  • Page 1 MediaRing Talk is a registered trademark of MediaRing Inc. WordPerfect is a registered trademark of Corel Corporation Ltd. Other names used in this publication may be trademarks and are acknowledged. Copyright © 1999 All Rights Reserved MS7381SGM, V1.2 S6T/Aug 1999...

  • Page 2: Federal Communications Commission (Fcc)

    Federal Communications Commission (FCC) Federal Communications Commission (FCC) Federal Communications Commission (FCC) Federal Communications Commission (FCC) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 Table of Contents Chapter 1 Introduction............1 Chapter 2 Mainboard Installation........7...
  • Page 4 !     Chapter 3 BIOS Setup ............27 Chapter 4 Software & Applications ........39...
  • Page 5 !     Appendix A: Corel WordPerfect Suite 8 ......A1 Appendix B: Gamut ............B1...
  • Page 6 Chapter 1 Introduction            ...
  • Page 7 !     Key Features Slot-1 Processor Support Socket-370 Processor Support Memory Support Expansion Slots Onboard IDE channels Power Supply and Power Management...
  • Page 8 !     Built-in Graphics System Sound System Onboard I/O Ports...
  • Page 9 !     Hardware Monitoring Fax/Modem DAA Module Onboard Flash ROM Bundled Software Dimensions...
  • Page 10 !     Package Contents Optional Accessories...

  • Page 11: Static Electricity Precautions

    !     Static Electricity Precautions...

  • Page 12: Mainboard Installation

    Chapter 2 Mainboard Installation Note:...
  • Page 13 !     Mainboard Components Note:...

  • Page 14: Install The Processor

    !     Install the Processor                Processor Clock Rate Processor System Bus Cartridge Socket Pentium-III Slot-1 Pentium-III Slot-1 Pentium-III Slot-1 Pentium-III Slot-1 Pentium-II Slot-1 Pentium-II Slot-1 Pentium-II Slot-1 Pentium-II Slot-1 Pentium-II Slot-1 Pentium-II Slot-1 Pentium-II Slot-1 SEPP Celeron Slot-1 SEPP Celeron...

  • Page 15: Installing A Slot-1 Processor Cartridge

    !     Installing a Slot-1 Processor Cartridge FAN1 Slot-1 with pre-installed cartridge holder. The upright arms are folded down for shipping.

  • Page 16: Installing A Socket-370 Processor

    !     Selects a Socket- Selects a Slot-1 370 processor processor Installing a Socket-370 Processor Socket-370 Pin-1 Corner FAN1...

  • Page 17: Install Memory

    !     Selects a Socket-370 Selects a Slot-1 processor processor Install Memory DIMM1 DIMM2 DIMM3...

  • Page 18: Set The Jumpers

    !     Set the Jumpers...
  • Page 19 !     Jumper JP2: Keyboard Power On Selector Note: Function Jumper Setting Disable Keyboard Power On Short Pins 1-2 Enable Keyboard Power On Short Pins 2-3 Jumper JP6: Clear CMOS Memory Function Jumper Setting Normal Operation Short Pins 1-2 Clear CMOS Memory Short Pins 2-3 Jumper JP1: Enable/Disable Onboard Audio...
  • Page 20 !     Jumper JP3: Enable/Disable Onboard Fax/Modem Function Jumper Setting Disable Onboard Modem Short Pins 1-2 Enable Onboard Modem Short Pins 2-3 Jumper JP5: Select Slot-1 or Socket-370 Processor Function Jumper Setting Socket-370 Processor Short Pins 1-2 Slot-1 Processor Short Pins 2-3...

  • Page 21: Install The Mainboard

    !     Install the Mainboard AT-PWR1 ATX-PWR2...
  • Page 22 !     Power LED Speaker Pins 2-4-6 Pins 1-3-5-7 Keylock Pins 8-10 HDD LED Pins 15-16 Reset Switch Pins 17-18 Power Switch Pins 21-22 21 22...

  • Page 23: Install The Extension Brackets

    !     Install the Extension Brackets Note: Audio Ports and Game/MIDI Port Extension Bracket J1-Audio Header Stereo Line-in /Rear speaker channels 3-4 Microphone Stereo Line-out /Speaker channels 1-2 Game/MIDI Audio Ports & Game/MIDI Extension Bracket...

  • Page 24: Serial/Parallel Ports Extension Bracket

    !     Serial/Parallel Ports Extension Bracket COM1 PRN1 Serial Port COM1 Parallel Port LPT1 Serial/Parallel Ports Extension Bracket...

  • Page 25: Fax/Modem Daa Module

    !     Fax/Modem DAA Module J2-MODEM Header GND 1 2 MCLK GND 3 4 FRA-SY GND 5 6 SCLK AUX 3V 7 8 RIN-WAK HOOK 9 10 GPIO RIN 11 12 SDO AUX 5V 13 14 SDI MUTE 15 16 RST Line &...

  • Page 26: Vga Extension Bracket

    !     VGA Extension Bracket VGA1-VGA Header VGA Extension Bracket...

