  • Page 1 1050p User Manual...

  • Page 3: Table Of Contents

    Table of Contents Safety Information Safety Information ................1-3 1.1.1 Warning and Precaution Symbols ..........1-3 1.1.2 Meaning of Symbols ..............1-3 Regulation Notices ................. 1-11 1.2.1 Laser Safety ................. 1-11 1.2.2 Ozone Release ................1-13 1.2.3 Electromagnetic Interference ............1-13 1.2.4 For European Users ..............
  • Page 4 Removing Finished Sets from LS-501/502 Large Capacity Stacker .. 4-17 Printing Operation Machine Status Screen ..............5-3 Features of the bizhub PRO 1050P ..........5-5 To Stop Printing .................5-7 Overview of Job List Screen .............5-9 Job Operation on Job List Screen ..........5-10 5.5.1...
  • Page 5 5.6.3 Creating a Box (Personal Folder/Public Folder) ......5-30 5.6.4 Deleting a Box (Personal Folder/Public Folder/Confidential Folder) 5- 5.6.5 Output from the Internal HDD ............5-45 About the Recall Tab’s Output Setting Screen ......5-51 About the Confidential Folder ............5-54 5.8.1 Creating a Box (Confidential Folder) ..........
  • Page 6 03 Centring Adjustment ..............9-18 9.7.1 01 Printer Centring Adjustment ............9-18 Finisher Adjustment ................9-20 01 Stapler Position Adjustment ............9-21 9.9.1 01 Stapling Centre Position Adjustment ........9-21 9.9.2 02 Paper Width Adjustment ............9-23 9.10 02 Multi Folder (Punch) Adjustment ..........9-26 9.10.1 01 Paper Width Adjustment ............9-26 9.10.2 02 Hole-Punch Vertical Position Adjustment ........9-28 9.11...
  • Page 7 12.1.3 03 1SHOT Indication Time ............12-8 12.1.4 04 Default Screen Setting ............12-9 12.1.5 05 Auto Reset Setting ..............12-10 12.1.6 06 Key Response Time .............. 12-11 12.1.7 07 Change User Password ............12-12 12.2 02 Function Setting ............... 12-14 12.2.1 01 Feed Tray Setting ..............
  • Page 8 13.7.1 01 User Call ................13-100 13.8 07 Security Setting ..............13-101 13.8.1 01 Machine Manager Password ..........13-101 13.8.2 02 HDD Management Setting ...........13-103 13.8.3 03 Security Strengthen mode ...........13-110 14 Browser Control Setting 14.1 About PageScope Web Connection ..........14-3 14.1.1 Web Browser Settings ..............14-4 14.2 Access ....................14-5 14.3...
  • Page 9 14.7.10 Authentication ................14-51 15 Security 15.1 Security Functions ................15-4 15.1.1 Environments in which Security Strengthen mode is recommended .. 15-5 15.1.2 Creating a secure environment ............ 15-5 15.2 Security Strengthen Mode ............. 15-6 15.2.1 Description of Security Strengthen mode ........15-6 15.2.2 Data protected by Security Strengthen mode ......
  • Page 10 17 Maintenance 17.1 Checking Print Count ..............17-3 17.2 Preventive Maintenance ..............17-6 18 Machine Specifications 18.1 Main Body Specifications ...............18-3 18.1.1 Main Body ..................18-3 18.1.2 Adobe Post Script3 Expansion kit ..........18-4 18.2 Option Specifications ..............18-5 18.2.1 PF-701 Paper Feeder Unit ............18-5 18.2.2 LS-501/LS-502 Large Capacity Stacker ........18-5 18.2.3...

  • Page 11: Machine Name

    ® NERGY Program NERGY TAR Program has been established to encourage the wide- spread and voluntary use of energy-efficient technologies that reduce energy consumption and prevent pollution. As an NERGY TAR Partner,we have determined that this product meets the NERGY TAR guidelines for ener- gy efficiency, based on the following features.
  • Page 12 ACKNOWLEDGEMENTS: bizhub PRO is a trademark of KONICA MINOLTA BUSINESS TECHNOLO- GIES, Inc. Microsoft, MS, Windows and MS-DOS are registered trademarks or trade- marks of Microsoft Corporation in the United States and / or other countries. IBM is a registered trademarks of the IBM Corporation.

  • Page 13: Machine Name

    OpenSSL Statement OpenSSL License Copyright © 1998-2000 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modifica- tion, are permitted provided that the following conditions are met: - Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
  • Page 14 Original SSLeay License Copyright © 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved. This package is an SSL implementation written by Eric Young (eay@crypt- soft.com). The implementation was written so as to conform with Netscapes SSL. This library is free for commercial and non-commercial use as long as the fol- lowing conditions are aheared to.

  • Page 15: Machine Name

    GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILI- TY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
  • Page 16 x-14 Machine name...

  • Page 17: Safety Information

    Safety Information...

  • Page 19: Warning And Precaution Symbols

    This symbol warns against cause burns. A diagonal line indicates a prohibited course of action. This symbol warns against dismantling the device. A solid circle indicates an imperative course of action. This symbol indicates you must unplug the device. bizhub PRO 1050P...
  • Page 21 Safety Information...
  • Page 22 Use of an adapter or an extension cord could cause a fire or electrical shock. Contact your authorized service representative if an extension cord is required. • Consult your authorized service representative before connecting other equipment on the same wall outlet. Overload could result in a fire. bizhub PRO 1050P...

  • Page 23: Safety Information 1

    Dust that accumu- lates between the plug terminals may cause a fire. Grounding WARNING • Connect the power cord to an electrical outlet that is equipped with a grounding terminal. bizhub PRO 1050P...
  • Page 24 Ventilation CAUTION • Always use this product in a well ventilated location. Operating the product in a poorly ventilated room for an extended period of time could injure your health. Ventilate the room at regular intervals. bizhub PRO 1050P...
  • Page 25 • When moving this product, always hold it by the locations specified in the User manual or other documents. If the unit falls it may cause severe personal injury. The product may also be damaged or mal- function. bizhub PRO 1050P...
  • Page 26 Safety Information Before successive holidays CAUTION • Unplug the product when you will not use the product for long pe- riods of time. 1-10 bizhub PRO 1050P...

  • Page 27: Regulation Notices

    Dersom apparatet brukes på annen måte enn spesifisert I denne bruk- sanvisning, kan brukeren utsettes for usynlig laserstråling som over- skrider grensen for laser klass 1. Dette en halvleder laser. Maksimal effekt till laserdiode er 15 mW og bøkgelengde er 770 - 800 nm. bizhub PRO 1050P 1-11...
  • Page 28 överskrider gränsen för laserklass 1. Det här är en halvledarlaser. Den maximala effekten för laserdioden är 15 mW och våglängden är 770 - 800 nm. Rear side of main body 1-12 bizhub PRO 1050P...

  • Page 29: Ozone Release

    The use of non-shielded cables is likely to result in interfer- ence with radio communications and is prohibited under 89/336/EEC rules. 1.2.5 For German Users Maschinenlärminformations -Verordnung - 3. GSGV, 18.01.1991: Der arbeitsplatzbezogene Immisionswert betraegt 70 dB(A) oder weniger nach ISO 7779. bizhub PRO 1050P 1-13...

  • Page 30: Caution Labels And Indicators

    CAUTION This product employs a Class IIIb Laser Diode that emits an invisible laser beam. The cover should not be opened under any circumstances. 1-14 bizhub PRO 1050P...

  • Page 31: Installation Space

    Leave an adequate space behind the machine to let hot air out from the rear fan. Unit: mm Main body + DF-603 + PF-701 + FS-503 Unit: mm Main body + DF-603 + PF-701 + FS-502 bizhub PRO 1050P 1-15...
  • Page 32 Unit: mm Main body + DF-603 + PF-701 + LS-501 + LS-502 Unit: mm Main body + DF-603 + PF-701 + LS-501 + LS-503 Unit: mm Main body + DF-603 + PF-701 + LS-501(×2) + LS-503 1-16 bizhub PRO 1050P...
  • Page 33 Finisher tray of FS-503 Finisher gradually goes down while printed mate- rials output. DO NOT allow any object to interfere with the operation of the tray on the left side of the finisher, as any interference may cause damage to the finisher. bizhub PRO 1050P 1-17...
  • Page 34 Safety Information 1-18 bizhub PRO 1050P...

  • Page 35: Preparation For Use

    Preparation for Use...

  • Page 37: Machine Configuration

    A3 to A5. OHP films and thick paper are available from this tray only. Tray 5 (universal tray) is user-adjustable and holds 2,000 sheets from A3 to A5. Tray left side door opens to allow removal of mishandled paper. bizhub PRO 1050P...
  • Page 38 Options see descritpion for each on the following pages Left side door opens together with the Front door to allow removal of mishandled paper or when turning on/off the main power switch. bizhub PRO 1050P...

  • Page 39: Internal Machine Items

    Main power switch used only by service representative turns machine power on/off when pressed. 7 CAUTION The internal fixing unit is very hot. To avoid getting burned, DO NOT TOUCH. bizhub PRO 1050P...

  • Page 40: Control Panel Layout

    Utility Menu Screen / Counter Screen or ac- cesses porgramming modes for setting special functions. Accessibility adjusts the response time when touch panel keys or con- trol panel keys are pressed. Help displays a screen with help for the currently selected function. bizhub PRO 1050P...
  • Page 41 Stop the operation to prevent any unexpected accident. Write down the report code as stated on the 2nd line of the message, then switch off the machine and disconnect from the power socket. Contact your service representative and inform them of the report code. bizhub PRO 1050P...

  • Page 42: Standard/Optional Equipment

    FD-501 Folding Unit FS-503 Finisher LS-501 Large Capacity Stacker Main Body + PF-701 Paper Feed Unit FS-503 Finisher + LS-501 Large Capacity Stacker (×2) LS-501 Large Capacity Stacker + LS-502 Large Capacity Stacker LS-502 Large Capacity Stacker bizhub PRO 1050P...

  • Page 43: Folding Unit

    Upper cover feed tray hold cover sheets to fix the position. guide plates Upper cover opens to allow removal of mishandled paper. Folding unit door opens to allow removal of mishandled paper or waste pa- per. bizhub PRO 1050P...
  • Page 44 Conveyance knob/1 can be turned counterclockwise to ease removal of mis- handled paper. Outlet lever opens rightward to remove mishandled paper. Upper/Lower right side opens upward to remove mishandled paper. lever 2-10 bizhub PRO 1050P...
  • Page 45 Left side lever (right/ opens leftward to remove mishandled paper. left) Upper lever opens upward to remove mishandled paper. Conveyance knob/2 can be turned clockwise to ease removal of mishandled cover paper. bizhub PRO 1050P 2-11...

  • Page 46: Finisher

    Stapler unit convey- opens downward to remove mishandled paper. ance lever Stapler unit handle withdraws the unit to allow removal of mishandled paper. Stapler unit knob can be turned counterclockwise to ease removal of mis- handled paper. 2-12 bizhub PRO 1050P...

  • Page 47: Ls-501/Ls-502 Large Capacity Stacker

    Non-sort mode. Top cover handle (left) opens to remove mishandled paper. Top cover handle opens to remove mishandled paper. (right) Paper removal indica- lights while the stacker goes down in order to allow takeout of printed sheets. bizhub PRO 1050P 2-13...
  • Page 48 Inlet lever opens downward to remove mishandled paper. Stacker holds sets output in Non-sort mode or Collated mode (offset). Carriage carries paper together with the stacker. Outlet lever opens downward to remove mishandled paper. 2-14 bizhub PRO 1050P...

  • Page 49: Turning On/Off The Power Switch

    The sub power switch is located on the right side of the control panel. When the sub power switch is turned on, the Power LED will turn green. The Wake-up Screen and Machine Status Screen with warm-up image will be displayed. bizhub PRO 1050P 2-15...
  • Page 50 For details, refer to “Making User Au- thentication” on page 2-25. If a key counter is required, follow the instruction on the screen. 2-16 bizhub PRO 1050P...

  • Page 51: To Turn Off The Power

    Be sure not to turn off the main power switch in usual operation. When turning the main power switch off then on, be sure to wait 10 sec- onds or longer before turning it on again; otherwise the machine may not operate properly. bizhub PRO 1050P 2-17...

  • Page 52: To Use Machine When Power Save Led Lights

    “Timer interrupt mode / Enter password” displayed in the message area, and the machine operation will be available temporarily by the For details, refer to Timer Interrupt function. “When Weekly Timer Is Activat- ed” on page 2-22. 2-18 bizhub PRO 1050P...

  • Page 53: Auto Low Power

    To start a printing job, press [Power Save]. The printing operation will become available. Note The Auto shut-off can be set for 30 minutes/ 60 minutes/ 90 minutes/ 120 minutes/ 240 minutes, or can be deactivated. For details, refer to “01 Power Save Setting” on page 13-6. bizhub PRO 1050P 2-19...

  • Page 54: Using Power Save Manually

    Press [Power Save] for one second or longer, then release it. The following message will be displayed. Using Auto Shut-Off: Entry Shut off mode, after 10 second Press key/screen to cancel Using Auto Low Power: Entry LowPower mode, after 10 second Press key/screen to cancel 2-20 bizhub PRO 1050P...
  • Page 55 Press POWER SAVER continuously more than one second for low power mode Power Save will be activated. The [Power Save] LED will be lit and the touch panel will be turned off. bizhub PRO 1050P 2-21...

  • Page 56: When Weekly Timer Is Activated

    However, the following procedure temporarily enables the machine opera- tion. (Timer Interrupt) Press [Power Save] on the control panel. The Machine Status Screen will be displayed along with the mes- sage shown below. Timer interrupt mode Please input password 2-22 bizhub PRO 1050P...
  • Page 57 Set the hour for the interrupt use, then press [Start]. Enter a 1-digit hour (ex. 3 for 3 hours) using the control panel key- pad. (0 ~ 9) Input copy time 3 hour(s) 05 minute(s) Press [Start]. bizhub PRO 1050P 2-23...
  • Page 58 60 is unavailable. Printing is available until the set time is up. When the machine operation is finished, press [Power Save] for one second or longer, then release it. The machine returns to OFF condition. 2-24 bizhub PRO 1050P...

  • Page 59: Making User Authentication

    Print quantity limit for each section can also be set. When [STORE] or [RECALL] tab is touched, one of the following User Au- thentication Screen will be displayed according to the authentication setting. bizhub PRO 1050P 2-25...
  • Page 60 (max. 8 characters) and/or 8-digit sec- tion password. Touch [OK]. Start machine operation. Normal printing job is available on the machine. Details If the message “Print limit reached” is displayed and machine operation becomes unavailable, contact your machine manager. 2-26 bizhub PRO 1050P...
  • Page 61 Preparation for Use When machine operation is completed, press [Access]. The initial state will be restored, with the User Authentication Screen displayed on the touch panel. bizhub PRO 1050P 2-27...

  • Page 62: Displaying Screen For Operation Guide (Help Mode)

    Screen key information (01~04) can also be displayed from each screen by pressing [Help] on the control panel. To reach item 05 or 06 from any subordinate Help Screens, touch Top Menu to display the top page, then select the desired item. 2-28 bizhub PRO 1050P...

  • Page 63: To Display Help Screen

    Preparation for Use 2.5.1 To Display Help Screen Pressing [Help] when Machine Status Screen is displayed: Top Page of the Help Screen This screen appears when [Top Menu] on the subordinate Help Screen is touched. bizhub PRO 1050P 2-29...

  • Page 64: Adjusting Response Time Of Touch Keys (Accessibility)

    The Accessibility LED lights in green to indicate that the specified re- sponse time is set on the machine. Details If Normal is selected as response time, pressing [Accessibility] will not make any change in the touch key operation. 2-30 bizhub PRO 1050P...
  • Page 65 Preparation for Use To deactivated this function, press [Accessibility] for one second or longer. The Accessibility LED goes off, and normal response time will be re- stored in touch key operation. bizhub PRO 1050P 2-31...
  • Page 66 Preparation for Use 2-32 bizhub PRO 1050P...

