Model No. WEBE34111B
Serial No.
Write the serial number in the space
above for reference.
USER'S MANUAL
Serial Number Decal (under seat)
QUESTIONS?
As a manufacturer, we are
committed to providing complete
customer satisfaction. If you
have questions, or find that there
are missing or damaged parts,
we will guarantee you complete
satisfaction through direct
assistance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Visit our website at
Read all precautions and instruc-
www.weiderfitness.com
tions in this manual before using
this equipment. Save this manual
new products, prizes,
for future reference.
fitness tips, and much more!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weider Pro Xt20 Weight Bench
Summary of Contents for Weider Pro Xt20 Weight Bench
- Page 1 Model No. WEBE34111B Serial No. Write the serial number in the space above for reference. USER’S MANUAL Serial Number Decal (under seat) QUESTIONS? As a manufacturer, we are committed to providing complete customer satisfaction. If you have questions, or find that there are missing or damaged parts, we will guarantee you complete satisfaction through direct...
-
Page 2: Table Of Contents
• Do not allow children on or around machine. a.m. until 6 p.m. Mountain Time, to • Replace label if damaged, illegible, or removed. order a free replacement decal. Apply the decal in the location shown. WEIDER is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight bench. 1. Read all instructions in this manual before 6. Keep children under the age of 12 and pets using the weight bench. Use the weight away from the weight bench at all times. -
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the versatile WEIDER ® toll-free at 1-800-999-3756, Monday through Friday, XT20 weight bench. The PRO XT20 is designed to be 6 a.m. until 6 p.m. Mountain Time (excluding holidays). used with your weight set (not included) to help you To help us assist you, please note the product model develop every major muscle group of the body. -
Page 5: Part Identification Chart
PART IDENTIFICATION CHART Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST on page 14. Note: Some small parts may have been pre-attached. -
Page 6: M10 Nylon
ASSEMBLY • As you assemble the weight bench, make sure all Make Things Easier for Yourself parts are oriented as shown in the drawings. Everything in this manual is designed to ensure • For help identifying small parts, use the PART that the weight bench can be assembled suc- IDENTIFICATION CHART on page 5. - Page 7 3. Press four 25mm x 51mm Inner Caps (28) into the ends of the Backrest Frame (27). Attach the Backrest Bracket (34) to the Backrest Frame using two M10 x 22mm Bolts (7) and two M10 Nylon Locknuts (11). 4. Attach the Backrest (15) to the Backrest Frame (27) with four M6 x 64mm Screws (4) and four M6 Washers (30).
-
Page 8: M8 Nylon
7. Press three 45mm Square Inner Caps (17) into the Leg Lever (18). Press a 25mm Round Inner Cap (33) into the indicated end of the Weight Tube (21). Attach the Weight Tube (21) to the Leg Lever (18) with an M8 x 58mm Bolt (16), two M8 Flat Washers (13), a 10mm Spacer (20), and an M8 Nylon Locknut (9). -
Page 9: Adjustments
ADJUSTMENTS This section explains how to adjust the weight bench. See the EXERCISE GUIDELINES on page 11 for impor- tant information on how to get the most benefit from your exercise program. Also, refer to the accompanying exercise guide to see the correct form for each exercise. Inspect and tighten all parts each time you use the weight bench. - Page 10 ADJUSTING THE BACKREST The Backrest (15) can be adjusted to any of five posi- tions. To adjust the Backrest, pull the Backrest Knob (29) outward and move the Backrest up or down. Slowly release the Backrest Knob, making sure the pin on the Backrest Knob is inserted through one of the holes in the Backrest Bracket (34).
-
Page 11: Exercise Guidelines
EXERCISE GUIDELINES THE FOUR BASIC TYPES OF WORKOUTS PERSONALIZING YOUR EXERCISE PROGRAM Muscle Building Determining the exact length of time for each workout, To increase the size and strength of your muscles, as well as the number of repetitions or sets completed, push them close to their maximum capacity. - Page 12 Rest for a short period of time after each set. The slowly as you stretch and do not bounce. Ease into ideal resting periods are: each stretch gradually and go only as far as you can • Rest for three minutes after each set for a muscle without strain.
- Page 13 EXERCISE WEIGHT SETS REPS MONDAY Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEIGHT SETS REPS WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE WEIGHT SETS REPS FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts.
-
Page 14: Part List
PART LIST—Model No. WEBE34111B R0802A Key No. Qty. Description Key No. Qty. Description 50mm Square Inner Cap M10 x 65mm Bolt 51mm x 76mm Outer Cap Stabilizer M6 x 16mm Screw Pad Tube M6 x 64mm Screw Curl Pad Bench Frame Backrest Frame M10 Washer 25mm x 51mm Inner Cap... -
Page 15: Exploded Drawing
EXPLODED DRAWING—Model No. WEBE34111B R0802A 11 37 11 37... -
Page 16: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information when calling: • The MODEL NUMBER of the product (WEBE34111B) • The NAME of the product (WEIDER ® PRO XT20 weight bench) •...
