DL451 Modular I/O
Operator Manual
Midas Klark Teknik Limited,
Klark Industrial Park,
Walter Nash Road,
Kidderminster.
Worcestershire.
DY11 7HJ.
England.
Tel: +44 1562 741515
Fax: +44 1562 745371
Email: info@midasklarkteknik.com
Website: www.midasconsoles.com
DL451 Modular I/O — Operator Manual
DOC02-DL451 Issue B — April 2010
© Red Chip Company Ltd.
In line with the company's policy of continual improvement, specifications and function may be
subject to change without notice. This document was correct at the time of writing. E&OE.