  • Page 27: Optional Extension Brackets

    !     Optional Extension Brackets ATX Form Card J4-ATX Header Infrared Port PS/2 Mouse Port USB Ports ATX Form Card Note:...

  • Page 28: Optic Module Extension Bracket

    !     Optic Module Extension Bracket J3-SPDIF Header SPDIF Out Optic Out Optic In SPDIF In Aux In Optic Module Extension Bracket      ...

  • Page 29: Optional Infrared Port

    !     Optional Infrared Port IR1-Infrared Header Install Other Devices FDC1 IDE1 IDE2 Floppy Disk Drive...
  • Page 30 !     IDE Devices Internal Sound Connections...

  • Page 31: Expansion Slots

    !     Expansion Slots PCI3 / 2 / 1 JP4- Wake On LAN Header ISA1 Wake On LAN...

  • Page 32: Bios Setup

    Chapter 3 BIOS Setup Introduction The BIOS setup utility stores information about your computer such as the date and time, the kind of hardware you have installed, and so on. Your computer uses this information to initialize all the components at boot up time, and make sure that everything runs smoothly.

  • Page 33: Running The Setup Utility

    !     Running the Setup Utility Each time your computer starts, before the operating system is booted, a message appears on the screen that prompts “Hit <DEL> if you want to run SETUP”. When you see this message, press the Delete key and the Mainmenu page of the setup utility appears on your monitor.

  • Page 34: Standard Cmos Setup Page

    !     with a set of default values. Press F7 to install the setup utility with a set of high-performance values. Standard CMOS Setup Page Use this page to set basic information such as the date and time, the IDE devices, and the diskette drives.

  • Page 35: Advanced Setup Page

    !     Advanced Setup Page Use this page to set more advanced information about your system. Take some care with this page. Making changes can affect the operation of your computer. Share Memory This item lets you allocate a portion of the main Size memory for use by the onboard VGA system.
  • Page 36 !     Floppy Drive If you enable this item, your system will check the Seek diskette drives at start up time. Disable this item unless you are using an old 360K diskette drive. Password Check If you have installed a password on your system, use this item to determine if the password is required to enter the setup utility (Setup) or required at start-up time and to enter the setup...

  • Page 37: Power Management Setup Page

    !     Power Management Setup Page This page sets some of the parameters for the system power management operation. Power Use this item to enable or disable the power Management/APM management routines. If you enable the power management, you can use the items below to set the power management operation.

  • Page 38: Pci / Plug And Play Setup Page

    !     Lan Card Power Your system can enter a software power down. If you enable this item, the system can automatically resume if there is traffic on the built-in network adapter. You must have an ATX power supply in order to use this feature.

  • Page 39: Load Optimal Settings

    !     Primary Graphics Use this item to define if your primary graphics Adapter adapter is installed in a PCI slot or on an AGP bus. PCI VGA Palette When this item is enabled, multiple VGA Snoop devices operating on different buses can handle data from the CPU on each set of palette registers on every video device.

  • Page 40: Features Setup Page

    !     Features Setup Page This page sets some of the parameters for peripheral devices installed on the system. Onboard FDC Use this item to enable or disable the onboard floppy disk drive interface. Onboard Serial Use this item to enable or disable the onboard Port1 serial port COM1, and to assign a port address Onboard IR Port...

  • Page 41: Cpu Pnp Setup Page

    !     Onboard IDE Use this item to enable or disable either of the two onboard IDE channels, Primary or Secondary. Ultra DMA Support Use this item to determine if you require Ultra DMA support for IDE devices on the primary or secondary IDE channels.

  • Page 42: Hardware Monitor Page

    !     CPU Multiple Use this item to set a multiplier for the system Factory bus frequency. The multiplier x the system bus frequency must equal the internal clock speed of your CPU, e.g. 100 MHz (system bus) x 3.5 (muliplier) = 350 MHz (internal clock speed of installed CPU).
  • Page 43 !    ...

  • Page 44: Change Password

    !     Change Password If you highlight this item and press Enter, a dialog box appears which lets you enter a Supervisor password. You can enter no more than six letters or numbers. Press Enter after you have typed in the password.

  • Page 45: Software & Applications

    Chapter 4 Software & Applications Introduction The support software CD-ROM that is included in the mainboard package contains all the drivers and utility programs needed to properly run our products. Please check all the README files for the latest information on installing and using the software. Using the PCI Sound Application 1.

  • Page 46: The Four Speakers System

    !     in the CONTROL PANEL. Select the MIDI page and click on “CM8338 MPU-401” (Win98) or “CM8338/C3DX PCI Audio External MIDI Port” (Win95), and then click “OK” to confirm. 5. For more information, refer to the PCI Sound manual in the CD which ships with this mainboard.

  • Page 47: Mixer Setup

    !     Mixer Setup There is a 4-speakers option in the Volume Control of the Mixer when you are setting up the PCI Audio Application. Click on the 4 SPK icon to enable this option. This means that the output to the rear speakers is sent through the Line-in/Rear jack.
