MS6393E Mainboard User's Manual
This publication, including all photographs, illustrations and
software, is protected under international copyright laws, with all
rights reserved. Neither this manual, nor any of the material
contained herein, may be reproduced without the express written
consent of the manufacturer.
The information in this document is subject to change without
notice. The manufacturer makes no representations or warranties
with respect to the contents hereof and specifically disclaims any
implied warranties of merchantability or fitness for any particular
purpose. Further, the manufacturer reserves the right to revise this
publication and to make changes from time to time in the content
hereof without obligation of the manufacturer to notify any person
of such revision or changes.
Trademarks
IBM, VGA, and PS/2 are registered trademarks of International
Business Machines.
Intel, Pentium, Pentium-II, Pentium-III, MMX, and Celeron are
registered trademarks of Intel Corporation.
Microsoft, MS-DOS and Windows 95/98/NT are registered
trademarks of Microsoft Corporation.
Sound Blaster is a trademark of Creative Technology Ltd.
PC-cillin and ChipAwayVirus are trademarks of Trend Micro Inc.
AMI is a trademark of American Megatrends Inc.
A3D is a registered trademark of Aureal Inc.
Gamut is a registered trademark of Formosoft International Inc.
SuperVoice is a registered trademark of Pacific Image
Communications Inc.
MediaRing Talk is a registered trademark of MediaRing Inc.
Other names used in this publication may be trademarks and are
acknowledged.
Copyright © 2000
All Rights Reserved
MS6393E, V1.5
S54X/JUNE 2000

Advertisement

Table of Contents
loading

Related Manuals for MATSONIC MS6393E

Summary of Contents for MATSONIC MS6393E

  • Page 1 MS6393E Mainboard User’s Manual This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the manufacturer.

  • Page 2: Declaration Of Conformity

    MS6393E Mainboard User’s Manual Federal Communications Commission (FCC) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Table Of Contents

    MS6393E Mainboard User’s Manual Table of Contents Chapter 1: Introduction ..............1 Key Features..............2 Package Contents ...............6 Static Electricity Precautions ..........7 Pre-Installation Inspection...........7 Chapter 2: Mainboard Installation ..........7 Mainboard Components............8 I/O Ports................9 Install A CPU ..............9 Install Memory..............10 Setting Jumper Switches ........... 11 Install the Mainboard............
  • Page 4 MS6393E Mainboard User’s Manual Appendix A: Gamut .............A1 Introduction ..............A2 Before Installing .............A3 Installation ..............A4 Produce MP3 file Use CD-Cashier ........A5 Play MP3 file Use Musician .........A7 Play music CD Use 3D -ACD ........A8 Play MIDI file Use Midier ..........A9...

  • Page 5: Chapter 1: Introduction

    1: Introduction Chapter 1 Introduction This mainboard supports all Socket 7 processors including newer designs which feature a 100 MHz system bus . The mainboard firmware supports CPU Plug and Play so that the system will automatically adopt the correct configuration for the Socket-7 processor that you install.

  • Page 6: Key Features

    MS6393E Mainboard User’s Manual Key Features This key features of this mainboard include: Socket-7 Processor Support Supports all recent socket-7 processors including the Intel P55C (Pentium MMX), the Cyrix/IBM 6x86L/6x86MX /MII, the AMD K6/K6-2/K6-III, IDT C6, and WinChip 2/2A CPUs...
  • Page 7 1: Introduction Built-in Graphics System Onboard 128-bit 2D/3D 100MHz Host interface AGP Graphics Accelerator Complies with AGP V2.0 Shared memory architecture allows a maximum of 64 MB main memory to act as frame buffer Supports high resolutions up to 1920x1200 16M colors, up to 2048x2048 Texture size and Virtual screen up to 4096x4096 Supports hardware DVD Accelerator and Direct DVD to...
  • Page 8 MS6393E Mainboard User’s Manual Built-in Ethernet LAN 10BaseT/100BaseTX Ethernet LAN LAN controller integrates Fast Ethernet MAC and PHY compliant with IEEE802.3u 100BASE-TX, 10BASE-T and ANSI X3.263 TP-PMD standards Compliant with ACPI 1.0 and the Network Device Class Power Management 1.0...
  • Page 9 1: Introduction Dimensions Micro-ATX form factor (24.4cm x 19cm)

  • Page 10: Package Contents

    MS6393E Mainboard User’s Manual Package Contents Your mainboard package ships with the following items: The mainboard This User’s Guide 1 UDMA/66 IDE cable 1 Floppy disk drive cable Support software on CD-ROM disk Optional Accessories You can purchase the following optional accessories for this mainboard.

