Owners Manual

VNET 12, VNET 12 HP, VNET 15, VNET 300
VNET 15 HL, VNET 15BP & VNET 18DR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VNET 12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tannoy VNET 12

  • Page 1: Owners Manual

    T: (04102) 888 393 F: (04102) 888 959 E: info@tannoy.com VNET 12, VNET 12 HP, VNET 15, VNET 300 Tannoy adopts a policy of continuous improvement and product specification is subject to change. VNET 15 HL, VNET 15BP & VNET 18DR...
  • Page 2 Ne placez pas d'objets contenant du liquide à proximité de l'appareil. 16.0: WARRANTY AVERTISSEMENT DE SECURITE Ne remplacez le fusible de réseau principal que par un fusible T10A HBC du même type fourni par Tannoy sous la référence 17.0: DECLARATION OF CONFORMITY 34610919.
  • Page 3: Installation Instructions

    Ensure that there is at least 100mm (4") of space around all sides of the product for ventilation. ensures the most even frequency response over a wide coverage area in the medium size venues for which the Tannoy V300 Only use attachments and accessories approved by or specified by Tannoy.
  • Page 4: Operation

    100 to 240 Volts; the auto ranging power supply detects the mains voltage automatically and configures accordingly. Replace the mains fuse only with the same T10A HBC type supplied by Tannoy under part number 3.1: PRELIMINARY RECOMMENDATION...
  • Page 5: Network Connections

    IT supplier. At the time of writing this manual extensive testing was carried out with the following devices:- and Web services. The .NET Framework: Tannoy USB – RS485 Converter (Part No. 8001 3920) Supports over 20 different programming languages.
  • Page 6 7.0 SOFTWARE INSTALLATION 7.0 SOFTWARE INSTALLATION You can check to see if you already have the .NET Framework 1.1 installed by clicking Start on your Windows desktop, 3. Confirm Installation. Click <Next> 4. If you accept the licence agreement check ‘I Agree’ and Click <Next>...
  • Page 7: Software Operation

    8.0 SOFTWARE OPERATION 8.0 SOFTWARE OPERATION Menus PodWare communicates with VNET™ using a serial ‘COM’ port as a ‘network’ connection. When a network connection is open and actively The menu system is arranged like so: connected to a compatible device, the system is said to be ‘On Line’. Whilst On-line, you can control the connected device in ‘real time’, and File continuously receive status information from the device.
  • Page 8: Speaker Properties

    8.0 SOFTWARE OPERATION 8.0 SOFTWARE OPERATION 8.0 SOFTWARE OPERATION VNET CONTROL PANEL The control panel for VNET™ allows VNET™ parameters to be viewed and adjusted. The panel is organised into a monitoring The control panel shows the model name (not editable), and firmware area (at the top left of the panel) where the status of VNET™...
  • Page 9: Updating Firmware

    Occasionally it may be necessary to update the devices firmware (with file extension .dfw); this may be due to added features or amendments to the VNET™ product. Check with your dealer/distributor or (www.tannoy.com) for any applicable updates. The two shelving filters allow all frequencies below that of the frequency parameter (for the Low shelf) or all frequencies above...
  • Page 10 8.1: UPDATING FIRMWARE 9.0: EQUALISATION At the bottom right hand side of the screen a blue bar will show the progress of the firmware update. VNET™ loudspeakers are designed to need no equalisation or correction to overcome system limitations. As a result, they will only need equalisation to compensate for difficult acoustic environments.
  • Page 11 11.0 DIMENSIONS 11.0 DIMENSIONS VNET 12 & 12HP VNET 15 BP 440.0 440.0 195.0 370.0 290.0 CAUTION TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS EQUIPMENT TO WARNING 180.0 RAIN OR MOISTURE AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR.
  • Page 12: Performance Data

    A full range of measurements, performance data, and Ease™ Data can be downloaded from www.tannoy.com Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications, which Tannoy reserves...
  • Page 13 A full range of measurements, performance data, and Ease™ Data can be downloaded from www.tannoy.com Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications, which Tannoy reserves the right to alter without prior The VMY is an adjustable yoke bracket (available in both black and white), allowing the user to fly the Tannoy VNET™...
  • Page 14 14.2 : SECUR ET - V15Y & V12Y V15Y Fig.1 Fig.2 Use the table of parts along with the assembly drawing (Figure 3.) to assemble the VMY. Figure 4 shows the VMY assembled. V12Y Fig.3 Fig.4 Number on Assembly View (Fig 3.) Description Quantity Hanging Bracket...
  • Page 15: Secur Et - Vmb Wall Mounting Bracket

    14.4 : SECUR ET - VEB EYEBOLT The VMB is wall mounting bracket for the attachment of a VMY, FIG 1. The Tannoy VNET™ loudspeaker can be flown with high quality FIG 1. available in both black and white finishes, allowing the user secure VEB M10 eyebolts with collar to BS4278:1984.
  • Page 16 VMY and a length of M10 7900 0326 HF Diaphragm Kit threaded rod (not supplied by Tannoy Limited). The VCS ceiling saddle allows the Tannoy VNET™ loudspeaker to be suspended at VNET15BP a user defined distance from the ceiling as shown in Figure 1.
  • Page 17: Warranty

    Claims will not be considered is the serial number has been altered or removed. Work under warranty should only be carried out by a Tannoy Professional dealer or service agent. This warranty in no way affects your statutory rights.
  • Page 18 NOTES NOTES...

This manual is also suitable for:

Vnet 12 hpVnet 15bpVnet 18drVnet 15Vnet 300Vnet 15 hl
