Replacing The Filter Cartridge - Sanyo PLC-ZM5000 Owner's Manual

1 Turn off the projector, and unplug the AC power cord
from the AC outlet.
First, clean up the dust on the projector and around
2
the air vents.
3
latch and open the filter cover.
4 Pull out the filter cartridge. When taking out the filter
cartridge, put your finger on the filter cartridge's tab
and then pull.
5 Put the new one back into the position and close
the filter cover. Make sure that the filter cartridge is
properly and fully inserted.
6 Connect the AC power cord to the projector and turn
on the projector.
7 Reset the filter counter and the scroll counter (p.68).
CAUTION
Make sure the filter cartridge is inserted in the
projector. If the filter cartridge is not inserted, the
projector cannot be turned on.
Do not put anything into the air vents. Doing so
may result in malfunction of the projector.
RECOMMENDATION
We recommend avoiding dusty/smoky environments
when operating the projector. Usage in these
environments may cause a poor image quality.
When using the projector under dusty or smoky
conditions, dust may accumulate on a lens, liquid crystal
panels, or optical elements inside the projector. Such
condition may degrade the quality of the projected image.
When the symptoms above are noticed, contact your
authorized dealer or service center for proper cleaning.
ORDER REPLACEMENT FILTER CARTRIDGE
Replacement filter cartridge can be ordered through
your dealer. When ordering, give the following
information to the dealer.
Model No. of your projector
PLC-ZM5000, PLC-ZM5000L
Replacement Filter Cartridge Type No.
POA-FIL-080 (Service Parts No. 610 346 9034)

Replacing the Filter Cartridge

Maintenance and Care
Filter cover
Filter
Tab
cartridge
Latch
67
