INSTALLATION INSTRUCTIONS KK-K9-D14-K
TOOLS REQUIRED:
Power Drill
Standard And Metric Socket Sets
6" Extension
7/16" Wrench
HARDWARE: (some hardware included in assembly)
QTY:
DESCRIPTION:
10
#10 X ½" Stainless Phillips Flat Head Screw
70
1/4-20 X ½" Stainless Carriage Bolt
96
1/4-20 Serrated Nut
30
#10 X 1/2 Stainless Phillips Screw
15
#10 X 3/4 Stainless Phillips Screw
26
1/4-20 X ¾" Stainless Carriage Bolt
24
#12 X ¾" Stainless Phillips Screw
6
¼" X 1 ¼" Hex Head Lag bolt
2
3/8" X 1 ½" Hex Head Bolt
2
3/8" Flat Washer
2
3/8" Lock Washer
2
3/8" Hex Nut
4
3/8" X ½" Flat Washer
4
Rubber Feet
4
8-32 Keps Nut
4
8-32 X 1" Pem Stud
4
8-32 X 1" Phillips Machine Screws
1
Tube of Silver Silicone
COMPONENTS:
1
1
Dome Light Kit
1
Rubber Mat
1
Front Mounting Adjustable Legs
1
Set Of Tunnel Assemblies
1
Set Of Hinged Window Guards
1
Set Of Aluminum Door Panels
1
Rubber Edge Molding
SUB ASSEMBLIES:
• Attach dome light with wire to housing ceiling.
• Install rubber edge molding on edges of tunnels
K-9 TRANSPORTATION SYSTEM
1997-2003 DODGE DURANGO
Drill Bits – 1/8" Through 3/8"
Phillips Screwdriver
Wire Cutters and Crimping Tool
Ratcheting Wrench
PART #:
GSM34150
GSM32022
GSM30023
GSM34169
GSM34170
GSM32024
GSM34177
GSM33061
GSM33030
GSM31007
GSM31028
GSM30008
GSM31021
PRM97609
GSM30027
GSM32252
GSM33112
PRM97343
Advertisement
Table of Contents
Related Manuals for Havis-Shields K-9 Transportation System KK-K9-D14-K
Summary of Contents for Havis-Shields K-9 Transportation System KK-K9-D14-K
- Page 1 INSTALLATION INSTRUCTIONS KK-K9-D14-K K-9 TRANSPORTATION SYSTEM TOOLS REQUIRED: Power Drill Standard And Metric Socket Sets 6” Extension 7/16” Wrench HARDWARE: (some hardware included in assembly) QTY: DESCRIPTION: #10 X ½” Stainless Phillips Flat Head Screw 1/4-20 X ½” Stainless Carriage Bolt 1/4-20 Serrated Nut #10 X 1/2 Stainless Phillips Screw #10 X 3/4 Stainless Phillips Screw...
- Page 2 REMOVE INTERIOR: • Remove rear seats in vehicle • Remove door panels and handles • Remove seat belt assembly • Remove carpet in rear. Note: If doors have electric door switches, they must be reattached to original plug assembly. Switch assembly must then be wire tied down so it does not interfere with window or door latch operations.
- Page 3 INSTALL CEILING AND WALLS: • Install ceiling with ¼-20 x ½” carriage bolts and serrated nuts. • Install front wall with ¼-20 x ½” carriage bolts • Install rear wall of K-9 unit with ¼-20 x ½” carriage bolts. INSTALL TUNNELS & DOORS: •...
