OVEN AND ACCESSORIES

1 Oven lamp

2 Control panel

3 Waveguide cover
4 Coupling
5 Oven cavity
6 Door seals and sealing surfaces
ACCESSORIES:
Check to make sure the following accessories are
provided:
(13) Turntable (14) Roller stay (15) Rack
Place the roller stay in the coupling on the floor of the
cavity.
Then place the turntable on the roller stay.
To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
7:06 PM Page 2
7 Door safety latches
8 Door opening handle
9 Grill heating element
10 Power supply cord
11 Ventilation openings
12 Outer cover
4
