Rate and Resolution:
Rate: Set video frame here, from "full-speed to 1fp/5s". (Figure 3.8)
Resolution: Set the resolution to be 160*120/ VGA(640*480)/ QVGA (320*240). (Figure 3.9)
NOTE: When doing recording, Rate and Resolution parameter settings is very helpful for getting small
size record files, the lower parameter to get the smaller file.
Figure 3.8

TOP Menu

:
: Click it to get live video. When you want to back to live video from other menus, just click it.
Only under live video, you can do the operation on the right side, such as play, stop, snapshot etc.
: Click it to get into play mode, when you click stop icon, the video will be stopped, then click
play icon, it will show the video again.
: Click it to stop the live video. You can click play icon if you want to see live again.
: Click it to get snapshot. It will show the date and time of the snapshot you get, when you want
to save it, you will find the snapshot file named by "snapshot_MAC ID_date_time" .
: Click it to start record by manual, and the icon will change to red color
again, it will stop record. The record file will be saved to the folder you set. (Figure 10.8-Figure11.0)
: Click it to collect the sound around the camera, if you plug a earphone or a speaker in the
computer which you are using, you will hear the sound around the camera. This IP Camera has a built-in
microphone, when you click it to start work, the icon will change to red color
audio function.
: Click it to start the talk function, firstly you have to plug a microphone in your computer.
When you are talking about something with the microphone from your computer, the sound will come out from
the built-in speaker of the camera, people beside the camera will hear the sound. If you connected an external
speaker from the audio output hole at the back of the camera (Figure 1.2), you will get better sound effect.
Once click it to start work, the icon will change to red color
Shenzhen Apexis Electronic Co., Ltd
More Security, More Convenience
Figure 3.9
Tel: +86-755-26509025
www.apexis.com.cn / www.apexis.cc
Figure 4.0
, click it again, will stop talk function.
18
, click it
, click it again, will stop
