  • Page 1 AtlonA Wireless HDMI Transmitter and Receiver Box AT-WHD200 User Manual...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Introduction ..........2. Application ..........3. Contents ..........4. System Require ..........5. Features ..........6. Operation Controls and Functions ..........6.1 Wireless HDMI Transmitter Front Panel ..........6.2 Wireless HDMI Transmitter Rear Panel ..........6.3 Wireless HDMI Receiver Front Panel ..........
  • Page 3: Introduction

    1. INTRODUCTION The wireless HDMI transmitter and receiver box are using UWB(Ultra-wideband) technology with breakthrough Wireless for HDMI (High-Definition Multimedia interface) offering its de- signed to enable wireless video and audio connections. 2. APPLICATION Input source can be HDMI, Component and analog audio with all types of products – HDTVs, video projectors, DVD players, set-top boxes, game systems and other home entertainment products.
  • Page 4: Features

    5.FEATURES • HD audio/video wireless transmission at wire-equivalent quality. • Supports most video resolution including 480i/p, 576i/p, 720p, 1080i and 1080p 24/30 (1080p 50/60 excluded). • 10 meters open field, no line of sight required. • Strong 128-bit AEC based encryption. •...
  • Page 5: Wireless Hdmi Transmitter Rear Panel

    6.2 Wireless HDMI Transmitter Rear Panel 1. +5V – Power jack for plugging the adaptor from the power source. 2. HDMI 1 In – Plug with HDMI cable from the input source device. 3. HDMI 2 In – Plug with HDMI cable from the input source device. 4.
  • Page 6: Wireless Hdmi Receiver Rear Panel

    6.4 Wireless HDMI Receiver Rear Panel 1. +5V – Power jack for plugging the adaptor from the power source. 2. HDMI Out – Plug with HDMI cable to the output display device. 3. Audio Out – Plug with 3.5mm phone jack audio cable to the output display device. 4.
  • Page 7: Specifications

    8.SPECIFICATIONS Standard Wireless HDMI UWB (Ultra-wideband) Video resolutions support 480i, 480p, 576i, 576p, 720p, 1080i and 1080p(24fps/30fps) Frequencies Supported 3.1 ~ 4.8GHz HDMI HDMI v1.2a Audio encoding 2-Channel Surround, Analog 33kHz, 44.1kHz, 48kHz Support 38kHz Hardware encryption 128 bit AEC Wireless Range 10M in room straight line Power Supply...
  • Page 8: Safety Information

    Use only accessories recommended by ATLONA to avoid fire, shock or other Do not modify the wall plug. hazards. Doing so will void the warranty and safety features.
  • Page 9: 10.Warranty

    LIMITED ONE-YEAR WARRANTY ATLONA by Lenexpo Electronics warrants only to the initial purchaser of this product for a period of one year from the date of purchase from an Authorized ATLONA Reseller, the product will be free of electrical and mechanical de- fects that materially affect the products operation as described in this users manual.
