Apexis IP Wireless / Wired Camera User Manual page 16

C hannels:
Our IE software supports 9 channels totally. Click
Click this one, you can view the main channel of the camera you login.
:
Click this one; you can view 4 Channels of cameras which connected, from CH1 to CH4.
:
Click this one; you can view 9 Channels of cameras which connected, from CH1 to CH9.
:
NOTE: If you want to view 4/9 channels, you should set the Multi-Device firstly (See 3.1 Mult
Settings)
S tatus of Channels:
There are 9 icons at the bottom of the UI which show the status of each channel of the camera.
Grey color, means there is no device connected to the main device from this channel.
:
Green color, means the device connected from this channel, and it works well.
:
Red color, means the device of this channel is recording
:
Yellow color, means set this channel in multi-device already, but it fails to connect to the main device
:
Shenzhen Apexis Electronic Co., Ltd
More Security, More Convenience
Tel: +86-755-26509025
www.apexis.com.cn / www.apexis.cc
Figure 3.5
can get different windows.
.
16
