Osburn 1800 Owner's Manual

Us environmental protection agency phase ii certified wood insert
Hide thumbs Also See for 1800:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
OWNER`S MANUAL
1800 MODEL INSERT
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED
WOOD INSERT
Verified and tested following
ULC S627 and UL 1482 Standards
by:
Manufactured by : STOVE BUILDER INTERNATIONAL INC.
1700, Léon-Harmel, Québec (Québec) G1N 4R9
Tel : (418 ) 527-3060
Fax : (418 ) 527-4311
www.osburn-mfg.com
READ AND KEEP THIS MANUAL FOR REFERENCE
45058
NorthlineExpress.com
http://www.northlineexpress.com
Toll-Free 1-866-667-8454

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1800 and is the answer not in the manual?

Questions and answers

Related Manuals for Osburn 1800

Summary of Contents for Osburn 1800

  • Page 1 OWNER`S MANUAL 1800 MODEL INSERT US ENVIRONMENTAL PROTECTION AGENCY PHASE II CERTIFIED WOOD INSERT Verified and tested following ULC S627 and UL 1482 Standards Manufactured by : STOVE BUILDER INTERNATIONAL INC. 1700, Léon-Harmel, Québec (Québec) G1N 4R9 Tel : (418 ) 527-3060 Fax : (418 ) 527-4311 www.osburn-mfg.com...

  • Page 2: Introduction

    Keep your sales invoice. We also recommend that you register your warranty online at www.osburn-mfg.com Registering your warranty online will help us track rapidly the information we need on your insert.

  • Page 3: Table Of Contents

    4.3 C ........................18 HIMNEY LEANING 4.4 B :................19 AFFLE NSTALLATION AND RICK OTES 4.5 S ...................22 ECONDARY EPLACEMENT 4.6 F & C ......................23 AINTENANCE SECTION 5.0 TROUBLESHOOTING ...................24 SECTION 6.0 SPECIFICATIONS....................25 OSBURN LIMITED LIFETIME WARRANTY ................26 NorthlineExpress.com http://www.northlineexpress.com Toll-Free 1-866-667-8454...
  • Page 4 NorthlineExpress.com http://www.northlineexpress.com Toll-Free 1-866-667-8454...

  • Page 5: Section 1.0 Pre-Installation Requirements

    (Note – using a louvered face plate {surround} complies with this requirement). Note: A custom made surround may be required or a modified Osburn surround may be used. NorthlineExpress.com http://www.northlineexpress.com...

  • Page 6: Venting Requirements

    THE INSERT. 1.2 Venting requirements The flue is a critical component to a satisfactory installation. Your Osburn insert will attain its best performance if installed with a chimney that generates its own draft. The minimum requirement of a flue will be the installation of a flue connector (the liner must conform to UL1777 chimney liners) from the insert into the first flue tile of the chimney (USA), see Figure 2.3 , or a continuous stainless steel...
  • Page 7 Ensure that all joints in the flue systems are tightly sealed, since any leaks will result in reduced performance as well as a possible safety hazard. This heating unit must serve as a supplementary heat source. An alternate heat source should be available in the home if needed.

  • Page 8: Section 2.0 Installation

    Section 2.0 Installation 2.1 Clearances To Combustibles (Measured From Insert Body) North America Sidewall (A) 17” (432mm) Top Facing (B) 14” (356mm) Side Facing (C) 10” (254mm) Mantel (D) 22” (559mm) Table 2.1 CLEARANCES Figure 2.1 Note: If side facing protrudes more than 1.5” (38mm) in front of face of fireplace, then use sidewall clearance.

  • Page 9: Suitable Fireplace Dimensions (Refer To Figure 2.1)

    Floor protection to the front is to be measured from the fuel loading door opening. 5. Osburn recommends that you install a listed smoke detector or alarm in your home. Normal operation of the insert will have no effect on the detector or alarm.

  • Page 10: Installation Instructions

    8. Do not use makeshift compromises during installation, as they could create a safety hazard and a fire could result. 9. DO NOT CONNECT THIS APPLIANCE TO THE CHIMNEY OR FLUE SERVING ANOTHER APPLIANCE. 2.4 Installation Instructions 1. Inspect the fireplace according to the safety information and fireplace requirements and have it cleaned and/or upgraded as necessary.

  • Page 11: Air Control Plate, Faceplate And Fan Assembly Instructions

    2.5 Air control plate, faceplate and fan Assembly Instructions 1. Place the faceplate panels with the finished side down on a flat, soft, non-abrasive surface. 2. Assemble the faceplate trim, attaching the mitered corners with the corner brackets. (see Figure 2.5) 3.
  • Page 12 Figure 2.5 Figure 2.6 Figure 2.7 7. Fan is already attached to the unit at the factory with two tie straps to reattach fan to unit see (Figure 2.7) NorthlineExpress.com http://www.northlineexpress.com Toll-Free 1-866-667-8454...
  • Page 13 8. Cooktop is installed at the factory, Shipping screw must be removed before installation of faceplates. (Figure 2.8) 9. Install faceplate (Figure 2.7) with four (#10 x 3/8” sheet metal) screws supplied, ensuring the ¼” rod on the air control plate extension protrudes through the slot in the RH faceplate & moves freely horizontally.

