• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Hearth & Home Technologies • RBV4236/RBV4842 • 4048-210 • Rev Z • 12/16/13
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
DO NOT touch glass until it is cooled
•
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fi replace.
•
Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
•
Keep clothing, furniture, draperies and other fl ammable
materials away.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
A CO detector shall be installed in the room where the appliance
in installed.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory trained
professionals, or technicians supervised by an NFI
certifi ed professional.
1
Advertisement
Table of Contents
Related Manuals for Hearth and Home Technologies RBV4236IH
Summary of Contents for Hearth and Home Technologies RBV4236IH
- Page 1 Owner’s Manual Installation and Operation Model(s): RBV4236IH, RBV4236IT RBV4842IH, RBV4842IT NOTICE DO NOT DISCARD THIS MANUAL • Important operating • Read, understand and follow • Leave this manual with these instructions for safe a n d m a i n t e n a n c e party responsible for use instructions included.
-
Page 2: Congratulations
Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. A. Congratulations This owner’s manual should be retained for future reference. Congratulations on selecting a Hearth & Home Tech- We suggest that you keep it with your other important nologies gas fireplace, an elegant and clean alternative documents and product manuals. -
Page 3: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. • NOTICE: Used to address practices not related to personal injury. -
Page 4: Warranty
B. Warranty Hearth & Home Technologies LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance... - Page 5 B. Warranty (continued) WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. •...
-
Page 6: Listing And Code Approvals
Listing and Code Approvals A. Appliance Certification C. BTU Specifications MODELS: RBV4236/RBV4842 Series Reveal Series RBV4236 RBV4842 LABORATORY: Underwriters Laboratories, Inc. (UL) TYPE: Vented Gas Fireplace Input Rate (NG) 40,000 BTUH 43,000 BTUH STANDARD: ANSI Z21.50a-2008/CSA 2.22a-2008 Orifice Size (NG) #31/3.05 mm .125 in./3.18 mm Input Rate (LP) 38,000 BTUH 41,000 BTUH Orifice Size (LP) #49/1.85 mm... -
Page 7: User Guide
User Guide Operating Instructions A. Gas Fireplace Safety • Install a switch lock or a wall/remote control with child protection lockout feature. • Keep remote controls out of reach of children. WARNING • Never leave children alone near a hot fi replace, whether operating or cooling down. -
Page 8: Clear Space
C. Clear Space E. Remote Controls, Wall Controls and Wall Switches WARNING! DO NOT place combustible objects in Follow the instructions supplied with the control installed front of the fireplace or block louvers. High tempera- to operate your fireplace: tures may start a fire. See Figure 2.2. For safety: Avoid placing candles and other heat-sensitive objects on mantel or hearth. -
Page 9: Lighting Instructions (Ipi)
H. Lighting Instructions (IPI) • For normal use, activate/deactivate your fireplace with the wall switch or remote control. • The IPI system may be operated with two D-cell batteries. When using batteries, unplug the transformer. To prolong battery life, remove them when using the transformer. •... -
Page 10: After Fireplace Is Lit
I. After Fireplace is Lit Initial Break-in Procedure Indicator • The fireplace should be run three to four hours continuously on high. • Turn the fireplace off and allow it to completely cool. • Run continuously on high an additional 12 hours. This cures the materials used to manufacture the fire- place. -
Page 11: Maintenance And Service
Maintenance and Service Remote Control Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace. Frequency: Seasonally By: Homeowner When properly maintained, your fireplace will give you Tools needed: Replacement batteries and remote control in- structions. -
Page 12: Maintenance Tasks-Qualified Service Technician
B. Maintenance Tasks-Qualified Service Burner Ignition and Operation Technician Frequency: Annually The following tasks must be performed by a qualified By: Qualified Service Technician service technician. Tools needed: Protective gloves, vacuum cleaner, whisk broom, flashlight, voltmeter, indexed drill bit set, and a manom- eter. -
Page 13: Installer Guide
Installer Guide Getting Started A. Typical Appliance System NOTICE: Illustrations and photos reflect typical installations and are for design purposes only. Illustrations/diagrams are not drawn to scale. Actual product may vary from pictures in manual Vertical Termination Cap Noncombustible roof flashing maintains minimum Storm Collar clearance around pipe Vent pipe penetrates roof,... -
