LE-362
User Manual
Edition 1.1
Copyright
©
Copyright
2003 - 2004. All rights reserved. This document is copyrighted and
all rights are reserved. The information in this document is subject to change
without prior notice to make improvements to the products.
This document contains proprietary information and protected by copyright.
No part of this document may be reproduced, copied, or translated in any
form or any means without prior written permission of the manufacturer.
All trademarks and/or registered trademarks contains in this document are
property of their respective owners.
Disclaimer
Taiwan Commate Computer Inc. shall not be liable for any incidental or
consequential damages resulting from the performance or use of this product.
Taiwan Commate Computer Inc. does not issue a warranty of any kind,
express or implied, including without limitation implied warranties of
merchantability or fitness for a particular purpose.
The company has the right to revise the manual or include changes in the
specifications of the product described within it at any time without notice and
without obligation to notify any person of such revision or changes.
Trademark
All trademarks are the property of their respective holders.
Any questions please visit our website at http://www.commell.com.tw.
LE-362 User's Manual
1
Advertisement
Table of Contents
Related Manuals for Commell LE-362
Summary of Contents for Commell LE-362
-
Page 1: User Manual
Trademark All trademarks are the property of their respective holders. Any questions please visit our website at http://www.commell.com.tw. LE-362 User’s Manual... -
Page 2: Packing List
Packing List Hardware LE-362 Single Board Computer ........X 1 Cable Kit Audio Cable ..............X 1 IDE Flat Cable (UltraDMA/100, 40-pin) ....... X 1 IDE Flat Cable (UltraDMA/66, 44-pin) ......X 1 26-pin slime-type FDD Cable ........X 1 COM Port DB9 ............ -
Page 3: Table Of Contents
Expansive Bus Interfaces ............25 2.11.1 PC/104-plus Interface ..........25 2.12 Switches and Indicators ............26 Chapter 3. BIOS Setup ................. 27 Flat Panel Type Setting ............. 28 3.1.1 Advanced Chipset Features Screen......28 3.1.2 Panel Type ..............29 LE-362 User’s Manual... - Page 4 BIOS Auto Flash Tool ..............39 Flash Method ................39 Appendix C. System Resources ..............41 I/O Port Address Map..............41 Memory Address Map ............... 42 System IRQ and DMA Resource..........43 C.3.1 IRQ ..................43 C.3.2 DMA................... 44 Contact Information..................45 LE-362 User’s Manual...
-
Page 5: Le-362 Single Board Computer
Fast Ethernet, AC97 3D audio, CompactFlash solid state disk, UltraATA/100 PCI enhanced IDE interfaces, and multiple I/O ports including 1 RS232, 1 LPT and 1 USB ports. These features make LE-362 be the ideal solution of multimedia platform, node terminal, transaction station, POS, Kiosk, panel PC, ATM and embedded application. -
Page 6: Specifications
USB ports with USB version 2.0 compliant Parallel Port one bi-direction parallel port with SPP/ECP/EPP mode One FPC connector to support slime type floppy IrDA Port 1 x IrDA compliant Infrared interface supports SIR K/B & Mouse PS/2 keyboard and mouse ports LE-362 User’s Manual... -
Page 7: Solid State Disk Interface
10Base-T / 100Base-TX, auto-switching Fast Ethernet, full duplex, IEEE802.3U compliant Audio Interface Chipset VIA VT8235 integrated AC97 3D audio controller with onboard Realtek ALC201A codec Interface Line-in, line-out, CD-in, Mic-out Connector Onboard 10-pin header connector for line-in, line-out and Mic-out LE-362 User’s Manual... -
Page 8: Expansive Interface
With Eden 667 MHz CPU ,SVGA, Audio, LAN, Compact Flash, PC/104+ Interface and 1 COM Ports, 1 LPT and 1 LE-362VL-128 Same as LE-362VL-P but with 128MB SDRAM onboard Online product information detail and updates are available on http://www,commell.com.tw LE-362 User’s Manual... -
Page 9: Component Placement
Component Placement VIA CLE266 VT8623 and VT8235 VIA Eden CPU TTL Flat Panel 667 MHz @ 133 FSB PC/104+ Interface System Memory Onboard 128 MB 144-pin CompactFlash SSD SO-DIMM Type-II Socket SOCKET CFC / MicroDrive LE-362 User’s Manual... - Page 10 Notes (This page left blank intentionally) LE-362 User’s Manual...
