The information presented in this publication has been
carefully checked for reliability; however, no responsibility
is assumed for inaccuracies. Specifications are subject to
change without notice.
Trademarks
IBM, PC/AT, and PC/XT are trademarks of International
Business Machines Corporation.
®
Intel and Pentium
II are trademarks of Intel
Corporation.
AMI is a trademark of American Megatrends Inc.
MS-DOS and WINDOWS 95/98/NT are registered
trademarks of Microsoft Corporation.
Sound Blaster and SB-Link are trademarks of Creative
Technology Ltd.
PC-cillin and ChipAwayVirus are trademarks of Trend
Micro, Inc.
Copyright (C) 1999.
All Rights Reserved.
MS7080SG, Version 1.2
I6X/January 1999
Advertisement
Table of Contents
Related Manuals for MATSONIC MS7080SG
Summary of Contents for MATSONIC MS7080SG
- Page 1 MS-DOS and WINDOWS 95/98/NT are registered trademarks of Microsoft Corporation. Sound Blaster and SB-Link are trademarks of Creative Technology Ltd. PC-cillin and ChipAwayVirus are trademarks of Trend Micro, Inc. Copyright (C) 1999. All Rights Reserved. MS7080SG, Version 1.2 I6X/January 1999...
-
Page 2: Table Of Contents
Contents Chapter 1: Introduction ..............1 Key Features ................... 2 Unpacking the Mainboard & Static Electricity Precautions..5 Chapter 2: Hardware Configuration ..........6 Mainboard Component Locations ..........7 CPU Installation ................8 Installation Procedures............9 CPU Speed Setting ..............11 Memory Installation.............. - Page 3 J7 – SPDIF OUT Signal Level Selector......22 J8 – Internal SPDIF IN Connector......... 22 Notice for PCI Sound Application........23 The Four Speakers System ........... 24 Chapter 3: BIOS Setup ..............27 Entering BIOS Setup ..............28 Default ................... 28 Load Optimal Settings ............
-
Page 5: Chapter 1 Introduction
Chapter 1 Introduction This mainboard is an Intel 440BX 100MHz highly integrated high-performance mainboard based on the advanced Pentium® II microprocessor and provides CPU Plug and Play feature for faster and easier CPU installation. The mainboard features with highly flexible configurations and is fully IBM PC/AT compatible. -
Page 6: Key Features
Chapter 1 Key Features The advanced features of the mainboard include: Intel 440BX AGP chipset: — supports Pentium® II 233~500MHz and Celeron 266~433MHz CPUs — supports both 66.6MHz and 100MHz FSB (Front Side Bus) — provides CPU Plug and Play feature for faster and easier CPU installation Memory: —... - Page 7 Introduction Onboard DC-DC Step Down Regulator: — complies with Intel VRM V8.2 specification Onboard 64-bit 3D AGP Graphics Accelerator, — supports AGP Ver1.0 specification (x1 or x2) — provides 8MB frame buffer — high resolution graphic modes up to 1600x1200 Onboard CMI 8338 PCI Sound, —...
- Page 8 Chapter 1 BIOS: — Onboard 2M Flash ROM supports complete ACPI and Legacy PMU and is fully compatible with PC'97 and PC'98 — provides Plug & Play function which detects the peripheral devices and expansion cards automatically — supports Trend’s ChipAwayVirus option to ensure the entire boot process is virus free, no installation and configuration necessary Bundled:...
