TECHNICAL DATA –INFINEA TAB M
Electrical
Power supply
Compatibility
Communications
Power Consumption
Magnetic Stripe Reader
Encryption Methods
Barcode Scanner
Barcode Type
RFID Reader (Optional)
Bluetooth
Communication
LEDs
Buttons
Battery
Cables
Audio Indicator
Mechanical
Dimensions
Weight
Environment
Operating Environment
Certifications
PCI
* Specifications subject to change without notice.
Internal voltage 3.3V & 5V
iPad mini
USB Interface – between Infinea TAB mini and iPad mini
USB Synchronization between Apple iPad mini ® & PC
Deep sleep ~20uA
3-track bidirectional reading capabilities
Type: ISO 7816-1/2/3 compatible & RAW mode
3DES-112 with DUKPT Key Management
AES-256 with Fixed Key Management
Optional: AES-128 with Fixed Key Management
2D High Speed Imager
2D Supported Symbologies:
Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F,
Composite codes, Data Matrix (ECC200/EC0-140), Maxi Code
(mode 2~5), MicroPDF41, QR & Micro-QR Code, PDF417
1D Scanner Supported Symbologies:
JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code
93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial
2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/Plessey, S-
Code, Telepen, Tri-Optic, UK/Plessey
MIFARE MINI
MIFARE CLASSIC-1K, MIFARE CLASSIC-4K
MIFARE ULTRALIGHT, ULTRALIGHT-C
ISO 14443, ISO 15693
MIFARE PLUS 2K/4K
DESFire cardm FeLiCa
Bluetooth 2.0 Class 2
Distance – Up to 10m
Serial Port Profile (SPP)
Green LED for battery
Blue LED for device status
Four LEDs for Contactless indication
Scan and status buttons
Rechargeable Li-ion Battery 3.7V/1100mAh, charging from USB port
or charging station
Standard USB A to mini B Cable (0.9m)
Audio magnetic buzzer
103mm (L) x 88mm (W) x 23.5mm (H)
140 grams (without iPad mini)
- Operating temperature 0°C to +40°C
- Operating humidity 35 to 85% RH
- Storage temperature -5°C to +40°C
- Storage humidity 10 to 90% RH
PTS 3.x SRED compliant (optional)