  • Page 11: Static Electricity Precautions

    1: Introduction Static Electricity Precautions Components on this mainboard can be damaged by static electricity. Take the following precautions when unpacking the mainboard and installing it in a system. 1. Keep the mainboard and other components in their original static-proof packaging until you are ready to install them. 2.

  • Page 13: Chapter 2: Mainboard Installation

    Chapter 2 Mainboard Installation To install this mainboard in a system, follow the procedures in this chapter: Identify the mainboard components Install a CPU Install one or more system memory modules Verify that any jumpers or switches are set correctly Install the mainboard in a system chassis (case) Connect any extension brackets or cables to the mainboard connector headers...

  • Page 14: Mainboard Components

    MS6393E Mainboard User’s Manual Mainboard Components Use the diagram below to identify the major components on the mainboard. Note: Any jumpers on your mainboard that do not appear in this illustration are for testing only.

  • Page 15: I/O Ports

    I/O Ports The illustration below shows a side view of the built-in I/O ports on the mainboard. Parallel Port PS/2 Mouse Game/MIDI Port VGA Port Line-Out Jack PS/2 Keyboard Microphone Jack Line-In Jack USB Ports Serial Port COM1/3 Install A CPU This mainboard has a Socket-7 which may be installed with any of the socket-7 processors including the Intel P55C (MMX) series, the Cyrix/IBM 6x86L/6x86MX/MII series, the AMD K6/K6-2/K-III...

  • Page 16: Install Memory

    MS6393E Mainboard User’s Manual The socket-7 processor installs into the ZIF (Zero Insertion Force) socket-7 on the mainboard. 1. Locate the Socket-7 and J1. Pull the locking lever out slightly from the socket and raise it to the upright position.

  • Page 17: Setting Jumper Switches

    DIMM1 DIMM2 For this mainboard, you must use 168-pin, 3.3V unbuffered SDRAM memory modules. If the installed CPU uses a 100 MHz system bus, you must use PC100 memory. If the installed CPU uses a 66 MHz system bus, you must use PC66 memory. You can install any size memory module from 16 MB to 512MB, so the maximum memory size is 2 x 512MB = 1GB.
  • Page 18 MS6393E Mainboard User’s Manual J6 J5 Jumper J3: Clear CMOS Memory Use this jumper to clear the contents of the CMOS memory. You may need to clear the CMOS memory if the settings in the Setup Utility are incorrect and prevent your mainboard from operating.
  • Page 19 Jumper J11: Keyboard Power On Selector If you enable the keyboard power on feature, you can use hot keys on your keyboard as a power on/off switch for the system. Note: The system must provide 1A on the +5VSB (+5V Standby) signal before using the Keyboard Power On function.

  • Page 20: Install The Mainboard

    MS6393E Mainboard User’s Manual Install the Mainboard Install the mainboard in a system chassis (case). The board is a micro-ATX size mainboard with a twin-tier of I/O ports. You can install this mainboard in any ATX case. Special micro-ATX cases are also available with a reduced number of expansion slot bays and a smaller power supply unit.
  • Page 21 22 21 Power SW 21-22 Suspend LED 19-20 Reset SW 17-18 HDD LED 15-16 Speaker 1-3-5-7 Power LED 2-4-6...

  • Page 22: Install The Extension Brackets

    MS6393E Mainboard User’s Manual Install the Extension Brackets The extension brackets are used to connect features on the mainboard to external connectors that can be attached to the system chassis. Follow the steps below to install the extension brackets. Note: All the ribbon cables used on the extension brackets have a red stripe on the Pin-1 side of the cable.

  • Page 23: Install Other Devices

    Install Other Devices Install and connect any other devices in the system following the steps below. FDD1 IDE1 IDE2 Floppy Disk Drive The mainboard ships with a floppy disk drive cable that can support one or two drives. Drives can be 3.5” or 5.25” wide, with capacities of 360K, 720K, 1.2MB, 1.44MB, or 2.88MB.
  • Page 24 MS6393E Mainboard User’s Manual Internal Sound Connections If you have installed a CD-ROM drive or DVD-ROM drive, you can connect the drive audio cable to the onboard sound system. On the mainboard, locate the two 4-pin connectors CD1 and CD2.

  • Page 25: Expansion Slots

    Expansion Slots This mainboard has two 32-bit PCI expansion slots and one ADIMM slot. The PCI slot PCI1 is shared with the ADIMM slot, the PCI slot PCI2 is shared with the USB port. It means that you can use either one of shared both but you cannot use the both at the same time.
  • Page 26 MS6393E Mainboard User’s Manual signals from the VGA circuitry and transforms them into ® composite or component video output for a TV display, TMDS signals for an LCD display or analog RGB signals for a secondary CRT display.