-
Page 11: Chapter 2. Hardware Setup
CPU and memory installation, fan, I/O and panel connections. Jumpers and Connectors Location CHASFAN USB1 LCD1 JLCD JRTC TVOUT1 VGA1 VIO1 LAN1 CON2 CDIN JAUDIO KBMS1 COM1 JWOL JFRNT ATX1 J2 J3 NB FDD IDE2 PRINTER IDE1 CPUFAN CON3 LE-362 User’s Manual... -
Page 12: Jumpers Reference
2.1.1 Jumpers Reference Jumper Function Section JRTC COMS Setting COM1 pin-1 Voltage setting 2.10 COM1 pin-9 Voltage setting 2.10 PC/104+ Voltage setting for V/IO 2.11 JLCD Flat Panel’s Voltage Setting 2.7.2 LE-362 User’s Manual... -
Page 13: Connectors Reference
16-pin Internal VGA Port Standard LCD1 40-pin TTL Flat Panel Interface Standard JAUDIO 10-pin Audio Port Standard CDIN 4-pin CD-in Interface Standard LAN1 10-pin Primary LAN Port Connector Standard 104-pin PC/104+ Connector Standard TVOUT1 10-pin TV-out Connector Standard LE-362 User’s Manual... -
Page 14: Cpu And Dram Setting
The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to proceed to clear (reset) the CMOS to its default values. Jumper: JRTC Type: onboard 3-pin header JRTC Mode Normal Operation Clear CMOS Default setting JRTC LE-362 User’s Manual... -
Page 15: Watchdog Timer Setting
Select Logical Device 8 4F, 08 4E, 30 Set Watchdog Active 4F, 01 4E, F3 Set Count as Second* 4F, 00 4E, F4 Set as 5 Second 4F, 05 * Minute: bit 3 = 1; Second: bit 3 = 0 LE-362 User’s Manual... -
Page 16: Embedded Flash Disk
The board supports both IDE-based DiskOnModule and CompactFlash embedded Solid State Disk (SSD). Please note that this board doesn’t provide VCC on IDE1, please use external power Connector with DiskOnModule. CompactFlash SSD Type-II Socket CFC / MicroDrive LE-362 User’s Manual... -
Page 17: Power And Fan Connectors
Yellow Ground Black Ground Black Connector: ATX1 Type: 3-pin ATX Function Connector Description Description Description 5V Standby Ground Power On Connector: SYSFAN, CPUFAN Type: 3-pin Fan Power Wafer Connector Pin Description Description Description Ground +12V Fan Control LE-362 User’s Manual... -
Page 18: Vga Interface
VGA accelerator with 3D/2D engine and 64 MB of video ProSavage™ memory shared with system memory. VGA1 Connector: VGA1 Type: 16-pin header Description Description Green Blue Ground Ground Ground Ground N/C / Vcc Ground Data HSYNC VSYNC Clock LE-362 User’s Manual... -
Page 19: 2.7.2 Tv-Out Interface
The board integrates with VIA VT1622M TV codec, supports NTSC/PAL TV format with S-Video and RCA output. Connector: TVOUT1 Connector type: onboard 2 x 5 pin header, pitch = 2.54mm Description Description Ground DAC_A Ground Ground Ground CVBS_E Ground TVOUT1 LE-362 User’s Manual... -
Page 20: Digital Vga Interface
The board’s digital video interface provides 24-bit TTL interface of flat panel. The digital video interfaces used BIOS selectable 8/16/32/64 MB of video memory shared with system memory. LCD1 JLCD Jumper: JLCD Type: onboard 3-pin (1 x 3) header JLCD LCD Voltage Setting +3.3V Default setting LE-362 User’s Manual... - Page 21 Connector: LCD1 Type: onboard 40-pin (2 x 20) 2.0 pitch header Signal Signal +12V +12V (LCD) ENAVDD BLON SHFCLK DATAENA ENABKL LE-362 User’s Manual...
-
Page 22: Ethernet Interface
Fast Ethernet interface with embedded operating system (OS) supported, green function (power saving mode / wake-on-LAN) and advanced network management functions. LAN1 Connector: LAN1 Type: 14-pin header connector (1~10 pin for LAN signal & 11~14 for LED) Description Description Ground Ground SP100 LE-362 User’s Manual... -
Page 23: Audio Interface
Connector: JAUDIO Type: 10-pin header Description Description Line – Right Ground Line – Left Ground Line Out – Left Line Out – Right Ground Connector: CDIN Type: 4-pin header Description CD – Left Ground Ground CD – Right LE-362 User’s Manual... -
Page 24: Multiple I/O Port Configuration
The onboard COM1 can provide +5V or +12V power with J2 and J3 jumper selectable. 2.10.1 COM1 VCC Mode Selection Jumper: J2 Type: onboard 3-pin header COM1 Mode +12V Default setting Jumper: J3 Type: onboard 3-pin header COM1 Mode Default setting LE-362 User’s Manual... -
Page 25: Expansive Bus Interfaces
PC/104-plus interface. There is one set of bus master PCI signal is supported on the onboard PC/104-plus interface. More information about PC/104-plus interface is available at: http://www.pc104.org/ VIO1 Jumper: VIO1 Type: onboard 3-pin header VIO1 PC/104+ Mode 3.3V Standby 5V Standby Default setting LE-362 User’s Manual... -
Page 26: Switches And Indicators
2.12 Switches and Indicators JFRNT Connector: JFRNT Type: onboard 10-pin header Function Signal Signal Function Vcc (+) (+) Vcc IDE LED Power Active Reset Reset Power PW_BN Button LE-362 User’s Manual... -
Page 27: Chapter 3. Bios Setup
CMOS Setup Utility, the Main Menu will be displayed as Figure 3-1. You can use arrow keys to select your function, press Enter key to accept the selection and enter the sub-menu. Figure 3-1. CMOS Setup Utility Main Screen LE-362 User’s Manual... -
Page 28: Flat Panel Type Setting
Please entry the “Advanced Chipset Features” screen on the main screen and find the item of “Panel Type”, and set it with the specification of the flat panel. Figure 3.2 - Advanced Chipset Features Screen Phoenix – AwardBIOS CMOS Setup Utility LE-362 User’s Manual... -
Page 29: Panel Type
The chipset / BIOS built-in flat panel selection offers the support of general flat panel. Please find the panel type you use on the list below, save and exit BIOS to restart the system. Panel Type Support Function 640x480 800x600 1024x768 1280x768 1280x1024 1400x1500 1600x1200 Default Setting LE-362 User’s Manual... - Page 30 Notes (This page left blank intentionally) LE-362 User’s Manual...
