Slide out the polythene bag with the
polystyrene stuffing before using the appliance.
Should the appliance be moved, it must be
transported vertically.


It is recommended that, for your convenience, the
machine is positioned close to your washing
The tumble dryer must be installed in a clean place,
where dirt does not build up.
Air must be able to circulate freely all round the
appliance. Do not obstruct the front ventilation grille
or the air intake grilles at the back of the machine.
To keep vibration and noise to a minimum when the
dryer is in use, it should be placed on a firm, level
Once in its permanent operating position, check that
the dryer is absolutely level with the aid of a spirit
level. If it is not, raise or lower the feet until it is.
The feet must never be removed.
Do not restrict the floor clearance through deep-
pile carpets, strips of wood or similar. This might
cause heat build-up which would interfere with
the operation of the appliance.
The hot air emitted by the tumble dryer can reach
temperatures of up to 60°C. The appliance must
therefore not be installed on floors which are not
resistant to high temperatures.
When operating the tumble dryer, the room
temperature must not be lower than +5°C and higher
than +35°C, as it may affect the performance of the

Electrical connection

This machine is designed to operate on a 220-230 V,
single-phase, 50 Hz supply.
Check that your domestic electrical installation can
take the maximum load required (2.6 kW), also
taking into account any other appliances in use.
Connect the machine to an earthed socket, in
accordance with current wiring regulations.
The manufacturer declines any
responsibility for damage or injury
through failure to comply with the
above safety precaution.
Should the appliance power supply
cable need to be replaced, this must
be carried out by our Service
The power supply cable must be accessible after
installing the machine.

Stacking kit

A special stacking kit is available through your
dealer, to enable the mounting of the dryer on top of
a front loading washing machine with cover's depth
between 48 and 60 cm.
Read carefully the instructions supplied with the kit
before installing the dryer.

Door reversal

To make it easier to load or unload the laundry the
door can be reversed.
This operation must be carried out by qualified
Please contact the nearest Service Centre.
