MATSONIC MS-7090S Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Important Information

Copyright
This publication, including all photographs, illustrations and software, is protected
under international copyright laws, with all rights reserved. Neither this manual, nor
any of the material contained herein, may be reproduced without the express written
consent of the manufacturer.
Disclaimer
The information in this document is subject to change without notice. The
manufacturer makes no representations or warranties with respect to the contents
hereof and specifically disclaims any implied warranties of merchantability or fitness
for any particular purpose. Further, the manufacturer reserves the right to revise this
publication and to make changes from time to time in the content hereof without
obligation of the manufacturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Celeron are a registered trademarks of Intel Corporation.
VGA, OS/2, PS/2 are registered trademarks of International Business Machines.
AMD, K5, K6 are registered trademarks of Advanced Micro Devices Inc.
Cyrix, M1 are registered trademarks of Cyrix Corporation.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Version 1.0

Advertisement

Table of Contents
loading

Related Manuals for MATSONIC MS-7090S

Summary of Contents for MATSONIC MS-7090S

  • Page 1: Important Information

    Important Information Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the manufacturer. Disclaimer The information in this document is subject to change without notice.

  • Page 2: Canadian Department Of Communications

    Safety Compliance Federal Communications Commission (FCC) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 3: Table Of Contents

    Chapter 1: Introduction Welcome ..............1 About the Manual............1 Checklist ..............2 Features ..............2 Chapter 2: Installation Before You Begin............5 Mainboard Guide....

  • Page 4: Chapter 1: Introduction

    Welcome Congratulations on your purchase of the MS-7090S mainboard. The MS-7090S mainboard is a micro-ATX board measuring 243.8 mm by 200 mm and using a 4-layer printed circuit board. This board features a PGA370 ZIF (Zero Insertion Force) processor socket. This socket can be installed with the latest generation of Intel Celeron processors that are packaged in a Plastic Pin Grid Array (PPGA), just like the original Pentium processors.

  • Page 5: Checklist

    Compare the contents of your mainboard package with the standard checklist below. If any item is missing or appears damaged, please contact the vendor of your mainboard package. Standard Items ü 1 x MS-7090S Mainboard ü 1 x Cable/Bracket Pack Diskette drive ribbon cable IDE drive ribbon cable ü...
  • Page 6 with 16 MB up to 128 MB of memory, and can be single-sided or double sided. However, total installed memory must not exceed 256 MB. If you install a double- sided module in either DIMM 2 or DIMM 3, you cannot install any memory module in the other socket.
  • Page 7 Hardware Monitoring This mainboard features hardware monitoring supported by the GL520SM system monitor chip. Using the system BIOS, system administrators can track critical hardware parameters such as CPU temperature and cooling fan speeds. Limits can be set to ensure system power management prevents threshold temperatures and parameters from being exceeded.

  • Page 8: Chapter 2: Installation

    Some features on the mainboard are implemented by cabling connectors on the mainboard to indicators and switches on the system case. Ensure that your case supports all the features required. The MS-7090S mainboard can support one or two floppy diskette drives and four enhanced IDE drives. Ensure that your case has sufficient power and space for all the drives that you intend to install.

  • Page 9: Mainboard Guide

    Mainboard Guide Use the following illustration and key to identify the components on your mainboard. CPU FAN1 DIMM2 DIMM1 DIMM3 ATX1 SOCKET PGA 370 FDD1 IDE2 IDE1 AGP1 SIR1 CASE FAN1 CD-IN SB LINK1 PCI2 WOL1 PCI1 SPDIF PANEL1 PCI3 ISA1 WOM1 Key to Mainboard Components...

  • Page 10: Preparing The Mainboard

    WOM1 Connector for modem wake up WOL1 Connector for LAN wake up SPDIF SPDIF In/out connector (professional 24-bit digital audio interface) SB LINK1 SB-Link connector for optional PCI Sound Blaster audio card CD-IN Audio connector for optional CD-ROM drive Clear CMOS memory jumper Keyboard power on jumper Audio enable/disable jumper Set SPDIF output signal level jumper...

  • Page 11: Install The Processor

    Install the Processor This mainboard is installed with a PGA370 ZIF processor socket. This socket will only support the PPGA Celeron processor. Do not try to insert a socket-7 processor such as a Pentium or Pentium-compatible processor. The Celeron processors all run over a 66 MHz system bus and have internal clock speeds ranging from 300 to 400 MHz.

