BIOS Setup Utility
3-8 INTEGRATED PERIPHERALS
Caution: Change these settings only if you are already familiar
with the Chipset.
The [INTEGRATED PERIPHERALS] option changes the values of the
chipset registers. These registers control the system options in the
computer.
The following screen shows setup default settings.
OnChip IDE Channel0
OnChip IDE Channel1
IDE Prefetch Mode
Primary Master PIO
Primary Slave PIO
Secondary Master PIO
Secondary Slave PIO
Primary Master UDMA
Primary Slave UDMA
Primary Master UNMA
Primary Slave UDMA
Init Display First
Onboard FDC Controller
The following tables describe each field in the INTEGRATED
PERIPHERALS Menu and provide instructions on how to configure the
IDE controls, FDC controls, and the onboard serial and parallel ports.
ROM PCI/ISA BIOS
INTEGRATED PWEIPHERALS
AWARD SOFTWARD, INC.
: Enabled
: Enabled
: Disabled
: Auto
: Auto
: Auto
: Auto
: Auto
: Auto
: Auto
: Auto
: PCI Slot
: Enabled
81
Onboard Serial Port 1
Onboard Serial Port 2
UR2 Mode
UR2 Duplex Mode
Onboard Parallel Port
Parallel Port Mode
ECP Mode Use DMA0
ESC : Quit
F1 : Help
F5 : Old Values
F7 : Load Setup Defaults
SY-6VBA133-B
: 3F8/IRQ4
: 2F8/IRQ3
: Standard
: Full
: 378/IRQ7
: SPP
: 1
: Select Item
PU/PD/+/- : Modify
(Shift) F2 : Color
