Page 1: Owners Manual
Owners Manual VNET 12, VNET 12 HP, VNET 15, VNET 300 VNET 15 HL, VNET 15BP & VNET 18DR... - Page 2 1.0: IMPORTANT SAFETY INSTRUCTIONS 2.0: INTRODUCTION 3.0: THE BASICS Unpacking and visual checks Preliminary recommendation 4.0: INTERFACE PANEL 5.0: OPERATION 5.1: AC power requirements Cooling LED functions Limiters Audio Connections User DSP on/off 6.0: NETWORK CONNECTIONS Linking cabinets 7.0 SOFTWARE INSTALLATION 8.0 SOFTWARE OPERATION 8.1: Updating firmware...
- Page 3 Ne placez pas d’objets contenant du liquide proximit de l’appareil. AVERTISSEMENT DE SECURITE Ne remplacez le fusible de r seau principal que par un fusible T10A HBC du m me type fourni par Tannoy sous la r f rence 34610919.
-
Page 4: Installation Instructions
Neutrik ’Powercon’ type NEC3FCA connector (Tannoy part number 3461 0919 as supplied with the equipment. The other end of the green or green and yellow conductor must be connected to the earthing pin of a suitable mains plug or the earthing terminal of the installation. - Page 5 VNET300 is the natural choice. The 12 SuperDual“ ensures the most even frequency response over a wide coverage area in the medium size venues for which the Tannoy V300 is designed.
- Page 6 A word of warning on high sound levels - these speakers are capable of generating high output levels over sustained periods of time and such levels, over 95dBspl for 8 hours per day, can eventually cause permanent hearing loss. Since Tannoy loudspeakers have a natural-sounding flat frequency response and low distortion, it’s possible not to be aware just how high...
- Page 7 100 to 240 Volts; the auto ranging power supply detects the mains voltage automatically and configures accordingly. Replace the mains fuse only with the same T10A HBC type supplied by Tannoy under part number 3461 0919.
-
Page 8: Network Connections
RS232 to RS485 or USB to RS485 interface. These devices are readily available from your IT supplier. At the time of writing this manual extensive testing was carried out with the following devices:- Tannoy USB — RS485 Converter (Part No. 8001 3920) K2 from KK (www.kksystems.com) USB-COMi from Easysync (www.easysync.co.uk) -
Page 9: Software Installation
The enclosed disc contains the Podware software package; a comprehensive editor, interface, & diagnostics tool for the VNET“ range of loudspeakers. Check the Tannoy website for any updates http://www.tannoy.com The disk should AUTORUN , if not open the Podware folder & double click on the Setup.exe icon. - Page 10 7.0 SOFTWARE INSTALLATION You can check to see if you already have the .NET Framework 1.1 installed by clicking Start on your Windows desktop, selecting Control Panel, and then double-clicking the Add or Remove Programs icon. When that window appears, scroll through the list of applications.
- Page 11 7.0 SOFTWARE INSTALLATION 3. Confirm Installation. Click <Next> 4. If you accept the licence agreement check I Agree and Click <Next> 5. The programme will begin installing 6. Installation Complete...
-
Page 12: Software Operation
8.0 SOFTWARE OPERATION Menus The menu system is arranged like so: File Open opens a file which contains parameters for the device Save saves the current settings in the current file name Save As saves the current settings under a new file name Exit closes the application Device... - Page 13 8.0 SOFTWARE OPERATION PodWare communicates with VNET“ using a serial COM port as a network connection. When a network connection is open and actively connected to a compatible device, the system is said to be On Line . Whilst On-line, you can control the connected device in real time , and continuously receive status information from the device.
- Page 14 8.0 SOFTWARE OPERATION The control panel shows the model name (not editable), and firmware version for the device. The device properties panel also have an editable Configuration Name, and Loudspeaker name, the latter will appear in the tree menu after editing. Each panel will in addition have a complete set of controls relating to the adjustable parameters within the device (press the EQ/DELAY tab to access this section).
-
Page 15: Speaker Properties
8.0 SOFTWARE OPERATION 8.0 SOFTWARE OPERATION VNET CONTROL PANEL The control panel for VNET“ allows VNET“ parameters to be viewed and adjusted. The panel is organised into a monitoring area (at the top left of the panel) where the status of VNET“ may be viewed, and a control area where all the controls to adjust parameters are located. - Page 16 7.0 SOFTWARE OPERATION 8.0 SOFTWARE OPERATION Audio Processing VNET“ provides the following processing options: • • Crossover filtering with frequency variable over the range 10Hz to 25kHz (and Out ) with the following alignments: order • • 12dB/Octave Bessel 12dB/Octave Butterworth •...
