INSTALL INSTRUCTIONS KK-S-ST-RP
PERMANENT REAR STEP
2002-2008 SPRINTER VAN
TOOLS REQUIRED:
HARDWARE:
QTY DESCRIPTION
PART #
SUB ASSEMBLY:
(See note below)
(2 per-side)
Note: Three Channel brackets will come with Rear Step
kit, one short and two long. Use two long brackets for
vehicles with single rear wheels & one short bracket
and one long on vehicles with dual rear wheels.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Havis-Shields Van Permanent Rear Step KK-S-ST-RP
Summary of Contents for Havis-Shields Van Permanent Rear Step KK-S-ST-RP
- Page 1 INSTALL INSTRUCTIONS KK-S-ST-RP PERMANENT REAR STEP 2002-2008 SPRINTER VAN TOOLS REQUIRED: HARDWARE: QTY DESCRIPTION PART # SUB ASSEMBLY: (See note below) (2 per-side) Note: Three Channel brackets will come with Rear Step kit, one short and two long. Use two long brackets for vehicles with single rear wheels &...
- Page 2 INSTALLATION: 1. MOUNT PERMANENT REAR STEP: • • Note: Depending on single rear wheel standard length van, dual rear wheels standard length van, and dual rear wheels extended length van will effect which side of the frame rail the (4) Upper Mounting Brackets will bolt to.
