MATSONIC MS7012D Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Important Information

Copyright
This publication, including all photographs, illustrations and software, is
protected under international copyright laws, with all rights reserved.
Neither this manual, nor any of the material contained herein, may be
reproduced without the express written consent of the manufacturer.
Disclaimer
The information in this document is subject to change without notice. The
manufacturer makes no representations or warranties with respect to the
contents hereof and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. Further, the
manufacturer reserves the right to revise this publication and to make
changes from time to time in the content hereof without obligation of the
manufacturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft
Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered
trademarks of Intel Corporation.
VGA, OS/2, PS/2 are registered trademarks of International Business
Machines.
AMD, K5, K6 are registered trademarks of Advanced Micro Devices Inc.
Cyrix, M1 are registered trademarks of Cyrix Corporation.
Other product names used in this manual are the properties of their
respective owners and are acknowledged.
Version 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS7012D and is the answer not in the manual?

Questions and answers

Related Manuals for MATSONIC MS7012D

Summary of Contents for MATSONIC MS7012D

  • Page 1: Important Information

    Important Information Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the manufacturer. Disclaimer The information in this document is subject to change without notice.

  • Page 2: Canadian Department Of Communications

    Safety Compliance Federal Communications Commission (FCC) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Table Of Contents

    Contents Chapter 1: Introduction ........... 1 Welcome..............1 About the Manual............2 Checklist ..............3 Standard Items -------------------------------------------------------3 Recommendations ............ 3 Features..............4 Chapter 2: Installation..........8 Quick Installation Table..........8 Quick Jumper Setting Reference........ 9 Before You Begin............11 Static Electricity ------------------------------------------------------11 Choosing a Case-----------------------------------------------------11 How to Set Jumpers ------------------------------------------------12...
  • Page 4 Running the Support CD-ROM........66 Utility Folder Installation Notes ........66 CMI8X38 Folder Installation Notes ......67 Audio Software--------------------------------------------------------67 Modem Driver and Software-------------------------------------68 Intel Folder Installation Notes........68 Mainboard (MS7012D) Installation Notes....69 Appendix 1: Quick Jumper Setting Reference ..70...

  • Page 5: Chapter 1: Introduction

    Intel 810 chipset which includes an accelerated graphics adapter with digital video output for use by televisions of flat- panel displays. The MS7012D has a slot1 and a socket-370 so that it can be installed with either a slot1 processor (SEPP Celeron or Pentium- II) or a socket-370 processor (PPGA Celeron).

  • Page 6: About The Manual

    This chapter contains the following information: q About the Manual explains how the information in this manual is organized q Checklist comprises a list of the standard and optional components that are shipped with this mainboard q Recommendations lists some Do’s and Don’ts from the manufacturer to help ensure reliability and performance from this product q Features highlights the functions and components that make this...

  • Page 7: Checklist

    Compare the contents of your mainboard package with the standard checklist below. If any item is missing or appears damaged, please contact the vendor of your mainboard package. Standard Items ü 1 x MS7012D Mainboard ü 1 x Cable/Bracket Pack Diskette drive ribbon cable IDE drive ribbon cable ü...

  • Page 8: Features

    Value-class Processors Functioning as a platform for a value PC, the MS7012D is ideally suited for the PPGA (Plastic Pin Grid Array) Celeron processor. The PPGA Celeron has 32k of internal cache memory, 128K of external cache memory, and operates over a 66MHz system bus.
  • Page 9 BIOS. You must install at least one memory module. Highly Integrated Design As well as the Intel 810 chipset, the MS7012D features other highly integrated silicon chips. The ITE LPC I/O controller handles the mainboard’s I/O functions. The CMI 8738/PCI C3DX is a two-chip solution that provides an integrated audio and fax/modem system.
  • Page 10 Built-in V.90 Fax/modem The PCI C3DX chip is a single chip solution for value PC communications. The chip supports 56 Kbps transmission using rhe V.90 protocol. The chip is integrated with the built-in audio system to support voice as well as data transmissions. Up-to-date Expansion Options This is a full-sized ATX board with a full set of current technology expansion slots.
  • Page 11 Suspend to RAM Feature This mainboard features the suspend to RAM function. In a suspend to RAM, the system is totally powered down with the exception of the small current required to refresh the system memory. To resume from a suspend to RAM, press the power button (or use the hot keys or password if you have enabled a hot-key or password power on).