-
Page 9: Unpacking The Mainboard & Static Electricity Precautions
Introduction Unpacking the Mainboard & Static Electricity Precautions This Mainboard package contains the following items: 1. This Mainboard and the Device Driver 2. The Slot1 Holder and AT cables 3. This User’s Guide and COM2 cable/bracket 4. Internal SPDIF/IN cable (optional) 5. -
Page 10: Chapter 2 Hardware Configuration
Chapter 2 Hardware Configuration Before you install the mainboard into the system chassis, you may find it convenient to first configure the mainboard’s hardware. This chapter describes how to set jumpers and install memory modules, and where to attach components, however, the CMOS jumper is set on “Clear”... -
Page 11: Mainboard Component Locations
Hardware Configuration Mainboard Component Locations Line in COM1 Line out /Rear PS/2-KBD USB ( B ) USB ( T ) PS/2-Mouse Sound LPT1 Game FDC1 COM2 Chipset Chipset Battery SECONDRY PRIMARY Figure 2-1. Mainboard Component Locations... -
Page 12: Cpu Installation
Chapter 2 CPU Installation This mainboard supports Intel Pentium® II CPU by a Single Edge Contact(SEC) slot and a retention clip set which is fit for 3 different mechanical types of Intel CPU (SEPP, SECC and SECC2). The following drawing shows the retention clip set. -
Page 13: Installation Procedures
Hardware Configuration Installation Procedures Follow the following steps in order to install your intel Pentium® II properly. Step 1: Make sure that the mainboard is set in the same direction as the following drawing before installing. Sound Chipset Chipset... - Page 14 Chapter 2 Step 2: There is one set of Slot1 retention Holder which was installed on your motherboard. The two chutes of the retention Holder are screwed in. Lift up both chutes as shown in the drawing. Step 3: Flatten the two latches on the side of the CPU. Insert CPU into the retention Holder.
-
Page 15: Cpu Speed Setting
Hardware Configuration Step 4: After installing CPU card into the retention Holder, push the retention locker downward to secure the CPU card as indicated in the following 2 drawings. CPU Speed Setting This mainboard provides CPU Plug and Play technology, so that there is no need to set the CPU jumper. -
Page 16: Memory Installation
Chapter 2 Memory Installation The mainboard allows you to have up to 768MB of memory through 3 DIMM sockets on the board, Bank 0, Bank 1, and Bank 2. They support the following memory configurations. Bank Memory Module Bank 0 DIMM1 4MB, 8MB, 16MB, 32MB, 64MB, 128MB, 256MB Bank 1... -
Page 17: Jumper Settings
Hardware Setup Jumper Settings RTC – CMOS RAM Clear Selector The battery on this mainboard is designed to retain system configuration in CMOS RAM. In order to save the battery, the jumper is set on “Clear CMOS” position when this board is shipped; therefore, you need to set this jumper to “Normal”... -
Page 18: Atx Functions & Connectors
Chapter 2 ATX Functions & Connectors This mainboard supports ATX power and ACPIspec. The ATX functions and connectors are described below, and which work with ATX power supply. Software Power-Off Follow the steps below for the “Software Power-Off Control” function in Windows 95/98. 1. -
Page 19: Modem Ring Power-On
Hardware Setup LAN/Modem Ring Power-On While in Soft-off/Suspend state, if an external LAN/ modem ring-up signal occurs, the system will wake up and be remotely accessed. Please refer to the BIOS Setup section. Alarm Wake Up If you want to autoboot the system at a certain time, set the RTC Alarm time. -
Page 20: J11 (21, 22) (Pwrbt) Ð Power Button And Suspend Switch Connector
Chapter 2 J11 (21, 22) (PWRBT) – Power Button and Suspend Switch Connector Attach the ATX Power Button cable to this connector. In the AT power system, this connector will act as a suspend switch; and in the ATX power system, this connector will be not only an ATX power button but a Suspend switch as well. -
Page 21: External Connectors Loctaion
Hardware Setup External Connectors Loctaion Chipset Chipset Chip Sound Parallel (printer) port (25-pin Female) Game (15-pin Female) PS/2 Mouse (6-pin Female) PS/2 Keyboard (6-pin Female) COM1 Serial Port Side View J4 – Floppy Disk Drive Connector Primary/Secondary – IDE Port Connectors COM2 –... -
Page 22: J12, J14 - Cpu, Sys Fan Power Connectors
Chapter 2 J5 – Infrared Connector The mainboard provides a 6-pin Infrared connector for infrared devices. You must configure the setting for infrare d device through the Peripheral Setup in BIOS Setup section. J12/J14 – Cooling Fan Connectors Connect CPU/chassis fan cables to these connectors. Sound Sensor +12V... -