-
Page 17: Updating Firmware
Occasionally it may be necessary to update the devices firmware (with file extension .dfw); this may be due to added features or amendments to the VNET“ product. Check with your dealer/distributor or (www.tannoy.com) for any applicable updates. Firmware can be updated over the network (no need to disconnect speakers from the network) A firmware update will be common to all VNET“... - Page 18 8.1: UPDATING FIRMWARE At the bottom right hand side of the screen a blue bar will show the progress of the firmware update. After the download is complete the following message appears. The DSP is updating at this point. Do not power down the unit or disconnect any network cable at this point.
- Page 19 9.0: EQUALISATION VNET“ loudspeakers are designed to need no equalisation or correction to overcome system limitations. As a result, they will only need equalisation to compensate for difficult acoustic environments. Over equalisation can reduce system headroom, and introduce phase distortion resulting in greater problems than cures. If equalisation is required then it should be applied gently and smoothly.
- Page 20 11.0 DIMENSIONS VNET 12 & 12HP 370.0 290.0 WARNING CAUTION TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE 180.0 AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR. THIS CLASS D DIGITAL DEVICE MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE-CAUSING EQUIPMENT REGULATIONS AND COMPLIES WITH PART 15 OF THE FCC RULES.
- Page 21 11.0 DIMENSIONS VNET 15 BP 440.0 440.0 195.0 400.0 40.0 CAUTION WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR. THIS CLASS D DIGITAL DEVICE MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE-CAUSING EQUIPMENT REGULATIONS AND COMPLIES WITH PART 15 OF THE FCC RULES.
-
Page 22: Performance Data
12.0 PERFORMANCE DATA VNET12 Anechoic Frequency Response VNET12 HP Anechoic Frequency Response VNET300 Anechoic Frequency Response VNET15 Anechoic Frequency Response... -
Page 23: Technical Specifications
A full range of measurements, performance data, and Ease“ Data can be downloaded from www.tannoy.com Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications, which Tannoy reserves... - Page 24 A full range of measurements, performance data, and Ease“ Data can be downloaded from www.tannoy.com Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications, which Tannoy reserves...
-
Page 25: Secur Et - Vmy Yoke Bracket
14.1 : SECUR ET - VMY YOKE BRACKET The VMY is an adjustable yoke bracket (available in both black and white), allowing the user to fly the Tannoy VNET“ Full Range loudspeakers in either portrait or landscape orientations using the same bracket (Figures 1 & 2). - Page 26 Fig.1 Fig.2 Use the table of parts along with the assembly drawing (Figure 3.) to assemble the VMY. Figure 4 shows the VMY assembled. Fig.3 Fig.4 Number on Assembly View (Fig 3.) Description Quantity Hanging Bracket Cross Member Pivot Stud M10 Plain Washer M8 Spring Washer M10 Spring Washer...
- Page 27 14.2 : SECUR ET - V15Y & V12Y V15Y V12Y...
-
Page 28: Secur Et - Vmb Wall Mounting Bracket
The VMB is wall mounting bracket for the attachment of a VMY, FIG 1. available in both black and white finishes, allowing the user secure the Tannoy VNET“ Full range loudspeaker in either portrait or landscape orientations to a wall. The Tannoy VNET“ loudspeaker is attached to the bracket using the accessories supplied. -
Page 29: Secur Et - Veb Eyebolt
14.4 : SECUR ET - VEB EYEBOLT FIG 1. The Tannoy VNET“ loudspeaker can be flown with high quality VEB M10 eyebolts with collar to BS4278:1984. The loudspeakers are equipped with internal steel braces, which also double as the flying points, and accept VEB M10 eyebolts. -
Page 30: Secur Et - Vth Pole Mount
The VCS ceiling saddle available in both black and white finishes, and is to be used in conjunction with the VMY and a length of M10 threaded rod (not supplied by Tannoy Limited). The VCS ceiling saddle allows the Tannoy VNET“ loudspeaker to be suspended at a user defined distance from the ceiling as shown in Figure 1. -
Page 31: Service Parts & Accessories
15.0: SERVICE PARTS & ACCESSORIES Full Range VNET Amplifier & DSP Module 7300 1045 Duals 7300 1062 Subs VNET12 7900 0433 Driver Kit - 3142 7900 0441 Recone Kit - 3142 7900 0199 HF Diaphragm Kit VNET12HP 7900 0715 Driver Kit - 3190 7900 0716 Recone Kit —... -
Page 32: Warranty
Claims will not be considered is the serial number has been altered or removed. Work under warranty should only be carried out by a Tannoy Professional dealer or service agent. This warranty in no way affects your statutory rights. - Page 33 18.0: NOTES...
- Page 34 NOTES...
- Page 35 NOTES...
- Page 36 Tannoy North America T: (519) 745 1158 F: (519) 745 2364 E: inquiries@tannoyna.com Tannoy Deutschland T: 0180 1111 88 1 F: 0180 1111 88 2 E: info@tannoy.com Tannoy adopts a policy of continuous improvement and product specification is subject to change.