-
Page 31: Driver Cd
Link to < Website > Homepage The selection help you to link to the website to find the updated technical documents and download directly. Browse this CD The selection helps you to find the drivers in this CD directly. LE-362 User’s Manual... - Page 32 Notes (This page left blank intentionally) LE-362 User’s Manual...
-
Page 33: Appendix A. I/O Port Pin Assignment
Appendix A. I/O Port Pin Assignment IDE Port Connector: IDE1 Type: 40-pin (2 x 20) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY IDESEL DACK- Ground CBLID CS0 (MASTER CS) CS1 (SLAVE CS) LED ACT- Ground LE-362 User’s Manual... - Page 34 Connector: IDE2 Type: 44-pin (2 x 22) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY Ground DACK- Ground ASP1 Ground Ground Ground LE-362 User’s Manual...
-
Page 35: Fdd Port
FDD Port Connector: FDD1 Type: 26-pin connector Description Description INDEX DRV0 DSKCHG DRV1 MTR1 MTR0 STEP Ground WRITE DATA Ground WRITE GATE TRACK 0 WRPTR Ground RDATA- Ground LE-362 User’s Manual... -
Page 36: Serial And Parallel Port
Description Description STROBE- AUTO FEED- ERROR- INITIALIZE- SELECT INPUT- Ground Ground Ground Ground Ground ACKNOWLEDGE- Ground BUSY Ground PAPER EMPTY Ground SELECT+ Ground Serial Port Connector: COM1 Type: 10-pin (2 x 5) 2.54-pitch header Description Description Ground LE-362 User’s Manual... -
Page 37: Usb Port
Type: 5-pin (1 x 5) header for SIR Port Description IRRX Ground IRTX PS/2 Keyboard and Mouse Port Connector: JPS2 Type: 10-pin (2 x 5) header connector Description Description Keyboard Data Mouse Data Ground Ground Keyboard Clock Mouse Clock LE-362 User’s Manual... - Page 38 Notes (This page left blank intentionally) LE-362 User’s Manual...
-
Page 39: Appendix B. Flash The Bios
Get the “.bin” file including the image of new BIOS you want to update. Power on the system and flash the BIOS. Re-star the system. Any question about the BIOS re-flash please contact your distributors or visit the web-site at below: http://www.commell.com.tw/Support/Support_Index.htm LE-362 User’s Manual... - Page 40 Notes (This page left blank intentionally) LE-362 User’s Manual...
-
Page 41: Appendix C. System Resources
Mainboard resource x03F2 - x03F5 Standard Floppy Disk Controller x03F6 - x03F6 VIA Bus Master PCI IDE Controller x03F6 - x03F6 Primary IDE controller (dual fifo) x03F8 - x03FF Communication port (COM1) x04D0 - x04D1 PCI bus LE-362 User’s Manual... -
Page 42: Memory Address Map
VIA PCI to USB Enhanced Host Controller xEA001000 - xEA0010FF VIA Rhine II Fast Ethernet Adapter xFEC00000 - xFEC0FFFF System board extension for PnP BIOS xFEE00000 - xFEE0FFFF System board extension for PnP BIOS xFFFE0000 - xFFFFFFFF System board extension for PnP BIOS LE-362 User’s Manual... -
Page 43: System Irq And Dma Resource
VIA Tech 3038 PCI to USB Universal Host Controller VIA/S3G CLE266 IRQ Holder for PCI Steering PS/2 compatible mouse port Numeric Data Proccesor Primary IDE controller (dual fifo) VIA Bus Master PCI IDE Controller Secondary IDE controller (dual fifo) VIA Bus Master PCI IDE Controller LE-362 User’s Manual... -
Page 44: C.3.2 Dma
C.3.2 DMA Channel Device (free) (free) Standard Floppy Disk Controller (free) Direct memory access controller (free) (free) (free) LE-362 User’s Manual... -
Page 45: Contact Information
Taiwan Commate Computer Inc. COMMELL www.commell.com.tw Your Embedded Applied Computer Partner Address 8F, No. 94, Sec. 1, Shin Tai Wu Rd., Shi Chih Taipei Hsien, Taiwan +886-2-26963909 +886-2-26963911 Website http://www.commell.com.tw E-mail info@commell.com.tw (General Information) tech@commell.com.tw (Technical Support) Authorized Distributor LE-362 User’s Manual...