Page 23: Case Connectors: J11
Hardware Setup Case Connectors: J11 This connector contains: Speaker, Power LED, Keylock, Suspend LED, HDD LED, Reset Switch, and Power Button. Please refer to the following drawing for the locations on the mainboard. Sound pin1, 3, 5, 7 – Speaker pin2, 4, 6 –... -
Page 24: J11 (1, 3, 5, 7) (Spk) - Speaker Connector
Chapter 2 J11 (1, 3, 5, 7) (SPK) – Speaker Connector Description N.C. Ground Data Out J11 (13, 14) (SP-LED) – Suspend LED Connector Description 13 (+) Active High 14 (–) Ground J11 (15, 16) (HD-LED) – HDD LED Connector Description 15 (+) 16 (–) -
Page 25: Onboard Pci Sound
Hardware Configuration Onboard PCI Sound J9/J10 – Analog Audio from CD-ROM Connectors Connect “AUDIO” output of the CD-ROM driver to these connectors. Panasonic compatible CD-ROM should connect to J10 (pin signals assignment is G-L-G-R), Sony compatible CD-ROM shouldconnect to J9 (pin signals assignment is L-G-G-R). -
Page 26: J16 - Digital Audio Connector
Chapter 2 J16 – Digital Audio Connector Connect this connector to the Digital Audio ribbon cable/ bracket that contains 3 jacks for Aux IN, SPDIF IN and SPDIF OUT device. Aux IN is used for the second Line-in port. SPDIF IN is used for input the external digital audio. Connect SPDIF OUT to the AC3 Audio Amplifier or Mini- Disk to play, and set the following jumper to select 5V or 0.5V signal level for used device. -
Page 27: Notice For Pci Sound Application
Hardware Configuration Notice for PCI Sound application 1. Before you install PCI Sound drivers, make sure your operating system has already been installed. Otherwise the PCI Sound might be detect as "Other Device" by the device manager. 2. After the drivers installed, if you wants to use Software Wave-Table drivers as MIDI output device. -
Page 28: The Four Speakers System
Chapter 2 The Four Speakers System Onboard Sound provides 2 wave channels (front/rear), known as the 4 speakers system. When application programs via DirectSound® 3D or A3D® interface locate the sound sources to the listener's back, the two rear speakers will work to enhance the rear audio positional effect, so as to complement the insufficiency of using only two front speakers to emulate the audio effect. - Page 29 Hardware Configuration (Sound Port) Line-in/Rear Rear Speakers Speaker Speaker Monitor Speaker Speaker Front Speakers A picture on the 4 speakers application JP2 - Onboard Sound Selector Set this jumper to disable the onboard Sound. Sound Description Chipset Enabled Chipset (default) Disabled...
-
Page 31: Chapter 3 Bios Setup
Chapter 3 BIOS Setup This chapter explains how to configure the mainboard’s BIOS setup. The BIOS setup is from AMI. After you have configured the mainboard and assembled the components, turn on the computer and run the software setup to ensure that the system information is correct. -
Page 32: Entering Bios Setup
Chapter 3 Entering BIOS Setup To enter the BIOS Setup program: 1. Turn on or reboot the system. A screen appears with a series of diagnostic checks. 2. When “Hit <DEL> if you want to run SETUP” appears, press the <DEL> key to enter into the BIOS setup program. -
Page 33: Setup Items
BIOS Setup Setup Items Standard CMOS Setup Choosing the item from the BIOS Setup main menu. All Standard Setup options are described in this section. AMIBIOS SETUP - STANDARD CMOS SETUP (C)1998 American Megatrends, Inc. All Rights Reserved Date (mm:dd:yy) : Sat Oct 17, 1998 Time (hh:mm:ss) : 00:32:28 32Bit... - Page 34 Chapter 3 Floppy Drive Choose Floppy Drive A or B icon to specify A; B floppy drive type. The settings are 360KB ", 1.2MB 5 ", 720KB 3 ", 1.44MB 3 ", or 2.88MB 3 ".
-
Page 35: Advanced Cmos Setup
BIOS Setup Advanced CMOS Setup Choosing the item from the BIOS Setup main menu. All Advanced Setup options are described in this section. AMIBIOS SETUP - ADVANCED CMOS SETUP (C)1998 American Megatrends, Inc. All Rights Reserved Quick Boot Disabled DC00,16K Shadow Disabled 1st Boot Device Floppy... - Page 36 Chapter 3 Floppy Drive Seek Choose Enabled or Disabled. Disabled provides a faster boot and reduces the possibility of damaging the heads. PS/2 Mouse Support When this option is set to Enabled, BIOS supports a PS/2-type mouse. Password Check This option specifies the type of BIOS password protection that is implemented.