  • Page 12: Install The Memory Modules

    Swing the locking lever down and hook it under the latch on the side of the socket to lock it in place. Locate the power connector for the processor cooling fan CPU FAN1. If your processor has a cooling fan installed, connect the cable from the cooling fan to CPU FAN1.
  • Page 13 The DIMM sockets are keyed with notches and the DIMMs are keyed with cut- outs so that they can only be installed correctly. Check that the cut-outs on the DIMM module edge connector matches the notches in the DIMM socket. Push the latches on each side of the DIMM socket down.
  • Page 14 JP2: Keyboard Power On Jumper This jumper lets you use a typed-in password as a power switch to turn your system on. If you enable this property, you need to define the password or the hot keys using the setup utility. See Chapter 3 for more information. Function Jumper Cap Enable keyboard...

  • Page 15: Install The Mainboard In The System Case

    JP5: Set SPDIF Output Signal Level Jumper If you use the SPDIF Input/Output connector (SPDIF), you can use this jumper to set the level of the output signal to either 5 volts or 0.5 volts. Function Jumper Cap 5 volts Short pins 1-2 0.5 volts Open pins 1-2...
  • Page 16 FDD1 IDE1 IDE2 Locate the power connector ATX1. Connect the power cable from the power supply unit to ATX1. The connector is keyed so that it can only be installed correctly. If your system case has a built-in cooling fan, you can supply power to the fan from the case fan power connector CASE FAN1.
  • Page 17 Locate the bank of switch and indicator connectors PANEL1. These connectors provide control functions to your system case. Use the table below to make the connections. 22 21 Function Pins Power SW Speaker 1, 3, 5, +7 Suspend SW Reset SW Power Indicator +2, +4, 6 HDD LED...
  • Page 18 CD-IN SB LINK1 SPDIF Locate the three 32-bit PCI expansion slots, the 8/16 bit ISA expansion slot, and the AGP graphics adapter slot. Install optional 32-bit PCI cards into the PCI slots. Install an optional 8/16-bit card into the ISA slot. The ISA slot is shared with the the PCI3 slot just above it.
  • Page 19 Part Two – External Connections After you have installed the mainboard and completed the internal connections, you can use the external connectors to attach peripheral devices to your system. LPT1 PS2KBM1 USB1 COM1 COM2 PS2KBM1 is a stack of two PS/2 mini-DIN ports. The upper port can be used by a PS/2 mouse or pointing device.

  • Page 20: Chapter 3: Setup

    About the Setup Utility This chapter explains how to use and modify the BIOS setup utility that is stored on the mainboard. The setup utility stores information about the mainboard components, and the configuration of other devices that are connected to it. The system uses this information to test and initialize components when it is started up, and to make sure everything runs properly when the system is operating.
  • Page 21 Some options lead to tables of items. These items usually have a value on the right side. The value of the first item is highlighted, and you can use the cursor arrow keys to select any of the other values in the table of items. When an item is highlighted, you can change the value by pressing the PageUp or PageDown keys, or the Plus or Minus keys.

  • Page 22: Standard Cmos Setup Option

    Standard CMOS Setup Option This option displays a table of items which defines basic information about your system. Date and Time The Date and Time items show the current date and time held by your computer. If you are running a Windows operating system, these items will automatically be updated whenever you make changes to the Windows Date and Time Properties utility.

  • Page 23: Bios Feature Setup Option

    Floppy 3 Mode Support Default: Disabled Floppy 3 mode refers to a 3.5” diskette with a capacity of 1.2 MB. Floppy 3 mode is sometimes used in Japan. Video Default: EGA/VGA This item defines the video mode of the system. This mainboard has a built-in VGA graphics system so you must leave this item at the default value.
  • Page 24 External Cache Default: Enabled All the Celeron processors that can be installed in this mainboard use external (level 2) cache memory to improve performance. Leave this item at the default value Enabled for better performance. Quick Power On Self Test Default: Enabled You can enable this item to shorten the power on testing and have your system start up a little faster.

  • Page 25: Chipset Features Option

    XXXXX-XXXXX Shadow Default: Disabled These items allow the BIOS of other devices to be copied to system memory for faster performance. Chipset Features Option This option displays a table of items that define critical timing parameters of the mainboard components including the CPU, the memory, and the system logic. As a general rule, you should leave the items on this page at their default values unless you are very familiar with the technical specifications of your system hardware.
  • Page 26 CPU-To-PCI IDE Posting Default: Enabled If you enable this item, the system will use a fast buffer for posting writes to memory. This allows release of the CPU before completion of the write cycle. System BIOS Cacheable Default: Enabled This item allows the system BIOS to be cached for faster performance. We recommend that you leave this item at the default value Enabled.