  • Page 14: Section 3.0 Operation

    Misuse is not covered by warranty. Even though your Osburn has been specifically designed and tested to prevent smoke spillage, always open the door slowly as this will minimize the likelihood of smoke spillage or a back draft causing flame or smoke to spill into the room.

  • Page 15: Fuel

    3.2 Fuel Fuel for the insert must not be stored closer than the required clearances to combustibles and not in the space required for ash removal. Your Osburn insert is designed to burn . Do not burn coal, charcoal, or ORDWOOD trash in the unit.

  • Page 16: Simple Wood Moisture Test

    Common Heating Values of Cordwood Hardwoods Million Btu/Cord Softwoods Million Btu/Cord Birch 23.6 Douglas Fir 20.6 White Oak 28.3 Hemlock 17.1 Alder 17.6 Jack Pine 18.4 Table 3.1 3.2.1 Simple Wood Moisture Test Add one large piece of wood to the top of an established fire. If it starts to burn on three sides within one minute, it is dry and seasoned and right for burning.
  • Page 17 Ideally the large kindling should be burned until a thick bed of red embers is obtained. At that point, add cordwood fuel and continue to operate the draft control wide open until the fire is well established. Once the firebox is hot, the draft control can be partially closed by moving the knob to the left to adjust the intensity of the fire.

  • Page 18: Maintaining The Fire

    3.5 Maintaining The Fire Your Osburn insert will work best if a thick bed of hot embers is maintained in the bottom of the firebox, and a minimum of two large pieces of seasoned fuel are added. Combustion efficiency is largely related to establishing a hot ember bed, and hot firebox temperatures.

  • Page 19: Section 4.0 Maintenance

    Section 4.0 Maintenance 4.1 Care And Cleaning Clean the insert frequently so that soot, ash and creosote do not accumulate. Do not attempt to clean the insert, glass or door when the unit is hot. Special care must be taken with Gold surfaces in order to maintain the finish at its original brilliance.

  • Page 20: Baffle Installation And Brick Notes Note

    Osburn dealer. Your Osburn insert has been designed to reduce the amount of creosote produced. Even so, the chimney connector pipe and chimney should be inspected at least once every two months during the heating season to determine if a creosote build-up has occurred.
  • Page 21 2. Put them on the horizontal air duct (C) (see figure 3.4b). Afterwards, push them towards the bottom and sides so that they rest on the back of the firebox (D) and on the side air ducts. Figure 3.4b 3. Install the baffle support/extension (H) ensuring that it fits between the front risers and hold it in place.
  • Page 22 All firebrick and duraboard baffles must be properly in place for correct burning operation. Have any damaged firebricks replaced. Check the firebricks annually for damage and replace if they are broken or damaged. See Figure 3.3 for the firebrick layout. Install the side & back firebricks first, and then the bottom firebricks.

  • Page 23: Secondary Air Tube Replacement

    4.5 Secondary Air Tube Replacement (see Figure 4.3) Remove cotter pin at LH end of tube. Slide tube to right and lower tube end below LH plenum. Slide tube to left to remove. Reassemble in reverse order using a new cotter pin. The cotter pin is a hammerlock style and locks into place by hitting the head sharply with a hammer.

  • Page 24: Fan Maintenance & Care

    4.6 Fan Maintenance & Care Clean the fan air inlet louvres and squirrel cage impeller regularly. The fan should be kept clean and dust free. Life of the fan will be shortened if operated in a dust filled environment, or if the fan is overheated by restricting air supply.

  • Page 25: Troubleshooting

    Section 5.0 Troubleshooting Symptom Possible Cause Corrective Action Down draft Upgrade chimney Smoke in room Chimney blocked Clean chimney Chimney damper shut Open or remove damper Baffle out of position Correctly position baffle New paint is curing Refer to instructions Low draw Upgrade chimney Wood burns...

  • Page 26: Section 6.0 Specifications

    Section 6.0 Specifications Fuel Type Cordwood Test Standards ULC S628 (CSA B366.2) & UL 1482 residential. U.S. Environmental Protection Agency. Meets July 1990 Emission Standards. E.P.A. rate: 2.7 g/hr average. Meets AS/NZA4013 emission standards for hardwood fuel. Emission factor is 1.5 g/kg dry wood.

  • Page 27: Osburn Limited Lifetime Warranty

    Proof of purchase (dated bill of sale), model name and serial number must be supplied when making any warranty claim to your OSBURN dealer.