Page 14: Design And Installation Considerations
B. Design and Installation Considerations D. Inspect Appliance and Components Hearth & Home Technologies B-type vent gas appliances The following B-vent components are needed for installa- are designed to operate with all exhaust gases expelled tion. to the outside of the building, and combustion air pulled •... -
Page 15: Negative Pressure
E. Negative Pressure • Ensure furnace and air conditioning return vents are not located in the immediate vicinity of the fireplace. WARNING! Asphyxiation Negative pressure can Risk! • Avoid installing the fireplace near doors, walkways or cause spillage of combustion fumes and soot. Fireplace small isolated spaces. -
Page 16: Framing And Clearances
Framing and Clearances A. Selecting Appliance Location NOTICE: Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams When selecting a location for the appliance it is important are not drawn to scale. Actual installation may vary due to to consider the required clearances to walls (see Fig- individual design preference. -
Page 17: Constructing The Appliance Chase
B. Constructing the Appliance Chase seal gaps. Gas line holes and other openings should be caulked with high temp caulk or stuffed with unfaced A chase is a vertical box-like structure built to enclose the insulation. If the appliance is being installed on a cement gas appliance and/or its vent system. -
Page 18: Mantel And Wall Projections
D. Mantel and Wall Projections WARNING! Risk of Fire! Comply with all minimum clear- ances as specified. Framing or finishing material closer than the minimums listed must be constructed entirely of noncombustible materials (i.e., steel studs, concrete board, etc). Mantels 30 in. minimum to ceiling 18-1/4 17-1/2 16-3/4... -
Page 19: Termination Locations
Termination Locations A. Vent Termination Minimum Clearances 6 in. (minimum) up to 20 in. 18 in. minimum WARNING 152 mm/508 mm 457 mm 20 in. and over 0 in. minimum Fire Risk. Gas, Wood or Fuel Oil Maintain vent clearance to combustibles as Termination Cap specified. -
Page 20: Vent Information And Diagrams
Vent Information and Diagrams A. Vent Guidelines B. Vent System Configuration WARNING! Fire Risk/Asphyxiation! This appliance re- CAUTION! Risk of Fire! ALL vent configuration specifi- quires the specified pipe for operation. Incorrect pipe may cations MUST be followed. This product is tested and listed cause spillage, condensation and overheating. to these specifications. -
Page 21: Vent Clearances And Framing
Vent Clearances and Framing A. Pipe Clearances to Combustibles B. Wall and Ceiling Penetration Framing Vent clearances are per vent manufacturer’s specifica- For a wall or ceiling penetration consult B-vent pipe tions. The vent MUST be Listed B-Vent pipe. manufacturer’s instructions to provide adequate clear- ances. -
Page 22: Appliance Preparation
Appliance Preparation A. Installing Outside Air Kit Damper Assem- C. Securing and Leveling the Appliance WARNING! Risk of Fire! Prevent contact with: CAUTION! Risk of Cuts/Abrasions/Flying Debris. • Sagging or loose insulation Wear protective gloves and safety glasses during installa- • Insulation backing or plastic tion. Sheet metal edges are sharp. •... -
Page 23: Installing Vent Pipe
Installing Vent Pipe A. Assembly of Vent Sections C. Securing Vent Sections This B-Vent appliance requires 6 in. B-vent double-wall Secure vent sections with vent supports following B-vent pipe. Follow the pipe manufacturer’s installation guide- manufacturer’s instructions. lines when installing the unit. This will ensure proper WARNING! Risk of Fire or Explosion! Use vent run operation and prevent safety hazards. -
Page 24: Gas Information
Gas Information A. Fuel Conversion C. Gas Connection • Make sure the appliance is compatible with available • Refer to Reference Section 16.A. for location of gas line gas types. access in appliance. • Conversions must be made by a qualified service •... -
Page 25: Electrical Information
Electrical Information B. Intellifire Ignition System Wiring A. Wiring Requirements • Wire the appliance junction box to 110 VAC for proper NOTICE: This appliance must be electrically wired operation of the appliance. and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code WARNING! Risk of shock or Explosion! DO NOT ANSI/NFPA 70-latest edition or the Canadian Electric... -
Page 26: Electrical Service And Repair