  • Page 12: Chapter 2: Installation

    Quick Installation Table This chapter explains how to successfully install the mainboard into a computer case and build a working system. The installation procedure is as follows: Quick Jumper Provides a quick reference for the jumper Setting Reference settings on this mainboard. Before you Begin Provides advice on choosing a case, avoiding static electricity damage, and setting...

  • Page 13: Quick Jumper Setting Reference

    Quick Jumper Setting Reference If you are familiar with most of the material in this chapter, you can begin preparing the mainboard for installation by using this quick reference to begin the setting the jumpers. A detailed description of the jumper setting appears later in this chapter.
  • Page 14 JP6: Audio codec select jumper Use this jumper to select if the system uses the audio codec chip integrated on the mainboard, or an audio codec chip located on an optional AMR card. Function Jumper Cap 1 2 3 Turn on onboard codec Short Pins 1-2 Turn off onboard codec Short pins 2-3...

  • Page 15: Before You Begin

    Before You Begin Before you begin to install your MS7012D mainboard, take some precautions to ensure that you avoid the possibility of damage to the product from static electricity. Ensure too that you are installing the mainboard into a suitable case.

  • Page 16: How To Set Jumpers

    The mainboard has a set of I/O ports on the rear edge. Ensure that your case has an I/O template that supports the I/O ports and expansion slots. How to Set Jumpers A jumper consists of two or more pins mounted on the mainboard. Some jumpers might be arranged in a series with each pair of pins numbered differently.

  • Page 17: Preparing The Mainboard

    Preparing the Mainboard Mainboard Guide Use the following illustration and key to identify the components on your mainboard. DIMM2 CASFAN1 CPUFAN1 DIMM1 PWRFAN1 Socket-370 LED1 FDD1 ATX1 IDE2 Slot-1 JP12 IDE1 JP11 PANEL1 COM2 AMR Slot PCI1 LED2 PCI2 PCI3 PCI4 SIR1 PCI5...
  • Page 18 Key to Mainboard Components Component Description Slot-1 Slot for Slot-1 processor cartridge Socket-370 Socket for PPGA Celeron Processor PCI 1,2,3,4,5 Five 32-bit PCI Slots AMR Slot Slot for an Audio Modem Riser card. DIMM 1, 2 Two slots for 168-pin SDRAM memory module FDD1 Connector for floppy disk drives IDE1, IDE2...

  • Page 19: I/O Ports Side View

    **LED2 This red indicator turns on whenever system is turned on. The LED warns users not to work on the mainboard, for example adding expansion cards or changing jumpers, because the system is still active. I/O Ports Side View PS2KBM LPT1 COM1 VGA1...

  • Page 20: Check The Jumper Settings

    Check the Jumper Settings Check all the mainboard jumpers to ensure that the board is configured correctly. JP12 JP11 JP1 Clear CMOS Memory Jumper This jumper lets you erase the system setup settings that are stored in CMOS memory. You might need to erase this data if incorrect settings are preventing your system from operating.
  • Page 21 JP3: Audio/Modem System Enable/disable Jumper This 3-pin jumper can be used to enable or disable the onboard audio system. If you prefer to install a different audio system on a third party expansion card, you must disable the onboard audio. Function Jumper Cap Enable audio/modem system...
  • Page 22 JP9: Set System Bus Frequency Jumper (133 MHz) Use this 3-pin jumper to set the system bus frequency. In the normal setting, the system automatically selects the correct frequency according to the kind of processor installed. In the Force 133 MHz setting, the system uses a 133 MHz system bus even if the processor is designed to operate with a 100 MHz bus.

  • Page 23: Install The Mainboard In The Case

    Install the Mainboard in the Case The mainboard is drilled with a series of holes. Most system cases have mounting brackets installed in the case which correspond to the holes in the mainboard. You can secure the mainboard in the system case by placing the mainboard over the mounting brackets and driving screws through the mainboard into the mounting brackets.
  • Page 24 The illustration below shows the mainboard installing into a tower-type case. Power Supply Unit Drive Cage Template Expansion Slots...