  • Page 67: Paper Information

    Paper Information...
  • Page 69 - ADU (Automatic Duplex Unit) (attached to Main body) - Finisher (FS-503) - Folding Unit (FD-501) - Post Inserter (attached to FD-501 Folding Unit) - Large Capacity Stacker (LS-501/LS-502) Refer to the following information on paper capacity for each. bizhub PRO 1050P...

  • Page 70: Paper Weight

    (sub) tray on the left side of the Folding unit. Reminder Be sure to use paper only of the weight specified for the tray; otherwise print quality may be deteriorated or machine trouble may occur. bizhub PRO 1050P...

  • Page 71: Tray/ Exit Tray Capacity

    Large capacity Stacker • Max. 5,000 sheets stacker (A3, B4, F4, A4, A4R, 12”x18”, 11”x17”, 8.5”x14”, 8.5"x11", 8.5"x11"R, Wide sizes (Max. 324mm x 460mm) • Max. 2,000 sheets (B5, A5) Secondary (sub) Max. 200 sheets tray bizhub PRO 1050P...
  • Page 72 Folding unit. Using Letter fold-in, Letter fold-out, Double parallel, or Gate mode, the finished set will be delivered only to the secondary (sub) tray on the left side of the Folding unit. bizhub PRO 1050P...

  • Page 73: Paper Size

    Folding unit Post inserter Upper/Lower • STD size: A3 to A5 tray • Wide sizes Large capacity Stacker STD size: A3 to A5 stacker Secondary (sub) Wide sizes: tray Max. 324mm x 460mm ~ Min. B6R bizhub PRO 1050P...
  • Page 74 Paper Information Reminder Be sure to specify the actual size to use wide size in a tray. Refer to “Set Paper Size, Conditions, Air Assist Function for a Tray” on page 8-16 for details in setting procedure. bizhub PRO 1050P...

  • Page 75: To Store Paper

    - Store paper in a cool, dry area. Using damp paper may cause a paper misfeed. - Keep partially used packages tightly wrapped during storage. - Do not place paper packages vertically to store. - Paper curl due to the vertical storage may cause a paper misfeed. bizhub PRO 1050P...
  • Page 76 Paper Information 3-10 bizhub PRO 1050P...

  • Page 77: Supplies & Handling

    Supplies & Handling...

  • Page 79: Loading Paper

    When paper in a tray becomes empty, the indicator blinks on the tray key. Follow the procedure below to supply the empty tray with paper. Reminder Be sure to load the specified paper; otherwise mishandled paper may oc- cur. bizhub PRO 1050P...

  • Page 80: Loading Paper In Tray

    Be sure that the machine is powered ON before withdrawing the tray. Only one tray can be withdrawn at a time. Reminder Do not withdraw the tray forcibly; otherwise you may be injured. Open the paper feed roller. Tray 1 and 2 Tray 3, 4, and 5 bizhub PRO 1050P...
  • Page 81 Be sure that the side guide plates and rear edge guide are securely aligned to the paper; otherwise the machine cannot detect the correct paper size, or machine trouble may occur. When paper is seated properly, close the paper feed roller. bizhub PRO 1050P...
  • Page 82 Supplies & Handling Push in the tray until it locks into place. The indicator on the Machine Status Screen will change. Reminder Do not bump the tray into the main body; otherwise machine trouble may be caused. bizhub PRO 1050P...

  • Page 83: Loading Tabbed Sheets In Tray

    Refer to “Paper Setting Outlines” on page 8-3 details of Tray Setting. Open the paper feed roller. Place paper on the tray. Place paper referring to the illustration shown above. Reminder Do not load above the limit level on the side guide plate. bizhub PRO 1050P...
  • Page 84 When paper is seated properly, close the paper feed roller. Push in the tray until it locks into place. bizhub PRO 1050P...

  • Page 85: Adding Toner

    Use the same number toner bottle as described on the label applied on the inside of the toner unit door. Otherwise, machine trouble may occur. Add toner according to the procedure as follows. Open the toner unit door. bizhub PRO 1050P...
  • Page 86 Remove the empty toner bottle. Shake the new toner bottle several times to loosen toner. Remove the cap from the new toner bottle, then put it to the used one. Used 4-10 bizhub PRO 1050P...
  • Page 87 Do not throw the empty toner bottle into a fire. If it is thrown into a fire, the toner may ignite and cause a dangerous situation. bizhub PRO 1050P 4-11...

  • Page 88: Inserting A New Staple Cartridge Into Fs-503 Finisher

    Machine Status Screen. Follow the procedure below to set the staple roll into the staple cartridge. Open the Finisher door. Pull out the stapler unit slowly by holding the stapler unit handle until it stops. 4-12 bizhub PRO 1050P...
  • Page 89 Set the staple cartridge. Return the staple cartridge to its original position as shown below. Push up and in to secure it in place. bizhub PRO 1050P 4-13...
  • Page 90 Supplies & Handling Return the stapler unit to its original position. Close the Finisher door. 4-14 bizhub PRO 1050P...

  • Page 91: Empty Trash Basket Of Fd-501 Folding Unit

    When the trash basket becomes full, the Punch Dust indicator lights in red in the option status area of the Machine Status Screen. Follow the procedure below to empty the trash basket. Open the Finisher door. Then withdraw the trash basket. bizhub PRO 1050P 4-15...
  • Page 92 Supplies & Handling Empty the trash basket. Return the trash basket to its original position. Close the Finisher door securely. 4-16 bizhub PRO 1050P...

  • Page 93: Removing Finished Sets From Ls-501/502 Large Capacity Stacker

    The carriage is for the exclusive use of carrying paper. Do not drive it in any other use. Never put yourself in the large capacity stacker. bizhub PRO 1050P 4-17...
  • Page 94 Close the large capacity stacker door. Reminder When returning the stacker unit to its original position, fit the two projections of the carriage to the two holes of the stacker unit, otherwise the carriage cannot be returned properly. 4-18 bizhub PRO 1050P...

  • Page 95: Printing Operation

    Printing Operation...

  • Page 97: Machine Status Screen

    Post inserter. The cur- rently selected tray will be indicated in different color. Job list displays the current status of the jobs to be operated on the machine. Controller key is touched to set the controller. bizhub PRO 1050P...
  • Page 98 Toner message idisplays the current status of toner supply. Machine status display prompts you if any door or cover is open. Icon area displays various machine status icons. Message area displays messages concerning printing job. bizhub PRO 1050P...

  • Page 99: Features Of The Bizhub Pro 1050P

    Printing Operation Features of the bizhub PRO 1050P Auto Low Power Automatically lowers the power after a specified period of machine inac- tivity. Auto Reset Automatically resets to the default settings after a specified period of ma- chine inactivity. Auto Shut-Off Automatically shuts off the power after a specified period of machine in- activity.
  • Page 100 Off/On daily or weekly, during lunch time, on holidays, and also enables the Timer Interrupt mode, which allows temporary use of the machine even when the machine is in the daily, weekly, or holiday Off mode. bizhub PRO 1050P...

  • Page 101: To Stop Printing

    Job List Screen” on page 5-10. Press [Stop] while the current job is in progress. The current machine operation of the selected job will be suspended, and the popup menu will be displayed. Touch the desired key on the popup menu. bizhub PRO 1050P...
  • Page 102 Printing Operation Touch [Stop Job] to cancel the job, or touch [Continue] to complete the job. Reminder Touching [Stop Job] will delete all the data. bizhub PRO 1050P...

  • Page 103: Overview Of Job List Screen

    The Job List Screen will be displayed. Touch the desired key at the bottom of the screen. See the following pages for details of each subsequent screen. Touch other tab key to exit the Job List Screen. bizhub PRO 1050P...

  • Page 104: Job Operation On Job List Screen

    Follow the procedure below to check the settings, change the output order, and suspend/delete/stop reserved jobs. Touch [JOB LIST] tab, then touch [Reserved Job] if not highlighted. Check the status of the reserved jobs. Touch [Next] to scroll, if 8 or more jobs are entered. 5-10 bizhub PRO 1050P...
  • Page 105 To check the settings of reserve job: Touch to highlight the desired reserve job key, then touch [Details]. Check the settings of the selected job on the screen. Touch [Close] to return to the Job List Screen. bizhub PRO 1050P 5-11...

  • Page 106: To Display Output History

    Touch [Next] to scroll, if 8 or more jobs are entered. Touch the desired job key, then touch [Details]. Detailed settings of the selected job will be displayed. Touch [Close] to return to the previous screen. 5-12 bizhub PRO 1050P...

  • Page 107: To Check Incomplete Jobs

    Touch [Next] to scroll, if 8 or more jobs are entered. Touch the desired job key, then touch [Details]. Detailed settings of the selected job will be displayed. Touch [Close] to return to the previous screen. bizhub PRO 1050P 5-13...

  • Page 108: To Check/Operate Suspended Jobs

    Suspended on the key appears red to prompt you that a suspended job remains in the machine. Check the status of the suspended jobs. Touch [Next] to scroll, if 8 or more jobs are entered. 5-14 bizhub PRO 1050P...
  • Page 109 To check the settings of suspended job: Touch to highlight the desired job key, then touch [Details]. Check the settings of the selected job on the screen. Touch [Close] to return to the Job List Screen. bizhub PRO 1050P 5-15...

  • Page 110: To Check/Control Spool Jobs

    Touch to highlight the desired job key, then touch [Print Next]. The highlighted job will be moved just under the current print job. Details This will not function if printing operation has already been started for the selected job. 5-16 bizhub PRO 1050P...
  • Page 111 To clear spool job: Touch to highlight the desired job key, then touch [Delete]. Touch [Yes] on the popup menu to clear the selected job. Details All the data of the selected job will be cleared. bizhub PRO 1050P 5-17...

  • Page 112: About Screens Of The [Store]/[Recall] Tabs

    (Personal Folder/Public Folder) screens to specify a storage location as a Box No., or the Direct Call input screen. This page describes the keys on the list screens. The screens are different depending on how to store data. 5-18 bizhub PRO 1050P...
  • Page 113 Pressing this key cancels each setting on the screen, and you are brought back to the previous page. [OK] Pressing this key determines the settings and brings you to the next page. On the file list screen, pressing this key starts to transmit/output the selected file. bizhub PRO 1050P 5-19...

  • Page 114: Registering A Personal Folder

    A Personal Folder is registered (created) for each user, where you manage data you want to STORE/RECALL. Register a Personal Folder in the follow- ing steps. Details At maximum, 1000 Personal Folders can be registered. Select the [STORE] tab. Press the [Folder/Box Entry] key. 5-20 bizhub PRO 1050P...
  • Page 115 Printing Operation Select the [Personal Folder] key. Press the [New Register] key. bizhub PRO 1050P 5-21...
  • Page 116 Details Input a Folder Name within 64 characters in alphameric characters and signs. Reminder The below characters cannot be registered as a Folder Name irrespec- tively whether they are upper or lower case. Public, Admin, BoxAdmin 5-22 bizhub PRO 1050P...
  • Page 117 Input any Password. Details Input a Password within 64 characters in alphameric characters and signs. Reminder The input Password is shown by asterisks (1). Be sure to keep a record of the password. bizhub PRO 1050P 5-23...
  • Page 118 If you register only a folder, press the [Cancel] key to go to the step 9. If you register a box also, go to the step 4. For details, refer to “Creating a Box (Personal Folder/Public Folder)” on page 5-30. 5-24 bizhub PRO 1050P...
  • Page 119 Printing Operation Make sure that the Folder Name you registered on the folder list is dis- played. If you want to register multiple Personal Folders, return to the step 4 and re- peat the procedures. bizhub PRO 1050P 5-25...

  • Page 120: Deleting A Personal Folder

    Printing Operation 5.6.2 Deleting a Personal Folder To delete a registered Personal Folder, follow the steps below. Select the [RECALL] tab. Press the [Personal Folder] key. 5-26 bizhub PRO 1050P...
  • Page 121 If a Password is configured for the Folder, the Password input screen ap- pears. If a Password is not configured for the Folder, a screen appears and confirms you whether to delete the folder. Go to the step 6. bizhub PRO 1050P 5-27...
  • Page 122 Enter the Password and press the [OK] key. The confirmation screen appears and confirms you whether to delete the folder. Press the [Yes] key. The folder is deleted and the folder list screen (Personal Folder) ap- pears. 5-28 bizhub PRO 1050P...
  • Page 123 When you want to delete those Personal Folders or Personal Boxes with unknown password, your administrator can delete such folders. Your administrator cannot have access to boxes in a Personal Folder with unknown password. But deleting the folder enables him to delete those boxes in the folder. bizhub PRO 1050P 5-29...

  • Page 124: Creating A Box (Personal Folder/Public Folder)

    The print data are managed in boxes created in the folders of the internal HDD (Personal Folder/Public Folder). Create a box by the following steps. Details At maximum, 1000 Boxes can be registered. Select the [STORE] tab. Press the [Folder/Box Entry] key. 5-30 bizhub PRO 1050P...
  • Page 125 Press the [OK] key. If a Password is configured for the folder, the Password input screen appears. Enter the Password and press the [OK] key. When you select a Public Folder Press the [Public Folder] key. bizhub PRO 1050P 5-31...
  • Page 126 Printing Operation Press the [New Box] key. In case of Personal Folder In case of Public Folder 5-32 bizhub PRO 1050P...
  • Page 127 Name. Details Input a Box Name within 20 characters in alphameric characters and signs. If you configure a Password for a box, press the [Password Input] key to display the character input screen. Enter any Password. bizhub PRO 1050P 5-33...
  • Page 128 When you change the box number, press the [Box No. Input] to display the character input screen. Enter any Box No. Details Usually, there is no need to change a Box No. Input a 9 digit (000000001-999999998) Box No. The Box No. already registered cannot be used. 5-34 bizhub PRO 1050P...
  • Page 129 Printing Operation Press the [OK] key. The file list screen appears. Make sure that the Box Name you registered on the box list is dis- played. In case of Personal Folder bizhub PRO 1050P 5-35...
  • Page 130 If you have not registered a Box Name, the Box No. becomes the Box Name, and the Box No. is displayed on the list. If you want to register multiple boxes, return to the step 4 and repeat the pro- cedures. 5-36 bizhub PRO 1050P...

  • Page 131: Deleting A Box (Personal Folder/Public Folder/Confidential Folder)

    Select the [RECALL] tab. Select a folder. When you select a Personal Folder Press the [Personal Folder] key to display the list. Select the folder containing the box you want to delete, and press the [OK] key. bizhub PRO 1050P 5-37...
  • Page 132 Printing Operation When you select a Public Folder Press the [Public Folder] key. When you select a Confidential Folder Press the [Confidential] key. 5-38 bizhub PRO 1050P...
  • Page 133 Printing Operation Select the box you want to delete. When you select a Personal Folder When you select a Public Folder bizhub PRO 1050P 5-39...
  • Page 134 Printing Operation When you select a Confidential Folder Press the [Box Delete] key. When you select a Personal Folder 5-40 bizhub PRO 1050P...
  • Page 135 If a Password is configured for the box, the Password input screen appears. If a Password is not configured for the box, a screen appears and confirms you whether to delete the folder. Go to the step 6. bizhub PRO 1050P 5-41...
  • Page 136 Printing Operation Enter the Password and press the [OK] key. The confirmation screen appears and confirms you whether to delete the box. Press the [Yes] key. The box is deleted, and the box list screen appears. 5-42 bizhub PRO 1050P...
  • Page 137 Printing Operation Confirm that the box is deleted. When you select a Personal Folder When you select a Public Folder bizhub PRO 1050P 5-43...
  • Page 138 Printing Operation When you select a Confidential Folder Details As for Public Boxes and Confidential Boxes, your administrator can de- lete such boxes even when password is unknown. 5-44 bizhub PRO 1050P...

