011 JUPITER-80 fig.d-panelC.eps@R EN204 EVEGC1F2024B EN4_A_PC EN4_B_PC D_GND_PC EN204 EN204 EVEGC1F2024B EVEGC1F2024B D_GND_PC...

  • Page 82: Circuit Diagram (Panel-R Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Panel-R Board) fig.d-panelR.eps@L ToMainBoard FFC(1.25mm) PR+5V SSD7_PR C413 C414 D411 D413 D414 D415 EXIT ENTER STOP PLAY 10uF 0.1uF SW411 SW413 SW414 SW415 24FE-ST-VK-N SKPDALD010 SKPDALD010 SKPDALD010 SKPDALD010 CN403 SSD7_PR SSD6_PR SSD6_PR SSD5_PR SD7_PR D403...
  • Page 83 Jun. 2011 JUPITER-80 fig.d-panelR.eps@R PR+5V D417 D418 FORWARD Q405 R420 SW417 SW418 LSD5_PR EVQ11A05R EVQ11A05R R421 D408 D409 D410 DOWN REVERB REVERB Q404 R418 SW408 SW409 SW410 LED406 SKRGAED010 SKPDALD010 EVQ11A05R SLI-343DCT32W LSD4_PR R419 D401 D402 LEFT SONG SW401 SW402...

  • Page 84: Circuit Diagram (Bender Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Bender Board) fig.d-bender.eps BD+5V C502 C501 10uF 0.1uF 10FE-ST-VK-N ToMainBoard CN502 BEND_BD MOD_BD LED1_BD LED0_BD SW1_BD SW0_BD D_GND_BD BD+5V C503 ToBenderUnit 0.1uF BEND_BD MOD_BD CN501 B4B-PH-K-S (LF)(SN) D_GND_BD BD+5V LED501 SLR-325DCT31(ORANGE) R501 SW0_BD LED0_BD SW501...
  • Page 85 Jun. 2011 JUPITER-80...

  • Page 86: Circuit Board (Tone-L/C/R, Front-L/R, Led, Usb Board: 1/2)

    Jun. 2011 JUPITER-80 Circuit Board (Tone-L/C/R, Front-L/R, LED, USB Board: 1/2) fig.b-panelSW-1.eps@L...
  • Page 87 Jun. 2011 JUPITER-80 fig.b-panelSW-1.eps@R...

  • Page 88: Circuit Board (Tone-L/C/R, Front-L/R, Led, Usb Board: 2/2)

    Jun. 2011 JUPITER-80 Circuit Board (Tone-L/C/R, Front-L/R, LED, USB Board: 2/2) fig.b-panelSW-2.eps@L...
  • Page 89 Jun. 2011 JUPITER-80 fig.b-panelSW-2.eps@R...

  • Page 90: Circuit Diagram (Tone-L Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Tone-L Board) fig.d-toneL.eps@L TL+5V TL+5V SW411 SW412 SKPDALD010 SKPDALD010 R425 R421 ROTARY ON/OFF ROTARY F/S R424 R419 R422 R417 TSW0 TSW1 R423 R418 C408 C407 SW413 SW414 100pF 100pF SKPDALD010 SKPDALD010 R426 R420 MANUAL_PERC DRUMS/SFX...
  • Page 91 Jun. 2011 JUPITER-80 fig.d-toneL.eps@R TL+5V Q404 LSD7_TL ORANGE YELLOW AMBER(Lamp) LED406 LED403 LED413 TLOK1100C(T11) TLWF1100C(T11) SLI-343DCT32W R413 R415 Q407 LSD6_TL TONE2 TONE6 ROTARY F/S 1/4W 1/4W LED405 LED401 LED412 TLOK1100C(T11) TLWF1100C(T11) SLI-343DCT32W Q406 LSD5_TL TONE3 TONE7 ROTARY ON/OFF AMBER(Lamp) LED404...

  • Page 92: Circuit Diagram (Tone-C Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Tone-C Board) fig.d-toneC.eps@L SSD4_TC SW511 EVQ11A05R TC+5V ALTERNATE(LOWER) SW508 TONE10 CARBON_SW MI064_TONE 1SS360(TE85L,F) SW512 D503 CARBON_SW MI064_TONE R514 TONE13 SSD3_TC R515 R519 TSW2_TC TONE11 TONE12 1SS360(TE85L,F) D504 SW509 SW510 R516 C503 CARBON_SW MI064_TONE CARBON_SW MI064_TONE...
  • Page 93 Jun. 2011 JUPITER-80 fig.d-toneC.eps@R TC+5V C506 0.1uF TC+5V D_GND_TC R506 LED506 SDFG04002A1-A TONE15 GREEN R507 LED507 TLWF1100C(T11) TONE16 R517 R508 LEDD0_TC LED508 TLWF1100C(T11) TONE17 DATA R509 LED509 TLWF1100C(T11) TONE18 BLUE-GREEN(WHITE) R518 R510 LCLK_TC LED510 TLWF1100C(T11) TONE19 CLOCK R511 LED511 TLWF1100C(T11)

