  • Page 1: User Manual

    + Documentation ++ Documentation ++ Documentation ++ Documentation ++ Documentation ++ User Manual PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 2: Table Of Contents

    Switching the printer on and off.............2-13 Printing a configuration page ............2-14 Connecting the printer to a computer (parallel port) .....2-15 Connecting the printer to a computer (USB port) ......2-16 PagePro 4100E TOC-1 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 3 Printing multiple document pages per print page (N-up) ....4-12 Printing watermarks ..............4-13 Custom watermarks ..............4-14 Scaling the printed document ............4-15 Duplex function................4-15 TOC-2 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 4 Specifying the print language............5-10 Test print index card..............5-11 The various test prints..............5-11 Counter index card ..............5-12 Checking the status of a counter...........5-13 Resetting a counter 5-13 Configuration index card............5-14 PagePro 4100E TOC-3 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 5 What should I watch out for when loading envelopes? ....7-1 Which sizes of paper can I use?............. 7-2 What types of paper can I use?............7-3 Printable area ................. 7-3 TOC-4 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 6 Clearing paper misfeeds at the duplex unit (top) .......10-10 Clearing paper misfeeds at the duplex unit (bottom) ....10-11 10.2 Problems with print quality ............10-12 10.3 General printing problems ............10-15 PagePro 4100E TOC-5 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 7 Software ..................11-1 Operating system ................. 11-1 11.2 Technical specification .............. 11-2 PagePro 4100E printer ..............11-2 500-sheet paper feed tray (option) ..........11-3 Duplex unit (option) ..............11-4 Network card (option) ..............11-4 SDRAM-SIMM memory module (option) ........11-4 Interfaces and cables ..............

  • Page 8: Introduction

    Introduction Introduction Welcome to Minolta/QMS Thank you for purchasing a Minolta/QMS PagePro 4100E laser printer. To achieve the best possible results and to use your laser printer effectively, this User’s Manual provides you with information on the following topics: installing the printer driver,...

  • Page 9: Roadmap Of This Manual

    Troubleshooting Help with analysing and rectifying faults. Appendix A collection of helpful additional information, e.g.: • technical specification • index of keywords PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 10: Brief Explanation Of Special Type Styles And Method Of Presentation

    This is a helpful tip Text passages that are identified in this manner provide you with tricks and handy tips to make it even easier to work with the printer. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 11: Working Safely With Your Laser Printer

    Use only extension cables that are designed for at least the maximum power rating of the machine. Extension cables with lower ratings can result in overheating and can even cause a fire. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 12: Pagepro 4100E

    If the machine becomes unusually hot, or if you notice smoke or an unusual odour coming from the machine, switch it off immediately and remove the power cable from the socket. Contact your customer support technical specialist. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 13: Laser Safety

    Using the printer in a manner other than as indicated in this manual may result in exposure to dangerous radiation. ➜ Use the printer only according to the instructions contained in the User’s Manual. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 14: Cdrh Regulations

    The safety label shown here confirms compliance with the CDRH regulations. This label must be attached to all products sold or used in the USA. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 15: Laser Safety Label

    Using the controls, adjusting the printer or performing procedures other than as specified in this manual may result in exposure to hazardous radiation. ➜ Use the printer only according to the instructions contained in the User’s Manual. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 16: Laser Caution Label

    This is a semiconductor laser. The maximum power of the laser diode is 5 mW and the wavelength is 770–810 nm. ➜ Use the printer only according to the instructions contained in the User's Manual. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 17: Ozone Emission

    1-10 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 18: Unpacking, Installing And Setting Up The Printer

    ❍ Printer ❍ Installation Guide ❍ CD-ROM ❍ Power cable ❍ Paper feed tray. Remove the packaging material from the printer. Remove the transport retainers from the printer. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 19 Why save packaging materials? If you need to move the printer, you can use the packaging again. In this way you can be certain that your printer is correctly packed. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 20: Overview Of The Printer

    Paper feed tray 1 (multipurpose tray) Control panel Power Switch (ON/OFF) Paper output tray USB port (face down) Top cover Socket for power cable Paper guides Parallel port PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 21: Inside The Printer

    Unpacking, installing and setting up the printer Inside the printer Description Description Fusing unit Cover to paper feed tray 2 Paper guide Image transfer roller Manual paper feed unit Imaging cartridge PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 22: Optional Accessories

