PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED
TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR
EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY
CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK
AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT
PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Part
1 Left Half Housing
2 Slip Gutter
3 Roller
4 Laser Switch
5 Shell
6 Screw (ST4.2 x 19)
7 Screw (ST4.2 x 37)
8 Name Plate
9 Blade Guard
10 Ring Dowel
11 Ring
12 Washer Board (4)
13 Axle
14 Wiring Spring
15 Guide Roller
16 Hex Screw (M4 x 15)
17 Square Nut
18 Cord Guard
19 Brush Holder
20 Speed Control Dial
21 Trigger
22 Bearing (607-2Z)
23 Rotor
24 Bearing (608-2Z)
25 Stator
26 Center Support
27 Balance Patch
28 Balance Blade
29 Axle (P4 x 13.8)
30 Gear
31 Guide Case
Page 14
Description
For technical questions, please call 1‑800‑444‑3353.

PARTS LIST

Part
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
Description
Axle Bearing
Washer Board (6)
Slide Mass
Support
Washer Board (5)
Slide Rod
Blade Guide Assembly
Blade Clamp
Washer Board
Base Plate
Screw (ST4.2 x 16)
Power Cord
Right Half Housing
Name Plate
Cutting Mode Selector
Top Cover
Cord Clip
Negative Pole
Positive Electrode
Screw (ST3 x 10)
Battery (sold separately)
Laser Socket
Screw (ST3 x 10)
Laser
Screw (M3 x 8)
Battery Compartment Lid
Cover
Saw Blade (Qty. 2 @ 4" x 10 TPI)
Saw Blade (Qty. 1 @ 3-1/4" x 25 TPI)
Trigger Lock
SKU 92772
