- Page 1 Owners Manual POWER V6, POWER V8, POWER V12, POWER V12HP, POWER V15, POWER VS10BP & POWER VS15BP...
- Page 2 1.0: IMPORTANT SAFETY INSTRUCTIONS 2.0: INTRODUCTION 3.0: THE BASICS Unpacking and visual checks Preliminary recommendation 4.0: INTERFACE PANEL 5.0: OPERATION 5.1: AC power requirements Cooling LED functions Limiters Audio Connections 6.0: EQUALISATION 7.0: ARRAYING 8.0 DIMENSIONS 9.0: TECHNICAL SPECIFICATIONS 10.0: RIGGING 10.1 : SECUR ET - V6Y yoke bracket 10.2 : SECUR ET - V8Y yoke bracket 10.3 : SECUR ET - VMY yoke bracket...
- Page 3 Ne placez pas d'objets contenant du liquide à proximité de l'appareil. AVERTISSEMENT DE SECURITE Ne remplacez le fusible de réseau principal que par un fusible T10A HBC du même type fourni par Tannoy sous la référence 34610919. AVERTISSEMENT DE SECURITE Le radiateur arrière de cet appareil devient chaud.
-
Page 4: Installation Instructions
In order to satisfy a wide scope of fixed or on the road sound reinforcement applications there are five full range models and two subwoofers in the Power V™ range; Power V6, Power V8, Power V12, Power V12HP and Power V15; along with the subwoofers - Power VS10 BP and Power VS15 BP. -
Page 5: Unpacking And Visual Checks
A word of warning on high sound levels - these speakers are capable of generating high output levels over sustained periods of time and such levels, over 95dBspl for 8 hours per day, can eventually cause permanent hearing loss. Since Tannoy loudspeakers have a natural-sounding flat frequency response and low distortion, it's possible not to be aware just how high the sound level is high while working with them. -
Page 6: Operation
5.0: OPERATION The Power V™ range of products are integrated designs which include system specific EQ and protection circuitry, without the need for external amplification. For room equalization, delay and other commissioning or setup functions, we recommend you use a Vnet SC1 or TDX1 Digital Controller. Below are example setups... - Page 7 5.1: AC POWER REQUIREMENTS PowerV™ products are equipped with Neutrik Powercon™ mains connectors which mate with the Neutrik NAC3FCA Cable connector, quick lock with a securing lever for power-in. This AC mains connector is supplied with each PowerV™ product. The amplifier operates between the ranges of 100 to 240 Volts; the auto ranging power supply detects the mains voltage automatically and configures accordingly.
- Page 8 7.0: ARRAYING As discussed in the previous section, comb filtering cannot be cured by equalisation. Small alterations to loudspeaker positions can have the effect of minimising problematic combing frequencies. Arrays should be constructed so that the individual coverage patters of each loudspeaker combine with minimal overlap. The design of the PowerV™ cabinet greatly simplifies the creation of effective arrays, allowing seamless wide horizontal coverage using two loudspeakers without the need for tedious experimentation.
- Page 9 OPERATION SUBJECT TO CONDITIONS STATED IN THE MANUAL. THIS EQUIPMENT MUST BE EARTHED 334.0 296.0 [13.15"] [11.65"] FUSE 235.0 T10AL 250V [9.25"] REPLACE ONLY WITH TANNOY PART 3461 0913 POWER 125.0 - LIMIT [4.92"] - SIGNAL MODE - POWER INPUT LINK LEVEL...
- Page 10 THIS EQUIPMENT MUST BE EARTHED 486.0 406.0 180.0 359.0 [19.13"] [15.98"] [7.09"] [14.13"] 360.0 FUSE T10AL 250V [14.17"] REPLACE ONLY WITH TANNOY PART 3461 0913 POWER - LIMIT 175.0 153.0 - SIGNAL MODE - POWER INPUT LINK LEVEL 115-230V [6.89"] 500VA Max...