    Unpacking, installing and setting up the printer Optional accessories Description Description Paper feed tray 2 Duplex unit (500-sheet cassette) Paper feed tray 3 (500-sheet cassette) PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 23: Printer Control Panel

    Unpacking, installing and setting up the printer Printer control panel The control panel has three lamps and one button. Description Description Stand-by lamp (green) Fault (red) Paper empty (orange) Control button PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 24: Installing Your Laser Printer

    Toner is harmful if swallowed. ➜ If you swallow toner, consult a doctor immediately. ➜ If you get toner on your hands, wash them immediately with cold water and soap. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 25: Ambient Conditions

    Temperature range 50°F to 95°F / 10°C to 35°C (maximum variation of 18°F / 10°C per hour); Relative humidity of 15% to 85% (maximum variation of 20% per hour). PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 26: Space Required

    33 in. / 840 mm 11-3/4 in. / 300 mm 24-3/4 in. / 630 mm 4 in. / 100 mm 6 in. / 150 mm 11-3/4 in. / 300 mm PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 27 33 in. / 840 mm 11-3/4 in. / 300 mm 29-1/2 in. / 750 mm 4 in. / 100 mm 6 in. / 150 mm 11-3/4 in. / 300 mm 2-10 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 28: Setting Up Your Laser Printer

    Attach the paper output tray to the printer as shown here. Slide the lower part of the paper feed tray into the printer. Fit the cover of paper feed tray 1. PagePro 4100E 2-11 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 29: Connecting The Power Cable

    ➜ Only use cables with a ground connection. ➜ Always observe the relevant local regulations regarding the connection of electrical equipment to the mains network. 2-12 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 30: Switching The Printer On And Off

    If the printer receives a new print job while it is in Power Save mode, or if the side cover is opened, or if the [ON LINE] key is pressed, the printer automatically starts its warm-up phase. PagePro 4100E 2-13 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 31: Printing A Configuration Page

    Please have a current configuration page available when calling for technical assistance. Make a note of the Serial No. of your printer on the configuration page, see page 1-8 (laser safety label). 2-14 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 32: Connecting The Printer To A Computer (Parallel Port)

    ➜ Minolta/QMS does not warrant the use of any particular cable. The user assumes all responsibility as to the quality and performance of the cable. PagePro 4100E 2-15 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 33: Connecting The Printer To A Computer (Usb Port)

    Connect one end of the interface cable to the USB port of the printer. Connect the other end of the interface cable to the USB port of the computer. 2-16 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 34: Installing The Printer Driver

    More questions? If you are still not certain about making a setting, you can display additional information on screen by using the HELP button. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 35: General Information On The Printer Driver

    Do not use the Add Printer Wizard from the Printers folder. Installation through the Add Printer Wizard will prevent the printer from performing properly. We recommend the printer driver being installed using the CD-ROM´s installer. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 36: Information On Installing A Network Printer

    Do not use the hardware wizard for printer installation. If your printer will not be printing any documents in a network environment, set the data spool format of the client to RAW. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 37: Installing The Usb Device Driver

    Installing the printer driver Installing the USB device driver When connecting the PagePro 4100E printer to your computer with a USB cable, install the USB device driver according to the following instructions before installing the printer driver. This printer can only be connected with a USB cable if the computer is running Windows 98.
  • Page 38 [NEXT]. When the next dialogue appears, check the Specify a location box, and then click [BROWSE...]. Browse the CD-ROM and navigate to “Drivers\Pw4100\Win98\ D\Pcl\Drv\usb“. Then click [OK]. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 39 Installing the printer driver When the following dialogue appears, click [NEXT]. When the following dialogue appears, click [FINISH] to complete the installation. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 40 Eject the CD-ROM from your computer’s CD-ROM drive. This completes the installation of the USB device driver for the PagePro 4100E printer. And now install the printer When installing the PCL printer driver you must select “USB/0“ when prompted for the printer port (Select Port).

