Havis-Shields K-9 Kit KK-K9-C15-K Installation Instructions

K-9 kit 1998-2003 s10 blazer

Advertisement

Quick Links

TOOLS REQUIRED:

Power Drill
Standard And Metric Socket Sets
6" Extension
7/16" Wrench

COMPONENTS:

1
1
Dome Light Kit
1
Rubber Mat
1
Front Mounting Adjustable Legs
1
Set Of Tunnel Assemblies
1
Set Of Hinged Window Guards
1
Set Of Aluminum Door Panels
1
Rubber Edge Molding

HARDWARE:

QTY:
DESCRIPTION:
10
#10 X ½" Stainless Phillips Flat Head Screw
70
1/4-20 X ½" Stainless Carriage Bolt
96
1/4-20 Serrated Nut
30
#10 X 1/2 Stainless Phillips Screw
15
#10 X 3/4 Stainless Phillips Screw
26
1/4-20 X ¾" Stainless Carriage Bolt
24
#12 X ¾" Stainless Phillips Screw
6
¼" X 1 ¼" Hex Head Lag bolt
2
3/8" X 1 ½" Hex Head Bolt
2
3/8" Flat Washer
2
3/8" Lock Washer
2
3/8" Hex Nut
4
3/8" X ½" Flat Washer
4
Rubber Feet
4
8-32 Keps Nut
4
8-32 X 1" Pem Stud
4
8-32 X 1" Phillips Machine Screws
1
Tube of Silver Silicone

SUB ASSEMBLIES:

• Attach dome light with wire to housing ceiling.
• Install rubber edge molding on edges of tunnels
INSTALLATION INSTRUCTIONS
KK-K9-C15-K K-9 KIT
1998-2003 S10 BLAZER
Drill Bits – 1/8" Through 3/8"
Phillips Screwdriver
Wire Cutters and Crimping Tool
Ratcheting Wrench
PART #:
GSM34150
GSM32022
GSM30023
GSM34169
GSM34170
GSM32024
GSM34177
GSM33061
GSM33030
GSM31007
GSM31028
GSM30008
GSM31021
PRM97609
GSM30027
GSM32252
GSM33112
PRM97343

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K-9 Kit KK-K9-C15-K and is the answer not in the manual?

Questions and answers

Summary of Contents for Havis-Shields K-9 Kit KK-K9-C15-K

  • Page 1 INSTALLATION INSTRUCTIONS TOOLS REQUIRED: Power Drill Standard And Metric Socket Sets 6” Extension 7/16” Wrench COMPONENTS: K9 Main Housing Dome Light Kit Rubber Mat Front Mounting Adjustable Legs Set Of Tunnel Assemblies Set Of Hinged Window Guards Set Of Aluminum Door Panels Rubber Edge Molding HARDWARE: QTY:...
  • Page 2 REMOVE INTERIOR: • Remove rear seats in vehicle • Remove door panels and handles • Remove seat belt assembly • Remove carpet in rear. Note: If doors have electric door switches, they must be reattached to original plug assembly. Switch assembly must then be wire tied down so it does not interfere with window or door latch operations.
  • Page 3 INSTALL DOOR PANELS AND WINDOW GAURDS: • Install aluminum door panels with hardware provided • Install hinge and window guard on top of door panel with hardware provided • Lift window guard to installed position and mark mounting holes • Install top mounting bracket with #10 x ½ “ screws, making sure that holes in window guards align with holes in mounting bracket.
  • Page 4 INSTALL CEILING AND WALLS: • Install ceiling with ¼-20 x ½” carriage bolts and serrated nuts. • Install front wall with ¼-20 x ½” carriage bolts • Install rear wall of K9 unit with ¼-20 x ½” carriage bolts. INSTALL TUNNELS & DOORS: •...
  • Page 5 OPTIONAL FAN: If optional fan has been purchased, install at this time. • Mount dome light switch as desired. A switch box is provided so switch can be mounted to K9 housing in various locations. (side of tunnel housing at top works very well). Wire to 12 volt power source.
