700EL Assembly Instructions

Transportation Wheel Assembly
1. Slide the Wheel Sleeve onto the bar at the base of the left rear of
the unit. Attach the sleeve to the bar using the supplied Phillips
head screw.
2. Press the Transportation Wheel onto the Wheel Sleeve until it
snaps into place.
3. Repeat this process on the other end of the rear bar.
Console Mast Assembly
1. Connect main wire harness at the bottom of console mast to
wire harness at the front of frame.
2. Slide console mast into console mast receptor at front end of
frame. IMPORTANT: Gently pull up on the wire harness at the
top of the console mast while doing so to avoid pinching the
wire harness.
3. First, attach console mast to frame at upper holes location on
both sides using the 5mm Allen wrench and two M8x20mm
screws with one flat washer and one lock washer each. Thread
these screws in, but do not tighten them all the way yet.
4. Next, attach console mast at lower holes location on both sides
of console mast receptor. NOTE: There are three holes on either
side to choose from. The middle hole is for average-sized users.
The hole closest to the footpads is for taller users, and the hole
farthest from the footpads is for shorter users. Choose the de-
sired hole and fully tighten the bolts using two M8x20mm screws
with one flat washer and one lock washer each. Then fully tighten
the two screws in the upper holes.
5. Attach the Console Mast Base Cover to the front of the Console
Mast Receptor using 4 Phillips head screws, with the arrow on
the cover facing upward.
Handrail Assembly
1. Attach right handrail to the console mast at the right handrail
axle using the set-screw collar. Tighten the set-screw of the reght
handrail set-screw collar by using the 3mm Allen wrench.
2. Next, attach the right handrail to the bottom of the right steparm.
Insert the handrail/steparm axle through the holes in the steparm
and through the tube at the bottom of handrail, and attach hand-
rail by using & tighten the M8 x 20mm screw with washer and a
5mm Allen wrench.
3. Assemble left handrail the same way.
4. Attach both steparm/handrail connecting covers using M5x25mm
screws each and a Phillips screwdriver.
5. On either side of water-bottle cover, attach the handrail covers
to each other around the handrails. Use the two M4x 40mm
screws and nuts on each side and tighten them with a Phillips
screwdriver and an open wrench
7 0 0 S E R I E S O W N E R' S M A N U A L
Handlebar Assembly
1. Insert the hand pulse harness through the opening of the con-
sole mast and out of the top of the console mounting plate.
2. Assemble the handlebar onto the mount and insert and tighten
the four M8x12mm screws using a 5mm Allen wrench. Be sure
not to pinch the hand pulse harness during this procedure, as
this will damage the electronic console.
Console Assembly
1. Connect both plugs from main wiring harness and hand pulse
wiring harness to the plug receptors on the backside of the con-
sole taking care to install correctly (see plug alignment marks).
WIRING HARNESS INSTALLATION HINT: Any excess wiring
must be carefully inserted (stored) back into the console
mast before installing the console onto the console mounting
plate.
2. Fasten the console to the console mounting plate with the four
M5 x 12mm screws and washers using 1 Phillips screwdriver.
Waterbottle
1. Insert the water bottle into the water bottle holder.
Transformer Assembly
1. Plug transformer into plug receptor located on the rear/bottom
side of main frame.
2. Plug the transformer output into power outlet. NOTE: Be sure to
use right transformer for your power outlet, 110V or 220V.