  • Page 139: Output From The Internal Hdd

    Print data stored on the internal HDD with the [STORE] tab or confidential print jobs transmitted from a computer can be output using the [RECALL] tab. Details For more information on confidential output, refer to the User’s Guide (Printer). Select the [RECALL] tab. bizhub PRO 1050P 5-45...
  • Page 140 Specify the folder in which the data you output are stored. When you select a Personal Folder Press the [Personal Folder] key to display the list. Select any folder and press the [OK] key. When you select a Public Folder Press the [Public Folder] key. 5-46 bizhub PRO 1050P...
  • Page 141 Password input screen appears. Enter the Password. If you know the target file, press the [Direct Call] key to specify the loca- tion directly. Select a box and press the [OK] key. When you select a Personal Folder bizhub PRO 1050P 5-47...
  • Page 142 Press the [No. Search] key and enter a Box No. to search a box by Box If you know the target file, press the [Direct Call] key to specify the loca- tion directly. The output setting screen appears. 5-48 bizhub PRO 1050P...
  • Page 143 For more information on the keys on the setting screen, refer to “About the Recall Tab’s Output Setting Screen” on page 5-51. Select [Wait Output], [Proof Output] or [Auto Output], and press the [OK] key. bizhub PRO 1050P 5-49...
  • Page 144 The confirmation screen asks you whether to continue to recall data. To continue recalling data, press the [Yes] key. To finish recalling data, press the [No] key. Pressing the [Yes] key displays the file list screen. Return to the step 4 and repeat the procedures. 5-50 bizhub PRO 1050P...

  • Page 145: About The Recall Tab's Output Setting Screen

    [Yes] key to delete the file. [Wait Output] After recalling data, the [MACHINE] tab’s screen appears. You can change the setting. For more information, refer to “The flow of operation of the Wait Output and Proof Output” on page 5-53. bizhub PRO 1050P 5-51...
  • Page 146 For more information, refer to “The flow of operation of the Wait Output and Proof Output” on page 5-53. [Auto Output] If this key is pressed, the output starts without pressing the start button. 5-52 bizhub PRO 1050P...

  • Page 147: The Flow Of Operation Of The Wait Output And Proof Output

    If you exit the job and you don't output it, please delete the present job from the [Reserved JOB] of [JOB LIST] tab. For more information on the method of job It is outputted Press the [Close] key deletion, see p. 4-5. bizhub PRO 1050P 5-53...

  • Page 148: About The Confidential Folder

    Also, using the [RECALL] tab enables you to create or delete a box in the confidential folder. Details To perform confidential printing, select Secure Print from the computer to which you installed the printer driver. For more information on how to perform confidential printing, refer to the User’s Guide (Printer). 5-54 bizhub PRO 1050P...

  • Page 149: Creating A Box (Confidential Folder)

    The Box Name and Password inputted by the following procedure is used in the Confidential Print of printer feature. For more information on confidential output, refer to the User’s Guide (Printer). Select the [RECALL] tab. Press the [Confidential] key. bizhub PRO 1050P 5-55...
  • Page 150 If you do not register a Box Name, a Box No. becomes the Box Name. You cannot use the confidential Box Name already registered. Input a Box Name within 20 characters in alphameric characters and signs. 5-56 bizhub PRO 1050P...
  • Page 151 Input a Password within 8 characters in alphameric characters and signs. Eight asterisks (1) are displayed regardless of the number of characters you input. Be sure to keep a record of the password. Press the [OK] key. bizhub PRO 1050P 5-57...
  • Page 152 Printing Operation Make sure that the Box Name you registered on the box list is dis- played. If you want to create multiple boxes, return to the step 3 and repeat the procedures. 5-58 bizhub PRO 1050P...

  • Page 153: Setting Output Methods

    Setting Output Methods...

  • Page 155: Sorting / Stapling Printed Sheets (Fs-503 Finisher)

    Example: Make 3 printed sets from 4 original sheets Non-sort Staple Collated Uncollated 2 staples Offset by 30mm 1 oblique staple Offset by 30mm bizhub PRO 1050P...
  • Page 156 - Number of cut staples: 5,000 or more (cut staples must be disposed of by a service centre during regular maintenance.) - The primary (main) tray's specifications are described separately. For de- tails refert to “Paper Weight” on page 3-4 and “Paper Size” on page 3-7. bizhub PRO 1050P...
  • Page 157 - The secondary (sub) tray's specifications are described separately. For details, refer to “Paper Weight” on page 3-4 and “Paper Size” on page 3-7. Reminder Be careful not to exceed the finisher tray capacity, otherwise unexpected trouble may be caused. bizhub PRO 1050P...

  • Page 158: Loading / Sorting Large Numbers Of Sheets (Ls-501/Ls-502)

    Uncollated mode groups together multiple sheets of each original. No offset output is available. Combined with the output modes above, you can also choose to output face up or face down, and output front to back or back to front. bizhub PRO 1050P...
  • Page 159 - The secondary (sub) tray's specifications are described separately. For details, refer to “Paper Weight” on page 3-4 and “Paper Size” on page 3-7. Reminder Be careful not to exceed the tray / stacker capacity, otherwise unexpect- ed trouble may be caused. bizhub PRO 1050P...

  • Page 160: Punching File Holes / Folding Printed Sheets (Fd-501)

    Double Parallel, Gate, and Folding. Choose to print outside the fold (out- side print) or inside (inside print) for each folding mode except Z-fold. 80 mm Z-Fold Letter Fold-out Gate 80 mm Letter Fold-in Double Parallel Folding bizhub PRO 1050P...
  • Page 161 Punched sheets will be delivered to FS-503 Finisher's primary (main) tray / secondary (sub) tray or to the secondary (sub) tray on the left side of FD- 501 Folding unit. Be careful not to exceed the capacity of each tray, oth- erwise unexpected trouble may be caused. bizhub PRO 1050P...
  • Page 162 Double parallel, or Gate, the folded sheets will be delivered only to the secondary (sub) tray on the left side of FD-501 Folding unit. Be careful not to exceed the capacity of each tray, otherwise unexpected trouble may be caused. 6-10 bizhub PRO 1050P...

  • Page 163: Output With Cover Sheet (Post Inserter)

    Reminder Printed sheets will be delivered to the FS-503 Finisher's primary (main) tray. Be careful not to exceed the finisher tray capacity, otherwise unex- pected trouble may be caused. bizhub PRO 1050P 6-11...

  • Page 164: Using Folder/Finisher Functions Manually

    Paper size: A3, B4, A4R, 12"x18", 11"x17", 8.5"x14", 8.5"x11"R, 8K – Paper weight: – Z-Fold / Letter Fold-in / Letter Fold-out / Folding: 50 - 130 g/m – Double Parallel / Gate: 50 - 91 g/m 6-12 bizhub PRO 1050P...
  • Page 165 Place paper in the upper tray of the Upper tray post inserter. 1 or 2 stapling: Place paper face up. Punching: Place paper face up. Folding: Place the surface to be inside the fold face up. Align the guide plate with the paper. bizhub PRO 1050P 6-13...
  • Page 166 When selecting folding (from 6 styles), press the Fold selection but- ton to turn on the desired mode lamp. Details Punching and stapling can be combined. When combining them, turn on the lamps for both functions. Fold&Staple button cannot be selected at present. 6-14 bizhub PRO 1050P...
  • Page 167 To interrupt the operation, press the Multi-Feed Detection button Start/Stop button again. Reminder Printed sheets will be delivered to the FS-503 Finisher's primary (main) tray. Be careful not to exceed the finisher tray capacity, otherwise unex- pected trouble may be caused. bizhub PRO 1050P 6-15...
  • Page 168 Setting Output Methods 6-16 bizhub PRO 1050P...

  • Page 169: Machine Status Screen Setting

    Machine Status Screen Setting...

  • Page 171: Machine Status Screen Setting Outlines

    Set the tray size, paper type/weight, air assist on/off of the tray that paper is loaded. For details, refer to “Paper Setting Outlines” on page 8-3. Details You may set the other settings on another screen while specifying the pa- per setting. Press the tab key to switch the screens. bizhub PRO 1050P...
  • Page 172 You cannot set the other settings while specifying the Adjustment mode. Controller The Controller Setting Menu Screen is displayed. Specify the settings concerning the Print Controller. For details, refer to “Controller Setting” on page 10-3. Touch the [MACHINE] tab to exit the Controller Setting mode. bizhub PRO 1050P...

  • Page 173: Paper Setting

    Paper Setting...

  • Page 175: Paper Setting Outlines

    For details, refer to “Recommended Setting of Paper Type/Weight” on page 8-9 for details of paper type specifications and relation between pa- per type and weight. 3. Colored Paper Select one of the following six types. White, Transparent, Yellow, Pink, Blue, Green bizhub PRO 1050P...
  • Page 176 The coated paper is mostly used for luxury art books, calendars, car brochures, books, magazines, leaflets, and posters. Always specify [Coated A] to a tray to which the coated paper is loaded. bizhub PRO 1050P...
  • Page 177 User When a paper type other than that of which can be specified on this machine is used, use this function. For the details, contact your service representa- tive. bizhub PRO 1050P...
  • Page 178 Printing speed becomes a little slow. Printing speed is 90 sheets per minute when printing A4 in the simplex print mode. Printing speed becomes slow. Printing speed is 63 sheets per minute when print- ing A4 in the simplex print mode. bizhub PRO 1050P...
  • Page 179 110.7 121.8 190.0 50.6 70.4 105.2 86.8 116.9 128.5 200.0 53.3 74.1 110.8 91.3 123.1 135.3 210.0 55.9 77.8 116.3 95.9 129.2 142.1 220.0 58.6 81.5 121.8 100.5 135.4 148.8 230.0 61.3 85.2 127.4 105.0 141.5 155.6 bizhub PRO 1050P...
  • Page 180 153.8 169.1 260.0 69.2 96.3 144.0 118.7 160.0 175.9 270.0 71.9 100.0 149.5 123.3 166.1 182.7 280.0 74.6 103.7 155.1 127.9 172.3 189.4 290.0 77.2 107.4 160.6 132.4 178.4 196.2 300.0 79.9 111.1 166.1 137.0 184.6 202.9 bizhub PRO 1050P...

  • Page 181: Recommended Setting Of Paper Type/Weight

    Details Service representative can make adjustments for all trays at the same time. Contact your service representative, if desired. Refer to a label on a paper package when registering the paper condi- tions. bizhub PRO 1050P...

  • Page 182: Register Paper Type/Weight

    Paper Setting Register Paper Type/Weight Follow the procedure below to register paper type/weight according to the paper type to be used. 8-10 bizhub PRO 1050P...
  • Page 183 Paper Setting Procedure Touch [Paper Set] - [Register Type/Weight] bizhub PRO 1050P 8-11...
  • Page 184 Touch the key to be registered. The Input Condition Screen will be dis- played. Touch [Type] to display the Type popup menu, then select the desired paper type. Details For details, refer to “Paper Setting Outlines” on page 8-3. Touch [OK] to complete the setting. 8-12 bizhub PRO 1050P...
  • Page 185 Touch [OK] to complete the setting. Touch [Weight] on the Input Condition Screen, then select the desired paper weight. Details Refer to “Recommended Setting of Paper Type/Weight” on page 8-9 for details of the relation between specified paper type and weight. bizhub PRO 1050P 8-13...
  • Page 186 Touch [OK] to complete the setting. Touch [Hole-Punch] on the Input Condition Screen, then touch [With Punch Hole] if the paper has punch holes. Touch [OK] to complete the setting. 8-14 bizhub PRO 1050P...
  • Page 187 Refer to “Paper Setting Outlines” on page 8-3 for the range of the adjust- ment value. Touch [OK]. Touch [OK] on the Input Condition Screen to complete the setting. The Input Condition Screen will be restored. Touch [Close]. The Machine Status Screen will be restored. bizhub PRO 1050P 8-15...

  • Page 188: Set Paper Size, Conditions, Air Assist Function For A Tray

    Paper Setting Set Paper Size, Conditions, Air Assist Function for a Tray Specify the paper sizes, programmed paper type/weight, air assist function for each tray. 8-16 bizhub PRO 1050P...
  • Page 189 Paper Setting Procedure Touch [Paper Set] -[Tray Setting]. Touch the tray key (Tray 1 to 5) to be specified. Touch [Size Setting]. The Size Setting Screen will be displayed. Follow the procedure for each setting. bizhub PRO 1050P 8-17...
  • Page 190 8.5x14. 3. Touch [OK] to complete the setting. The Tray Setting Screen will be re- stored. 4. Touch [OK] on the Size Setting Screen to complete the setting. 5. Proceed to step 5. (p. 8-24) 8-18 bizhub PRO 1050P...
  • Page 191 3. Touch [Lead Edge], [Rear Edge], or [Centre] to specify the desired image position. 4. Touch [OK] to complete the setting. The Tray Setting Screen will be re- stored. 5. Proceed to step 5. (p. 8-24) bizhub PRO 1050P 8-19...
  • Page 192 (+) and (,) to enter the horizontal size. The entered number should fall within the range from the horizontal size of the standard size corresponding to the selected wide size, to a maxi- mum of 460 mm. 8-20 bizhub PRO 1050P...
  • Page 193 7. Touch [Select Size] to return to the Select Size Screen. 8. Touch [OK] on the Size Setting Screen to complete the setting. The Tray Setting Screen will be restored. 9. Proceed to step 5. (p. 8-24) bizhub PRO 1050P 8-21...
  • Page 194 Setting Tab Paper 1. Touch [Tab Paper] to highlight it. 2. Touch the desired tabbed paper size key to highlight it. 3. If setting the custom tabbed paper size, touch [Custom Size] to display the Size Setting Screen. 8-22 bizhub PRO 1050P...
  • Page 195 Setting range is from 1 to 5. 6. Touch [OK] to complete the setting. 7. Touch [OK] on the Size Setting Screen to complete the setting. The Tray Setting Screen will be restored. 8. Proceed to step 5. (p. 8-24) bizhub PRO 1050P 8-23...
  • Page 196 Paper Setting Touch [Type/Weight] on the Tray Setting Screen. Use [Next] or [Previous] to scroll to the desired paper type/weight from the list, then touch the key to highlight it. 8-24 bizhub PRO 1050P...
  • Page 197 Touch [OK] to complete the setting. The Tray Setting Screen will be re- stored. Touch [Close] on the Tray Setting Screen. The Paper Set Screen will be restored. Touch [Close] on the Paper Set Screen. The Machine Status Screen will be restored. bizhub PRO 1050P 8-25...

  • Page 198: Change Paper Type/Weight Specified For A Tray

    Front and Back Page Adjustment is required to execute every time the paper type is changed or as daily maintenance, because a shrinkage ratio varies depending upon the paper type, paper brand, and the temperature and/or humidity of a storage location. 8-26 bizhub PRO 1050P...
  • Page 199 Paper Setting Procedure Touch [Paper Set] - [Tray Setting]. Touch [Change] to display the Change Setting Screen. bizhub PRO 1050P 8-27...
  • Page 200 Paper Setting Touch the key of the setting item to be changed. 8-28 bizhub PRO 1050P...
  • Page 201 Paper Setting To change it, follow the same procedure as registering the paper con- ditions. For details, refer to “Register Paper Type/Weight” on page 8-10. bizhub PRO 1050P 8-29...
  • Page 202 Change it in this step, if desired. For details of entering texts in the field, see the appendix. Touch [OK]. To restore the previous setting, touch [Cancel]. Touch [OK] to complete the setting. The Tray Setting Screen will be re- stored. 8-30 bizhub PRO 1050P...
  • Page 203 Paper Setting Touch [Close] to return to the Paper Set Screen. Touch [Close]. The Machine Status Screen will be restored. bizhub PRO 1050P 8-31...
  • Page 204 Paper Setting 8-32 bizhub PRO 1050P...

  • Page 205: Adjustment

    Adjustment...