  • Page 94: Circuit Diagram (Tone-R Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Tone-R Board) fig.d-toneR.eps@L TR+5V TR+5V TR+5V SW200 EVQ11A05R SW202 SW204 R236 R222 R228 ALTERNATE(UPPER) R216 R224 CARBON_SW MI064_TONE R230 CARBON_SW MI064_TONE TONE22 TONE24 R238 R226 R231 TSW4_TR TSW3_TR TSW5_TR R212 R225 R229 C200 C203 C204...
  • Page 95 Jun. 2011 JUPITER-80 fig.d-toneR.eps@R TR+5V C208 0.1uF TR+5V D_GND_TR R211 R210 R233 R209 LEDD1_TR LED209 SLI-343DCT32W SOLO_SPLIT DATA R208 LED208 SLI-343DCT32W ALTERNATE(SOLO) R234 R207 LCLK_TR LED207 TLWF1100C(T11) TONE27 CLOCK R206 LED206 TLWF1100C(T11) TONE26 PURPLE(WHITE) R205 LED205 TLWF1100C(T11) TONE25 R204 LED204...

  • Page 96: Circuit Diagram (Front-L Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Front-L Board) fig.d-frontL.eps@L FL+5V To MainBoard FL+5V FFC(1.0mm) C812 C808 0.1uF 0.1uF D_GND_FL 14FMN-BMTTN-A-TF (LF)(SN) CN801 LD_Q15_FL ADOUT_FL LD_Q14_FL LDA_FL R833 LDA_FL LD_Q13_FL LCLK_FL DATA LD_Q12_FL LD7_FL R834 R808 LCLK_FL LD6_FL CLOCK R807 LSD7_FL R806...
  • Page 97 Jun. 2011 JUPITER-80 fig.d-frontL.eps@R FL+5V To Front-R Board C813 0.1uF FFC(1.0mm) FL+5V LD7_FL LD6_FL LSD7_FL LSD6_FL LD_Q15_FL LD_Q14_FL LED808 TLOU1002A (T02) LD_Q13_FL REG2 LED807 TLOU1002A (T02) LD_Q12_FL REG1 LED806 TLOU1002A (T02) SWAD7_FL LED805 TLOU1002A (T02) ORANGE SWAD6_FL LED804 TLOU1002A (T02)

  • Page 98: Circuit Diagram (Front-R Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (Front-R Board) fig.d-frontR-e.eps@L To Front-L Board FR+5V FFC(1.0mm) C906 0.1uF 16FMN-BMTTN-A-TF (LF)(SN) CN901 LD7_FR LD6_FR LSD7_FR LSD6_FR LD_Q15_FR LD_Q14_FR FR+5V LD_Q13_FR LD_Q12_FR SWAD7_FR SWAD6_FR R904 LD_Q15_FR SWAD5_FR LED904 TLOU1002A (T02) REG6 SWAD4_FR R903 LD_Q14_FR LED903...
  • Page 99 Jun. 2011 JUPITER-80 fig.d-frontR-e.eps@R FR+5V LSD7_FR Q904 RN2426(TE85L.F) LED906 LED908 TLOU1002A (T02) TLOU1002A (T02) UnPop REG8 LOCK LSD6_FR Q903 RN2426(TE85L.F) LED905 LED907 REG7 LOAD NEXT TLOU1002A (T02) TLOU1002A (T02) R925 R926 RPC18@1/4W RPC18@1/4W Q901 Q902 DTC114EKAT146(PB FREE) DTC114EKAT146(PB FREE) D_GND_FR...

  • Page 100: Circuit Diagram (Led Board)

    Jun. 2011 JUPITER-80 Circuit Diagram (LED Board) fig.d-LED.eps@L SL+3.3V SL+5V C602 0.1uF C601 0.1uF D_GND_SL ToMain Board FFC(1.0mm) 12FMN-BMTTN-A-TF (LF)(SN) CN601 LDA3_SL LDA2_SL LDA1_SL LDA0_SL LCLK_SL D_GND_SL SL+3.3V C603 SL+3.3V C606 SL+3.3V SL+3.3V 0.1uF 0.1uF SL+3.3V SL+3.3V D_GND_SL D_GND_SL R666 R621 2.2k...
  • Page 101 Jun. 2011 JUPITER-80 fig.d-LED.eps@R SL+3.3V C612 SL+3.3V C615 SL+3.3V SL+3.3V 0.1uF 0.1uF SL+3.3V SL+3.3V D_GND_SL D_GND_SL R653 R699 2.2k 2.2k R672 Q618 R705 Q626 2.2k Q620 2.2k Q628 R687 2.2k R720 2.2k LDA2_SL LDA3_SL R648 R691 DATA DATA R686 R719...

Table of Contents