D. Electrical Service and Repair WARNING! Risk of shock! Replace damaged wire with WARNING! Risk of shock! Label all wires prior to type 105° C rated wire. Wire must have high temperature disconnection when servicing controls. Wiring errors can insulation. cause improper and dangerous operation. Verify proper operation after servicing. Battery Ignitor Flame... -
Page 27: Junction Box Installation
E. Junction Box Installation If the box is being wired from the OUTSIDE of the appli- ance: • Remove the cover plate located on the outer shell - right side. • Loosen two screws on the Romex connector, feed the necessary length of wire through the connector and tighten the screws.) •... -
Page 28: Finishing
Finishing A. Mantel and Wall Projections WARNING! Risk of Fire! Comply with all minimum clear- ances as specified. Framing closer than the minimums listed must be constructed entirely of noncombustible materials (i.e., steel studs, concrete board, etc.) Failure to comply could cause fire. Mantels 30 in. -
Page 29: Facing Material
B. Facing Material • Metal front faces may be covered with non-combustible materials only. • Facing and/or finishing materials must not interfere with air flow through louvers, operation of louvers or doors, or access for service. • Facing and/or finishing materials must never overhang into the glass opening. -
Page 30: Appliance Setup
Appliance Setup A. Remove the Shipping Materials C. Clean the Appliance Remove shipping materials from inside or underneath the Clean/vacuum any sawdust that may have accumulated firebox. inside the firebox or underneath in the control cavity. B. Remove Shipping Supports D. -
Page 31: Place The Lava Rock & Vermiculite
G. Place the Rockwool • Install left top log as shown in Figure 14.6 using locating pins to position log properly. WARNING! Risk of Explosion! Follow rockwool placement instructions. DO NOT place rockwool directly over burner ports. Replace rockwool material annually. Improperly placed rockwool interferes with proper burner operation. •... -
Page 32: Log Removal/Replacement
H. Log Removal/Replacement The log set should look similar to that in Figure 14.11. Figure 14.14 Remove Hearth Refractory - Step 2 Figure 14.11 Reveal Log Set • Remove log/grate assembly from the hearth pan by removing two screws (one per side). See Figure 14.15. -
Page 33: Glass Door Assembly
I. Glass Door Assembly • Remove the shorter door pins using a phillips screwdriver and replace them with the longer pins. See WARNING! Risk of Asphyxiation! Handle glass doors Figure 14.18. with care. Inspect the gasket to ensure it is undamaged and inspect the glass for cracks, chips or scratches. • DO NOT strike, slam or scratch glass. -
Page 34: Air Shutter Setting
K. Air Shutter Setting • Slide the burner assembly to the left and remove from the appliance. See Figure 14.22. Air shutter settings should be adjusted by a qualified installer at the time of installation. The air shutter is set at the factory for minimum vertical vent run. -
Page 35: Troubleshooting
Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualified service technician in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualified service technician. Con- tact your dealer to arrange a service call by a qualified service technician. - Page 36 A. Intellifire Ignition System (continued) 4. Pilot lights but continues A. A shorted or loose connection Verify all connections to wiring diagram in manual. Verify connec- to spark, and main burner in flame sensing rod. tions underneath pilot assembly are tight. Verify connections are not will not ignite.
-
Page 37: Reference Materials
Reference Materials A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 5. 8-3/4 in. (222 mm) 21-1/2 in. (546 mm) 8-1/4 in. (210 mm) Ouside 39-1/2 in. (1003 mm) Electric 30-1/4 in. -
Page 38: Service Parts List
B. Service Parts List Hearth & Home Technologies • RBV4236/RBV4842 • 4048-210 • Rev Z • 12/16/13... - Page 39 Hearth & Home Technologies • RBV4236/RBV4842 • 4048-210 • Rev Z • 12/16/13...
- Page 40 Hearth & Home Technologies • RBV4236/RBV4842 • 4048-210 • Rev Z • 12/16/13...
- Page 41 Hearth & Home Technologies • RBV4236/RBV4842 • 4048-210 • Rev Z • 12/16/13...
-
Page 42: Optional Components
C. Optional Components ID4 Insulated Duct 4 in. (102 mm) i.d. 42 in. (1067 mm) SMART-STAT-HTL Remote control with Thermostat Control SMART-BATT-HTL UD4 Uninsulated Duct Battery-operated Remote Control with Thermostat Control 4 in. (102 mm) i.d. WSK100-HTL Wall Switch 42 in. (1067 mm) Thermally Activated Automatic Damper... - Page 43 This page intentionally left blank. Hearth & Home Technologies • RBV4236/RBV4842 • 4048-210 • Rev Z • 12/16/13...
-
