- Page 1 External document Wireless peripherals EYE-02 GSM Security Camera Application note File name: EYE-02 Wireless peripherals 1/12...
- Page 2 Jablotron Alarms. OASiS system is based on the principle of control panel communicating with wireless peripherals. When the peripherals are used with camera EYE-02, the camera plays the role of the control panel. Camera EYE-02 is equipped with 7 internal detectors and 2 programmable switches. Wireless peripherals further expand camera capabilities.
- Page 3 Jablotool via internet or via USB cable. Wireless devices are described in more detail in www.jablotron.cz user manual of each peripheral on Picture 2: Screenshot from JabloTool via internet, tab Peripherals File name: EYE-02 Wireless peripherals 3/12 URL: http://www.jablocom.com/download...
- Page 4 Picture 3: Using EYE-02 with wireless buttons RC-87 and RC-88 Help! button RC-87 Pushing the button causes Panic alarm even if EYE-02 is in SLEEP mode. Example of use: Elderly people who may be in emergency due to sudden drop in their health condition simply press the panic button and the camera will report the Panic alarm via SMS, MMS, call, email or JabloTool server and contact parents, neighbours or hospital for help.
- Page 5 JA-80M, JA-81M and JA-80D also have terminal point to which an additional detector can be connected by wires. Universal transmitter JA-80D wirelessly indicates status of connected peripheral, typically a detector. Any comercially avaiIable external sensor can be used. JA-80D does not have its own magnetic sensor. File name: EYE-02 Wireless peripherals 5/12 URL: http://www.jablocom.com/download...
- Page 6 JA-80G is activated by combustive gases or fume leakages. This detector is mains-powered (230V AC) because of higher power consumption. Besides wireless signalling to EYE-02, it also provides a relay switch to shut down an electric gas inlet valve, if installed.
- Page 7 OASiS system. The transmitter and receiver are enrolled into the EYE-02 as one device each, together as two devices. There can be up to 60m distance between the units. JA-80IR can well be used in outdoor environment, it is protected from dust and flushing water.
- Page 8 5.1 Using smart socket and relay modules Camera EYE-02 is equipped with two virtual switches. These switches work as wirelessly sent commands to relays to make or disconnect their contact. The switches can be remotely controlled in JabloTool via internet or via USB cable.
- Page 9 External document Picture 5: Using EYE-02 camera with relays Example 1: On your cottage you have a watering system with water pump placed in the well. You connect the power supply of the pump via the relay AC-82. Then you remotely turn on the watering in your cottage. You can adjust the time for which you turn on the watering depending on the weather.
- Page 10 Undo the cover and repeatedly press the button of the first relay (X), achieve the highest number of LED flashes (4, or if not possible, then 3) Press the same button and keep it pressed until all the LEDs flash a couple of times (=reset) File name: EYE-02 Wireless peripherals 10/12 URL: http://www.jablocom.com/download...
- Page 11 (within 2 days) and it will adjust the settings accordingly. You only set at what time you wish to achieve the selected temperature and the thermostat will, within 2 days prior to this moment, adjust the heating so that the set temperature is achieved. File name: EYE-02 Wireless peripherals 11/12 URL: http://www.jablocom.com/download...
- Page 12 Please note that thermostat cannot be enrolled into a relay where camera is already enrolled. 6.1.1 Enrolling thermostats into EYE-02 camera 1. Switch the camera into Enroll mode (it is described in chapter 1.2) 2. Insert battery into the thermostat TP-82 or TP-83 6.1.2...
