CONTROL PANEL
1

1 Program Selector

Selects the wash program see page 7.
2 Option Select Buttons
Selects the wash Temperature or Spin Speed
or Soak Time or Rinse Type see page 9 - 10.
3 Modify Option Buttons
This button is using for modify an option
that you choose.
4 Reduce Time Button
Selects the reduce washing time see page 10.
ON - OFF Switch
7
2
3
4
5
5 Save Favourite Button
Selects the save favourite program see
page 10.
6 Delay - End Buttons
Selects the delay start program see page 11.

7 Digital Display

8 Start/Hold To Pause
Starts the wash program see page 11.
The On/Off switch is located at the back of the control panel
on the LH side above the rating plate.
2
3
8
6
Simpson Control panel