  • Page 41: Cd-Rom Installation For Win95, Win98 Or Winnt4.0

    When the Update Device Driver Wizard dialog appears under Win 95 or 98: ➜ Click [CANCEL] to close the dialog. Place the PagePro 4100E printer driver CD in the CD-ROM drive of your computer. The installation program starts automatically. The installation program does not start automatically? ➜...
  • Page 42 After the printer driver has been successfully installed, the “Minolta QMS Printer Utilities“ Program Group appears. You can now call up the “Minolta QMS Printer Utilities“ Program Group via the Windows Start menu. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 43: Installation For Windows 3.1X

    The following box appears. Browse to the CD-ROM drive and navigate to “Drivers\Pp4100\Win311\GB\Pcl\drv“. Confirm with [OK]. Select Minolta/QMS PagePro 4100 [UNI] from the list and confirm with [OK]. 3-10 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 44 An error message appears announcing that the UNIDRV.DLL file is required but cannot be found. ➜ Install a UniTool Driver from the list of printers and try again. PagePro 4100E 3-11 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 45: Uninstalling The Windows Printer Driver

    Click on “Uninstall“. The deinstallation program starts automatically. Follow the subsequent instructions. The deinstallation of the printer driver is successfully completed once the Windows operating system has been restarted. 3-12 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 46: Deinstallation For Windows 3.1X

    Click on "Remove". You are prompted to confirm/cancel your selection. Click on [YES] in order to delete the printer driver. Click on [Close]. The program group is deinstalled. PagePro 4100E 3-13 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 47: Installation For Ms-Dos

    Make sure that the printer is connected to your computer locally or via a network. Switch on the printer. Switch on the computer and start MS-DOS. Place the PagePro 4100E printer driver CD in the CD-ROM drive of your computer. Change to the CD-ROM drive. Enter, for example: d:\ (d = corresponding letter of your CD-ROM drive) Change to the directory which contains the installation program.

  • Page 48: Working With The Windows Printer Drivers

    Click on the “Minolta/QMS PagePro 4100“ icon. Under “File“, select the item “Properties“. The following box appears. Click on the "-> 32-bit SuperDriver Setup" tab. The printer driver dialogue box appears. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 49 Working with the Windows printer drivers The operating system also uses index cards! The “About“ index card is automatically determined by the operating system and is therefore not described in this manual. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 50: Displaying Settings In Windows Nt 4.0

    In the START menu, select “Settings – Printer“. The “Printer“ dialogue box appears. Click on the “Minolta/QMS PagePro 4100“ icon. Under “File“, select the item “Document Defaults“. The following box appears. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 51: Displaying The Settings In Windows 3.1X

    The “Printer“ dialogue box appears. In the “Printer“ dialogue box, select Minolta/QMS PagePro 4100 [UNI] from the list of “Installed printers“. Click on [SETUP...]. The Driver Setup dialogue box appears. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 52: Paper Index Card

    (Default). PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 53: Selecting A Paper Format

    Not all paper formats available? If you have selected the optional paper feed tray 2 or 3 under “Paper source“, then not all the paper formats given in the table are available. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 54: Creating A Custom Paper Format

    You wish to delete a custom format? In the “Custom papers“ dialogue box, mark the paper size you wish to delete. Then click on [DELETE]. Confirm with [OK]. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 55: Adjusting The Print-Out To Fit The Paper

    You may enter any value between 1 and 999. Specifying the orientation of the print paper Under “Orientation“ you can specify whether your document should be printed in portrait (vertical) or landscape (horizontal) format. Portrait Landscape PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 56: Switching On/Off The Printer's Sorting Function

    Deactivate the sort feature in other applications! Deactivate the sort feature in other software applications if there is a conflict between the setting in the printer driver and the setting in the other application. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 57: Specifying The Paper Source

    Recalling the original setings [DEFAULT] Click on [DEFAULT] in order to reset all options on this index card to their original factory settings. 4-10 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 58: Page Layout Index Card

    (enlarge/reduce) documents upon print-out, activate the duplex function (printing on both sides). PagePro 4100E 4-11 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 59: Printing Multiple Document Pages Per Print Page (N-Up)

    ➜ Click on [DETAIL OF N-UP...] to define the layout of document pages on the print page. The “N-Up“ dialogue box appears. 4-12 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 60: Printing Watermarks

    Watermarks as copy protection! Provide your print-outs with a watermark in order to prevent the printed pages from being copied. PagePro 4100E 4-13 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 61: Custom Watermarks

    The dialogue box closes. Deleting watermarks? No problem! If you would like to delete a watermark, mark it in the list of watermarks and click on [DELETE]. 4-14 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 62: Scaling The Printed Document

    The booklet function is not available? The Scaling, Fit to paper and N-up functions cannot be used at the same time as the Booklet function. PagePro 4100E 4-15 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 63: Quality Index Card

