Generac Power Systems 02010-2, 04164-3 Installation And Owner's Manual page 51

ITEM PART NO. QTY. DESCRIPTION
1 0G2565 1
2 0E3221 1
3 0E1466 1
4 071983 2
5 021713B 1
6 0A1442 8
7 021742 4
8 0G2751 1
9 076701 1
10 045756 2
11 080308 2
12 080309 1
13 080338 1
14 0D4788 1
15 083897 2
16 072694 2
17 0D3998 2
18 078672 1
19 078694 1
20 083907 2
21 021714 1
22 0D2274 2
23 086515 4
24 086516 1
25 086517 1
26 089673 2
27 0C4391 2
Section 6 — Exploded Views and Parts Lists
GN-410 Engine (Model 02010-2 and 04164-3) – Drawing No. 0E9615-A
RING SET, PISTON DIA 90
CONNECTING ROD
PISTON PIN
PISTON PIN RETAINER
CYLINDER HEAD GASKET
FLANGED HEX HD. CAPSCREW
M8-1.25 X 42
M10 1.5 X 105MM HHFL
PISTON, FLAT TOP DIA 90 COATED
CRANKCASE GASKET
M6-1.0 X 10 TAPTITE (THD.
FORMING)
BREATHER GASKET
BREATHER COVER
OIL BREATHER SEPARATOR
PIPE PLUG-3/8"
TAPPET, SOLID
PIVOT BALL STUD
NUT HEX M8-1.0 G8
SEAL, VALVE STEM
PUSH ROD GUIDE PLATE
ROCKER ARM
CYLINDER HEAD W/VALVE SEATS
AND GUIDES
VALVE SPRING RETAINER
VALVE SPRING KEEPER
EXHAUST VALVE
INTAKE VALVE
WASHER, VALVE SPRING
VALVE SPRING
Recreational Vehicle Generator
ITEM PART NO. QTY. DESCRIPTION
28 0A9877 1
29 0E3812 2
30 076361 1
31 0A5776 1
32 0A7811 1
33 078645 1
34 078691 1
35 074908 1
36 0A7975 1
37 0A5771 1
38 0B2104 1
39 0E9667 1
40 078658 1
41 078659 2
42 0A7628 1
43 089288C 1
44 0E3341 1
45 086025 1
46 0D9853B 2
47 0E9666 1
48 090747 1
49 0C3150 1
50 092362 1
51 068527 4
52 083921 1
53 077158 1
54 076329 1
55 0E0057 1
56 093064 1
CAMSHAFT ASSEMBLY
CRANKSHAFT SEAL
THRUST WASHER
PRESSURE RELIEF BALL
GOVERNOR SPOOL
GOVERNOR RETAINER (C-RING)
COVER, OIL PRESSURE RELIEF
M5-0.8 X 10MM TAPTITE
GOVERNOR GEAR ASSEMBLY
OIL PRESSURE SPRING
SPRING WASHER
OIL SUMP ASSEMBLY
GOVERNOR ARM "R" PIN
THRUST WASHER
GOVERNOR ARM RC45
CRANKCASE SUB ASSEMBLY
BALANCER
SET GEROTOR
PUSH ROD
CRANKSHAFT ASSEMBLY
BREATHER VALVE ASSEMBLY
ROCKER COVER GASKET
ROCKER COVER W/FILL
M6-1.0 X 20MM HEX HEAD. SCREW.
AND LOCKWASHER
BEARING TUBE SHAFT
OIL SCREEN PICKUP ASSEMBLY
OIL FILL PLUG
"O" RING
OIL FILL CAP ASSEMBLY
49