  • Page 207: Machine Adjustment Outlines

    The following adjustments for image control are included in the Machine Ad- justment functions. 01 Magnification Adjustment Provide controls for image magnification. 02 Timing Adjustment Provide controls for image timing. 03 Centring Adjustment Provide the centring control to the direction of paper feed. bizhub PRO 1050P...

  • Page 208: Magnification Adjustment

    In the printer control, perform this adjustment to control the magnification for Side 1 to the direction of paper feed. Note This adjustment is a baseline for both sides adjustment enabled in Tray Setting and Register Type/Weight. bizhub PRO 1050P...
  • Page 209 Load A3 paper into the tray, then press [Start] to output the sample pat- tern (No. 16). Measure the resultant magnification to the direction of paper feed. 205.7 Paper feed direction If the desired result cannot be obtained, touch the [ADJUSTMENT] tab to return to the Adjustment Screen. bizhub PRO 1050P...
  • Page 210 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -10 (short) to +10 (long), 1 step = 0.05 %. Repeat steps 3 to 7 until the desired result is obtained. Touch [Return] to restore the Magnification Adjustment Menu Screen. bizhub PRO 1050P...

  • Page 211: Printer Drum Clock Adjustment

    In the printer control, perform this adjustment to control the magnification for Side 2 to the direction of paper feed. Details This adjustment is a baseline for both sides adjustment enabled in Tray Setting and Register Type/Weight. bizhub PRO 1050P...
  • Page 212 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -10 (short) to 0 (long), 1 step = 0.05 %. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Magnification Adjustment Menu Screen. bizhub PRO 1050P...

  • Page 213: Printer Horizontal Adjustment

    Adjustment 03 Printer Horizontal Adjustment <SIDE1> In the printer control, perform this adjustment to control the magnification for Side 1 perpendicular to the direction of paper feed. bizhub PRO 1050P...
  • Page 214 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -10 (short) to +10 (long), 1 step = 0.1 %. Repeat steps 3 to 7 until the desired result is obtained. Touch [Return] to restore the Magnification Adjustment Menu Screen. 9-10 bizhub PRO 1050P...

  • Page 215: Printer Horizontal Adjustment

    Adjustment 04 Printer Horizontal Adjustment <SIDE2> In the printer control, perform this adjustment to control the magnification for Side 2 perpendicular to the direction of paper feed. bizhub PRO 1050P 9-11...
  • Page 216 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -5 (short) to 0 (long), 1 step = 0.1 %. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Magnification Adjustment Menu Screen. 9-12 bizhub PRO 1050P...

  • Page 217: Timing Adjustment

    Adjustment 02 Timing Adjustment 9.6.1 01 Printer Restart Timing Adjustment <SIDE1> Perform this adjustment to control the restart timing for Side 1. Reminder Perform this adjustment after completing Printer Drum Clock Adjustment <SIDE1>. bizhub PRO 1050P 9-13...
  • Page 218 – PFU lower tray offset Touch the [PRINT] tab to display the Print Setting Screen. Select A3 paper, then press [Start] to output the sample pattern (No. 16). Measure the resultant restart timing. Paper feed direction 9-14 bizhub PRO 1050P...
  • Page 219 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -30 (short) to +30 (long), 1 step = 0.1 mm. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Timing Adjustment Menu Screen. bizhub PRO 1050P 9-15...

  • Page 220: Printer Restart Timing Adjustment

    Adjustment 9.6.2 02 Printer Restart Timing Adjustment <SIDE2> Perform this adjustment to control the restart timing for Side 2. Reminder Perform this adjustment after completing Printer Drum Clock Adjustment <SIDE2>. 9-16 bizhub PRO 1050P...
  • Page 221 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -30 (short) to +30 (long), 1 step = 0.1 mm. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Timing Adjustment Menu Screen. bizhub PRO 1050P 9-17...

  • Page 222: Centring Adjustment

    Adjustment 03 Centring Adjustment 9.7.1 01 Printer Centring Adjustment Perform this adjustment to control image centring to the direction of paper feed. 9-18 bizhub PRO 1050P...
  • Page 223 Use the touch panel keypad to enter an appropriate value, then touch [Set]. Available range: -64 (forward) to +63 (backward), 1 step = 0.1 mm. Repeat steps 3 to 7 until the desired result is obtained. Touch [Return] to restore the Centring Adjustment Menu Screen. bizhub PRO 1050P 9-19...

  • Page 224: Finisher Adjustment

    03 Multi Folder (Fold) Adjustment Make adjustments on folding functions operated by the FD-501 Folding Unit. 04 Stacker Adjustment Make adjustments on the LS-501/502 Large Capacity Stacker. 05 Saddle Stitcher Adjustment Not supported in this version. 9-20 bizhub PRO 1050P...

  • Page 225: Stapler Position Adjustment

    01 Stapling Centre Position Adjustment Perform this adjustment for the centre position of printed sheets and of sta- ples processed by the FS-503 Staple Finisher. The paper width adjustment is supposed to be completed before this adjust- ment. bizhub PRO 1050P 9-21...
  • Page 226 If the test desired result cannot be obtained, touch the [ADJUSTMENT] tab. Repeat the adjustment steps from 3 to 6 until the desired result is obtained. Touch [Return] to restore the Stapler Position Adjustment Mode Menu Screen. 9-22 bizhub PRO 1050P...

  • Page 227: Paper Width Adjustment

    Adjustment 9.9.2 02 Paper Width Adjustment Perform this adjustment if stapled sheets are not aligned neatly processed by the FS-503 Staple Finisher. bizhub PRO 1050P 9-23...
  • Page 228 Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -20 (wide) to +20 (narrow), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. 9-24 bizhub PRO 1050P...
  • Page 229 Adjustment Touch [Return] to restore the Stapler Position Adjustment Mode Menu Screen. bizhub PRO 1050P 9-25...

  • Page 230: Multi Folder (Punch) Adjustment

    Adjustment 9.10 02 Multi Folder (Punch) Adjustment 9.10.1 01 Paper Width Adjustment Perform this adjustment for the specific paper size if punch holes processed by the FD-501 Folding Unit dislocate largely. 9-26 bizhub PRO 1050P...
  • Page 231 If the setting is too narrow, the position of punch holes may vary. Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. Touch [Return] to restore the Multi Folder (Hole-Punch) Adjustment Mode Menu Screen. bizhub PRO 1050P 9-27...

  • Page 232: Hole-Punch Vertical Position Adjustment

    Adjustment 9.10.2 02 Hole-Punch Vertical Position Adjustment Perform this adjustment for the position of punch holes to the direction of pa- per feed. 9-28 bizhub PRO 1050P...
  • Page 233 Use the touch panel keypad to enter the desired adjustment value, then touch [Set]. Available range: -40 (wide) to +40 (narrow), 1 step = 0.1 mm Repeat the adjustment steps from 3 to 9 until the desired result is ob- tained. bizhub PRO 1050P 9-29...
  • Page 234 Adjustment If adjustment in any other hole type or paper size is required, repeat steps from 3 to 10. Touch [Return] to restore the Multi Folder (Hole-Punch) Adjustment Mode Menu Screen. 9-30 bizhub PRO 1050P...

  • Page 235: Multi Folder (Fold) Adjustment

    Adjustment 9.11 03 Multi Folder (Fold) Adjustment 9.11.1 01 Folding Position Adjustment Perform this adjustment for the folding position processed by the FD-501 Folding Unit. bizhub PRO 1050P 9-31...
  • Page 236 When misalignment (a) of step 5 has occurred, enter the "+" value. Repeat the adjustment steps from 3 to 8 until the desired result is ob- tained. If adjustment in any other size is required, repeat steps 3 to 9. 9-32 bizhub PRO 1050P...
  • Page 237 Adjustment Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. bizhub PRO 1050P 9-33...

  • Page 238: Letter Fold-In Position Adjustment

    The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold. 9-34 bizhub PRO 1050P...
  • Page 239 Touch [Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All - 11x17 - A3 - B4 - 8.5x14 - A4R - 8.5x11R - 8K - 12x18 bizhub PRO 1050P 9-35...
  • Page 240 The distance (b) in step 5 will increase when the "+" value is entered, and decrease when the "-" value is entered. Repeat steps 3 to 10 until the desired result is obtained. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. 9-36 bizhub PRO 1050P...

  • Page 241: Letter Fold-Out Position Adjustment

    The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold. bizhub PRO 1050P 9-37...
  • Page 242 Touch [Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All - 11x17 - A3 - B4 - 8.5x14 - A4R - 8.5x11R - 8K - 12x18 9-38 bizhub PRO 1050P...
  • Page 243 Repeat steps 3 to 10 until the desired result is obtained. If adjustment in any other size is required, repeat steps from 3 to 11. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. bizhub PRO 1050P 9-39...

  • Page 244: Double Parallel Position Adjustment

    The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold. 9-40 bizhub PRO 1050P...
  • Page 245 Touch [Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All - 11x17 - A3 - B4 - 8.5x14 - A4R - 8.5x11R - 8K - 12x18 bizhub PRO 1050P 9-41...
  • Page 246 Repeat steps 3 to 10 until the desired result is obtained. If adjustment in any other size is required, repeat steps from 3 to 11. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. 9-42 bizhub PRO 1050P...

  • Page 247: Fold Position Adjustment

    The baseline of Single Fold is calculated from the edge of the sheet, while that of Double Fold is calculated from the position of the first fold line, therefore a distance (b) in step 5 will be altered by changing the position of either Single Fold or Double Fold. bizhub PRO 1050P 9-43...
  • Page 248 Touch [Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All - 11x17 - A3 - B4 - 8.5x14 - A4R - 8.5x11R - 8K - 12x18 9-44 bizhub PRO 1050P...
  • Page 249 Repeat steps 3 to 10 until the desired result is obtained. If adjustment in any other size is required, repeat steps from 3 to 11. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. bizhub PRO 1050P 9-45...

  • Page 250: Gate Position Adjustment

    Triple Fold is calculated from the position of the second fold line, therefore a distance (a), distance (b) and distance (c) in step 5 will be al- tered by changing the position of any fold position. 9-46 bizhub PRO 1050P...
  • Page 251 Touch [Next] or [Back] to select the paper size to be adjusted. Touching [Next] continuously will change the paper size as follows: All - 11x17 - A3 - B4 - 8.5x14 - A4R - 8.5x11R - 8K - 12x18 bizhub PRO 1050P 9-47...
  • Page 252 Repeat steps 3 to 10 until the desired result is obtained. If adjustment in any other size is required, repeat steps from 3 to 11. Touch [Return] to restore the Multi Folder (Fold) Adjustment Mode Menu Screen. 9-48 bizhub PRO 1050P...

  • Page 253: Stacker Adjustment

    9.12 04 Stacker Adjustment 9.12.1 01 Paper Width Adjustment Perform this adjustment when output sheets are not aligned in a perpendic- ular position to the direction of paper feed processed by the LS-501/502 Large Capacity Stacker. bizhub PRO 1050P 9-49...
  • Page 254 Available range: -20 (narrow) to +20 (wide), 1 step = 0.1 mm If the desired result cannot be obtained, touch the [ADJUSTMENT] tab. Repeat steps 3 to 8 until the desired result is obtained. Touch [Return] to restore the Stacker Adjustment Mode Menu Screen. 9-50 bizhub PRO 1050P...

  • Page 255: Paper Length Adjustment

    Adjustment 9.12.2 02 Paper Length Adjustment Perform this adjustment when output sheets are not aligned to the direction of paper feed processed by the LS-501/502 Large Capacity Stacker. bizhub PRO 1050P 9-51...
  • Page 256 Adjustment 9-52 bizhub PRO 1050P...

  • Page 257: Controller Setting

    Controller Setting...

  • Page 259: Function Overview

    Controller Setting Controller Setting 10.1 Function Overview Setting change concerning the printer controller is available from the Con- troller Setting Menu Screen. Touch [Controller] on the Machine Status Screen. The Controller Setting Menu Screen will be displayed. The menu comprises the following settings. 01 Report Type Use this function to print out the report type selected from the screen.

  • Page 260: Printer Setting

    Controller Setting 02 Printer Setting Various printer settings are available from this screen. It may not operate properly depending upon the combination of settings selected. Menu Items Description Setting Options (default is italic) Specify the default output setting 1-6 ( for each number.
  • Page 261 Controller Setting Menu Items Description Setting Options (default is italic) 14 Paper Size Select the paper size to be initially A3, B4, A4, B5, A5, 8x13, 8.25x13, used. 8.125x13, 12x18, 11x17, 8.5x14, When specifing tabs, select the 8.5x13, 8.5x11, 5.5x8.5, A3W, number of tabs as well.

  • Page 262: Select Printer Setting

    Controller Setting Menu Items Description Setting Options (default is italic) 01 Print to PS Error Select to print the error report OFF, when an error occurs while raster- izing PostScript data. 04 TIFF Setting 01 Auto Paper Select Select to use APS function. OFF, 02 Image Position Select the image position to be...

  • Page 263: Report Type

    Controller Setting 10.2 01 Report Type Use this function to print out the report type selected from the screen. Procedure Touch [Controller] - [01 Report Type] Touch the desired report type key to select it. Touch [Execute]. The Controller Setting Menu Screen will be restored, and the Data LED on the control panel blinks to indicate that the printing operation is in progress.
  • Page 264 Controller Setting If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. 10-8 Machine name...

  • Page 265: Printer Setting

    Controller Setting 10.3 02 Printer Setting Use this function to register the desired output form. Six types can be spec- ified at maximum. Specify the setting number (1 to 6) first, then specify the following four printer settings for that number. 01 Basic Setting specifies basic settings for printer.
  • Page 266 Controller Setting Use the touch screen keypad to enter the setting number for your setting. Available range is from 1 to 6. Touch [Set] to complete the setting. If wrong number is entered, touch [Reset] to reenter the correct number. Perform the Basic Setting.
  • Page 267 Controller Setting Touch [01 Basic Setting]. The Basic Setting Menu Screen will be dis- played. Make the desired setting. Touch [Next] or [Forward] to scroll to the de- sired item. The following settings are used unless otherwise specified by the print- er driver.
  • Page 268 Controller Setting 20 Booklet: Select to use the Booklet function. 21 Adhesive Binding: Select to use the Adhesive binding mode. 22 Print Position: Select the initial print position. Touch [Return] to complete the setting and restore the Printer Setting Screen. Perform the PCL Setting Touch [02 PCL Setting].
  • Page 269 Controller Setting 03 Symbol Set: Specify the symbol set. 04 Form lines: Specify the number of lines per page. 05 Font point size: Specify the font size by point. 06 Font pitch: Specify the font pitch. 07 CR/LF Mapping: Select the line feed code. Touch [Return] to complete the setting and restore the Printer Setting Screen.
  • Page 270 Controller Setting Touch [OK] to complete the setting. The PS Setting Screen will be re- stored. Touch [Return] to complete the setting and restore the Printer Setting Screen. Perform the TIFF Setting. Touch [04 TIFF Setting]. The TIFF Setting Menu Screen will be dis- played.
  • Page 271 Controller Setting Touch [Return] on the Printer Setting Screen. The Controller Setting Menu Screen will be restored. If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. Machine name 10-15...

  • Page 272: Select Printer Setting

    Controller Setting 10.4 03 Select Printer Setting Select the default port number, and specify the output format for each port. Procedure Touch [Controller] - [03 Select Printer Setting]. Touch the key to be specified, then use the touch screen keypad to en- ter the desired number.
  • Page 273 Controller Setting If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. Machine name 10-17...

  • Page 274: Spool

    Controller Setting 10.5 04 Spool Select to enable, disable, or automatically perform the spool function. Procedure Touch [Controller] - [04 Spool].. Touch the desired key to select it. Touch [OK] to complete the setting. The Controller Setting Menu Screen will be restored. If further changes are required, touch the desired key.