-
Page 37: Advanced Chipset Setup
BIOS Setup Advanced Chipset Setup Choose the item from the BIOS Setup main menu. All Chipset Setup options are displayed and are described in the following section: AMIBIOS SETUP - ADVANCED CHIPSET SETUP (C)1998 American Megatrends, Inc. All Rights Reserved Trend ChipAway Virus Enabled 16bit I/O Recovery Time... - Page 38 Chapter 3 EDO RASx, CASx These two options are designed to select the Wait State proper Wait State for EDO RASx, and CASx, and these options only support the 66MHz- base system. DRAM Integrity Choose Non-ECC, EC-Only, or ECC. Mode Non-ECC: Has byte-wise write capability but no provision for protecting data integrity in the DRAM...
- Page 39 BIOS Setup USB Function Set this option to enable the system BIOS USB (Universal serial Bus) functions. USB Legacy Choose Enabled or Disabled. Set this option Support to enable the passive release on the USB (Universal Serial Bus).
-
Page 40: Power Management Setup
Chapter 3 Power Management Setup Choosing the item from BIOS Setup main menu. AMIBIOS SETUP - POWER MANAGEMENT SETUP (C)1998 American Megatrends, Inc. All Rights Reserved Power Management/APM Enabled K/B Resume From OFF Disabled Monitor Power State Stand By Mouse Resume From OFF Disabled Video Power Down Disabled... - Page 41 BIOS Setup Hard Disk Power This option specifies the power Down conserving state that the hard disk drive enters after the specified period of hard drive inactivity has expired. Hard Disk/Standby These options specified the length of hard Time out(Minute) disk/system inactivity while in Full power on state.
- Page 42 Chapter 3 K/B Resume From Set these options to enable the signals OFF; of Keyboard/Mouse/Modem Ring/LAN Mouse Resume From to wake up the system from the Soft- OFF; Off. Ring Resume From OFF; LAN Resume From RTC Resume From Set this option to enable RTC Alarm to wake up the system which is in Soft Off.
-
Page 43: Pci/Plug And Play Setup
BIOS Setup PCI/Plug and Play Setup Choose the item from the BIOS Setup main menu. AMIBIOS SETUP - PCI / PLUG AND PLAY SETUP (C)1998 American Megatrends, Inc. All Rights Reserved Plug and Play Aware O/S IRQ14 PCI/PnP Clear NVRAM IRQ15 PCI/PnP Primary Graphics Adapter... - Page 44 Chapter 3 OffBoard PCI Use this option only if an offboard PCI IDE IDE Card controller adapter card is installed in the computer. You must specify the PCI expansion slot on the motherboard where the offboard PCI IDE controller is installed. If an offboard PCI IDE controller is used, the onboard IDE controller is automatically disabled.
-
Page 45: Peripheral Setup
BIOS Setup Peripheral Setup Choose the item from the BIOS Setup main menu. AMIBIOS SETUP - PERIPHERAL SETUP (C)1998 American Megatrends, Inc. All Rights Reserved OnBoard FDC Auto OnBoard Serial Port1 Auto OnBoard Serial Port2 Auto Serial Port2 Mode Normal RxD, TxD Active IR Transmit Delay OnBoard Parallel Port... - Page 46 Chapter 3 OnBoard Parallel This option specifies the base I/O port address Port Channel of the parallel port on the motherboard. Parallel Port Mode Depends on the type of your external device which connects to this port to choose Normal, EPP, or ECP mode.
-
Page 47: Cpu Plug And Play Setup
BIOS Setup CPU Plug and Play Setup Choose this item from the BIOS Setup main menu. AMIBIOS SETUP - CPU PLUG AND PLAY SETUP (C)1998 American Megatrends, Inc. All Rights Reserved CPU Plug & Play Auto CPU Frequency Selection 100 Mhz CPU Speed Selection (Mhz) 300(100x3) **System Hardware Monitor**... -
Page 48: Change Supervisor Password
Chapter 3 Change Supervisor Password This item allows you to set the system password which is required every time when an attempt is made to enter the Setup program. The password cannot be longer than six characters. If you want to disable the password which has already been set, please follow the steps as follows: 1. -
Page 49: Chapter 4 Software Driver
Chapter 4 Software Driver The support software CD-ROM came with the package is free of charge. It includes all our products’ drivers. Please first go to the CD-ROM to view "readme.txt" for each software program location.