  • Page 25: Connecting Power, Chassis Fans, Panel, Auxiliary Usb Ports, And Case Open Detect Circuit

    Connecting Power, Chassis Fans, Panel, Auxiliary USB Ports, and Case Open Detect Circuit After you have installed the mainboard into the system case, connect the power cable from the case power supply unit to the mainboard power connector ATX1. Connect the chassis/power fans (if your case has them) to the 12V power supply connectors CASFAN1or PWRFAN1 on the mainboard.
  • Page 26 J7: Auxiliary USB Connector This mainboard has two built-in USB ports on the rear edge of the board. Some system cases have built-in USB ports on the chassis that must be connected to a USB connector on the mainboard. If you have this kind of system case, connect the cable from the chassis-mounted USB ports to the J7 connector.

  • Page 27: Install Other Hardware

    Install Other Hardware Start installing the essential hardware required to get your system started. Install the Processor This mainboard has a Slot1 processor slot and a Socket-370 processor socket. You can only install one processor however, so you must choose what kind of processor to run on this.
  • Page 28 Intel SEPP Celeron SEPP stands for Single Edge Processor Package. The SEPP Celeron is similar to a Pentium-II except that it only has 128K of external cache memory. The first generation of SEPP Celerons had no external cache memory at all and ran at 266 MHz. These Celerons do not ship currently but are still supported by this mainboard.

  • Page 29: Installing A Slot1 Processor

    Installing a Slot1 Processor This board has a SLOT1 processor cartridge slot. The slot must be installed with a cartridge holder that supports the processor cartridge. The cartridge holder may be already installed on your mainboard with the support brackets folded over. In this case simply pull the support brackets into the upright position.
  • Page 30 Install the Processor Cartridge After you have installed the cartridge holder, follow the instructions supplied with the processor cartridge to insert the cartridge into the holder. If the processor has a cooling fan, connect the power cable of the fan to the power supply connector on the mainboard CPUFAN1. The mainboard must be configured to deliver the correct clock speed and the correct system bus for the kind of processor that you have installed.

  • Page 31: Installing A Socket-370 Processor

    Installing a Socket-370 Processor If you have decided to install the mainboard with a PPGA Celeron processor, follow the steps below. Locate the Socket-370 and CPUFAN1 CPUFAN1 Socket-370 Pin-1 corner Locking lever 1. On the mainboard, locate the socket-370 and CPUFAN1. 2.
  • Page 32 Socket-370 processor Cooling fan with heatsink/cooling power cable fan assembly CPUFAN1 cooling fan power supply Socket-370 with locking lever in upright position The mainboard must be configured to deliver the correct clock speed and the correct system bus for the kind of processor that you have installed.

  • Page 33: Install The Memory Modules

    Install the Memory Modules For this mainboard, you must use 168-pin 3.3V non-buffered Dual In-line Memory Modules (DIMMs). The memory chips must be standard or registered SDRAM (Synchronous Dynamic Random Access Memory). The memory bus can run at 66 MHz, 100 MHz or 133 MHz. If your processor operates over a 100 MHz system bus, install PC100 or PC- 133 memory that operates over a 100 MHz or 133 MHz bus.

  • Page 34: Install A Hard Disk Drive And Cd-Rom

    2. The DIMM slots are keyed with notches and the DIMMs are keyed with cut-outs so that they can only be installed correctly. Check that the cut-outs on the DIMM module edge connector match the notches in the DIMM slot. 3.
  • Page 35 Installing a Hard Disk Drive 1. Install the hard disk drive into the drive cage in your system case. 2. Plug the IDE cable into the primary IDE channel on the mainboard IDE1. 3. Plug one of the connectors on the IDE cable into the IDE connector on the back edge of the hard disk drive.
  • Page 36 Installing a CD-ROM/DVD Drive 1. Install the CD-ROM/DVD drive into the drive cage in your system case. Plug the IDE cable into the primary IDE channel on the mainboard IDE1. 2. Plug one of the connectors on the IDE cable into the IDE connector on the back edge of the CD-ROM/DVD drive.