  • Page 275: Interface Setting

    Controller Setting 10.6 05 Interface Setting Set the time for Parallel Timeout and Network Timeout. Procedure Touch [Controller] - [05 Interface Setting]. Touch [Parallel Timeout] or [Network Timeout]. Use the touch screen keypad to enter the time, then touch [Set]. The available range is from 10 to 300.
  • Page 276 Controller Setting If further changes are required, touch the desired key. Touch the [MACHINE] tab to complete the setting and restore the Ma- chine Status Screen. 10-20 Machine name...

  • Page 277: Utility Screen Setting

    Utility Screen Setting...

  • Page 279: Utility Screen Setting Outlines

    The Utility Screen includes two types of setting items: one in which a user can set and the other in which a machine manager is required to enter a password. This section describes the user setting and the machine manager setting separately in two parts. bizhub PRO 1050P 11-3...
  • Page 280 Return and Exit in the Utility screen Touch [Return] to return to the previous screen. Touch [Exit] to return to the screen before pressing [Utility/Counter] on the control panel. 11-4 bizhub PRO 1050P...
  • Page 281 Image Shift Decimal Point Select On/Off to enter a decimal point for image shift. Off/15 seconds/ 30 seconds Printer Prohibit Timer Select the interval time that printing via PC is prohib- seconds/90 seconds ited after touching the touch keys. bizhub PRO 1050P 11-5...
  • Page 282 Output the list of service modes, account values, and ROM version of the machine. Font Patter List Output the list of font patterns used with this machine. Audit Log Report Output the audit log report of the security mode. 11-6 bizhub PRO 1050P...
  • Page 283 13-66.) Set the IPP settings. 04 FTP (For details, refer to “04 FTP” on page 13-69.) Set the FTP settings. 05 SNMP (For details, refer to “05 SNMP” on page 13-71.) Set the SNMP settings. bizhub PRO 1050P 11-7...
  • Page 284 06 System Connection 01 User Call Start Touch [Start] when calling CSRC. 07 Security Setting 01 Machine Manager Password 00000000 Change the machine manager password which is reg- istered in the Service mode menu. 11-8 bizhub PRO 1050P...
  • Page 285 Set the period of time to keep data so that it will be days/7 days/30 days deleted automatically when specified period has passed. 03 Change HDD Lock Password Change the password when accessing data stored in HDD. 03 Security Strengthen mode Set the Security Strengthen mode. bizhub PRO 1050P 11-9...
  • Page 286 Utility Screen Setting 11-10 bizhub PRO 1050P...

  • Page 287: User Setting

    User Setting...

  • Page 289: System Setting

    Select the language used in the touch panel. The initial setting is English. Procedure Touch [01 System Setting] - [01 Language Setting]. Select the desired English mode. Touch [OK] to complete the setting and return to the Utility Menu Screen. bizhub PRO 1050P 12-3...

  • Page 290: Buzzer Setting

    01 Buzzer ON/OFF, Volume Setting Set the buzzer sound (the touch key sound) as touching the screen, and also select the buzzer volume. 12-4 bizhub PRO 1050P...
  • Page 291 [Small] or [Big] to regulate the buzzer volume of the touch keys.Touch [Off] to highlight it. The buzzer will go off. Touch [OK] to complete the setting and return to the Buzzer Setting Screen. Touch [Return] to restore the Utility Menu Screen. bizhub PRO 1050P 12-5...
  • Page 292 User Setting 02 Buzzer for Job Stop Setting Select the duration of the buzzer sound when the machine stops 12-6 bizhub PRO 1050P...
  • Page 293 Touch [01 System Setting] - [02 Buzzer Setting]. Touch [02 Buzzer for Job Stop Setting]. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Buzzer Setting Screen. Touch [Return] to restore the Utility Menu Screen. bizhub PRO 1050P 12-7...

  • Page 294: 1Shot Indication Time

    Procedure Touch [01 System Setting] - [03 1 SHOT Message Indication Time]. Touch [3 seconds] or [5 seconds] to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen. 12-8 bizhub PRO 1050P...

  • Page 295: Default Screen Setting

    Select the initial screen to be displayed when the power switch is turned on. Procedure Touch [01 System Setting] - [04 Default Screen Setting]. Select the desired initial screen to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen. bizhub PRO 1050P 12-9...

  • Page 296: Auto Reset Setting

    Procedure Touch [01 System Setting] - [05 Auto Reset Setting]. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen. 12-10 bizhub PRO 1050P...

  • Page 297: Key Response Time

    Select the response time between touching the key and the machine re- sponses to it. Procedure Touch [01 System Setting] - [06 Key Response Time]. Select the desired time to highlight it. Touch [OK] to complete the setting and return to the Utility Menu Screen. bizhub PRO 1050P 12-11...

  • Page 298: Change User Password

    User Setting 12.1.7 07 Change User Password Change a user password which the user has registered for user authentica- tion. Details The changed password is reflected to the user authentication setting de- scription. 12-12 bizhub PRO 1050P...
  • Page 299 Enter the user name and the password then touch [OK]. Enter a new user password in [New Password]. Reenter the new user password in [Check Input]. Touch [OK] to complete the setting and return to the Utility Menu Screen. bizhub PRO 1050P 12-13...

  • Page 300: Function Setting

    (Auto Tray Switching: ATS) 01 Feed Tray Auto Selection Select the tray size setting to be detected when ATS functions. You may also select the priority of the detection for each tray. 12-14 bizhub PRO 1050P...
  • Page 301 Touch to highlight the desired tray key under [Tray Priority], then change its priority by using the arrow keys (,) and (+). Touch [OK] to complete the setting and return to the Feed Tray Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. bizhub PRO 1050P 12-15...

  • Page 302: Ats Permit

    User Setting 12.2.2 02 ATS Permit Set ATS On or Off. 12-16 bizhub PRO 1050P...
  • Page 303 Select [On] when ATS is used, and [Off] when ATS is not used. Touch [OK] to complete the setting and return to the Feed Tray Setting Menu Screen. Touch [Return] to restore the Utility Menu Screen. bizhub PRO 1050P 12-17...

  • Page 304: Each Function Setting

    Touch [Decimal On] or [Decimal Off] to specify image shift in decimal point or not.Select the desired interval time key of the right side of [Printer Prohibit Timer] to set the timer. Touch [OK] to complete the setting and return to the Utility Menu Screen. 12-18 bizhub PRO 1050P...

  • Page 305: Touch Screen Adjustment

    4, repeat the adjustment pro- cedure from steps 2 to 4 or contact your service representative. Press [1] of the control panel keypad to return to the screen before pressing Utility/Counter on the control panel. bizhub PRO 1050P 12-19...
  • Page 306 User Setting 12-20 bizhub PRO 1050P...

  • Page 307: Machine Manager Setting

    Machine Manager Setting...

  • Page 309: Machine Manager Setting Outlines

    It is recommended to assign the ma- chine manager who will be the sole person to execute operations that are explained in this section. Details Please contact your service representative to set up your machine man- ager password. bizhub PRO 1050P 13-3...
  • Page 310 Machine Manager Setting How to access the Machine Manager Setting Menu Press [Utility/Counter] on the control panel to display the Utility Menu Screen. Touch [04 Machine Manager Setting]. 13-4 bizhub PRO 1050P...
  • Page 311 The Machine Manager Setting Menu is displayed. When the Password Input Screen is displayed, enter the eight-digit ma- chine manager password, then touch [OK] Set each function items. Touch [Return] to restore the Utility Menu Screen. bizhub PRO 1050P 13-5...

  • Page 312: System Setting

    Procedure Touch [01 System Setting] - [01 Power Save Setting]. Specify the Power Save mode to be set manually by pressing [Power Save] on the control panel, by selecting [Auto Low Power or Auto Shut Off]. 13-6 bizhub PRO 1050P...
  • Page 313 Auto Low Power, the period of time for Auto Low Power will be forcibly reset to the same period of time as Auto Shut Off. Auto Low Power will not function. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-7...

  • Page 314: Time And Date Setting

    (in 24-hour expression). Enter the time by using the touch panel keypad. Touch [Set] to move the highlighted section to the number to be changed. Repeat the same procedure for month, date, and time. 13-8 bizhub PRO 1050P...
  • Page 315 (e.g. Enter “-0600” for six hours later than the Universal time.) Touch [OK] to return to the Time and Date Setting Screen. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-9...

  • Page 316: Weekly Timer Setting

    If the Weekly Timer needs to be activated on your machine, contact your service representative. Conditions required to use the Weekly Timer - The power plug is inserted into the socket. - The power switch is turned on. - The current date and time are correctly set. 13-10 bizhub PRO 1050P...
  • Page 317 Machine Manager Setting 01 Weekly Timer On/Off Setting Enable and disable the Weekly Timer function. bizhub PRO 1050P 13-11...
  • Page 318 Off] to deactivate Weekly Timer. The default setting is [Weekly Timer Off]. The selected key will be highlighted. Touch [OK] to complete the setting and return to the Weekly Timer Set- ting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 13-12 bizhub PRO 1050P...
  • Page 319 Use this function to set the On/Off times in hours and minutes for each day of the week or set the collective time for the entire week, i.e., the same On/ Off time for a certain day of the week. bizhub PRO 1050P 13-13...
  • Page 320 When setting Sunday Off-time, Monday On-time is highlighted again. To set the On/Off time collectively for more than one day of the week, touch [Block Set] to display the Weekly Timer On/Off Time Collective Setting Screen. 13-14 bizhub PRO 1050P...
  • Page 321 Weekly Timer setting changes are required, select the desired menu item from 1 to 5. Touch [OK] to complete the setting and return to the Weekly Timer Set- ting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-15...
  • Page 322 Use this function to set the timer On/Off for a given day of a given month. Set the On-Off condition for specific days individually or collectively for all Mon- days through Sundays of the given month. Note The default setting is collective: On for Mondays through Saturdays, and Off for Sundays. 13-16 bizhub PRO 1050P...
  • Page 323 The Timer Action On/Off Setting Screen will be restored. Touch [OK] on the Timer Action On/Off Setting Screen to complete the setting and return to the Weekly Timer Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-17...
  • Page 324 Lunch Hour Off Setting to shut down the power during the lunch break and then turn it on again according to the Weekly Timer function setting. Only one off-time interval can be programmed. Note The factory default setting is [Function Invalid]. 13-18 bizhub PRO 1050P...
  • Page 325 Touch [OK] to complete the setting and return to the Weekly Timer Set- ting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-19...
  • Page 326 05 Set Password for Timer Interrupt Use this password setting mode to establish a four-digit password required for using the Timer Interrupt function. The default password of 0000 allows the timer function to be interrupted without entering the password. 13-20 bizhub PRO 1050P...
  • Page 327 (a period of time to turn the machine power on). Touch [OK] to complete the setting and return to the Weekly Timer Set- ting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-21...

  • Page 328: Management List Print

    13.2.4 04 Management List Print Use this function to print out the list selected from the following items. User management list Home position settings selected by user Use management list Information controlled by user authentication or division authentication 13-22 bizhub PRO 1050P...
  • Page 329 Machine Manager Setting Font pattern list Font patterns used in the machine bizhub PRO 1050P 13-23...
  • Page 330 Machine Manager Setting Audit log report Audited log 13-24 bizhub PRO 1050P...
  • Page 331 To suspend printing, press [Stop]. Touch the [UTILITY] tab to return to the Management List Print Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. Note Mode memory list can be selected to print out but its contents are not supported in this machine. bizhub PRO 1050P 13-25...

  • Page 332: Manager/Machine Register

    Machine Manager Setting 13.3 02 Manager/Machine Register 13.3.1 01 Machine Manager Register Use this function to register the machine manager name and the extension number which are displayed on the left side of the Utility Menu Screen. 13-26 bizhub PRO 1050P...
  • Page 333 Utility Menu Screen. The number which is entered will be displayed from the last digit, and it is shifted leftward as a next number is entered. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-27...

  • Page 334: Use Auth./Volume Track

    1,000 will be dis- tributed as user authentication. Details It is recommended to distribute authentication for both the user and the section, otherwise either party cannot be assigned authentication if it is distributed to only one party. 13-28 bizhub PRO 1050P...
  • Page 335 Machine Manager Setting bizhub PRO 1050P 13-29...
  • Page 336 Enter the number to distribute using the keypad or the arrow keys (,) and (+), then touch [OK]. Touch [OK] to complete the setting and return to the Authentication Method Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 13-30 bizhub PRO 1050P...
  • Page 337 The message “Print limit reached” is displayed, and the machine stops its operation. When [Warning Only] is selected, the message “Print limit reached” is dis- played as reaching the print limit, and the next job can be continuously exe- cuted. bizhub PRO 1050P 13-31...
  • Page 338 Select [Immediately], [After Print], or [Warning Only] on the right side of [Limit Reached Stop Setting]. Touch [OK] to complete the setting and return to the Authentication Method Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 13-32 bizhub PRO 1050P...

  • Page 339: Volume Track

    Use this function to assign a number to each section, and set a section name, password and limit value to each number. The registered section management setting is listed on the screen. Select the section management setting from the list and change, reset or delete the setting. bizhub PRO 1050P 13-33...
  • Page 340 Machine Manager Setting 13-34 bizhub PRO 1050P...
  • Page 341 Machine Manager Setting bizhub PRO 1050P 13-35...
  • Page 342 Touch [Section Name] to display the input screen. Enter the section name and touch [OK]. You may enter eight characters for the sec- tion name. For the details on entering texts in the input screen, see the appendix. 13-36 bizhub PRO 1050P...
  • Page 343 Touch any key to reset. Touch [Cancel] when not resetting. Touch [OK] to complete the setting and return to the Authentication Method Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-37...

  • Page 344: User Authentication Set

    Use this function to assign a number to each user, and set a user name, password and limit value to each number. The registered user setting is listed on the screen. Select the user setting from the list and change, reset or delete the setting. 13-38 bizhub PRO 1050P...
  • Page 345 Machine Manager Setting bizhub PRO 1050P 13-39...
  • Page 346 Machine Manager Setting 13-40 bizhub PRO 1050P...
  • Page 347 Touch [Belong Section] to display the screen to select a section be- long to.Touch [Next] or [Previous] to display the desired section name, touch to highlight it, then touch [OK]. bizhub PRO 1050P 13-41...
  • Page 348 Touch [Next] or [Previous] to display the user name to reset the count and touch to highlight it. Touch [Count Reset] to display the Reset Confirmation popup screen. Touch any key to reset. Touch [Cancel] when not resetting. 13-42 bizhub PRO 1050P...
  • Page 349 Touch any key to reset. Touch [Cancel] when not resetting. Touch [OK] to complete the setting and return to the Authentication Method Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-43...

  • Page 350: Non Register/Output Set

    Touch [On] to activate this function, or touch [Off] to deactivate this function. Touch [OK] to complete the setting and return to the Authentication Method Setting Menu Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. 13-44 bizhub PRO 1050P...

  • Page 351: Network Setting

    Machine Manager Setting 13.5 04 Network Setting 13.5.1 01 Machine NIC Setting Control the NIC settings such as the IP address and line speed of the ma- chine. bizhub PRO 1050P 13-45...
  • Page 352 Enter the IP address of the PC on which PageScope Job Editor Server is installed. Line Speed Setting Specify the line speed of the network. Choose from the options pro- vided. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 13-46 bizhub PRO 1050P...