  • Page 27: Power Management Setup Option

    Current CPU Temperature, Current System Temperature, Current CPUFAN1 Speed, etc. If you are using the hardware monitoring features of this system, you can use these items to set thermal parameters for the system. Power Management Setup Option This option displays a table of items which lets you control the power management of the system.
  • Page 28 Power Management Default: Disabled This item acts like a master switch for the power-saving modes and hard disk timeouts. If this item is set to Max Saving, doze, standby, and suspend mode, will occur after a timeout of 10 seconds. If this item is set to Min Saving, doze, standby, and suspend mode will occur after a timeout of 4 hours.
  • Page 29 Soft-Off by PWR-BTTN Default: Instant-Off Under ACPI (advanced configuration and power interface) the system can be turned off mechanically (by the power button) or it can undergo a software power off. If the system has been turned off by software, the system can be resumed by a LAN, MODEM or ALARM wake up signal.

  • Page 30: Pnp/Pci Configuration Option

    PNP/PCI Configuration Option This option displays a table of items that configures how PNP (Plug and Play) and PCI expansion cards operate in your system. If you have not installed PCI cards in the expansion slots, you do not need to make any changes to this option. PNP OS Installed Default: No If you have installed a Plug and Play operating system such as Windows 95 or 98, you can...

  • Page 31: Load Bios Defaults Option

    secondary channels. Leave this item at the default value unless you have disabled the onboard IDE channels and are using an ISA bus IDE card. Assign IRQ For USB Default: Enabled When this item is enabled, the system can assign an IRQ to devices connected on the USB port.
  • Page 32 IDE HDD Block Mode Default: Enabled Block mode transfers can improve the access to IDE devices. Enable this item if your IDE devices support block mode transfers. IDE Primary Master PIO Default: Auto IDE Primary Slave PIO Default: Auto IDE Secondary Master PIO Default: Auto IDE Secondary Slave PIO Default: Auto...
  • Page 33 Init Display First Default: PCI Slot Use this item to define if your graphics adapter is installed in one of the PCI slots, or if you have installed an AGP graphics adapter into the AGP slot. Power On Function Default: Hot Key KB Power ON Password Default: Enter Hot Key Power ON...

  • Page 34: Password Settings

    Password Settings This item can be used to install a password. To install a password, follow these steps: Highlight the item Password Settings on the main menu and press Enter. The password dialog box will appear. If you are installing a new password, carefully type in the password. You cannot use more than 8 characters or numbers.

  • Page 35: Chapter 4: Software

    You can install the software that is stored in the UTILITY folder and the software that is stored in the MS-7090S folder. The folder CMI8338 contains audio drivers and software for mainboards which use the Elite PCI Audio-CMI8338 audio chip, as this mainboard does.

  • Page 36: Utility Installation Notes

    Some software may be installed in separate folders for different operating systems, such as DOS, WIN NT, WIN95/98, and so on. Always log on to the correct folder for the kind of operating system you are using. Utility Installation Notes Award Flash Memory Utility This utility lets you erase the system BIOS that is stored on the system motherboard on a Flash Memory chip, and lets you write a new or updated BIOS onto the chip.

  • Page 37: Mainboard Folder Installation Guide

    Mainboard Folder Installation Guide Place the support disk in your CD-ROM drive. If you are running Windows with Autoplay enabled, the opening screen of the support CD should appear automatically. Click on the item READ ME and read the latest instructions. Click on the item BROWSE THE CD TITLE.

  • Page 38: Cmi8338 Audio Folder Installation Guide

    Next, the "Select OEM Option" dialog box will appear; select "PIIX/PIIX4 Bus Master EIDE/ATAPI" and click "OK." Next, the "Select SCSI Adapter Option" dialog box will appear; click on the "Install" button in the dialog box. If installation is successful, the "SCSI Adapter Setup"...
  • Page 39 Select item "Unlisted or Updated Driver" in "List of Drivers" list box. Specify the path to the PCI audio NT drivers. Select "C-Media CMI8338 PCI Device" and press the "OK" button. Choose proper I/O or the "OK" button for the default setting. 10.

  • Page 40: Appendix

    Appendix 1: Quick Jumper Setting Reference JP1: Clear CMOS memory jumper Use this 3-pin jumper top clear all the current data stored in the CMOS memory. Function Jumper Cap Normal operation Short pins 1-2 Clear CMOS Short pins 2-3 JP2: Keyboard power on jumper Use this 3-pin jumper to enable keyboard power on with hot keys or password.
