Index

Index ............................................................................. 3
1. EYE-02 Camera - Introduction ............................... 3
1.1 Basic Features .....................................................................3
1.2 EYE-02 Camera Description ...............................................4
1.3 EYE-02 Camera Internal Components ...............................4
2. Camera Installation ................................................ 4
2.1 Package Contents ...............................................................4
2.2 Installation ..........................................................................4
3. Camera Function ..................................................... 5
3.1 Switching ON and OFF ........................................................5
3.2 Wireless Remote Control ...................................................5
3.3 Working Modes ...................................................................6
3.4 Config Mode .......................................................................6
3.5 Profiles .................................................................................7
3.6 Detectors .............................................................................8
3.7 Reports & Contacts .............................................................9
3.8 Security settings ...............................................................10
4. Camera Control and Configuration ................... 11
4.1 Set-Up and Configuration via PC ......................................11
__________________________________________________________________________________________________________
Considerable effort has been made to ensure that this manual is free of inaccuracies and omissions. However, as we are constantly
improving our products, if you need exact specifications, please contact JABLOCOM.

1. EYE-02 Camera - Introduction

1.1 Basic Features

EYE-02 is a security and monitoring camera that communicates wirelessly via the GSM network. You can access, control and
configure your EYE-02 GSM camera also via web by going to www.jablotool.com.
EYE-02 integrates the following built-in detectors that allow an intruder to be detected:
Infrared motion detector
Motion-in-Picture detector
Glass break detector
Door opening detector
Tilt detector
Touch detector
Noise detector
• EYE-02 is simple to install and configure (suitable for DIY installation).
• EYE-02 records every detected event into its memory.
• EYE-02 sends an alarm record using MMS, e-mail, SMS, voice call or sends alarm records to external server for
further use in applications. It can also report events to Alarm Receiving Centers of professional security agencies.
Copies of pictures and videos can be stored on the memory card.
• EYE-02 allows 24 hour monitoring via its night view mode.
• EYE-02 is compatible with a wide range of external wireless devices (refer to the table on the inside back cover
of this manual).
EYE-02.ENG.MAN.User_Manual.21
5. OTHER FEATURES ..................................................... 15
6. MAINTENANCE ........................................................ 17
7. Troubleshooting .................................................... 18
8. Technical Specification ......................................... 19
Detects movement by sensitive detection of human body temperature
Detects changes in a scene by taking snapshots regularly and comparing them
Recognizes the specific sound of breaking window glass
Detects opening (or closing) of doors and windows by sensing air pressure changes.
Recognizes any unwanted change in the camera's position and angle
Recognises micro vibrations of camera body caused by touching it by hand or
another object.
Microphone which detects a noise above a defined level
- 3 -
4.2 SMS Commands ................................................................12
4.3 Configuration via SMS commands ...................................13
4.4 Call Control ........................................................................14
4.5 Reset to factory defaults ..................................................14
5.1 Night View .........................................................................15
5.2 Battery ...............................................................................15
5.3 Micro SD card ....................................................................16
5.4 External Wireless Devices ................................................16
5.5 Outdoor Installation .........................................................17
7.1 GSM Network Setting ......................................................18
8.1 Battery Information ..........................................................19
8.2 Warranty ...........................................................................20
8.3 Safety Instructions ............................................................20
8.4 Licence Compliance ..........................................................22
8.5 Disposal Information ........................................................22
EN
