Roland JUPITER-8 Parameter Manual

Roland JUPITER-8 Parameter Manual

Model expansion
Hide thumbs Also See for JUPITER-8:

Advertisement

Quick Links

Download this manual
JUPITER-8
Model Expansion
Parameter Guide
© 2021 Roland Corporation
© 2021 Roland Corporation
01
01

Advertisement

loading
Need help?

Need help?

Do you have a question about the JUPITER-8 and is the answer not in the manual?

Questions and answers

Related Manuals for Roland JUPITER-8

Summary of Contents for Roland JUPITER-8

  • Page 1 JUPITER-8 Model Expansion Parameter Guide © 2021 Roland Corporation © 2021 Roland Corporation...
  • Page 2 This document explains about the parameters and setting screens for the ZENOLOGY Pro Model Expansion. The parameter names, the order in which they appear and other information may differ, depending on the product.
  • Page 3 System System CONDITION KEY MODE Simulates the changes that occur as a unit ages. [SOLO] button PITCH DRIFT Sound is produced monophonically. Adjusts the slight pitch drift that occurs when notes are [POLY] button played on an analog synthesizer. Sound is produced polyphonically. [UNISON] button Sound is produced in unison.
  • Page 4 VCO-1 VCO-1 [CROSS MOD] knob [RANGE] knob [WAVE FORM] knob (OSC1 RANGE) (OSC1 WAVE FORM) Uses the OSC2 waveform to change Specifies the octave of OSC1. the frequency of OSC1. Higher values 16’ , 8’ , 4’ , 2’ Selects the waveform that is the basis cause the sound of OSC1 to be more of the OSC1 sound.
  • Page 5 VCO-2 VCO-2 [SYNC] button [FINE TUNE] knob [WAVE FORM] knob (SYNC SWITCH) (OSC2 FINE TUNE) (OSC2 WAVE FORM) This is oscillator sync. It produces a complex waveform by forcibly Specifies a fine adjustment to the Selects the waveform that is the resetting OSC1 to the beginning of pitch of OSC2.
  • Page 6 MIXER MIXER [VCO-1] knob (OSC1 LEVEL) Adjusts the volume balance of OSC1. [VCO-2] knob (OSC2 LEVEL) Adjusts the volume balance of OSC2.

  • Page 7: Key Follow

    [R] [M] [S] buttons (VINTAGE FLT TYPE) If a vintage type model is selected, these buttons change the type of filter. [R] models a Roland filter, and [M] and [S] model vintage synthesizers made by other companies. SLOPE FILTER MOD (FILTER SLOPE) Selects the type of slope for the low-pass filter.
  • Page 8 [LEVEL] knob (AMP LEVEL) Adjusts the volume of the tone. LFO MOD (AMP MOD STEP) Uses the LFO to vary the AMP volume (tremolo effect). Higher values produce a greater effect.

  • Page 9: Delay Time

    RATE DELAY TIME (LFO RATE) (LFO DELAY TIME) Specifies the rate of the LFO cycle. Adjusts the time from when the key is pressed until the LFO starts to apply modulation. WAVEFORM (LFO WAVEFORM) Selects the waveform of the LFO. SINE, SAW-DW, SQR, S&H...

  • Page 10: Select Buttons

    VCO MODULATOR VCO MODULATOR LFO MOD ENV MOD FREQ MOD (PIT ENV DEPTH) (DEST SELECT) Adjusts the depth at which the LFO Adjusts the depth at which the LFO Selects the OSC that is modulated modulates the OSC. modulates the ENV1. by LFO MOD.
  • Page 11 ENV-1 (Envelope) ENV-1 (Envelope) KEY FOLLOW POLARITY (ENV1 KEY FLW SW) Specifies the polarity of the envelope. Specifies the ENV1 key follow. If key follow is on, ADR times become longer for lower notes and shorter for higher notes. Envelope [A] knob (ENV1 ATTACK) You can edit the ADSR settings of the envelope.
  • Page 12 ENV-2 (Envelope) ENV-2 (Envelope) KEY FOLLOW (ENV2 KEY FLW SW) Specifies the ENV2 key follow. If key follow is on, ADR times become longer for lower notes and shorter for higher notes. Envelope [A] knob (ENV2 ATTACK) You can edit the ADSR settings of the envelope. Adjusts the Attack time.

  • Page 13: Mfx Parameters

    [MFX] button [MFX TYPE] indication [MFX LEVEL] knob Turns MFX on/off. Shows the currently selected Adjusts the MFX output level. MFX name. MFX parameters The edit screen is different for each MFX type.
  • Page 14 Controller Controller BEND [PIT] knob MOD [LFO] knob (BEND PITCH) (MODULATION LFO) Specifies the range of pitch change produced by pitch Specifies the amount of LFO applied by modulation. bend. BEND [FILT] knob (BEND FILTER) Specifies the range of filter change produced by pitch bend.
