Page 1: Log Splitter
22 Ton LOG SPLITTER YEAR MODEL NUMBER 92210 LIMITED WARRANTY 10006 Santa Fe Springs Road SAVE THESE INSTRUCTIONS Santa Fe Springs CA 90670 Important Safety Instructions USA / 1-877-338-0999 MADE IN CHINA are included in this manual. REV 92210-20110916 www.championpowerequipment.com... - Page 2 Have questions or need assistance? Do not return this product to the store! WE ARE HERE TO HELP! Visit our website: www.championpowerequipment.com for more info: • Product Info & Updates • Tech Bulletins • Frequently Asked Questions • Product Registration –...
-
Page 3: Table Of Contents
92210 22 Ton LOG SPLITTER TABLE OF CONTENTS Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . -
Page 4: Introduction
Introduction Accessories Congratulations on your purchase of a Champion Champion Power Equipment manufactures and sells Power Equipment log splitter . CPE designs and builds accessories designed to help you get the most from your log splitters to strict specifications . With proper use purchase . -
Page 5: Manual Conventions
. Please call our help line at 1-877-338-0999 situation which, if not avoided, could result in death or serious injury . CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury . REV 92210-20110916... -
Page 6: Safety Rules
Be alert. guards in place . DO NOT wear loose-fitting clothing, dangling drawstrings or items that could become caught . WARNING Keep Operator Work Zone Clear Keep work zone clear of debris while working to ensure safe footing . REV 92210-20110916... - Page 7 . DO NOT expose log splitter to excessive moisture, dust, or dirt . DO NOT allow any material to block the cooling slots . DO NOT use the engine if: – Equipment sparks, smokes or emits flames – Equipment vibrates excessively REV 92210-20110916...
-
Page 8: Controls And Features
. operating . Raise leg for towing . Wedge (13) Safety Chains – For use while towing . Splitting Beam (14) Auto Stop Pin (ASP) – Limits the return stroke of the splitting wedge . REV 92210-20110916... -
Page 9: Assembly
7 . Install the cotter pin through the castle nut and axle to prevent the nut from backing off . 8 . Place axle cap over castle nut and axle . 9 . Repeat steps 1-8 for the other wheel . REV 92210-20110916... -
Page 10: Install The Cylinder And Wedge
. Be sure to slide the cylinder all the way back into the mounting slots . (B) 5 . Install the hose retaining ring to the side of the splitting beam . REV 92210-20110916... -
Page 11: Install The Engine And Hoses
. Inspect hydraulic system regularly for possible leaks . Never check for leaks with your hand while the system is pressurized . Seek medical attention immediately if injured by escaping fluid . REV 92210-20110916... -
Page 12: Add Engine Oil
The engine is equipped with a low-oil-shutoff and the will stop when the oil level in the crankcase falls below the threshold level . NOTE Check oil often during the break-in period . Refer to the Maintenance section for recommended service intervals . REV 92210-20110916... -
Page 13: Operation
The log splitter needs to be on a dry level surface with good footing . DO NOT work on mud, ice, tall grass, brush or snow . Only operate log splitter from work zone shown below . REV 92210-20110916... -
Page 14: Starting The Engine
. This will cause the engine not to start . 6 . As engine warms up, move the choke lever (Item C) to “Run” (to the right) . 7 . Move the throttle lever (Item D) to the “Fast” position . REV 92210-20110916... -
Page 15: Log Splitter Operation
8 . Clear the split wood from the work zone . CAUTION Do not hold auto control valve in return position . It will damage the stop block or beam . NOTE It is normal for the hydraulic fluid to become foamy or frothy during operation . REV 92210-20110916... -
Page 16: Maintenance And Storage
Use a soft bristle brush to remove excess dirt and oil . Use an air compressor (25 PSI) to clear dirt and small debris . Wipe all metal parts with an oily rag to help prevent rust and corrosion . REV 92210-20110916... -
Page 17: Maintenance Schedule
WARNING Replace fuel line *To be performed by knowledgeable, experienced owners or Champion Power Equipment certified dealers . Never store the log splitter inside next to appliances where there is a source of heat or open flame, spark Log Splitter Maintenance or pilot light because they can ignite gasoline vapors . -
Page 18: Troubleshooting
Engine cannot supply enough power or Insufficient ventilation Check for air restriction . Move to a overheating well ventilated area For further technical support: Technical Service Mon – Fri 8:30 AM – 5:00 PM (PST/PDT) Toll Free: 1-877-338-0999 tech@championpowerequipment .com REV 92210-20110916... -
Page 19: Specifications
.12 . 1 3 inches (30 .8 cm) – Length . . . . . . . . . . . . . . . 14 .25 inches (36 .2 cm) REV 92210-20110916... -
Page 20: Parts Diagram
92210 ENGLISH SPECIFICATIONS Parts diagram REV 92210-20110916... -
Page 21: Parts List
GB/T 3452 .1-92 O Ring 10×2 .65 GB/T70 .2-2000 Bolt M8×12 PMJ22G-21 Outlet Connector Of Pump PMJ22G-38 Big Tension Spring PMJ22J-14 Gear Pump GB/T-798- Swing Bolt M8×28 JB/T-8870-1999-40 Clamp ø40 1988-M8-28 PMJ22G-17 Oil Pipe GB1160 .2-89 Oil Gauge REV 92210-20110916... -
Page 22: Engine Parts Diagram
92210 ENGLISH SPECIFICATIONS Engine Parts diagram REV 92210-20110916... -
Page 23: Engine Parts List
Oil Filler Cap Assembly 123 GB859-87-SW6 Spring Washer 6 ST160F--1030002 Oil Filler Cap Packing 124 GB5789--86-FB6-35 Flange Bolt M6*35 ST168F-1030007-5/16-G Crankcase CoverFor USA 125 GB5789--86-FB6-15 Flange Bolt M6*15 GB5789--86-FB8-32 Flange Bolt 8*32 126 GB6187-86-N6 Nut M6 ST168F-1090100 Air Cleaner Cover Nut(Plastic) REV 92210-20110916... -
Page 24: Warranty
Warranty Qualifications – Accessory parts such as starting batteries, and storage covers . Champion Power Equipment (CPE) will register this – Failures to due acts of God and other force majeure warranty upon receipt of your Warranty Registration Card events beyond the manufacturer’s control . -
Page 25: Emission Control System Warranty
United States Environment Protection Agency (U.S. EPA.) Emission Control System Warranty Your Champion Power Equipment (CPE) engine complies with U .S . EPA emission regulations . YOUR WARRANTY RIGHTS ANd OBLIGATIONS: The US EPA AND CPE are pleased to explain the Federal Emission Control Systems Warranty on your 2011 and later small off-road engine . - Page 26 ECS Warranty and shall be sufficient grounds for disallowing an ECS Warranty claim . CPE shall not be liable hereunder for failures of any warranted parts of a CPE engine caused by the use of such an unapproved add-on or modified part . REV 92210-20110916...
- Page 27 Champion Power Equipment dealer who is authorized by Champion Power Equipment, Inc . to sell and service that CPE product during his normal business hours . Claims for repair or adjustment found to be caused solely by defects in material or workmanship will not be denied because the engine was not properly maintained and used .