    If, for example, the emulation mode has been set to “Enhanced“, then the “All raster“ function is not available. If the “All raster“ function is set to OFF, the “Graphics mode“ menu is available, etc. 4-16 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 64: Optimizing Data Exchange With The Printer (All Raster)

    ➜ Select “ON“ to print your documents using a minimal amount of toner. ➜ Select “OFF“ to print your documents with the normal amount of toner. PagePro 4100E 4-17 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 65: Specifying The Graphics Mode

    Select “OFF“ to achieve an optimum print quality for photos (raster graphics). ➜ Select “ON“ to achieve an optimum print quality for text and graphics (vector graphics) in your document. 4-18 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 66: Specifying Truetype Mode

    Specifying the emulation mode This function is only available when “All raster“ is set to “OFF“. ➜ Select “ENHANCED“ for PCL6 compatibility. ➜ Select “STANDARD“ for PCL5e compatibility. PagePro 4100E 4-19 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 67: Optimizing The Presentation Of Graphics In The Print-Out (Detail Of Quality

    When you print out graphics that you intend to fax or copy afterwards, select the “Photocopy“ dither pattern. The graphics are then printed out in a form suitable for faxing or copying. 4-20 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 68: Font Index Card

    Working with the Windows printer drivers Font index card This index card allows you to: add fonts to the printer’s on-board memory, delete fonts from the printer’s on-board memory, set the ID. PagePro 4100E 4-21 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 69: Adding Fonts

    Click on [ID SETTING...] in order to determine the ID codes for the fonts you have already marked in the left-hand list. When downloading the font, the printer driver allocates the ID code to the respective font. 4-22 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 70: Device Option Index Card

    Working with the Windows printer drivers Device option index card This index card allows you to: activate the optional duplex unit, activate optional paper feed tray 2 or 3. PagePro 4100E 4-23 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 71: Activating The Optional Duplex Unit

    ➜ Activate paper feed tray 2 or 3 with the [ADD] button. ➜ Deactivate paper feed tray 2 or 3 with the [REMOVE] button. 4-24 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 72: Working With The Windows Printer Tools

    If upon installing the printer driver you activated the option to automatically start the printer driver, then the Status Display is automatically called up upon starting the computer. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 73: Calling Up The Status Display

    Calling up the Status Display in Windows 95/98, Windows NT 4.0 Open the “Minolta QMS PageWorks/Pro 4100“ Program Group. Click on “Minolta QMS Status Display 4100“. The Status Display appears. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 74: Calling Up The Status Display In Windows 3.1X

    The options on the individual index cards correspond to those of Windows 95/98. Open the “Minolta/QMS PagePro 4100 [UNI]“ program group within the Program Manager. Doubleclick the [MINOLTA/QMS PAGEPRO 4100 STATUS DISPLAY] icon. The "Status Display" appears. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 75: Altering The Size Of The Status Display Window

    “Reduce“ in order to decrease the size of the window. ➜ In the Status Display menu bar, select the "View" menu and then the option “Expand“ in order to increase the size of the window. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 76: Calling Up The Control Panel

    Open the “Minolta QMS PagePro 4100“ Program Group. Click on “Minolta QMS Control Panel 4100“. The Status Display appears. Click on [PRINTER SETTINGS] or select “Settings – Printer Settings“ The Control Panel appears. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 77: Paper Index Card

    This index card allows you to: define the response in the case of a lack of suitable paper (paper format error), define the paper format for paper feed tray 1. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 78: Defining The Response In The Case Of A Lack Of Suitable Paper

    J-Post (Postcard) 4 × 5.75 in. Settings The settings for paper feed tray 1 on the “Paper“ index card may be overridden by the settings of other print applications. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 79: Printer Setting Index Card

    – Jam Recovery, switch on/off the Pre-Heat function, specify the print language for communication between printer and computer. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 80: Switching On/Off The Power Save Mode

    Select “On“ to heat the fusing unit as soon as a print job is sent from the computer. ➜ Select “Off“ to suppress preheating of the fusing unit as soon as a print job is sent from the computer. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 81: Specifying The Print Language

    ➜ Select PCL or PostScript (optional) by clicking in the dropdown list. ➜ Select “Automatic“ to enable the most appropriate print language to be selected automatically. 5-10 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 82: Test Print Index Card

    List of PostScript-resident Prints out a list of all PostScript fonts available, with fonts designations and samples, provided an optional PostScript ROM-SIMM has been installed. PagePro 4100E 5-11 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 83: Counter Index Card

