Planning Information
Undercounter Model 249FF (I )
All Freezer
Serial and model
number plate
Automatic ice
maker (249FFI)
Removable ice
bucket (249FFI)
Model 249FF
One piece interior
Front venting with
Model 249FFI
removable kickplate
with Ice Maker
A
side from the full-size units
Sub-Zero offers in its Built-In and
Integrated lines of refrigeration, we
round out our product line-up with
a line of traditional Undercounter
refrigeration which meets all of the
exacting standards you have
grown to expect from Sub-Zero.
If you desire, this unit could be
matched with a 249RP and outfit
a compact New York apartment
with all the refrigeration space
necessary. While that is a limited
application, these units can sit
side-by-side in any home bar area
and be a great combination for
those party situations.
This model should be ordered with
or without an ice maker; you
cannot retrofit the ice maker.
Dimensions in parentheses are in
millimeters unless otherwise specified.
11/06
M O D E L 2 4 9 F F ( I )
Undercounter all freezer unit
24" (610) depth-true design for a complete built-in look
Door accepts custom panels
Smooth surface, easy-to-clean one piece interior
Automatic ice maker in Model 249FFI provides an ample
supply of crescent-shaped ice—removable ice bucket
provided
Automatic defrost
Interchangeable hinge allows door swing to be reversed
in the field
Front venting with removable kickplate allows unit to be
serviced from the front
Solid core door with magnetic gasket and door closer
UL approved for US and Canada
Two, five and twelve year residential warranty—
exclusions apply; warranty information can be found on
our website, subzero.com
Interchangeable
door hinge
Adjustable tempera-
ture control
Interior light
Four-sided
magnetic gasket
Removable wire
shelves
1
