- Page 1 Integrated Model IC-36FI Design Guide REVISED 9 / 2015...
- Page 2 Features and specifications are subject to change at any time without notice. Visit subzero.com/specs for the most up-to-date information. IMPORTANT NOTE: Throughout this guide, dimensions may vary by ± " . Dimensions in parentheses are millimeters unless otherwise specified.
-
Page 3: Integrated Refrigeration
INTEGRATED REFRIGERATION Integrated Refrigeration With custom front panels and hardware, Sub-Zero invented INTEGRATED COLUMN integrated columns, tall and drawer models that disappear into the decor. Integrated units fit flush with other cabinets, making integrated refrigeration as practical and beautiful in the master suite, bar or theatre room as in the kitchen. -
Page 4: Specifications
" (92) " " (2121) MIN TO (2146) MAX " (45) COLUMN MODEL IC-36FI 36" " " (914) (184) (876) Overall dimensions do not include panel IMPORTANT NOTE: or handle. Dimensions will vary with panel thickness. Sub-Zero Customer Care 800.222.7820... -
Page 5: Opening Dimensions
OPENING OPENING WIDTH Dual installation kits are available through an authorized HEIGHT Sub-Zero dealer. For local dealer information, visit the find a showroom section of our website, subzero.com. For ques- tions regarding the installation, call Sub-Zero customer care at 800-222-7820. -
Page 6: Plumbing Requirements
IC-36FI 9" (229) LEFT SIDE OF OPENING " RIGHT SIDE (114) OF OPENING " (108) FLOOR " " 6" (152) 3" (76) Electrical supply location. AREA EXTENDS 1 " (13) FORWARD ON FLOOR Water supply location. Sub-Zero Customer Care 800.222.7820... -
Page 7: Custom Panels
INTEGRATED REFRIGERATION Custom Panels For model IC-36FI, a custom door panel and handle hard- TYPICAL PANEL DIMENSIONS ware must be provided. Refer to the panel requirements chart and typical panel dimensions. The thickness of the custom panel can vary. A minimum "... -
Page 8: Custom Panel
" require a reduced toe kick accessory (51) (98) available through an authorized Sub-Zero dealer. For local dealer information, visit the find a showroom section of our website, subzero.com. For questions regarding the installa- " tion, call Sub-Zero customer care at 800-222-7820. - Page 9 INTEGRATED REFRIGERATION Standard Handles Optional stainless steel tubular and pro handles are avail- able through an authorized Sub-Zero dealer. For local dealer information, visit the find a showroom section of our website, subzero.com. Refer to the chart below for standard handle lengths for model IC-36FI.
-
Page 10: Full-Scale Template
90° door stop. " (19) PANEL DOOR OPEN MAXIMUM 105° " (3) REVEAL POTENTIAL DOOR CLOSED " INTERFERENCE (19) PANEL ADJACENT CABINETRY POTENTIAL INTERFERENCE 0" 1" (25) SCALE Maximum door opening (top view). Sub-Zero Customer Care 800.222.7820... - Page 11 FULL TWO YEAR WARRANTY* For two years from the date of original installation, this Sub-Zero product warranty covers all parts and labor to repair or replace, under normal residential use, any part of the product that proves to be defec- tive in materials or workmanship.