    Working with the Windows printer tools Counter index card This index card allows you to: check the status of a counter, reset a counter. 5-12 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 84: Checking The Status Of A Counter

    The“total counter“ status can only be reset by a customer service engineer. ➜ Click on the [RESET] button adjacent the counter you wish to reset. The associated counter is reset to zero “0“. PagePro 4100E 5-13 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 85: Configuration Index Card

    Working with the Windows printer tools Configuration index card This index card summarizes the most important printer settings for quick reference. No settings can be altered via this index card. 5-14 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 86: Using The Status Display

    Press the keys [CTRL]+[ALT]+[R] to call up the Status Display. Deleting the Status Display from the RAM! Enter the command status /d in order to delete the Status Display from the RAM. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 87: Switching On/Off Popup Messages (Setup Menu)

    Mark one of the error messages and press ENTER in order to change the status of the error message. Active = show popup message Inactive = suppress popup message PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 88: Using The Dos Control Panel

    You wish to close the Control Panel? No Problem! Press the keys [ALT] + [X] or select “File – Exit“ from the menu bar in order to close the Control Panel. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 89: Paper Panel

    1. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 90: Selecting A Paper Format

    Not all paper formats available? If you have selected the optional paper feed tray 2 or 3 under “Paper source“, then not all the paper formats given in the table are available. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 91: Specifying The Number Of Lines Printed Per Page

    Specifying the number of copies In the “Copies“ box, specify the number of copies that you wish to print out. You may enter any value between 1 and 999. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 92: Specifying The Orientation Of The Printing Paper

    ➜ Select “Clear“ to automatically cancel the print job when a paper format error is detected. ➜ Select “None“ to switch the printer to stand-by mode. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 93: Specifying A Paper Format For Paper Feed Tray 1

    J-Post (Postcard) 4 × 5.75 in. Settings The settings for paper feed tray 1 in the “Setup“ panel may be overridden by the settings in other printing applications! PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 94: Font Panel

    (Symbol Set) which is to be used for the print-out, determine the font size (Pitch/Point) which is to be used for the print- out. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 95: Output Quality Panel

    This panel allows you to: switch on/off the Toner Save mode, define the resolution for the print-out, define the print quality optimization for text and graphics (Fine-Art), specify the toner density. 6-10 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 96: Switching On/Off The Toner Save Function

    ➜ Select “PCL“ or “PostScript“ (optional) by clicking in the dropdown list. ➜ Select “Automatic“ to enable the most appropriate print language to be selected automatically. PagePro 4100E 6-11 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 97: Counter Panel

    Working with the DOS printer tools Counter panel This panel allows you to: check the status of a counter, reset a counter. 6-12 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 98: Checking The Status Of A Counter

    The “total counter“ status can only be reset by a customer service engineer. ➜ Click on the [RESET] button adjacent the counter you wish to reset. The associated counter is reset to zero "0". PagePro 4100E 6-13 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 99: Configuration Panel

    The designation of the printer. Total Memory Indicates the total memory available. Additional Accessories Indicates presence and status of optional accessories. No settings can be altered via this panel. 6-14 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 100: Printer Setting Panel

    – Jam Recovery, define the input/output timeout. PagePro 4100E 6-15 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 101: Switching On/Off The Power Save Mode

    Select “ON“ and enter a time period after which the a print job should be automatically continued despite the error. ➜ Select “OFF“ to suppress the automatic continuation function. 6-16 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 102: Detecting Paper Misfeeds - Jam Recovery

    Select “Parallel“ when the printer is connected to the computer via a parallel interface. ➜ Select “Network“ when the printer is connected to the computer via a Network. PagePro 4100E 6-17 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 103 Working with the DOS printer tools 6-18 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 104: Working With The Printer

    Test envelopes before buying large quantities! Some types of envelopes crease easily when they are run through a printer. Test a type of envelope before purchasing large quantities. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 105: Which Sizes Of Paper Can I Use

    * 1. Each of the 5 cassettes of Tray 2/Tray 3 support one of the 5 types of paper that are compatible with this printer. 2. Letter is standard cassette size for the second/third paper feed tray. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 106: What Types Of Paper Can I Use

    Special media is not supported for duplex printing. Printable area 0,16 in. / 4 mm 0,16 in. / 4 mm 0,16 in. / 4 mm Printable area 0,16 in. / 4 mm PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 107: Using The Control Button