  • Page 27: Chapter 3: Bios Setup Utility

    Chapter 3 BIOS Setup Utility Introduction The BIOS Setup Utility records settings and information about your computer such as the date and time, the kind of hardware installed, and various configuration settings. Your computer uses this information to initialize all the components when booting up and functions as the basis for coordination between system components.

  • Page 28: Running The Setup Utility

    MS6393E Mainboard User’s Manual Running the Setup Utility Each time your computer starts, before the operating system loads, a message appears on the screen that prompts you to “Hit <DEL> if you want to run SETUP”. When you see this message, press the Delete key and the Main menu page of the Setup Utility appears on your monitor.

  • Page 29: Standard Cmos Setup Page

    Standard CMOS Setup Page Use this page to set basic information such as the date and time, the IDE devices, and the diskette drives. If you press the F3 key, the system will automatically detect and configure the hard disks on the IDE channels.

  • Page 30: Advanced Setup Page

    MS6393E Mainboard User’s Manual Advanced Setup Page Use this page to set more advanced information about your system. Take some care with this page. Making changes can affect the operation of your computer. AMIBIOS SETUP – ADVANCED SETUP ©1998 American Megatrends, Inc. All Rights Reserved...
  • Page 31 BootUp Num- This items determines if the Num Lock key is Lock active or inactive at system start-up time. Floppy Drive If you have two diskette drives installed and you Swap enable this item, drive A becomes drive B and drive B becomes drive A.

  • Page 32: Power Management Setup Page

    MS6393E Mainboard User’s Manual Power Management Setup Page This page sets some of the parameters for system power management operation. Power Use this item to enable or disable a power Management/APM management scheme. If you enable power management, you can use the items below to set the power management operation.
  • Page 33 Ring On Power On The system can be turned off with a software command. If you enable this item, the system can automatically resume if there is an incoming call on the Fax/Modem. You must use an ATX power supply in order to use this feature.

  • Page 34: Pci / Plug And Play Setup Page

    MS6393E Mainboard User’s Manual PCI / Plug and Play Setup Page This page sets some of the parameters for devices installed on the PCI bus and devices that use the system plug and play capability. Plug and Play Enable this item if you are using an O/S that...

  • Page 35: Load Optimal Settings

    Load Optimal Settings If you select this item and press Enter a dialog box appears. If you press Y, and then Enter, the Setup Utility loads a set of fail-safe default values. These default values are not very demanding and they should allow your system to function with most kinds of hardware and memory chips.

  • Page 36: Features Setup Page

    MS6393E Mainboard User’s Manual Features Setup Page This page sets some of the parameters for peripheral devices connected to the system. AMIBIOS SETUP – FEATURES SETUP ©1998 American Megatrends, Inc. All Rights Reserved OnBoard FDC Enabled OnBoard Serial PortA 3F8h/COM1...
  • Page 37 Onboard PCI IDE Use this item to enable or disable either or both of the onboard Primary and Secondary IDE channels. Ultra DMA Support Use this item to set Ultra DMA support for IDE devices on the Primary or Secondary IDE channels.

  • Page 38: Cpu Pnp Setup Page

    MS6393E Mainboard User’s Manual CPU PnP Setup Page This page lets you manually configure the mainboard for the CPU. The system will automatically detect the kind of CPU that you have installed and make the appropriate adjustments to the items on this page.

  • Page 39: Hardware Monitor Page

    Hardware Monitor Page This page sets some of the parameters for the hardware monitoring function of this mainboard. AMIBIOS SETUP – HARDWARE Monitor ©1998 American Megatrends, Inc. All Rights Reserved --- Hardware Monitor --- CPU Temperature 30°C/86°F System Temperature CPU Fan Speed Chassis Fan Speed Vcore 2.000 V...

  • Page 40: Change Password

    MS6393E Mainboard User’s Manual Change Password If you highlight this item and press Enter, a dialog box appears which lets you enter a Supervisor password. You can enter no more than six letters or numbers. Press Enter after you have typed in the password.

  • Page 41: Chapter 4 Software & Applications

    4: Software & Applications Chapter 4 Software & Applications Introduction The support software CD-ROM that is included in the mainboard package contains all the drivers and utility programs needed to properly run our products. Please check all the README files for the latest information on installing and using the software.

  • Page 42: The Four Speakers System

    MS6393E Mainboard User’s Manual 4. If the devices that you are using require the MIDI port as the control interface, you need to select the MULTIMEDIA icon in the CONTROL PANEL. Select the MIDI page and click on “CM8738 MPU-401” (Win98) or “CM8738/C3DX PCI Audio External MIDI Port”...

  • Page 43: Mixer Setup

    4: Software & Applications Mixer Setup There is a 4-speakers option in the Volume Control of the Mixer when you are setting up the PCI Audio Application. Click on the 4 SPK icon to enable this option. This means that the output to the rear speakers is sent through the Line-in/Rear jack.