  • Page 37: Installing A Floppy Diskette Drive

    Installing a Floppy Diskette Drive The mainboard has a floppy diskette drive interface and it ships with a diskette drive ribbon cable that supports one or two floppy diskette drives. You can install a 5.25” drive or a 3.5 ” drive with various capacities. The floppy diskette drive cable has one type of connector for a 5.25”...

  • Page 38: Using The Expansion Slots

    Using the Expansion Slots This mainboard has five 32-bit PCI expansion slots and one AMR slot. PCI Slots: The PCI slots can be used to install add-in cards that have the 32-bit PCI (Peripheral Components Interconnect) interface. AMR Slot: The AMR (Audio Modem Riser) slot is an industry standard slot that allows for the installation of a special audio/modem riser card.
  • Page 39 5. Install the edge connector of the add-in card into the expansion slot. Press down quite firmly so that you are sure that the edge connector is correctly seated in the slot. 6. Secure the metal bracket of the card in the empty slot in the system case with a screw.

  • Page 40: Add-In Card Options

    Add-in Card Options The mainboard has two features that can be used if you have installed either a fax/modem card or a network adapter card. WOL1: Wake on LAN If you have installed a network adapter (LAN adapter), you can use the cable provided with the card to plug into the WOL1 connector on the mainboard.

  • Page 41: Install Options And Extension Brackets

    Install Options and Extension Brackets This mainboard has a number of special connectors that allow you to add optional features to your system. You can install any of the following items: Fax/modem card option Infrared port Serial port extension bracket 24-bit digital audio extension bracket (SPDIF) TV-out extension bracket Fax/modem Card...
  • Page 42 Line and Tel Fax/modem RJ11 sockets card fax/modem connector Serial Port Extension Bracket If you want to have a second external serial port available in your computer case, you must install a serial port extension bracket. COM2 1. Locate the serial port connector COM2. Remove a blanking plate from a free expansion slot in the system chassis.
  • Page 43 Note: An IR port and a second serial port use the same resources, and they may use some of the resources required by a fax/modem card. If you have more than one of these items installed, you may not be able to use them at the same time. You can use the Peripherals page of the setup utility to switch resources between an IR port and a second serial port.
  • Page 44 Infrared Port This option can be purchased from third-party vendors. SIR1 1. Connect the cable from the optional IR port to the SIR1 connector on the mainboard. 2. After you have connected the cable, secure the optional IR port to the appropriate place on your system case.
  • Page 45 Digital Audio Extension Bracket You can purchase an optional 24-bit digital audio extension bracket from a third-party vendor. You can use the audio RCA jacks to connect to digital audio devices. If your CD-ROM/DVD drive has digital audio output, you can connect it to the input pins of the SPDIF connector. Audio Input Pins SPDIF...

  • Page 46: Make The External Connections

    Make the External Connections After you have installed the mainboard, make the connections to the external ports. PS2KBM LPT1 COM1 VGA1 USB1 1. PS2KBM is a stack of two PS/2 mini-DIN ports. The upper port can be used by a PS/2 mouse or pointing device. The lower port can be used by a PS/2 keyboard.

  • Page 47: External Connector Color Coding

    External Connector Color Coding To help identify the external connectors, many connectors now use standard colors as shown in the table below. Connector Color Analog VGA Blue Audio line in Light blue Audio line out Lime Digital monitor / flat panel White IEEE 1394 Grey...

  • Page 48: Chapter 3: Setup

    About the Setup Utility This chapter explains how to use and modify the BIOS setup utility that is stored on the mainboard. The setup utility stores data about the mainboard components and the configuration of devices that are connected to it. This information is used to test and initialize components at start-up time and to make sure everything runs properly when the system is operating.
  • Page 49 Some options (marked with a triangle) lead to tables of items that usually have a value on the right side. The value of the first item is highlighted, and you can use the cursor arrow keys to select any of the other values in the table of items.

  • Page 50: How To Flash A New Bios

    How to Flash a New BIOS You can install an updated BIOS for this motherboard that you can download from the manufacturer’s website. New BIOS may provide support for new peripherals, improvements in performance or fixes to address known bugs. Install a new BIOS as follows: 1.