  • Page 353: Controller Nic Setting

    Specify RAW port numbers and to be used or not. (Set between 1 - 65535.) TCP/IP Filter permission settings * Specify to use the permission settings or not, and the range in which to permit connections. 0.0.0.0 - 0.0.0.0 (0 - 255) bizhub PRO 1050P 13-47...
  • Page 354 * 2:The functions that are affected by the permission and denial settings are as follows: HTTP servers (PSWC, IPP), HTTP servers (PSWC with SSL), printing over the network (LPD, RAW Port, SMB), SNMP 13-48 bizhub PRO 1050P...
  • Page 355 Printer Name Specify the printer name. It is initially set to a partic- ********** ular printer name allocated to the machine. Varied from machine to machine. Max. 63 characters combining symbols and alphanumerics can be used. bizhub PRO 1050P 13-49...
  • Page 356 NetWare Nprinter / Rprinter, NetWare Status Setting (continued) Select between 0 and 255. Printer Number Specify the printer number. File Server Name Specify file server names. Max. 10 servers can be displayed. Queue Name Specify queue names. Max. 10 queues can be displayed. 13-50 bizhub PRO 1050P...
  • Page 357 Specify the place in which to install the printer. symbols and alphanumerics can be used. Printer Information Max. 127 characters combining Specify printer information. symbols and alphanumerics can be used. Printer URI Printer URI's are set. Max. 8 addresses bizhub PRO 1050P 13-51...
  • Page 358 Max. 13 characters combining Print Service Name Specify a print service name. symbols and alphanumerics can be used. Work Group Max. 15 characters combining Specify a work group name. symbols and alphanumerics can be used. 13-52 bizhub PRO 1050P...
  • Page 359 E-Mail Send Maximum Size Specify to set the maximum size for e-mail trans- 0(Off) - 100Mb ( mission. Authentication Setting POP before SMTP Specify to use the POP before SMTP authentica- tion. Specify as required in your own environment. bizhub PRO 1050P 13-53...
  • Page 360 Not Use Port No. Specify the number of port that is used to commu- 1 - 65535 ( nicate with the POP server. Connection Time Out Time Specify the time out duration. 30 - 300 seconds ( 13-54 bizhub PRO 1050P...
  • Page 361 Specify the duration used for POP before SMTP. 0 - 60 seconds ( SMTP Authentication User Name Max. 63 characters combining If Authentication Setting SMTP Authentication symbols and alphanumerics can set to , specify a user name. be used. bizhub PRO 1050P 13-55...
  • Page 362 Enable the setting to block access to this I / F. /Off IS OpenAPI Login Name Max. 8 characters combining sym- Required if the IS OpenAPI Authentication is set to bols and alphanumerics can be used. 13-56 bizhub PRO 1050P...
  • Page 363 Specify the Network Setting Clear setting. For details, refer to “13 Network Setting Clear” on page 13-93. Specific setting and Description Setting options (italic: default) 13 Network Setting Clear Initialize Execute Restore the initial network settings specified at the time of shipment. bizhub PRO 1050P 13-57...
  • Page 364 Machine Manager Setting 01 TCP/IP Specify the settings for connecting a network printer, and the settings for TCP/IP, RAW port numbers, IP Filter (permission/denial), and ping. 13-58 bizhub PRO 1050P...
  • Page 365 Machine Manager Setting bizhub PRO 1050P 13-59...
  • Page 366 Touch [DNS Host Name] to display the input screen. After entering in the field, touch [OK]. DNS Domain Name Touch [DNS Domain Name] to display the input screen. After enter- ing in the field, touch [OK]. Select [Enable] or [Disable]. 13-60 bizhub PRO 1050P...
  • Page 367 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. bizhub PRO 1050P 13-61...
  • Page 368 Machine Manager Setting 02 NetWare Specify the settings for connecting network printer, and the NetWare set- tings. Where Novell NetWare is not used, make sure that [Not Use] is selected. 13-62 bizhub PRO 1050P...
  • Page 369 Machine Manager Setting bizhub PRO 1050P 13-63...
  • Page 370 NetWare Nprinter/Rprinter, NetWare Status Setting Printer Name Touch [Printer Name] to display an input screen. After entering in the field, touch [OK]. Printer Number Touch [Printer Number] to display an input screen. After entering in the field, touch [OK]. 13-64 bizhub PRO 1050P...
  • Page 371 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. bizhub PRO 1050P 13-65...
  • Page 372 Machine Manager Setting 03 IPP Specify the settings for connecting network printer and the IPP settings 13-66 bizhub PRO 1050P...
  • Page 373 Machine Manager Setting bizhub PRO 1050P 13-67...
  • Page 374 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 13-68 bizhub PRO 1050P...
  • Page 375 Machine Manager Setting 04 FTP Specify to use a machine as an FTP server. bizhub PRO 1050P 13-69...
  • Page 376 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 13-70 bizhub PRO 1050P...
  • Page 377 Machine Manager Setting 05 SNMP Specify the SNMP settings. bizhub PRO 1050P 13-71...
  • Page 378 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 13-72 bizhub PRO 1050P...
  • Page 379 Machine Manager Setting 06 SMB Specify the SMB printing setting. bizhub PRO 1050P 13-73...
  • Page 380 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 13-74 bizhub PRO 1050P...
  • Page 381 Machine Manager Setting 07 AppleTalk Specify the settings for connecting network printer and the ApplieTalk set- tings. bizhub PRO 1050P 13-75...
  • Page 382 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 13-76 bizhub PRO 1050P...
  • Page 383 Machine Manager Setting 08 E-Mail Specify the settings for an e-mail send/receive, division for transmitted data and authentication. bizhub PRO 1050P 13-77...
  • Page 384 Machine Manager Setting 13-78 bizhub PRO 1050P...
  • Page 385 [OK]. E-Mail Send Maximum Size Touch [E-Mail Send Maximum Size] to display an input screen. Af- ter entering in the field, touch [OK]. Authentication Setting Select [Off], [POP before SMTP], or [SMTP Auth].. bizhub PRO 1050P 13-79...
  • Page 386 Touch [Return] on the E-Mail Setting Menu Screen to specify other set- tings, or touch [Exit] to finish setting. After you have changed the settings, turn off the sub power, then turn off and on the main power. 13-80 bizhub PRO 1050P...
  • Page 387 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. bizhub PRO 1050P 13-81...
  • Page 388 Machine Manager Setting 09 Alert Mail Specify the settings for e-mail error notification. 13-82 bizhub PRO 1050P...
  • Page 389 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. bizhub PRO 1050P 13-83...
  • Page 390 Machine Manager Setting 10 CSRC CS Remote Care includes service tools, which you do not necessarily have to set. Contact your service representative for details. 13-84 bizhub PRO 1050P...
  • Page 391 Machine Manager Setting bizhub PRO 1050P 13-85...
  • Page 392 Touch [SMTP Server Address] to display an input screen. After en- tering in the field, touch [OK]. Port Number Touch [Port No.] to display an input screen. After entering in the field, touch [OK]. The range to be used is between 1 and 65535. 13-86 bizhub PRO 1050P...
  • Page 393 Touch [Password] to display an input screen. After entering in the field, touch [OK]. APOP Select [On] or [Off]. Port Number Touch [Port No.] to display an input screen. After entering in the field, touch [OK]. bizhub PRO 1050P 13-87...
  • Page 394 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 13-88 bizhub PRO 1050P...
  • Page 395 Machine Manager Setting 11 IS OpenAPI Specify the settings for Imaging Solution OpenAPI (IS OpenAPI). bizhub PRO 1050P 13-89...
  • Page 396 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 13-90 bizhub PRO 1050P...
  • Page 397 Machine Manager Setting 12 PSWC Specify to use PageScope Web Connection (PSWC). bizhub PRO 1050P 13-91...
  • Page 398 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 13-92 bizhub PRO 1050P...
  • Page 399 Machine Manager Setting 13 Network Setting Clear Recover the initial network settings specified at the time of shipment. bizhub PRO 1050P 13-93...
  • Page 400 When you turn off and on the main power, you need to wait at least 10 seconds to turn on after turning off. If you do not allow a sufficient interval in between, the machine may not run correctly. 13-94 bizhub PRO 1050P...

  • Page 401: Printer Setting

    Set the machine to offset the copies/printouts of different jobs. Procedure Touch [05 Printer Setting] - [01 JOB Offset Operating]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-95...

  • Page 402: Continuation Print(Print)

    Set the machine to output multiple reserved print jobs in succession. Procedure Touch [05 Printer Setting] - [02 Continuation Print(Print)]. Touch [On] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 13-96 bizhub PRO 1050P...

  • Page 403: Page No. Position (Booklet)

    Booklet with Page Numbering in Stamp. Procedure Touch [05 Printer Setting] - [03 Page No. Position (Booklet)]. Touch [On(Outside Page Print)] or [Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-97...

  • Page 404: Fixing Prerotation Set

    Procedure Touch [05 Copy/Printer Setting - [04 Fixing Prerotation Set. Touch [Rotation On] or [Rotation Off] to highlight it. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 13-98 bizhub PRO 1050P...
  • Page 405 Machine Manager Setting Note If pressing [Start] after altering the paper type and weight when [Rotation On] is selected, the message “Machine is warming up.” Is displayed. Please wait until printing is enabled. bizhub PRO 1050P 13-99...

  • Page 406: System Connection

    The monitored information will be useful for maintenance. Procedure Touch [06 System Connection] - [01 User Call]. Touch [Start]. Touch [Return] to restore the Machine Manager Setting Menu. 13-100 bizhub PRO 1050P...

  • Page 407: Security Setting

    Machine Manager Setting 13.8 07 Security Setting 13.8.1 01 Machine Manager Password Set the new machine manager password. bizhub PRO 1050P 13-101...
  • Page 408 Touch [07 Security Setting] - [01 Machine Manager Password]. Touch [Input Manager Password] to display the Input Manager Pass- word Screen. Enter the new password. Touch [OK]. Touch [OK] to complete the setting and return to the Machine Manager Setting Menu Screen. 13-102 bizhub PRO 1050P...

  • Page 409: Hdd Management Setting

    The user can create a folder or a box when saving images in a personal, pub- lic or confidential folder. The machine manager can refer to the name, pass- word, number or creation time of the folder created by the user, and delete the folder or box if necessary. bizhub PRO 1050P 13-103...
  • Page 410 Machine Manager Setting 13-104 bizhub PRO 1050P...
  • Page 411 Touch [Delete] to display the Delete Confirmation popup screen. Touch [Yes] to delete, or touch [No] to suspend deleting. Touch [OK] to complete the setting and return to the HDD Management Setting Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-105...
  • Page 412 02 HDD Data Auto Delete Period Setting Specify the period of time (12 hours to 30 days) to keep data so that it will be deleted automatically when specified period has passed. The initial setting is Not Delete. 13-106 bizhub PRO 1050P...
  • Page 413 Touch [Not Delete] to highlight it when not setting the automatically de- leting period. Touch [OK] to complete the setting and return to the HDD Management Setting Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-107...
  • Page 414 Machine Manager Setting 03 Change HDD Lock Password Change the HDD lock password. Note The HDD Lock Password cannot be changed unless the Security Strengthen mode is set to On. 13-108 bizhub PRO 1050P...
  • Page 415 Touch [Check Input] to enter the same new password, then touch [OK]. Touch [OK] to complete the setting and return to the HDD Management Setting Screen. Touch [Return] to restore the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-109...

  • Page 416: Security Strengthen Mode

    Set the Security Strengthen mode On/Off. Note In order to set the Security Strengthen mode to On, it is required by your service representative to set a CE password and a machine manager password to your machine. 13-110 bizhub PRO 1050P...
  • Page 417 Touch [Yes] to complete the setting. The machine power will be turned off, then on. Touch [No] to cancel the setting. Touch [Cancel] at the lower right side of the screen to restore the Machine Manager Setting Menu Screen. bizhub PRO 1050P 13-111...
  • Page 418 Machine Manager Setting 13-112 bizhub PRO 1050P...

  • Page 419: Browser Control Setting

    Browser Control Setting...

  • Page 421: About Pagescope Web Connection

    About PageScope Web Connection PageScope Web Connection is a device control utility program provided by the HTTP server built into the image controller of the KONICA MINOLTA bizhub PRO 1050. This utility can be used with a Web browser to display the status of the bizhub PRO 1050 printer and network, and to change default and network settings.

  • Page 422: Web Browser Settings

    Netscape Navigator Select [Preferences] under [Edit]. Click [Advanced] and then click [Cache]. Check [Every time I view the page] under [Compare the page in the cache to the page on the network:]. 14-4 bizhub PRO 1050P...

  • Page 423: Access

    When the IP address of the image controller is 192.168.0.10: http://192.168.0.10 The PageScope Web Connection screen appears. Operation PageScope Web Connection operation is identical to Internet Web pages. You can click a link on the Web page to jump to the link destination. bizhub PRO 1050P 14-5...

  • Page 424: Screen Configuration

    If user authentication is set, the user name and password entry screen will appear. KONICA MINOLTA PageScope Web Connection Logo Click the KONICA MINOLTA logo to jump to the Konica Minolta web site. http://konicaminolta.jp Click the PageScope Web Connection logo to jump to the About Screen, providing the version information and the copyright description.
  • Page 425 For the details of each menu, see the following sections. Information and Setting Details Displays the details of the selected menu. Help If an online manual URL has been set, the online manual will appear. For details, refer to “Online Assistance” on page 14-13. bizhub PRO 1050P 14-7...

  • Page 426: Logging In Using Administrator Mode

    [System] area of Administrator Mode. For details, refer to “System Tab” on page 14-10. You can also change it using the touch panel of the main body. Contact your service store for de- tails. 14-8 bizhub PRO 1050P...
  • Page 427 In order to ensure the security against data used in Administrator Mode, set SSL. SSL can be set on the [Network] tab of Administrator Mode. For details on the SSL setting, refer to “SSL/TLS” on page 14-36. bizhub PRO 1050P 14-9...

  • Page 428: Administrator Mode

    Retype New Password: Retype the new password as entered above for confirmation. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered or selected. 14-10 bizhub PRO 1050P...

  • Page 429: Device Information

    Click [Device Information] on the [System] tab of the User Mode Screen to display this screen. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. bizhub PRO 1050P 14-11...

  • Page 430: Rom Version

    Browser Control Setting 14.5.3 ROM Version This screen appears when you click [ROM Version] on the [System] tab. It shows the ROM version of the copier, the firmware version of the controller, and other information. 14-12 bizhub PRO 1050P...

  • Page 431: Online Assistance

    Online Help URL: Enter the online manual URL. Maximum 127 alphanumeric characters can be used. There are two choices: – Accessing the manual on the Internet posted on the Konica Minolta web- site: Enter: http://pagescope.com/download/webconnection/onlinehelp/ pro1050/help.html. bizhub PRO 1050P 14-13...
  • Page 432 Click the button to clear the settings that were entered or selected. Note If the online manual URLs are not used, users must save the online help file on their PCs. In this case, the [Help] button will not function. 14-14 bizhub PRO 1050P...

  • Page 433: Import/Export

    (The file format must be con- firmed.) [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered or selected. bizhub PRO 1050P 14-15...

  • Page 434: Maintenance

    Click [OK] to clear. Details It may take few minutes for clearing the network settings. After clearing the settings is completed, you can access the network again. When you use the network, restart the Web browser. 14-16 bizhub PRO 1050P...
  • Page 435 Click the [Reset] button to restart the network only to enable new pa- rameters. Details It may take few minutes for resetting the network. After resetting the net- work, you can access the network again. When you use the network, re- start the Web browser. bizhub PRO 1050P 14-17...

  • Page 436: Alert Mail

    Enter the e-mail address to which to send alert mail. Maximum 250 char- acters can be used. Alert: Choose notification items. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered or selected. 14-18 bizhub PRO 1050P...

  • Page 437: Print Tab

    Set parallel port timeout (10-300 seconds). Network Timeout: Set receive network timeout (10-300 seconds). [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. bizhub PRO 1050P 14-19...
  • Page 438 - RAW port number List the RAW port numbers 1 to 6 that are set in [TCP/IP] on the [Network] tab. Status Show enable or disable of each RAW port. 14-20 bizhub PRO 1050P...

  • Page 439: Default Settings

    Paper Size, Orientation, Resolution, Spool Setting, Banner Option, Banner Page Tray, Convert Paper Size, 1 Page/Sheet, Booklet, Print Po- sition. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. bizhub PRO 1050P 14-21...
  • Page 440 These settings also appear if you select Controller Settings on the touch pan- el's Device Status screen - 02 Printer Settings - 03 PCL Settings. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 14-22 bizhub PRO 1050P...
  • Page 441 Select whether or not to print the error report when an error occurs while rasterizing PostScript data. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. bizhub PRO 1050P 14-23...
  • Page 442 Device Status screen - 02 Printer Settings - 04 TIFF Settings. Enter for individual items. Auto Paper Select, Image Position. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 14-24 bizhub PRO 1050P...

