MISFEED REMOVAL
Roller rotating knob B
Fusing unit tab
Do not touch these two levers.
Roller rotating knob C
Exit area lever C
5-8
3 Remove the misfed paper.
If the misfed paper is in the inner part of the exit area:
1
Turn roller rotating knob
remove the paper.
2 If the misfed paper is deep in the fusing unit, lift the fusing unit
tab and remove any misfed paper.
CAUTION
The fusing unit is hot! Be sure to touch only the green tab or the
green roller rotating knob.
NOTE:
The levers are operated by service personnel only. The user is not
allowed to touch them.
If the misfed paper is in the exit area:
1
Turn roller rotating knob
remove the paper.
2 If the misfed paper cannot be removed in step
area lever and remove the paper.
C
4 Close the exit area cover.
in the direction of the arrow and
B
in the direction of the arrow and
C
1
, raise exit