    Stand-by lamp (green) Fault (red) Paper empty (orange) Control button The control button allows you to: print out the configuration page, continue a print job after an error mesage. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 108: Printing Out The Configuration Page

    If you have continued a print job after an error message, then check the print-out. It is often the case that not all pages required are printed out. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 109: Loading Paper

    How many sheets may I place in the cassette? ➜ The stack of paper should not rise above the "max." mark. Refit the cover to paper feed tray 1. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 110: Loading Paper Into The Manual Feed Unit

    How are envelopes fed in? ➜ Envelopes are loaded with the flap down and facing to the left. Slide the guides up to the paper. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 111: Loading Paper Into Paper Feed Tray 2/3

    2/3 until you feel a resistance. Then lift the front of the cassette slightly before continuing to withdraw the cassette completely. Paper feed tray 2 Paper feed tray 3 Remove the cassette cover. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 112 The stack of paper should not rise above the "max." mark. Refit the cassette cover. Paper feed tray 2 Slide the cassette back into paper feed tray 2/3. Paper feed tray 3 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 113: Monitoring Print Jobs With The Status Display

    When the background to the printer graphic is red, there is a current error and the print job has been interrupted. The status of the printer and the error message are shown in the dialogue boxes on the left. 7-10 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 114: Installing Optional Accessories

    Remove all packaging materials and adhesive tape. Remove the plastic pad from the feed tray. Switch the printer OFF and also disconnect the power cable and the interface cable from the printer. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 115 How many sheets may I place in the cassette? ➜ The stack of paper should not rise above the "max." mark. Refit the cassette cover. Slide the cassette back into the feed tray. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 116: Installing The Duplex Unit

    Remove the flat cover at the rear of the printer using a screwdriver or other similar tool. Attach the duplex unit as shown in the adjacent figure. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 117 Connect the power cable to the printer, see page 2-12, and switch on the printer, see page 2-13. Print out a configuration page in order to check whether "Duplex unit" is listed under “Printer Configuration“, see page 2-14. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 118: Installing A Simm Memory Module

    ➜ Always switch the printer OFF and unplug it from the power supply. ➜ Only remove the covers which are specifically referred to in the step- by-step instructions. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 119 Installing optional accessories Close the output tray. Press the top cover release button and open the cover. Remove the two screws from the side cover and take off the cover. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 120 Remove the internal cover in order to gain access to the motherboard. Insert the memory module into one of the three slots. Press it carefully onto the socket until it clips into place. Simm Slots Refit the internal cover. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 121 You wish to remove a memory module? To remove a module, press the tabs on both sides of the installation slot outwards. This will release the module and allow you to take it out. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 122: Installing A Postscript Rom-Simm Memory Module

    ➜ Always switch the printer OFF and unplug it from the power supply. ➜ Only remove the covers which are specifically referred to in the step- by-step instructions. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 123 Press the top cover release button and open the cover. Remove the two screws from the side cover and take off the cover. Remove the internal cover in order to gain access to the motherboard. 8-10 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 124 PostScript ROM-SIMM memory module Refit the internal cover. Refit the side cover and secure it with the two screws. PagePro 4100E 8-11 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 125 To remove a module, press the tabs on both sides of the installation slot outwards. This will release the module and allow you to take it out. 8-12 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 126: Installing A Network Card

    When working with the network card, always place it on an anti-static mat. Detailled information on the network card can be found in the associated user’s manual. The figure shows the 10BaseT/100BaseTX network card. PagePro 4100E 8-13 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 127 Remove the two screws from the cover at the rear of the printer. Insert the network card into the printer as shown in the figure. 8-14 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 128 Secure the network card with the same screws that were used originally to secure the cover. Connect the network cable to the network card. Continue as described in the user’s manual supplied with the network card. PagePro 4100E 8-15 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 129 Installing optional accessories 8-16 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 130: Caring For And Maintaining Your Printer

    Toner is harmful if swallowed. ➜ If you swallow toner, consult a doctor immediately. ➜ If you get toner on your hands, wash them immediately with cold water and soap. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 131: Cleaning The Printer

    After switching off the printer, wait at least 10 minutes before cleaning the inside of the printer. Switch the printer OFF and unplug the power cable. Close the output tray. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 132 Caring for and maintaining your printer Press the top cover release button and open the cover. Lift out the imaging cartridge. Fold back the cover over the paper feed roller. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 133 Caring for and maintaining your printer Wipe the paper feed roller with a soft, dry cloth. Re-insert the imaging cartridge. Close the printer cover and open the paper output tray. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 134: Replacing The Imaging Cartridge

