System Board Switches - HP ProLiant DL385 G6 User Manual

Item Description
10 System maintenance switch
11 Power supply backplane connector
12 Processor 1 socket
13 Primary riser connector
14 Secondary riser connector
15 Diagnostic LEDs
16 Processor 2 socket
17 Processor 2 DIMM slots
18 Fan 6 connector
19 Fan 5 connector
20 Fan 4 connector
21 Fan 3 connector
22 Fan 2 connector
23 Fan 1 connector

System board switches

System maintenance switch
Position
S1
S2
S3
S4
S5
S6
When the system maintenance switch position 6 is set to the On position, the system is prepared to erase
all system configuration settings from both CMOS and NVRAM.
CAUTION:
RBSU setting that erases default settings and fixed disk partitions, which causes a loss of data.
Diagnostic LEDs
Position
S7
Off
Off
Default Function
Off Off = iLO 2 security is enabled.
On = iLO 2 security is disabled.
Off Off = System configuration can be changed.
On = System configuration is locked.
Off Reserved
Off Reserved
Off Off = Power-on password is enabled.
On = Power-on password is disabled.
Off Off = No function
On = ROM reads system configuration as invalid.
Clearing CMOS and/or NVRAM deletes configuration information. There is an
Position Function
S8 Diagnostic LEDs
Off Port 85
On Port 84
Component identification 13
