SPK-W613
Two−Way Open−Back Rectangular In−Wall Speakers
FEATURES
Type
- 2−way component open back in−wall speaker with infinite baffle design.
Woofer
- 6.5" polypropylene cone.
Tweeter
- 1" ferro−fluid cooled.
Frequency Response
- 30Hz to 20kHz.
Impedance
- 8Ω.
Sensitivity
- 89dB 1W @1m with 1kHz SPL.
Recommended Power
- RMS 80W, 120W max.
Grille
- White baffle with aluminum grilles with UV treatment compliance. Locking arms for quick in−wall installation.
Dimensions
- External: 30.5cm x 21.6cm x 8.9cm (12" x 8.5" x 3.5") W, D, H; cutout size: 27.3cm x 18.54cm (10.75" x
7.3").
Weight (Single Speaker)
- 1.6kg (3.5lbs) approx.
Shipping Weight (Pair)
- 3.8kg (8.4lbs) approx.
Package
- 2 speakers (1 pair), template and user manual.
The SPK−W613 is a pair of two−way,
open−back speakers designed for mounting
in the wall. They have an infinite baffle
design and aluminum grilles.
Advertisement
Related Manuals for Kramer SPK-W613
Summary of Contents for Kramer SPK-W613
- Page 1 SPK-W613 Two−Way Open−Back Rectangular In−Wall Speakers The SPK−W613 is a pair of two−way, open−back speakers designed for mounting in the wall. They have an infinite baffle design and aluminum grilles. FEATURES Type - 2−way component open back in−wall speaker with infinite baffle design.
- Page 2 POWER RATING: 80W. RECOMMENDED AMPLIFIER POWER: WEIGHT PER SINGLE SPEAKER: 1.6kg (3.5lbs) approx. 3.8kg (8.4lbs) approx. SHIPPING WEIGHT (FOR PAIR): DIMENSIONS: 30.5cm x 21.6cm (12” x 8.5”). 27.3cm x 18.54cm (10.75” x 7.3”). CUTOUT SIZE: Kramer SKIC mounting kit. OPTIONS:...
