2.2 Rear Panel

This list of connectors describes where to connect the cables and power adapter when installing the cable
modem.
This is where you plug in the included power adapter. Remember to use only the power
Power
adapter that came with the cable modem.
This is where you plug in the included Ethernet cable. The other end connects to the Ethernet
1000BaseT
port on the PC or NIC.
Reset
Allows you to power-cycle the cable modem.
This is where you connect the coaxial cable (not included) that leads to the cable splitter (not
Cable
included) or the cable wall outlet.
7