  • Page 443: Network Tab

    TCP/IP, Speed, Auto IP, IP Address, Subnet Mask, Default Gateway, RAW Port Number 1-6, Host Name, Domain Name, DNS Server, LPD. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. bizhub PRO 1050P 14-25...
  • Page 444 Enter for individual items. Access Permission Addresses and their ranges, Access Refusal Ad- dresses and their ranges. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were selected. 14-26 bizhub PRO 1050P...

  • Page 445: Netware

    - Enter for individual items. NetWare Print Frame Type Mode Pserver Print Server Name Print Server Password Print Queue Scan Rate Bindery/NDS Bindery Preferred File Server Preferred NDS Context Name Preferred NDS Tree Name Nprinter/Rprinter Printer Name Printer Number bizhub PRO 1050P 14-27...
  • Page 446 Click the button to clear the settings that were selected. NetWare Status This screen appears when you click [NetWare Status] under the [NetWare] menu on the [Network] tab. This screen is used to confirm NetWare status. 14-28 bizhub PRO 1050P...

  • Page 447: Ipp

    Enter for individual items. IPP Print, Printer Name, Printer Location, Printer Information, Operations Supported. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. bizhub PRO 1050P 14-29...

  • Page 448: Ftp

    FTP server. FTP Server: Select enable or disable. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 14-30 bizhub PRO 1050P...

  • Page 449: Snmp

    SNMP. SNMP: Select enable or disable. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. bizhub PRO 1050P 14-31...

  • Page 450: Smb

    Enter for individual items. SMB Print, NetBIOS Name, Print Service Name, Work Group. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 14-32 bizhub PRO 1050P...

  • Page 451: Apple Talk

    Enter for individual items. Apple Talk, Printer Name, Zone Name. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. bizhub PRO 1050P 14-33...

  • Page 452: E-Mail

    Receive, Receiving Server Address, User Name, Password, APOP Au- thentication, Connection Timeout, Port Number. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 14-34 bizhub PRO 1050P...
  • Page 453 POP Before SMTP, SMTP Authentication, User Name, Password, Realm, Binary Division, Division Size. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. bizhub PRO 1050P 14-35...

  • Page 454: Ssl/Tls

    This screen appears when you click [SSL/TLS] on the [Network] tab. The screen is used to enter and confirm settings concerning SSL/TLS. You can configure them separately depending whether or not certificates are in- stalled. Creating a self-signed certificate 14-36 bizhub PRO 1050P...
  • Page 455 Following the screen indicating that the certificate is being created, an- other screen appears, saying, "The certificate has been created. SSL/ TLS can now be used." Click [OK]. It will take you back to the SSL/TLS Information screen of the self- signed certificate. bizhub PRO 1050P 14-37...
  • Page 456 Browser Control Setting Requesting a certificate to install 14-38 bizhub PRO 1050P...
  • Page 457 Browser Control Setting bizhub PRO 1050P 14-39...
  • Page 458 The certificate installation screen appears. Enter the data of the certificate that you requested. Click [Next]. The Encryption Strength Setting and the Mode using SSL/TLS screen appears. Enter discretionary settings, and click [Create]. Creation results appear. 14-40 bizhub PRO 1050P...
  • Page 459 Browser Control Setting Click [OK]. It will take you back to the SSL/TLS Information screen. bizhub PRO 1050P 14-41...
  • Page 460 Browser Control Setting Requesting a certificate to switch information 14-42 bizhub PRO 1050P...
  • Page 461 Browser Control Setting bizhub PRO 1050P 14-43...
  • Page 462 Enter the data of the certificate that you requested. Click [Next]. The Encryption Strength Setting and the Mode using SSL/TLS screen appears. Enter discretionary settings, and click [Create]. Creation results appear. Click [OK]. It will take you back to the SSL/TLS Information screen. 14-44 bizhub PRO 1050P...
  • Page 463 Browser Control Setting Changing mode settings Changing encryption strength setting bizhub PRO 1050P 14-45...
  • Page 464 Check [Set a Encryption Strength], and click [Next]. The Encryption Strength Setting screen appears. Select a discretionary value. Click [Create]. The completion screen appears. Click [OK]. It will take you back to the SSL/TLS Information screen. 14-46 bizhub PRO 1050P...
  • Page 465 Browser Control Setting Changing mode using SSL/TLS bizhub PRO 1050P 14-47...
  • Page 466 Check [Mode using SSL/TLS], and click [Next]. The Mode using SSL/TLS screen appears. Select a discretionary mode, and click [Create]. The completion screen appears. Click [OK]. It will take you back to the SSL/TLS Information screen. 14-48 bizhub PRO 1050P...
  • Page 467 Browser Control Setting Removing a certificate bizhub PRO 1050P 14-49...
  • Page 468 The SSL/TLS Setting screen appears. Check [Remove a Certificate], and click [Next]. The Remove a Certificate screen appears. Click [Remove]. The removal confirmation screen appears. Click [OK]. It will take you back to the SSL/TLS Information screen. 14-50 bizhub PRO 1050P...

  • Page 469: Authentication

    The screen is used to enter and confirm settings concerning logout time. - Enter for individual items. Admin Logout Time, User Logout Time. [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. bizhub PRO 1050P 14-51...
  • Page 470 IS OpenAPI. - Enter for individual items. Port Number, Use SSL/TLS, Port Number (SSL/TLS). [Apply] button: Click the button to apply the new settings. [Clear] button: Click the button to clear the settings that were entered. 14-52 bizhub PRO 1050P...

  • Page 471: Security

    Security...
  • Page 473 - Controller control program (IP Controller Control P1) version: 10-0000 or later About the ROM version display function: The bizhub PRO 1050P Control Software (Image control program / Controller control program) version mentioned above can be confirmed by using the service representative (CE) service mode ROM version display function.

  • Page 474: Security Functions

    Security 15.1 Security Functions The bizhub PRO 1050P device has two security modes. Normal mode Use this mode if the machine is used by a single person and there is a low possibility of illicit access and operations. This is the default mode when shipped from the factory.

  • Page 475: Environments In Which Security Strengthen Mode Is Recommended

    (CE). Clearly state in the service contract that the service rep- resentative will not engage in any fraudulent actions. Secure LAN We recommend that you use an apparatus such as WEP code (802.11x) to prevent tapping during communication when setting up a local area network. bizhub PRO 1050P 15-5...

  • Page 476: Security Strengthen Mode

    This log will be overwritten if the audit area is depleted. 15-6 bizhub PRO 1050P...
  • Page 477 Manager authentication, the setting change of various machine functions will be available on the machine. - Be sure to exit the Machine Manager Setting mode if you leave in front of the machine while using the Machine Manager Setting mode. bizhub PRO 1050P 15-7...

  • Page 478: Data Protected By Security Strengthen Mode

    If Security Strengthen mode is OFF, data can potentially be accessed, so be careful. If data is accessed in Security Strengthen mode, the machine manager may not notice until he/she analyzes the audit log. Be careful when the machine manager is absent for a long time. 15-8 bizhub PRO 1050P...

  • Page 479: Protect And Delete Data After Use

    - Data in the Box will be overwritten when a delete order is issued. - If data is sent externally, it will be overwritten when the transmission is complete. - If the machine manager issues a delete order for each Box, it will be over- written. bizhub PRO 1050P 15-9...

  • Page 480: User Authentication In Security Strengthen Mode

    HDD, all authentication operations with password will be saved in an au- dit log. Initially, the user authentication is not available on the machine. To acti- vate this function, the distribution number for each section should be changed. For details, see the User’s guide of main body. 15-10 bizhub PRO 1050P...

  • Page 481: To Register A User

    Touch [04 Machine Manager Setting]. The Input Password Screen will be displayed. Enter the password. Use the touch screen keypad to enter the 8-digit Machine Manager pass- word, then touch OK. The Machine Manager Setting Menu Screen will be displayed. bizhub PRO 1050P 15-11...
  • Page 482 Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. Touch [03 User Auth./Volume Track]. Touch [03 User Authentication Set]. The User Authentication Setting Screen will be displayed. 15-12 bizhub PRO 1050P...
  • Page 483 Security Touch [Add] to display the User Registration Screen. Touch [User No.], [User Name], [Password], or [Belong Section] to dis- play each subsequent screen, then make the desired setting. bizhub PRO 1050P 15-13...
  • Page 484 Touch [OK] to return to the User Registration Screen. To enter the User Name: Touch [User Name] on the User Registration Screen. Enter the desired user name from the screen keypad. Touch [OK] to return to the User Registration Screen. 15-14 bizhub PRO 1050P...
  • Page 485 Touch the desired section key to highlight it. Touch [OK] to return to the User Registration Screen. Touch [OK]. When settings are completed, touch [OK] on the User Registration Screen. The User Authentication Setting Screen will be restored. bizhub PRO 1050P 15-15...

  • Page 486: To Change A User

    Touch [04 Machine Manager Setting]. The Input Password Screen will be displayed. Enter the password. Use the touch screen keypad to enter the 8-digit Machine Manager password, then touch [OK]. The Machine Manager Setting Menu Screen will be displayed. 15-16 bizhub PRO 1050P...
  • Page 487 Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. Touch [03 User Auth./Volume Track]. Touch [03 User Authentication Set]. The User Authentication Setting Screen will be displayed. bizhub PRO 1050P 15-17...
  • Page 488 Touch the user name to be changed. Touch [Change]. The Change Registered User Screen will be dis- played. Touch [User Name], [Password], or [Belong Section] to display each subsequent screen, then make the desired setting change. 15-18 bizhub PRO 1050P...
  • Page 489 To change the Password: (Touch [Password] on the User Registration Screen. Enter the desired password from the screen keypad. Touch [OK] to return to the Change Registered User Screen. Note The current password cannot be used again. bizhub PRO 1050P 15-19...
  • Page 490 Touch the desired section key to highlight it. Touch [OK] to return to the Change Registered User Screen. Touch [OK]. When settings are completed, touch [OK] on the Change Registered User Screen. The User Authentication Setting Screen will be restored. 15-20 bizhub PRO 1050P...

  • Page 491: To Delete A User

    Touch [04 Machine Manager Setting]. The Input Password Screen will be displayed. Enter the password. Use the touch screen keypad to enter the 8-digit Machine Manager password, then touch [OK]. The Machine Manager Setting Menu Screen will be displayed. bizhub PRO 1050P 15-21...
  • Page 492 Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. Touch [03 User Auth./Volume Track]. Touch [03 User Authentication Set]. The User Authentication Setting Screen will be displayed. 15-22 bizhub PRO 1050P...
  • Page 493 Touch [Delete]. The popup menu will be displayed to confirm that the selected user will be deleted. Touch [Yes] to delete the selected user name, password, and also the Personal Folder that belongs to the deleted user. bizhub PRO 1050P 15-23...

  • Page 494: To Change Password By User

    We recommend that a user himself/herself changes the password assigned by the machine manager for security. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [01 System Setting]. The System Setting Menu Screen will be displayed. 15-24 bizhub PRO 1050P...
  • Page 495 [OK] key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. bizhub PRO 1050P 15-25...
  • Page 496 Details If password setup doesn’t proceed successfully, the information will be saved in the audit log. The password currently used cannot be entered as a new password. Touch [Exit]. The Machine Status Screen will be restored. 15-26 bizhub PRO 1050P...

  • Page 497: Hdd Store Function In Security Strengthen Mode

    For details on storing data into the HDD, refer to “02 Each Function Setting” on page 12-18. If the Security Strengthen mode is turned off temporarily for some reason, the machine manager should tell that to all users. bizhub PRO 1050P 15-27...

  • Page 498: Machine Manager Security Functions

    The following is an explanation of how to turn Security Strengthen mode ON/ OFF. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [04 Machine Manager Setting]. The Input Password Screen will be displayed. 15-28 bizhub PRO 1050P...
  • Page 499 OK key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. bizhub PRO 1050P 15-29...
  • Page 500 Security Touch [07 Security Setting]. Touch [03 Security Strengthen Mode]. 15-30 bizhub PRO 1050P...
  • Page 501 If you want to turn it OFF, touch [Off] to highlight it. Touch [OK]. The Restart Confirmation popup screen will appear. Touch [Yes]. The machine will restart and the new setting will be activated. bizhub PRO 1050P 15-31...

  • Page 502: Hdd Lock Password

    ON. When turned OFF, the message “Please set Security Strengthen mode” will be displayed. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [06 Machine Manager Setting]. The Input Password Screen will be displayed. 15-32 bizhub PRO 1050P...
  • Page 503 OK key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. bizhub PRO 1050P 15-33...
  • Page 504 Security Touch [07 Security Setting]. Touch [02 HDD Management Setting]. The HDD Management Setting Menu Screen will be displayed. 15-34 bizhub PRO 1050P...
  • Page 505 The main body serial number will be printed at the upper right corner of the audit log. For details, refer to “Print audit log” on page 15-37. If authentication is succeeded, touch [New Password] to enter the new password. The key will not be active until authentication is succeeded. bizhub PRO 1050P 15-35...
  • Page 506 The current password cannot be used again as a new password. Touch [OK] to return to the previous screen. Touch [Check Input] to re-enter the same password as above. Touch [OK] to return to the previous screen. Touch [OK]. 15-36 bizhub PRO 1050P...

  • Page 507: Print Audit Log

    All the audit log data can be output as follows. Procedure Press [Utility/Counter] on the control panel to display the Utility Screen. Touch [04 Machine Manager Setting]. The Input Password Screen will be displayed. Enter the password. bizhub PRO 1050P 15-37...
  • Page 508 OK key is touched, the warning message "Password does not match" will appear, and no key will work for five seconds. Enter the right password after five seconds. If authentication fails, the information will be saved in the audit log. Touch [01 System Setting]. 15-38 bizhub PRO 1050P...
  • Page 509 Security Touch [04 Management List Print]. Touch [Audit Log Report], then touch the [PRINT] tab. Press [Start]. Details To stop printing, press [Stop] on the control panel, then touch Cancel on the confirmation popup screen. bizhub PRO 1050P 15-39...

  • Page 510: Analyze Audit Log

    IDs narrow down the subject for protection. User ID (1 to 1000 numerical symbols) Confidential User ID (1 to 99999 numerical symbols) action: Used to specify the operation. Check details of operation that action indicates in the following table. 15-40 bizhub PRO 1050P...
  • Page 511 Security result: Result of an operation. For password authentication, success or failure will be indicated as OK and NG. For operations without password authentication, all log entries will be in- dicated as OK. bizhub PRO 1050P 15-41...

  • Page 512: Table Of Items Saved In Audit Log

    User ID Password authentication for Confidential user OK/NG confidential printing / Unregistered user ID Access to confidential print Confidential user file Delete confidential print file Confidential user Change HDD lock pass- Machine Manag- word er ID 15-42 bizhub PRO 1050P...
  • Page 513 The purpose of analyzing the audit log is to understand the following and im- plement countermeasures: - Whether or not data was accessed or tampered with - Subject of attack - Details of attack - Results of attack For specific analysis methods, see the next page. bizhub PRO 1050P 15-43...
  • Page 514 ID = Box that authentication was made Check the date and time the above operation occurred, and see if the oper- ation on the document in the personal box or confidential box was made by a legitimate box user. 15-44 bizhub PRO 1050P...
  • Page 515 - If you cannot find documents that should be in a box or if you find a doc- ument with changed content, unauthorized actions may have occurred. Similar countermeasures are needed. bizhub PRO 1050P 15-45...
  • Page 516 Security 15-46 bizhub PRO 1050P...

  • Page 517: Troubleshooting

    Troubleshooting...

