Sharp MD-R3 Operation Manual page 23

(Continued)
INPUT RECORD
DISPLAY/CHARACTER
SELECT
INPUT
SELECT
SYNC REC
DISPLAY
REC
CANCEL
REC
MD
3
When the digital optical input is selected
4
TOC
1
"PAUSE" indicator
12 4
1
12 4
1
Sound synchro recording
When music is played on another piece of equipment, such as
REC LEVEL
a stereo, that is connected to this unit, this unit will automatically
start recording on the MD.
MIN MAX
1
Press the MD
2
Insert a recordable MiniDisc.
3
Press the INPUT SELECT button to select the input. (Page
19)
If you will be recording from the analog input, adjust the re-
cording level after selecting the input.
4
Press the SYNC REC button on the remote control.
The unit will enter the recording stand-by mode.
"SYNC STANDBY" will appear.
5
Start playing the music you want to record using the other
equipment.
This unit will automatically start recording. When the other
equipment has finished playback, this unit will enter the re-
cording stand-by mode. Press the MD
To stop recording at any time, press the MD
To adjust the recording level: (Analog input only)
After you select analog input in step 3, press the RECORD (REC)
button, and then play the music on the other equipment.
Adjust the recording level using the REC LEVEL control.
Adjust the recording level so that the maximum level does not
exceed "0 dB".
After the level is adjusted, stop the other equipment, and go
to step 3.
0dB OVER
Manual recording:
Select the input, and then press the RECORD (REC) button.
0dB
The unit will enter the recording stand-by mode. 06
Press the MD
This unit will start recording.
The space cut function will not work.
0dB OVER
Space cut function:
During sound synchro recording, if there are more than 3 sec-
onds of silence in the playback sound, this unit will automat-
ically enter the recording stand-by mode. ("SYNC STANDBY"
will appear.) Then, when further playback is started on the
other equipment, this unit will resume recording. (A silence of
up to 3 seconds can be created between tracks.)
If there is noise between the tracks on the original recording,
the sound synchro recording or space cut function may not
work properly. If this happens, use manual recording.
When recording tracks or sounds in which there are 3 seconds
or more of very small continuous sounds that you want to
record, use manual recording.
22
MD-R3
button.
button to cancel it.
button.
button.