    To prevent injuries, avoid contact with this area. Switch the printer OFF and unplug the power cable. Close the output tray. Press the top cover release button and open the cover. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 135 Take the new imaging cartridge out of the box, hold it firmly with both hands and shake it to break down any lumps of toner that may have formed. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 136 Guide the new imaging cartridge into the printer as shown in the figure. Make sure that the new imaging cartridge is correctly seated in the guides and is clipped in place. Close the printer cover and open the output tray. PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 137 Caring for and maintaining your printer PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 138: Troubleshooting

    The fusing unit, which is located beneath the top cover, can become very hot when the printer is in operation. ➜ To prevent injuries, avoid contact with this area. Fusing unit PagePro 4100E 10-1 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 139: Clearing Paper Misfeeds

    Lift out the imaging cartridge. Wrap the the imaging cartridge in a cloth to protect it against exposure to light. Carefully pull the misfed sheet(s) out of the printer. 10-2 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 140 Re-insert the imaging cartridge. Move the imaging cartridge in the direction shown by the arrow until it clips into place. Close the printer cover and open the paper output tray. PagePro 4100E 10-3 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 141: Clearing A Paper Misfeed At The Fusing Unit

    Press the top cover release button and open the cover. Lift out the imaging cartridge. Wrap the the image transfer roller?? in a cloth to protect it against exposure to light. 10-4 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 142 Re-insert the imaging cartridge. Move the imaging cartridge in the direction shown by the arrow until it clips into place. Close the printer cover and open the paper output tray. PagePro 4100E 10-5 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 143: Clearing A Paper Misfeed At The Output Tray

    Clearing a paper misfeed at the output tray Carefully pull the misfed sheet(s) out of the tray. Open the top cover and close it again in order to reset the printer. 10-6 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 144: Clearing A Paper Misfeed At Paper Feed Tray 1

    Clearing a paper misfeed at paper feed tray 1 Carefully pull the misfed sheet(s) out of the tray. Open the top cover and close it again in order to reset the printer. PagePro 4100E 10-7 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 145: Clearing A Paper Misfeed At The Manual Feed Unit

    Clearing a paper misfeed at the manual feed unit Carefully pull the misfed sheet out of the unit. Open the top cover and close it again in order to reset the printer. 10-8 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 146: Clearing A Paper Misfeed At Paper Feed Tray 2 (Optional)

    Remove the stack of paper from the cassette and carefully pull the misfed sheet(s) out of the tray. Open the top cover and close it again in order to reset the printer. PagePro 4100E 10-9 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 147: Clearing Paper Misfeeds At The Duplex Unit (Top)

    Open the cover to the duplex unit and carefully pull out the misfed sheet(s). Open the top cover and close it again in order to reset the printer. 10-10 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 148: Clearing Paper Misfeeds At The Duplex Unit (Bottom)

    Open the cover to the duplex unit and carefully pull out the misfed sheet(s). Open the top cover and close it again in order to reset the printer. PagePro 4100E 10-11 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 149: Problems With Print Quality

    9-5. The imaging cartridge is Remove the imaging cartridge damaged. and check it for damage. If necessary, replace it with a new cartridge, see page 9-5. 10-12 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 150 Lift out the imaging cartridge and shake it in order to improve the distribution of the remaining toner. If the problem persists, fit a new cartridge, see page 9-5. PagePro 4100E 10-13 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 151 If the problem persists, fit a new cartridge, see page 9-5. The paper feed roller is dirty. Clean the paper feed roller, see page 9-2. 10-14 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 152: General Printing Problems

    The parallel port on your Disconnect the other equipment computer is also being used for and operate the printer via this other equipment (e. g. scanner, port. ZIP drive). PagePro 4100E 10-15 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 153: Printer Messages

    Stand-by (green) Fault (red) Paper (orange) Control button The table below shows the possible states of the lamps. State Meaning Lamp flashing Lamp on permanently Lamp off 10-16 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 154: Status Messages

    Lamp flashes when Printer is in Power Save printer is: mode • cancelling a print job • resetting a counter Lamp flashes when receiving data from USB- port. PagePro 4100E 10-17 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 155: User Messages