  • Page 51: Standard Cmos Features Option

    9. In the opening dialog box, type in the filename of the new BIOS and follow the onscreen directions to flash the new BIOS to the motherboard. 10. When the installation is complete, remove the floppy diskette from the diskette drive and restart your computer. If your mainboard has a Flash BIOS jumper, don’t forget to reset the jumper to protect the newly installed BIOS from being overwritten.
  • Page 52 IDE HDD Auto-Detection Press Enter while this item is highlighted if you want the setup utility to automatically detect and configure a hard disk drive on the IDE channel. IDE Primary/Secondary Master/Slave If you leave this item at Auto, the system will automatically detect and configure any IDE devices it finds.

  • Page 53: Advanced Bios Features Setup Option

    Halt On Default: All Errors This item defines the operation of the system POST (Power On Self Test) routine. You can use this item to select which kind of errors in the POST are sufficient to halt the system. Base Memory, Extended Memory, Total Memory These items are automatically detected by the system at start up time.
  • Page 54 External Cache Default: Enabled Most processors that can be installed in this system use external (L2) cache memory to improve performance. The exceptions are older SEPP Celeron CPUs running at 266 or 300 MHz. Enable this item for all but these two processors. CPU L2 Cache ECC Checking Default: Enabled This item enables or disables ECC (Error Correction Code) error checking on the...

  • Page 55: Advanced Chipset Features Option

    Chassis Open Warning Default: Disabled Chassis has been Default: CLOSING If you have connected a chassis open circuit to the Chassis Open detect connector on the mainboard, use these items to enable or disable the feature and determine the setting of the feature. Typematic Rate Setting Default: Disabled If this item is enabled, you can use the following two items to set the typematic...
  • Page 56 SDRAM CAS latency Time Default: 3 SDRAM Cycle Time Tras/Trc Default: 6/8 SDRAM RAS-to-CAS Delay Default: 3 SDRAM RAS Precharge Time Default: 3 These four items set the timing and wait states for SDRAM memory. We recommend that you leave these items at the default value. System BIOS Cacheable Default: Enabled Video BIOS Cacheable...

  • Page 57: Integrated Peripherals Option

    Local Memory Frequency Default: 100 MHz On this mainboard, you can select a frequency for the memory bus that is different from the frequency of the FSB (front side bus) used by the processor. Use this item to select the frequency required by the memory modules that you install.
  • Page 58 IDE devices. You can choose Auto, to let the system auto detect which PIO mode is best, or you can install a PIO mode from 0-4. IDE Primary Master UDMA Default: Auto IDE Primary Slave UDMA Default: Auto IDE Secondary Master UDMA Default: Auto IDE Secondary Slave UDMA Default: Auto...
  • Page 59 Power On Function Default: Hot KEY KB Power ON Password Default: Enter Hot Key Power ON Default: Ctrl-F12 The Power On Function item allows you to power on the system by pressing hot- keys, or typing a password. If you choose Password, you can use the item KB Power On Password to install a power on password.

  • Page 60: Power Management Setup Option

    Game Port Address Default: 201 This item lets you disable the built-in game port, or enable it by assigning an I/O address. Midi Port Address Default: 330 Midi Port IRQ Default: 10 This item lets you disable the built-in MIDI port, or enable it by assigning an I/O address.
  • Page 61 ACPI Function Default: Enabled This mainboard supports ACPI (Advanced Configuration and Power management Interface). Use this item to enable or disable the ACPI feature. ACPI Suspend Type Default: S1 (POS) Use this item to define how your system suspends. In the default, S1(POS), the suspend mode is equivalent to a software power down.
  • Page 62 Modem Use IRQ Default: 3 If you want an incoming call on a modem to automatically resume the system from a power-saving mode, use this item to specify the interrupt request line (IRQ) that is used by the modem. You might have to connect the fax/modem to a mainboard Wake On Modem connector for this feature to work.

  • Page 63: Pnp/Pci Configuration Option

    Primary IDE 0 Default: Disabled Primary IDE 1 Default: Disabled Secondary IDE 0 Default: Disabled Secondary IDE 1 Default: Disabled When these items are enabled, the system will restart the power-saving timeout counters when any activity is detected on any of the drives or devices on the primary or secondary IDE channels.