-
Page 11: Technical Specifications
A full range of measurements, performance data, and Ease!™ Data can be downloaded from www.tannoy.com Tannoy operates a policy of continuous research and development. - Page 12 A full range of measurements, performance data, and Ease!" Data can be downloaded from www.tannoy.com Tannoy operates a policy of continuous research and development.
- Page 13 10.1: SECUR ET™ - V6Y YOKE BRACKET The V6Y is a discreet yoke style bracket, available in both black and white, and is used to mount the Tannoy V6 in both portrait and landscape orientations. The Tannoy V6 loudspeaker is fixed to the bracket using the M6 bolts and washers supplied in the accessory pack Only the screws, fasteners, shakeproof and plain washers specified on figure 3.
-
Page 14: Assembly View
To ensure an equal mounting height, the 2 x Tannoy V6 loudspeakers being flown from the lower cluster bar should be attached to the upper surface of this bar. While the 2 x Tannoy V6 loudspeakers being flown from the upper bar should be attached to the underside of this cluster bar. - Page 15 Fig. 1. Fig. 3. Fig. 5. Fig. 2. Fig. 6. Contents of VCB2 DESCRIPTION QUANTITY Cluster Bar Washer M10 Plain Screw M10x40 Button Head M10 Nyloc Nut Blanking Plug Contents of VCB4 DESCRIPTION QUANTITY Cluster Bar Washer M10 Plain Screw M10x40 Button Head M10 Nyloc Nut Blanking Plug...
-
Page 16: Secur Et - Vmy Yoke Bracket
10.3: SECUR ET - VMY YOKE BRACKET Fig.1 Fig.2 Use the table of parts along with the assembly drawing (Figure 3.) to assemble the VMY. Figure 4 shows the VMY assembled. Fig.3 Fig.4 Number on Assembly View (Fig 3.) Description Quantity Hanging Bracket Cross Member... - Page 17 10.4: SECUR ET - V15Y & V12Y V15Y V12Y...
-
Page 18: Secur Et - Vmb Wall Mounting Bracket
The VMB is wall mounting bracket for the attachment of a VMY, available in both black and white finishes, allowing the user secure the Tannoy Power V™ Full range loudspeaker in either portrait or landscape orientations to a wall. The Tannoy Power V™ loudspeaker is attached to the bracket using the accessories supplied. -
Page 19: Secur Et - Veb Eyebolt
10.6 : SECUR ET - VEB EYEBOLT FIG 1. The Tannoy Power V™ loudspeaker can be flown with high quality VEB M10 eyebolts with collar to BS4278:1984. The loudspeakers are equipped with internal steel braces, which also double as the flying points, and accept VEB M10 eyebolts. -
Page 20: Secur Et - Vth Pole Mount
10.7 : SECUR ET - VTH POLE MOUNT The Tannoy Power V™ loudspeakers are fitted as standard with a blanking plate on the base of the cabinet. However, should you ever wish to mount the Power V™ onto a standard 35mm pole mount this blanking plate can be quickly and easily removed and replaced by a VTH pole mount. -
Page 21: Service Parts & Accessories
11.0: SERVICE PARTS & ACCESSORIES PowerV6 7900 0742 Driver Kit - 1728 7900 0683 HF Diaphragm Kit PowerV8 7900 0385 HF Diaphragm Kit 7900 0475 Recone Kit - 2062 7900 0474 Driver Kit - 2062 PowerV12 7900 0433 Driver Kit - 3142 7900 0441 Recone Kit - 3142 7900 0199... -
Page 22: Warranty
Claims will not be considered is the serial number has been altered or removed. Work under warranty should only be carried out by a Tannoy Professional dealer or service agent. This warranty in no way affects your statutory rights. - Page 23 14.0: NOTES...
- Page 24 NOTES...
- Page 25 NOTES...
- Page 26 NOTES...
- Page 27 NOTES...
- Page 28 Tannoy North America T: (519) 745 1158 F: (519) 745 2364 E: inquiries@tannoyna.com Tannoy Deutschland T: 0180 1111 88 1 F: 0180 1111 88 2 E: info@tannoy.com Tannoy adopts a policy of continuous improvement and product specification is subject to change.
