MITEL 5330e IP PHONE QUICK REFERENCE GUIDE
This guide provides information for frequently used features. For more information about these and other features, refer to the
user guide. For voice mail information, refer to the voice mail user guide for your system.
No.
Name
Handset
1
Programmable
2
Buttons
Display
3
Ring/Message
4
Indicator
Feature Buttons
5
Dialpad Buttons
6
Navigation Buttons
7
External Speaker
8
1
2
8
The handset is hearing aid compatible (HAC). If you are using a headset or if you are in
Handsfree Mode, you do not need to use the handset.
Provide 33 self-labeling, programmable buttons.
Provides a 160 x 320 (pixels) high-resolution viewing area for selecting and using features and
identifying callers.
Flashes or stays lit to indicate call, message, and feature activity.
Indicator Signals
Rapidly flashing
You have an incoming call.
Slowly flashing
You have a waiting message or callback message.
On
You are on a call or using a feature.
Off
Your IP phone is idle.
Provide quick access to commonly used features. See "Feature Buttons" on
descriptions.
Use the dialpad buttons to dial phone numbers, enter feature codes, and to enter characters
when using features that require text input.
Use the navigation buttons to page through Display screens.
Provides audio for handsfree calls and background music.
Document Part Number 835.3290-1, August 2013
®
Mitel
is a registered trademark of Mitel Networks Corporation.
© 2013, Mitel Networks Corporation. All other products and services are the trademarks of their respective holders. All rights reserved.