  • Page 519: If "Please Call Service" Message Is Displayed

    Manager Setting>06 System Connection>01 User Call). For details, refer to “01 User Call” on page 13-100. In this case, you don’t have to make a call for the report code, because your machine has been monitored automatically by your service repre- sentative. bizhub PRO 1050P 16-3...
  • Page 520 A printing job can continue without using the troubled portion of the ma- chine (ex. Tray 2). 7 CAUTION EVEN IF THE PRINTING JOB CAN BE CONTINUED WITH THE ABOVE OPERATION, BE SURE TO CONTACT YOUR SERVICE REPRESENT- ATIVE IMMEDIATELY WHEN THE CALL FOR SERVICE SCREEN IS DISPLAYED. 16-4 bizhub PRO 1050P...

  • Page 521: Clearing Mishandled Paper

    [Illustration] will display subsequent screens for the disposal action. Follow the procedure below to remove mishandled paper. Details A jam code can be displayed in the message area of the Jam Position Screen. Contact your service representative, if desired. bizhub PRO 1050P 16-5...
  • Page 522 Be especially careful not to put your hand into the fixing unit area when withdrawing the fixing conveyance unit to remove mishandled paper. Be careful of removing staples stuck inside the machine so as not to get injured. 16-6 bizhub PRO 1050P...

  • Page 523: If Machine Tab Blinks In Orange

    If a paper misfeed occurs with the print job in progress, the machine stops operation and the [MACHINE] tab may blink in orange. If the Jam Position Screen is displayed after touching [Detail Check], follow the procedure in “Clearing Mishandled Paper” on page 16-5 to remove mis- handled paper. bizhub PRO 1050P 16-7...

  • Page 524: Tray Empty

    To change the tray selection Touch the desired tray key. Touch [OK] to restore the Machine Status Screen. Press [Start]. Paper will be delivered from newly selected tray to continue the printing operation. 16-8 bizhub PRO 1050P...
  • Page 525 To supply the empty tray with paper Load paper in the empty tray. For details, refer to “Loading Paper” on page 4-3. Touch [Close] to restore the Machine Status Screen. Press [Start]. Printing operation will resume using the tray supplied with paper. bizhub PRO 1050P 16-9...

  • Page 526: Inconformity In Paper Presetting

    Using Custom size/Wide size/Tabbed standard size paper of different size or in different condition Replace paper in the tray with that specified in the paper presetting, then touch Change. Press [Start] to start the printing operation. 16-10 bizhub PRO 1050P...
  • Page 527 Replace paper in the tray with that specified in the paper presetting. Touch [Change], then press [Start] to start the printing operation. Details If wrong size is loaded in the tray, the above popup screen will be dis- played. Replace with the correct size, then touch [Close]. bizhub PRO 1050P 16-11...

  • Page 528: If "Memory Full" Message Is Displayed (Memory Overflow)

    Occasional memory overflow may occur if the installed memory is inade- quate for the print conditions selected, and the machine will stop its opera- tion with the following popup screen displayed. Touch [Cancel]. All the data will be cleared to terminate the job. 16-12 bizhub PRO 1050P...

  • Page 529: If Power Off/On Screen Is Displayed

    Follow the procedure below to turn the machine power off then on. Turn OFF the sub power switch. Turn OFF the main power switch. Wait about 10 seconds. Turn ON the main power switch and sub power switch. bizhub PRO 1050P 16-13...

  • Page 530: Troubleshooting Tips

    - Contact your service representative. Using user authentication, printed sheets cannot be made after pass- word is entered - Check to see if the message “Print limit reached” is displayed. - Contact the machine manager to reset limit. 16-14 bizhub PRO 1050P...
  • Page 531 - Empty the trash basket. Printed sheets cannot be stapled or punched in position - Check to make sure the side guide plates are securely aligned to the pa- per in the paper tray to be used. bizhub PRO 1050P 16-15...
  • Page 532 Troubleshooting 16-16 bizhub PRO 1050P...

  • Page 533: Maintenance

    Maintenance...

  • Page 535: Checking Print Count

    - Printer total count - PM count, cycle, counter start date - Developer count, cycle, counter start date - Drum count, cycle, counter start date Check the list, then print it if desired. Press [Utility/Counter] on the control panel. bizhub PRO 1050P 17-3...
  • Page 536 The counter information will be displayed on the left side of the screen. Touching [Exit] will return to the previous screen. Touch [Detail Check]. The PM count, Developer count, and Drum count will be displayed. Touching [Exit] will exit the Utility mode and restore the previous screen. 17-4 bizhub PRO 1050P...
  • Page 537 Print the counter list, if desired. Touch [PRINT] tab at the upper left corner of the screen, then press [Start]. After the Counter list is printed out, the Utility mode will be released automatically and the previous screen will be restored. bizhub PRO 1050P 17-5...

  • Page 538: Preventive Maintenance

    Manager Setting>06 System Connection>01 User Call). For details, refer to “01 User Call” on page 13-100. In this case, you don’t have to make a call for preventive maintenance, because your machine has been monitored automatically by your service representative. 17-6 bizhub PRO 1050P...

  • Page 539: Machine Specifications

    Machine Specifications...

  • Page 541: Main Body Specifications

    Machine Specifications Machine Specifications These specifications are subject to change without notice. 18.1 Main Body Specifications 18.1.1 Main Body Specifications Name bizhub PRO 1050P Type Console type Transfer method Indirect electrostatic method Light-sensitive unit Developing method Dry, 2-component magnetic brush developing...

  • Page 542: Adobe Post Script3 Expansion Kit

    (main body + PF-701 + LS-501 + LS-502) Effective size* 200 mm or more from the back side; 100 mm or more from both right and left sides * Space required for the safe operation 18.1.2 Adobe Post Script3 Expansion kit 18-4 bizhub PRO 1050P...

  • Page 543: Option Specifications

    • Stacker: 5,000 sheets (or 2,000 sheets for B5 and A5) • Secondary (sub) tray: 200 sheets Dimensions 785 (W) x 656 (D) x 1020 (H) mm Weight Approx. 110 kg Power source • LS-501: Internal battery • LS-502: Supply from main body bizhub PRO 1050P 18-5...

  • Page 544: In-Bin Stapler Finisher

    Staple cartridge 5,000 staples Dimensions • 544 (W) x 656 (D) x 1020 (H) mm • Width including primaty (main) tray: 781 mm/ 866 mm (pulled out) Weight Approx. 80 kg Power source Supply from main body 18-6 bizhub PRO 1050P...

  • Page 545: Folding Unit

    Stack capacity using PI 500 sheets max. (80 g/m paper) for each tray Dimensions 400 (W) x 656 (D) x 1190 (H) mm Weight Approx. 120 kg Power source Internal battery bizhub PRO 1050P 18-7...
  • Page 546 Machine Specifications 18-8 bizhub PRO 1050P...

  • Page 547: Appendix

    Appendix...

  • Page 549: How To Input Characters

    This key determines the characters you input, and the character input screen closes. [Cancel] This key cancels the characters you input, and the character input screen closes. [Shift] This key switches between an upper case letter and a lower case letter, and between numbers and signs. bizhub PRO 1050P 19-3...

  • Page 550: About Character Input

    The followings describe basic steps to input characters on the character in- put screen. Touch the corresponding key to input the desired character. Touch [OK]. The character input screen closes. The input characters are displayed on the corresponding column. 19-4 bizhub PRO 1050P...

  • Page 551: How To Search

    Confirm the Box No., and return to the step 1 to repeat the procedures. Details Pressing the [Cancel] key cancels the input Box No., and the No. Search screen closes. If a password is configured for the box, you need to enter the password. bizhub PRO 1050P 19-5...

  • Page 552: Direct Call

    Details If you press the [Direct Call] key on the box list screen, the Box Name in- put screen appears. If a folder or a box is Password-protected, you cannot search it with the Direct Call. 19-6 bizhub PRO 1050P...
  • Page 553 Appendix Input the Folder Name and press the [OK] key. The Box Name input screen appears. Input the Box Name and press the [OK] key. The File Name input screen appears. bizhub PRO 1050P 19-7...
  • Page 554 1 to repeat the procedures. Details If the desired file is not found, you are brought back to the list screen, and the message is displayed on the upper left of the Touch Panel. 19-8 bizhub PRO 1050P...

  • Page 555: Setting Data For Import/Export

    Notice of E-Mail Notice of E-Mail Address Item Paper Empty Paper Jam Maintenance Staple Empty Toner Empty Output Full Service Call Punch Waste Remove [2] Print Main menus Sub menus Target items Interface Interface Parallel Timeout Network Timeout bizhub PRO 1050P 19-9...
  • Page 556 Convert Paper Size 1 Page/Sheet Booklet Print Position Default Setting- Font Name Symbol Set Line/Page Font Point Size Font Pitch CR/LF Mapping Default Setting- Print To PS Error Default Setting- Auto Paper Select TIFF Image Position 19-10 bizhub PRO 1050P...
  • Page 557 Start address 4 - Ending address 5 NetWare Netware NetWare Print Frame Type Mode Pserver Print Server Name Print Server Password Print Queue Scan Rate Bindery/NDS Bindery Preferred File Server Preferred NDS Context Preferred NDS Tree Name Nprinter/Rprinter Printer Name Printer Number bizhub PRO 1050P 19-11...
  • Page 558 Connection Timeout Port Number Email-Send Send SMTP Server Capacity Port Number Connection Timeout Max Mail Size SMTP Server Capacity Administrator Mail Address Authentication POP Before SMTP SMTP Authentication User Name Password Realm Binary Division Division Size 19-12 bizhub PRO 1050P...
  • Page 559 Sub menus Target items SSL/TLS SSL/TLS Infor- Encryption Strength mation Validity Period Organization Organization Unit Locality State/Province Country Authentication Auto Logout Admin Logout Time User Logout Time IS OpenAPI IS OpenAPI Port Number Use SSL/TLS Port Number(SSL/TLS) bizhub PRO 1050P 19-13...

  • Page 560: Configuration Setting

    Appendix 19.4 Configuration Setting Note This list indicates the configuration setting for bizhub PRO 1050. When using bizhub PRO 1050P, the configuration setting list will include only the settings specific to bizhub PRO 1050P. 19-14 bizhub PRO 1050P...
  • Page 561 Appendix bizhub PRO 1050P 19-15...
  • Page 562 Appendix Print Sample 19-16 bizhub PRO 1050P...
  • Page 563 Appendix Print Sample bizhub PRO 1050P 19-17...
  • Page 564 Appendix Print Sample 19-18 bizhub PRO 1050P...

  • Page 565: Font List

    Appendix 19.5 Font List Print Sample bizhub PRO 1050P 19-19...
  • Page 566 Appendix Print Sample 19-20 bizhub PRO 1050P...
  • Page 567 Appendix Print Sample bizhub PRO 1050P 19-21...
  • Page 568 Appendix Print Sample 19-22 bizhub PRO 1050P...
  • Page 569 Appendix Print Sample bizhub PRO 1050P 19-23...
  • Page 570 Appendix Print Sample 19-24 bizhub PRO 1050P...
  • Page 571 Appendix Print Sample bizhub PRO 1050P 19-25...
  • Page 572 Appendix Print Sample 19-26 bizhub PRO 1050P...
  • Page 573 Appendix Print Sample bizhub PRO 1050P 19-27...
  • Page 574 Appendix Print Sample 19-28 bizhub PRO 1050P...
  • Page 575 Appendix Print Sample bizhub PRO 1050P 19-29...

  • Page 576: Pcl Font List

    Antique Olive Italic scalable Garamond Antique scalable Garamond Halbfett scalable Garamond Kursiv scalable Garamond Kursiv Halbfett scalable Marigold scalable Albertus Medium scalable Albertus Extra Bold scalable Arial scalable Arial Bold scalable Arial Italic scalable Arial Bold Italic scalable 19-30 bizhub PRO 1050P...
  • Page 577 New Century Schoolbook Italic scalable New Century Schoolbook Bold Italic scalable Times Roman scalable Times Bold scalable Times Italic scalable Times Bold Italic scalable ITC Zapf Chancery Medium Italic scalable ITC Zapf Dingbats scalable Symbol scalable bizhub PRO 1050P 19-31...
  • Page 578 CourierPS scalable CourierPS Bold scalable CourierPS Oblique scalable CourierPS Bold Oblique scalable Line Printer 16.67/8.5 Line Printer 16.67/8.5 Line Printer 16.67/8.5 Line Printer 16.67/8.5 Line Printer 16.67/8.5 Line Printer 16.67/8.5 Line Printer 16.67/8.5 Line Printer 16.67/8.5 19-32 bizhub PRO 1050P...

  • Page 579: Glossary

    Internet or other TCP/IP networks. Data can be transmitted to a remote printer through the Internet and printed there. Abbreviation of Local Area Network. A network connecting computers on the same floor, in the same building, in the buildings nearby, etc. bizhub PRO 1050P 19-33...
  • Page 580 Windows. SMTP Abbreviation of Simple Mail Transfer Protocol. A protocol to transmit or transfer the electronic mails. SNMP Abbreviation of Simple Network Management Protocol. A control protocol using TCP/IP in the network environment. 19-34 bizhub PRO 1050P...
  • Page 581 One of the file formats to save image data (extension; .tif). Various types of image information can be saved in one im- age data with the “tag” representing the data type. Web browser Software to access web pages. Internet Explorer, Netscape Navigator, etc. are examples. bizhub PRO 1050P 19-35...

  • Page 582: Index

    Auto Shut Off ......13-6 NetWare ......14-27 NetWare Status ....14-28 Auto Shut-Off ......2-19 Network Setting Clear ..14-16 Auto Tray Switching ..... 12-14 Network Tab ....14-25 Online Assistance ...14-13 PageScope Basic Setting ....10-4 10-11 Web Connection ....14-3 19-36 bizhub PRO 1050P...
  • Page 583 Drum unit ......... 2-5 Coated A ........8-4 Duplex ........10-4 Coated B ........8-5 Collate ........10-4 Each Function Setting ..12-18 Collated mode ..6-3 Electromagnetic Colored Paper ....8-3 8-14 Interference ......1-13 Confidential Folder ..5-37 5-54 bizhub PRO 1050P 19-37...
  • Page 584 Icon area ........5-4 Exit ......... 11-4 Image Order ......10-4 image shift ......12-18 Imaging Solution OpenAPI ...13-89 Features of the bizhub PRO 1050P ....5-5 Incomplete Job ......5-13 Feed Tray ....... 10-4 Inconformity in Paper Presetting ......16-10 Feed Tray Auto Selection ..12-14 Input Size .......8-20...
  • Page 585 Output with Cover Sheet ..6-11 Maintenance & supply Ozone Release ...... 1-13 indicator ........5-4 Management List Print ..13-22 Manager/Machine Register .. 13-27 Page No. Position (Booklet) ......13-97 Memory Full Message ..16-12 PageScope Web Connection 13-91 bizhub PRO 1050P 19-39...
  • Page 586 Printer Horizontal Adjustment Section Name Input .....13-30 <SIDE1> ........9-9 Security Setting ....13-102 Printer Horizontal Adjustment Security Strengthen mode .13-111 <SIDE2> ......... 9-11 Select Printer Setting ...10-16 Printer Prohibit Timer ... 12-18 Set Password for Timer 19-40 bizhub PRO 1050P...
  • Page 587 Using Folder/Finisher Functions Timer Action On/Off Setting . 13-17 Manually ........ 6-12 Timer Interrupt .......2-22 Using Power Save Manually .. 2-20 Timer Interrupt password ..2-23 Utility Menu Screen ....17-3 Timer Setting ......13-14 Utility Screen ......11-3 bizhub PRO 1050P 19-41...
  • Page 588 Wake-up Screen ....2-15 Warning and Precaution Symbols ........1-3 Weekly Timer ......2-22 Weekly Timer Setting ... 13-10 Weight ......8-6 8-13 Wide Size Paper ....8-20 Z-Fold mode ......6-10 Z-Fold Position Adjustment ... 9-43 19-42 bizhub PRO 1050P...

Table of Contents
