Tour - Planet ICA-530 User Manual

3.6.3 Tour

Tour Name: The group name of the sequence of camera tour. There are 4 tours: tour A to D.
Dwelling Time: Type a period of time during which the camera is to stay at each preset point,
between 1 to 3600 seconds.
Sequence: Set the sequence of the tour. Maximum 32 points can be assigned. The selected
preset position is added in the Sequence list from 1 to 32. The tour will ignore and skip any
"None" position in the sequence.
Tour: Choose which sequence group, tour, should be activated or disable it.
To use the camera tour function, user must preset some camera positions first. The maximum
number of preset points is 32.
In the Camera Tour page, choose the one tour name from A to D. Fill the dwelling time and
tour sequence by preset points, and then save these setting. You can repeat above procedure
to set more camera tours.
Now, you could choose one of the camera tours and click "OK" button to enable it.
40/68