  • Page 64: Pci Health Status Option

    Resources Controlled By Default: Auto(ESCD) You should leave this item at the default Auto(ESCD). Under this setting, the system dynamically allocates resources to plug and play devices as they are required. If you cannot get a legacy ISA (Industry Standard Architecture) expansion card to work properly, you might be able to solve the problem by changing this item to Manual, and then opening up the IRQ Resources and Memory Resources sub-menus.

  • Page 65: Frequency / Voltage Control Option

    Frequency / Voltage Control Option This item allows you to set the clock speed and system bus for your system. The clock speed and system bus are determined by the kind of processor you have installed in your system. Auto Detect DIMM/PCI Clk Default: Enabled When this item is enabled, the BIOS will disable the clock generator signal for unused DIMM and PCI slots.

  • Page 66: Load Fail-Safe Defaults Option

    Load Fail-Safe Defaults Option This option opens a dialog box that lets you install fail-safe defaults for all appropriate items in the whole setup utility. Press the Y key and then Enter to install the defaults. Press the N key and then Enter to not install the defaults.

  • Page 67: Save And Exit Setup Option

    press Enter, or just press Enter if you are deleting a password that is already installed. 5. If you typed the password correctly, the password will be installed. Save And Exit Setup Option Highlight this item and press Enter to save the changes that you have made in the setup utility and exit the setup program.

  • Page 68: Chapter 4: Software

    The folder for this mainboard is stored in the MS7012D folder. Note: Never try to install software from a folder that is not specified for use with your mainboard.
  • Page 69 Intel chipsets under Windows 95/98. q VGA: This folder has drivers and software for the graphics system built into the Intel 810 chipset. MS7012D Folder You can use the software in the following sub-folders: q MONITOR : Hardware monitoring software for Windows 95/98, and Windows NT4.0/5.0...

  • Page 70: Running The Support Cd-Rom

    Running the Support CD-ROM 1. Place the disk in your CD-ROM drive. If you are running Windows with Autoplay enabled, the opening screen of the CD appears automatically. Click on READ ME to read the latest instructions. 2. Click on the item BROWSE THE CD TITLE. This uses Windows Explorer to show the contents of the support CD.

  • Page 71: Cmi8X38 Folder Installation Notes

    PC-Cillin Anti-Virus Utility Anti-virus software is provided for DOS, for WIN95, and WIN 98. Log on to the appropriate directory for your operating system. For DOS, copy all the files in the DOS folder to your hard disk drive. For Windows 95, log on to the Disk 1 folder and run SETUP.

  • Page 72: Modem Driver And Software

    Modem Driver and Software Install the Modem driver from the sub-folders for Windows 95/98 or Windows NT4.0. Windows 95/98 The modem is a plug and play device so Windows 95/98 will automatically detect the presence of your modem. When the Plug and Play wizard begins to look for modem drivers, click on the button that says Have Disk and then browse or type in the pathname to the CMI8x58\modem\win9x folder.

  • Page 73: Mainboard (Ms7012D) Installation Notes

    Mainboard (MS7012D) Installation Notes Most of the sub-folders in this folder are empty, with a short README file giving directions to alternate folders for the appropriate software. One folder contains software that you can install. Monitor Sub-folder The software in this folder provides a graphical interface to the hardware monitoring feature of this mainboard.

  • Page 74: Appendix 1: Quick Jumper Setting Reference

    Appendix 1: Quick Jumper Setting Reference JP1: Clear CMOS memory jumper Use this 3-pin jumper top clear all the current data stored in the CMOS memory. Function Jumper Cap 1 2 3 Normal operation Short pins 1-2 Clear CMOS Short pins 2-3 JP2: Keyboard power on jumper Use this 3-pin jumper to enable keyboard power on with hot keys or password.
  • Page 75 JP9: Set System bus frequency jumper (133 MHz) Use this jumper to set the system bus frequency at auto-detect, or fixed at 133 MHz. Function Jumper Cap 1 2 3 Normal Short Pins 1-2 Force 133 MHz Short pins 2-3 JP11: Set TV-out format jumper Use this jumper to select the format of the TV-out connector.
  • Page 76 Panel Connector The mainboard PANEL1 connector has a standard set of switch and indicator connectors that are commonly found on ATX system cases. Use the illustration below to make the correct connections to the case switches and indicators. PANEL1 Function Pins Power SW 22-23 Power Indicator...