    Place a sheet in the manual feed unit and unit press the control button. No paper in feed tray Load paper into the appropriate feed tray. selected in printer driver. 10-18 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 156 Hold down the control button. not ready. If the problem persists, then the network interface has been deactivated or damaged. Please contact your technical customer service centre. PagePro 4100E 10-19 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 157: Service Messages

    Switch the printer off and then on again. If the problem persists, contact your technical customer service centre. System error or fault Fusing unit fault Polygon mirror fault Fan fault 10-20 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 158 Troubleshooting Lamps Meaning Action System error or fault Switch the printer off and then on again. If the problem persists, contact your technical customer service centre. PagePro 4100E 10-21 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 159 Troubleshooting 10-22 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 160: Appendix

    PageScope printer management tool for simple network operation. Operating system The PagePro 4100E can be used with the following operating systems: Windows 95, Windows 98, Windows 3.1x, Windows NT 4.0, MS-DOS 6.2 and higher (except MS-DOS 7.0)

  • Page 161: Technical Specification

    Appendix 11.2 Technical specification PagePro 4100E printer Technical specification Type Desktop laser printer Print system Electrostatic dry powder imaging system Exposure system Laser diode + polygon mirror scanning Resolution 1200 dpi × 600 dpi, 600 dpi × 600 dpi (with Fine-ART)

  • Page 162: 500-Sheet Paper Feed Tray (Option)

    Height:4-3/4 in. / 121 mm Width: 17-1/4 in. / 440 mm Depth: 13-3/4 in. / 350 mm Weight approximately 10 lbs. / 4.5 kg not including the legal cassette (Tray) PagePro 4100E 11-3 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 163: Duplex Unit (Option)

    8, 16 and 32 MB Type of function Burst Mode Access speed 60 ns or less No. of pins Type of module SIMM (Single In-line Memory Module) 11-4 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 164: Interfaces And Cables

    Type of cable Shielded Signal and ground pairs must be twisted Parallel cable IEEE 1284, type B Pin allocation Shell: Shield Length of cable max. 5 meters PagePro 4100E 11-5 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 165: Minolta/Qms's Concern For Environmental Protection

    This function can reduce your annual electricity costs by up to 60%. ® This laser printer fulfils the energy efficiency criteria for the Energy Star of the EPA (US Environmental Protection Agency). 11-6 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 166: Index

    Control Panel (DOS), calling up ............6-3 Control Panel, calling up ..............5-5 Control Panel, printer tools Configuration ................6-14 Counter ..................6-12 Font ....................6-9 Output Quality ................6-10 Paper .....................6-4 Printer setting ................6-15 PagePro 4100E 11-7 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 167 Installation using Add Printer Wizard ..........3-2 installation using Plug-and Play ............3-2 Installing optional accessories ............8-1 Installing the printer ................2-7 Interface connections ................ 11-5 11-8 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 168 Paper feed tray 2/3 ................8-1 ROM-SIMM memory module ............8-9 SIMM memory module ..............8-5 Overview of printer ................2-3 Control panel ..................2-6 External features ................2-3 Internal features ................2-4 Optional accessories ..............2-5 PagePro 4100E 11-9 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 169 Editing watermarks ..............4-14 Multiple document pages per print page ........4-12 Printing watermarks ..............4-13 PagePro 4100E printer, technical specification ........ 11-2 Paper feed tray 1, setting up ............. 2-11 Paper feed tray 2/3, activating ............4-24 Paper feed tray 2/3, installation ............8-1 Paper format error detection, switching on/off ........
  • Page 170 Printer tools, Windows .................5-1 Calling up the Status Display for Windows 3.1x ......5-3 Calling up the Status Display for Windows 95/98 & NT 4.0 ...5-2 Printer-computer connection .............2-15 PagePro 4100E 11-11 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 171 Specifying the emulation mode ............4-19 Stand-by lamp ................. 10-16 Status Display, calling up ............. 5-2 Status Display, changing hotkey ............6-2 Status Display, reduce/expand ............5-4 Storing accessories ................2-7 11-12 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 172 Technical specification 500-sheet paper feed tray ............11-3 Duplex unit ...................11-4 Interface connections and cables ..........11-5 Network card ................11-4 PagePro 4100E printer ..............11-2 SIMM memory module ..............11-4 USB Interface and cable ..............11-5 Test page ...................2-14 Test print index card Various test prints ................5-11 Test prints ..................5-11...
  • Page 173 Appendix 11-14 PagePro 4100E EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

Table of Contents
