Tip Over Hazard
A child or adult can tip the range and be
killed.
Connect anti-tip bracket to rear range foot.
Reconnect the anti=tipbracket, if the range
is moved.
Failure to follow these instructions can
result in death or serious burns to children
and adults.
Quick Reference
Table of
Pages
[]
[]
[]
[]
[]
I_l-[]
[]-[]
[]
[]
[]
if Vou need
Contents:
Before you start
Product dimensions
Cabinet dimensions/requirements
Electrical requirements
Gas supply requirements
Installation steps
Gas conversions
If range does not operate
If you need assistance/service
Moving the range
assistance:
Check your Use and Care Guide for a toll-free number to call or
call the dealer from whom you purchased this range. The dealer
is listed in the Yellow Pages of your phone directory under
"Appliances -- Household -- Major -- Service and Repair."
Call when you:
[]
Have questions about range installation or operation.
[]
Need to obtain the name and number of an authorized
service company.
When you call, you will need:
[] The range model number.
[] The range serial number.
Both numbers are listed on the model/serial rating plate located
on the frame behind the storage drawer.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whirlpool YSF377PEGQ7
Summary of Contents for Whirlpool YSF377PEGQ7
- Page 1 Quick Reference Table of Contents: Pages Before you start Product dimensions Cabinet dimensions/requirements Electrical requirements Gas supply requirements I_l-[] Installation steps []-[] Gas conversions @© If range does not operate If you need assistance/service Moving the range assistance: if Vou need Check your Use and Care Guide for a toll-free number to call or call the dealer from whom you purchased this range.
- Page 2 important: Observe all governing codes and Yoursafety and the safety of othersare very important. ordinances. We have provided many important safety messages in this Do not obstruct flow of combustion and ventilation air. manual and on your appliance. Always read and obey all safety This installation must conform with all local codes and messages.
- Page 3 Grounded e lectrical outlet is required. See "Electrical requirements," Page 5. ©O Proper gas supply connection must be available. See "Gas supply requirements," Page 6. 46-7/8" 27-1/8" (68.9 cm) (119.1 cm) depth with handle overall height 36 _l (91.4 cm) coektop height 25"...
-
Page 4: Mobile Home Installation
Mobile home installation The installationof this range must conform to the Manufactured When this range is installedin a mobile home, it must be Home Construction and Safety Standards, -i]tle 24 CFR,Part secured to the floor during transit. Any method of securing 3280 (formerly the Federal Standard for Mobile Home the range is adequate as long as it conforms to the standards listed above. -
Page 5: Recommended Ground Method
Recommended ground method For personal safety, this range is equipped with a power supply cord having a 3-prong ground plug. To minimize pos- sible shock hazard, the cord must be plugged into a mating 3-prong, ground-type outlet, grounded in accordance with Electrical S hockHazard the National Electrical Code, ANSl/NFPA 70 -- latest edition* or CSA Standard C22.1, Canadian Electrical Code, Part 1, --... -
Page 6: Explosion H Azard
Flexible metal appliance connector: If local codes permit, a new AGA or CSA design-certified, 1/2" or 3/4" I.D., flexible metal appliance connector is recommended for connecting range to the gas supply line. A 1/2" male pipe thread nipple is needed for connection to pressure regulator Explosion H azard female pipe threads. - Page 7 into grounded outlet ® ® © © _ _' Make proper Removeoven _gas connection racks and pa_s package. Check oven burnerfor properflarne Install anti- tip bracket ecure range with anti-tip bracket Level range Replace storage drawer Preparation [] Remove oven racks and parts package from inside oven.
-
Page 8: Operating Position
Anti4ip bracket installation Contact a qualified floor covering installer for the best procedure for drilling mounting holes through your type floor covering. _mUse the anti-tip bracket template/instruction sheet to install the anti-tip bracket. Tip Over Hazard Anti-tip bracket must be anchored A child or adult can tip the range and be killed. - Page 9 and electrical connections All connections must be wrench-tightened. Typical rigid pipe connection /gO°elbow nipple union manual gas shut- pressure off valve [] Use 15/16" combination wrench and channel regulator lock pliers to attach the flexible connector to the adapters. pipe Check that connector is not kinked.
-
Page 10: Check Operation
Check operation of oven burner Check operation -, Open oven door. Electronic ignition system Cooktop and oven burners use electronic ignitors in place of standing pilots. When a cooktop control knob isturned to the "LIGHT" position, the system creates a spark to light the burner. -
Page 11: Check Operation Of Oven Broil Burner
[] Check the oven burner for proper flame. The flame should be 1/2" (13 mm) long, with inner cone of bluish-green, and outer mantle of dark blue, and should be clean and soft in character. No yellow tips, blowing or lifting of flame should occur, if burner does not light, check that the regulator shutoff valve is in the "on"... -
Page 13: Lp Gas Conversion
Gas conversions (from Natural gas to L.P.gas; or from L.P. _U___ reinstall orifice one of the gas to Natural gas} must be done by a qualified installer. [] Surface Burners: screws spud Remove burner caps Use ..-_@_ s-ark electrode •... -
Page 14: Natural Gas Conversion
,, Reinstall the storage drawer. Complete installation sections D through E, Pages 9-12. Checking for proper cooktop burner and oven flame is very important. YOU MUST ADJUST "LOW" SETTING FOR EACH COOKTOP BURNER. SEE STEP 16, PAGE 10. The small inner cone should have a very distinct blue flame 1/4"... - Page 15 Natural _,, Oven burner: Use 1/2" combination wrench to loosen Surface Propane Orifice Color the orifice hood away from pin (approximately 2 to 2-1/2 burner Rate(BTU/hr) Number Marking turns). The burner flame cannot be properly adjusted if this conversion is not made. Left rear 8,000 N139...
-
Page 16: Moving The Range
Moving the range: if range does not operate: Check that the circuit breaker is not tripped or the house fuse blown. Check that the power supply cord is plugged into the wall receptacle. Check that gas line is turned on. See Use and Care Guide for troubleshooting list.
